Panasonic DVDPA65 - PORTABLE DVD User manual

Panasonic
Portable DVD Audio/VIdeo Player
Operating instructions
Dear customer
Thank you for purchasing this product.
Fur optlmunn performance and safety, please read these instructions caretuily.
Before ccrinoctlhij. Operating Or adjusting this product, please read these instructions com¬
pletely. Please keep this manual for future reference.
nn
i n the U. 5. A.; \ i ttp ://www.pg naseri ic, com
In Canada ; www.panasonic.ca
RQT5603-Y

CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUST¬
MENTS OR PERFORMANCE OF PRO¬
CEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPO¬
SURE.
DO NOT OPEN COVERS AND DO
NOT REPAIR YOURSELF. REFER
SERVICING TO QUALIFIED PER¬
SONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR PRODUCT
DAMAGE, DO NOT EXPOSE THIS
APPLIANCE TO RAIN, SPLASH¬
ING, DRIPPING OR MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK
MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.
The following mark and symbols are located on
the bottom of the unit.
A
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
A
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE SCREWS. NO USER-
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
A
The lightning flash with arrow¬
head symbol, within an equilater¬
al triangle, is intended to alert the
user to the presence of uninsulat¬
ed “dangerous voltage" within the
product’s enclosure that may be
of sufficient magnitude to consti¬
tute a risk of electric shock to per¬
sons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and mainte¬
nance (sen/icing) instructions in
the literature accompanying the
appliance.
CAUTION -VISIBLE ANO INVISIBLE LASER ATTENTION -RAYONNEMENT LASER VISIBLE ET
RADIATION WHEN OPEN. INVISIBLE EN CAS D'OUVERTURE.
00 NOT STARE INTO BEAM. NE PAS REGARDER DANS LE FAISCEAU.
(Bottom of the unit)
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
CAUTION:
This equipment has been tested and found to
comply with the limits for a Class B digital de¬
vice, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reason¬
able protection against harmful interference in
a residential installation. This equipment gener¬
ates, uses and can radiate radio frequency
energy and, if not installed and used in ac¬
cordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interfer¬
ence will not occur in a particular installation.
If this equipment does cause harmful interfer¬
ence to radio or television reception, which can
be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equip¬
ment and receiver.
•Connect the equipment into an outlet on a cir¬
cuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/
TV technician for help.
Any unautholized changes or modifications to
this equipment would void the user’s authority
to operate this device.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including in¬
terference that may cause undesired operation.
RQT5603

Open this page while reading the instructions so you can see where the controls
0 Disc lid
© Lock release
0 Remote control signal
sensor
© Charge [CHG] indicator
0 Standby [([)] indicator
O Volume [ ^ VOL] dial
© [ON/OFF, HOLD]
select switch
© Headphone[Q] jack
0 AOP[AOP]button
REPEAT AEfMRN GROUP
[REPEAT]——^q] (g| (gj
DCSPLAr TOP MEW UEMJ
-Display
[RETURN]
-[GROUP]
[DISPLAY]—p^Q] O [ □ ]-—[MENU]
[TOP MENU]. 1 5n?
! -[ENTER]
Cursor jockey—j
[A, ▼ , ◄ , ► ] Skip/Slow/
ffiH Qa ° ml ——Search
m _si
3 01 (Hr—. p _ lay i 0n
[ ► , ON]
Pause [II
[ACTION]
[(!), POWER]
Pause [I I]
Stop [ ■ ]
Slow/Search [ ◄ ◄ , ►► ]
Cursor jockey buttons
[A, T, ◄ , ► R ENTER]
*SU8TTTt« jj
- [PLAY MODE]
- [DISPLAY]
■ P layful
■ [TOP MENU]
[MENU]
[RETURN]
■ [SUBTITLE]
[AUDIO]
[ANGLE]
[CANCEL]
[V.S.S.]
■ Using the cursor
On the main unit: Slide the cursor }ockey in the direction you want to move the cursor,
[A] up, [T] down, [ ◄ } left, [ ► ] right.
On the remote control: Press the cursor button corresponding to the direction you want to
move the cursor.
[A] up, [ ▼ ] down, [M] left, [ ► ] right.
Numeric buttons
[GROUP]—h-o;

Accessories
Table of contents
Please check and identify the
supplied accessories.
(For U.S.A.)
To order accessories contact 1-800-332-5368
or web site (http://www.panasonic.com).
(For Canada)
To order accessories, call the dealer from
whom you have made your purchase.
Getting Started:
PRECAUTIONS. 6
Listening caution. 7
Disc information. 8
Disc and unit handling
precautions. 9
□
□
Remote control
(VEQ2382)
Button-type battery_
for remote control
(for replacement, see below)
□ Audio/video cable.i
(RJL3X001X15)
Q AC adaptor
(VSK0578)
□ AC power supply cord
(RJA0065-A)
Optional accessories:
Battery pack
(For U S A.: CGP-H501A/1B)
(For Canada: CGP-H501 C/1 B)
Button-type battery(CR2025)
Mini optical digital audio cable (RP-CA2110)
Available only in U.S.A.
Carrying case (DY-CC20)
Headphones (RP-HC100 or RP-HS900)
Basic Operations:
Basic play.14
•Stopping play.15
•Pausing play.16
•Skipping chapters and tracks.16
•Slow motion.16
Advanced Operations:
Other play modes
•All group play.19
•Program play.19
•Random play.19
Repeat play.20
For Your Reference:
How images appear on your TV.26
Changing initial settings
•Common procedures.27
• 1 Disc Languages.28
•2 Ratings.29
•3 Menu Language.29
•4 On-Screen Messages.30
•9 Other Settings.30
Use numbers indicated in parentheses when
asking for replacement parts.
Note
The included AC power supply cord and AC
adaptor are for use with this unit only. Do not use
them with other equipment.

Maintenance. ... 9
Easy setup—Television connections
Preparing the remote control.
... 10 and settings. 12
Power supply
•Using the AC adaptor .
.. 10
•Using the battery pack .
..11
•Fast forward and rewind — • Starting play from a selected title or
SEARCH . .. 16 track. 17
• Frame-by-frame viewing.
.. 16 • Playing only the audio . 17
•Selecting groups to play .
. . 17 • Returning to a menu .
18
Switching vocals ON or OFF for
• Icons for unit information .
23
karaoke discs. ..20
Changing soundtracks, subtitle
Using On-Screen Menu Icons
languages and angles.
24
• Basic operation .
. . 21
Enjoying virtual surround effects with
• Shuttle screen .
. . 21
2 speakers or headphones. 25
•Icons for disc information . . . 22
Glossary.
. .32 Recording to MDs and
Connecting other equipment.
.. 33 cassette tapes. 37
Enjoying more powerful sound
Using headphones.
37
•Enjoying surround sound with
Speaker settings.
38
3 or more speakers .
. . 34 Digital settings.
40
Enjoying better stereo sound
Troubleshooting guide.
42
•Listening through 2 speakers.
. . 36 Specifications. 45
Servicenter List (US).
46
Product service.
47
Open the facing page when
using the operating instructions.
R0T5603
For
Your
Reference
I
Advanced
Operations
I
Basic
Operations
I
Getting
Started

Getting
Started
PRECAUTIONS
Before using this unit, be sure to read the applic¬
able items of the operating instructions and
these safety suggestions carefully.
Afterwards keep them handy for future refer¬
ence. Take special care to follow the warnings
indicated on the unit itself as well as in the oper¬
ating instructions.
Power source
1. Power Source —The unit should be connect¬
ed to a power supply only of the type de¬
scribed in the operating instructions or as
marked on the unit. If you are not sure of the
type of power supply to your home, consult
your appliance dealer or local power com¬
pany.
Do not use a car cigarette lighter socket to
power the unit.
2. Polarization— I t the unit is equipped with a
polarized AC power plug (a plug having one
blade wider than the other), that plug will fit
into the AC outlet only one way. This is a
safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete out¬
let. Do not defeat the safety purpose of the
polarized plug.
3. Power Cord Protection —AC power supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placed upon or against them. Never take hold
of the plug or cord if your hand is wet, and al¬
ways grasp the plug body when connecting
or disconnecting it.
4. Overloading —Do not overload wall outlets
and extension cords as this can result in a
risk of fire or electric shock.
5. Nonuse Periods —If the set is not being
used for a long time, be sure to disconnect
the AC power supply cord from the AC power
outlet and detach the battery pack to prevent
potential damage caused by battery leakage.
6. Attachments— D o not use attachments not
recommended by the unit manufacturer as
they may cause hazards.
Maintenance
Disconnect this unit from the AC outlet before
cleaning.
Clean the cabinet, panel and controls with a soft
cloth lightly moistened with a mild detergent so¬
lution.
Do not use any type of abrasive pad, scouring
powder or solvent such as alcohol or benzine.
6
AC adaptor
This AC adaptor operates on AC between 100 V
and 240 V.
But
• In the U.S.A. and Canada, the AC power sup¬
ply cord must be connected to a 120 V AC
power supply only.
•When connecting to an AC supply outside of
the U.S.A. or Canada, use a plug adaptor to
suit the AC outlet configuration.
•When connecting to a supply of greater than
AC 125 V, ensure the cord you use is suited to
the voltage of the AC supply and the rated cur¬
rent of the AC adaptor.
•Contact an electrical parts distributor for assis¬
tance in selecting a suitable AC plug adaptor or
AC cord set.
Batteries
1. Battery pack
(Lithium ion battery pack) (not included)
• Use this unit to recharge the battery pack.
• Do not use the battery pack with equipment
other than the specified player.
• Do not use, charge or leave the battery
pack in locations where there is static elec¬
tricity.
• Do not use the player outside if it is snowing
or raining. (The battery pack is not water¬
proof.)
• Do not get dirt, sand, liquids, or other for¬
eign matter on the terminals.
• Do not touch the plug terminals (+ and -)
with metal objects.
• Do not disassemble, remodel, heat or throw
into fire.
2. Button-type battery (Lithium battery)
• Insert with poles aligned.
• Do not touch the terminals (+ and -) with
metal objects.
• Do not disassemble, remodel, heat or throw
into fire.
• Keep out of reach of children.
If any electrolyte should come into contact with
your hands or clothes, wash it off thoroughly with
water.
If any electrolyte should come into contact with
your eyes, never rub the eyes.
Rinse eyes thoroughly with water, and then con¬
sult a doctor.
3. Disposing of the batteries
Check and follow your local regulations before
disposal.
Installation
1. Water and Moisture —Do not use this unit
near water—for example, near a bathtub,
RQT56Q3

Listening caution
washbowl, swimming pool, or the like. Damp
basements should also be avoided.
2. Condensation —Moisture may form on the
lens in the following conditions...
•immediately after a heater has been turned
on.
• in a steamy or very humid room.
•when the unit is suddenly moved from a
cold environment to a warm one. If moisture
forms inside this unit, it may not operate
properly. To correct this problem wait about
one hour for the moisture to evaporate.
3. Heat —Never use or place this unit or battery
near a heat source. Do not leave it in an au¬
tomobile exposed to direct sunlight for a long
time with the doors and windows closed as
this may deform the cabinet.
4. Foreign Materia! —Care should be taken so
that objects do not fall into and liquids are not
spilled into the unit. Do not subject this unit to
excessive smoke, dust, mechanical vibration,
or shock.
Service
1. Damage Requiring Service— The unit
should be serviced by qualified service per¬
sonnel when:
(a) The AC power supply cord or AC adaptor
is damaged; or
(b) Objects have fallen or liquid has spilled
into the unit; or
(c) The unit has been exposed to water; or
(d) The unit does not appear to operate nor¬
mally or exhibits a marked change in per¬
formance; or
(e) The unit has been dropped, or the enclo¬
sure damaged.
2. Servicing — The user should not attempt to
service the unit beyond that described in the
operating instructions. All other servicing
should be referred to authorized service per¬
sonnel.
For the address of an authorized servicen-
ter:
In the U.S.A., call 1-800-211-7262, e-mail
consumerproducts @ panasonic.com, or
visit www.panasonic.com
In Canada, call 1-800-561-5505 or visit
www.panasonic.ca
3. Replacement parts— When parts need re¬
placing, ensure the servicer uses parts spec¬
ified by the manufacturer or parts that have
the same characteristics as the original parts.
Unauthorized substitutes may result in fire,
electric shock, or other hazards.
4. Safety check— After repairs or service, ask
the servicer to perform safety checks to con¬
firm that the unit is in proper working condi¬
tion.
Do not play your headphones or earphones at a
high volume. Hearing experts advise against
continuous extended play.
If you experience a ringing in your ears, reduce
volume or discontinue use.
Do not use while operating a motorized vehicle.
It may create a traffic hazard and is illegal in
many areas.
You should use extreme caution or temporarily
discontinue use in potentially hazardous situ¬
ations.
Even if your headphones or earphones are the
open-air type designed to let you hear outside
sounds, don’t turn up the volume so high that you
can’t hear what’s around you.
Sound can be deceiving. Over time your hearing
“comfort level” adapts to higher volumes of
sound. So what sounds '‘normal" can actually be
loud and harmful to your hearing.
Guard against this by setting your equipment at a
safe level BEFORE your hearing adapts.
To establish a safe level:
•Start your volume control at a low setting.
•Slowly increase the sound until you can hear it
comfortably and clearly, and without distortion.
Once you have established a comfortable sound
level:
•Set the dial and leave it there.
CAUTION:
The batteries used in this device may present
a risk of fire or chemical burn if mistreated.
Do not disassemble or incinerate the batter¬
ies. Do not heat the batteries above the fol¬
lowing temperatures.
Button-type battery .100 °C (212 °F)
Battery pack.60 X (140 °F)
Do not recharge the button-type battery.
Replace only with Panasonic part number in¬
dicated below:
Button-type battery (Lithium battery)
(for remote control). C R2025
Battery pack (Lithium ion battery pack)
For U.S.A.: CGP-H501A/1B
For Canada: CGP-H501C/1B
Use of other batteries may present a risk of
fire or explosion.
RQT5603
Getting
Started

Getting
Started
Disc information
O
Discs supported by this
unit
0
Discs not supported by this
unit
DVD-Audio
DVD-Video
Video CD
fates
(jjjgjuL video)
Audio CD
lfeg
DIGITAL AUDIO
► D VD-Video with a region number other
than “1” or “ALL” (See below.)
► Photo CD «CD-R
► PAL system DVD-Video* and Video CDs.
•CD-RW
• DVD-RW
•DVD+RW
• CVD
• Divx Video Disc
•CDV
•CD-G
etc.
• DVD-ROM
• DVD-R
• DVD-RAM
• CD-ROM
• VSD
• SVCD
• SACD
Do not try to play Photo CD or CD-R.
Data on the disc may be damaged.
‘When playing DVD-Audio, video output is cut off and only the audio is played.
“ EH3 ” (Audio Only Play) lights on the unit’s display to indicate this mode is on.
■ Region number supported by this
unit (DVD-Video only)
Region numbers are allocated to DVD play¬
ers and DVD-Video according to where
they are sold.
•The region number of this unit is “1”.
•This unit will play DVD-Video marked with
labels containing the region number “1”
or “ALL”.
Example:
Read the disc’s instructions carefully.
J V
■ Playing DVDs and Video CDs
The producer of the material can control
how these discs are played. This means
that you may not be able to control play of a
disc with some operations described in
these operating instructions. Read the
disc’s instructions carefully.
■ How the picture appears on your tele¬
vision
It depends on the aspect ratio of your tele¬
vision, and the television’s screen mode
and the aspect ratio recorded on the disc
( ■ * page 26).
■ The functions depend on the disc
being played. These marks indicate
the functions available.
I i-
(DVD-Audio) (DVD-Video)
HZJ ■ -
(Video CD) (Audio CD)
CD
VCD
DVD-V
DVD-A
HOT5603

Disc and unit handling precautions
Concerning discs
Do not use irregularly shaped discs, such as
heart-shaped. (These discs can damage the
unit.)
■ How to hold a disc
Do not touch the recorded shiny surface.
■ If the surface is dirty
Wipe it with a damp cloth and then wipe dry.
Wipe from the center toward the circumference.
Play surface (shiny surface)
■ If the disc is brought from a cold to a
warm environment, moisture may
form on the disc
Wipe with a soft, dry, lint-free cloth before using
the disc.
■ Handling precautions
•Do not write on the label side with a ball-point
pen or other writing instrument.
• Do not use record cleaning sprays, benzine,
thinner, static electricity prevention liquids or
any other solvent.
•Do not use scratch-proof protectors or covers
other than those specified for use with this unit.
•Do not attach labels or stickers to discs.
•Do not use discs with exposed adhesive from
tape or left over peeled off stickers.
• Do not use discs printed with label printers
available on the market.
■ Do not place or store discs in the fol¬
lowing places
• Locations exposed to direct sunlight
• Humid or dusty locations
•Locations directly exposed to the heat from a
heating appliance
To prevent damage
Avoid the following;
•Spraying flammable insecticides near the unit,
•Touching the lens and other parts of the laser
pickup.
Do not use the unit in the following places:
•Sandy places such as beaches,
•On top of cushions, sofas, or hot equipment
such as amplifiers.
Do not rest the unit on your lap for a long time
while using it. The unit can become hot and
cause burns.
Maintenance
■ To clean this unit, wipe with a soft,
dry cloth.
If the surfaces are extremely dirty, use a soft
cloth dipped in a soap-and-water solution or a
weak detergent solution.
• Never use alcohol, paint thinner or benzine to
clean this unit.
• Before using chemically treated cloth, read the
instructions that came with the cloth carefully.
■ Maintenance of the lens
•If dust is attached to the lens, remove dust
carefully with an air blower for camera lenses
(optional) .
•Be careful not to touch the lens with your
fingers.
9
R0T5603
Getting
Started

Getting
Started
Preparing the remote control Power supply
Insert the battery
(Lithium battery)
■ Replacing the button-type battery
The battery normally lasts for about a year.
Replace if the remote control fails to oper¬
ate the unit when used within the operation
range.
Note
Refer to “PRECAUTIONS” on pages 6 and 7.
Operation range
Remote control
signal sensor
About 7 m
(23 feet) in
front of the
signal sensor
10
•Do not expose the remote control signal
sensor to bright light.
•Do not place obstacles between the re¬
mote control signal sensor and the re¬
mote control.
•Do not use another unit’s remote control
at the same time.
Using the AC adaptor
Front of this unit
Note
Refer to “PRECAUTIONS” on page 6.
The unit is in the standby condition (the
[(])] indicator lights) when the AC power
supply cord is connected. The primary
circuit is always “live” as long as the AC
adaptor is connected to an electrical
outlet.
■ When the unit is not going to be used
for a long time
The unit consumes 2 W when in standby
mode.
To conserve power, disconnect the AC
power supply cord from the AC outlet.
RGT5603
