Panasonic WJ-NV200K User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Installation Guide
Network Disk Recorder
Model No. WJ-NV200K
WJ-NV200K/G

2
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulat-
ed "dangerous voltage" within the prod-
uct's enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
Before attempting to connect or operate this product, please
read the label on the bottom.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Power disconnection. Unit with or without ON-OFF switches
have power supplied to the unit whenever the power cord is
inserted into the power source; however, the unit is opera-
tional only when the ON-OFF switch is in the ON position.
Unplug the power cord to disconnect the main power for all
units.
WARNING:
• This apparatus must be earthed.
• Apparatus shall be connected to a main socket outlet with a
protective earthing connection.
• The mains plug or an appliance coupler shall remain readily
operable.
• To prevent fire or electric shock hazard, do not expose this
apparatus to rain or moisture.
• The apparatus should not be exposed to dripping or splash-
ing and that no objects filled with liquids, such as vases,
should be placed on the apparatus.
• All work related to the installation of this product should be
made by qualified service personnel or system installers.
• The connections should comply with local electrical code.
This Class A digital apparatus complies with Canadian
ICES-003.
For Canada
The model number and serial number of this product may
be found on the surface of the unit.
You should note the model number and serial number of
this unit in the space provided and retain this book as a
permanent record of your purchase to aid identification in
the event of theft.
Model No.
Serial No.
For U.S.A.
NOTE: This equipment has been tested and found to com-
ply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harm-
ful interference to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
FCC Caution: To assure continued compliance, (example -
use only shielded interface cables when connecting to
computer or peripheral devices). Any changes or modifi-
cations not expressly approved by the party responsible
for compliance could void the user’s authority to operate
this equipment.
For U.S.A.
UL listed model No.:
WJ-NV200K

3
FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT
CAREFULLY.
This appliance is supplied with a moulded three pin mains plug for your
safety and convenience.
A 5 amp fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the replacement
fuse has a rating of 5 amp and that it is approved by ASTA or BSI to
BS1362.
Check for the ASTA mark Hor the BSI mark Gon the body of the
fuse.
If the plug contains a removable fuse cover you must ensure that it is
refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a replacement
cover is obtained.
A replacement fuse cover can be purchased from your local Panasonic
Dealer.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET
OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED
AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT
OFF PLUG IS INSERTED INTO ANY 13 AMP SOCKET.
If a new plug is to be fitted please observe the wiring code as shown
below.
If in any doubt please consult a qualified electrician.
WARNING: This apparatus must be earthed.
IMPORTANT
The wires in this mains lead are coloured in accordance with the follow-
ing code.
Green-and-yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wire in the mains lead of this appliance may
not correspond with the coloured markings identifying the terminals in
your plug, proceed as follows.
The wire which is coloured green-and-yellow must be connected to
the terminal in the plug which is marked with the letter Eor by the earth
symbol Ior coloured green or green-and-yellow.
The wire which is coloured blue must be connected to the terminal
in the plug which is marked with the letter Nor coloured black.
The wire which is coloured brown must be connected to the termi-
nal in the plug which is marked with the letter Lor coloured red.
How to replace the fuse
Open the fuse compartment with
a screwdriver and replace the fuse
and fuse cover.
For U.K.
FUSE
Wij verklaren als enige aansprakelijke, dat het product waarop deze
verklaring betrekking heeft, voldoet aan de volgende normen of andere
normatieve documenten, overeenkomstig de bepalingen van Richtlijnen
2006/95/EC en 2004/108/EC.
Vi erklærer os eneansvarlige for, at dette produkt, som denne deklaration
omhandler, er i overensstemmelse med standarder eller andre normative
dokumenter i følge bestemmelserne i direktivene 2006/95/EC og
2004/108/EC.
Vi deklarerar härmed vårt fulla ansvar för att den produkt till vilken denna
deklaration hänvisar är i överensstämmelse med de standarder eller
andra normativa dokument som framställs i direktiv nr 2006/95/EC och
2004/108/EC.
Ilmoitamme yksinomaisella vastuullamme, että tuote, jota tämä ilmoitus
koskee, noudattaa seuraavia standardeja tai muita ohjeellisia asiakirjoja,
jotka noudattavat direktiivien 2006/95/EC ja 2004/108/EC säädöksiä.
Vi erklærer oss alene ansvarlige for at produktet som denne erklæringen
gjelder for, er i overensstemmelse med følgende normer eller andre
normgivende dokumenter som følger bestemmelsene i direktivene
2006/95/EC og 2004/108/EC.
We declare under our sole responsibility that the product to which this
declaration relates is in conformity with the standards or other normative
documents following the provisions of Directives 2006/95/EC and
2004/108/EC.
Nosotros declaramos bajo nuestra única responsabilidad que el producto
a que hace referencia esta declaración está conforme con las normas u
otros documentos normativos siguiendo las estipulaciones de las
directivas 2006/95/CE y 2004/108/CE.
Noi dichiariamo sotto nostra esclusiva responsabilità che il prodotto a cui
si riferisce la presente dichiarazione risulta conforme ai seguenti standard
o altri documenti normativi conformi alle disposizioni delle direttive
2006/95/CE e 2004/108/CE.
Wir erklären in alleiniger Verantwortung, daß das Produkt, auf das sich
diese Erklärung bezieht, mit den folgenden Normen oder normativen
Dokumenten übereinstimmt. Gemäß den Bestimmungen der Richtlinie
2006/95/EC und 2004/108/EC.
Nous déclarons sous notre propre responsabilité que le produit auquel se
réfère la présente déclaration est conforme aux normes spécifiées ou à
tout autre document normatif conformément aux dispositions des
directives 2006/95/CE et 2004/108/CE.

4
Limitation of liability
THIS PUBLICATION IS PROVIDED "AS IS" WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR ANY
PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF
THE THIRD PARTY'S RIGHT.
THIS PUBLICATION COULD INCLUDE TECHNICAL
INACCURACIES OR TYPOGRAPHICAL ERRORS.
CHANGES ARE ADDED TO THE INFORMATION HEREIN,
AT ANY TIME, FOR THE IMPROVEMENTS OF THIS
PUBLICATION AND/OR THE CORRESPONDING PRODUCT
(S).
Disclaimer of warranty
IN NO EVENT SHALL Panasonic System Networks Co., Ltd.
BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT
FOR REPLACEMENT OR REASONABLE MAINTENANCE
OF THE PRODUCT, FOR THE CASES, INCLUDING BUT
NOT LIMITED TO BELOW:
(1) ANY DAMAGE AND LOSS, INCLUDING WITHOUT
LIMITATION, DIRECT OR INDIRECT, SPECIAL,
CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF
OR RELATING TO THE PRODUCT;
(2) PERSONAL INJURY OR ANY DAMAGE CAUSED BY
INAPPROPRIATE USE OR NEGLIGENT OPERATION OF
THE USER;
(3) UNAUTHORIZED DISASSEMBLE, REPAIR OR
MODIFICATION OF THE PRODUCT BY THE USER;
(4) INCONVENIENCE OR ANY LOSS ARISING WHEN
IMAGES ARE NOT DISPLAYED, DUE TO ANY REASON
OR CAUSE INCLUDING ANY FAILURE OR PROBLEM
OF THE PRODUCT;
(5) ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE,
OR LOSS OR DAMAGE, ARISING OUT OF THE
SYSTEM COMBINED BY THE DEVICES OF THIRD
PARTY;
(6) ANY CLAIM OR ACTION FOR DAMAGES, BROUGHT
BY ANY PERSON OR ORGANIZATION BEING A
PHOTOGENIC SUBJECT, DUE TO VIOLATION OF
PRIVACY WITH THE RESULT OF THAT
SURVEILLANCE-CAMERA'S PICTURE, INCLUDING
SAVED DATA, FOR SOME REASON, BECOMES
PUBLIC OR IS USED FOR ANY PURPOSE;
(7) LOSS OF REGISTERED DATA CAUSED BY ANY
FAILURE.
Warranty for U.S.
WJ-NV200K is warranted for three years. Refer to the provided warranty about further information.

5
Important safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are pro-
vided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the appara-
tus has been exposed to rain or moisture, does not operate normally, or has been dropped.
S3125A

6
Contents
Limitation of liability.......................................................4
Disclaimer of warranty...................................................4
Warranty for U.S............................................................4
Important safety instructions.........................................5
Preface ..........................................................................7
Features.........................................................................7
System configuration ..................................................8
About the user manuals ................................................9
System requirements for a PC ......................................9
Trademarks and registered trademarks.......................10
Abbreviations...............................................................10
GPL/LGPL ...................................................................10
Copyright.....................................................................10
Network security .........................................................11
About the face matching function ...............................12
Notation about the installation and setup of the
camera ......................................................................12
Precautions .................................................................15
Precautions for installation..........................................17
Major operating controls and their functions ..............18
Front view..................................................................18
Rear view...................................................................20
User/Host management ..............................................21
Operations flow ...........................................................22
Connection ..................................................................23
Connection of cameras.............................................23
Connection of monitors.............................................24
Connection of a PC...................................................25
About the connector....................................................26
How to use the terminals of the ALARM/CONTROL
connector ..................................................................26
Time and polarities of the ALARM/CONTROL
connector ..................................................................28
Installation or replacement of the hard disk drives .....29
Install the hard disk drives ........................................29
Replace the hard disk drives.....................................30
Turn on the recorder....................................................31
Turn on the power of the recorder.............................31
Turn off the power of the recorder ............................32
Register the license.....................................................33
Basic operations..........................................................35
Setup menu .................................................................37
Configure the minimum settings [Easy Start]..............38
Configure the basic settings [Basic setup]..................41
Display the basic setup pages ..................................41
Set up date & time and language
[Date/Language]........................................................41
Camera setup [Camera] ............................................44
Set up recording/events [REC & event].....................50
Configure the settings relating to monitors
[Monitor] ......................................................................59
Set up the main monitor [Main monitor]....................59
Set up the live monitor [Live monitor] .......................59
Configure other settings relating to monitors
[Advanced setup] ......................................................60
Configure the settings relating to network
[Network] .....................................................................61
Configure the basic network settings [Basic]............61
Configure the settings relating to the mail
notification [e-Mail]....................................................63
Configure the Panasonic alarm protocol settings
[Panasonic alarm protocol] .......................................64
Configure the settings relating to NTP/SNMP
synchronization [NTP/SNMP]....................................65
Configure the settings relating to the user
management [User management] ...............................66
Configure the basic settings relating to user
management [Basic]..................................................66
Register, edit or delete the user information
[User registration] ......................................................68
Edit the administrator information
[Administrator setup].................................................69
Configure the settings relating to maintenance
[Maintenance]..............................................................70
Check the system information such as the version
[System information] .................................................70
Confirm the hard disk drive information
[HDD information]......................................................70
Configure the settings and operations
relating to the system [System management]...........71
Register the license [Registration Key]......................73
Manage the hard disk drives [HDD management] ......75
How to display the "HDD management" page..........75
Check the hard disk drive information
[HDD information]......................................................76
Format the hard disk drives [Format HDD] ...............76
About the removal process and the link process of
hard disk drives.........................................................76
Lists of the setting items (Setup menu).......................77
About the error logs and the network logs..................86
Error logs...................................................................86
Network logs .............................................................87
Troubleshooting...........................................................88
Specifications..............................................................92
Standard accessories..................................................93

7
Preface
Features
The network disk recorders WJ-NV200K and WJ-NV200K/G (hereinafter, recorders) are designed for use within a surveillance
system, and record images/audio from up to 16 network cameras (hereinafter, cameras) on the hard disk drives. Up to 16 camer-
as can be registered.
This recorder supports HDMI (High-Definition Multimedia Interface) standard which allows displaying playback/live images with
superior quality when connecting to a high-definition monitor using an HDMI cable (option). It is possible to operate cameras from
this recorder to display images from multiple cameras or switch cameras from which images are to be displayed, etc.
The recorders described in this installation guide are the models that are compatible as of July, 2010. Contact your dealer for fur-
ther information.
* No hard disk drive is supplied with this recorder. For purchasing the hard disk drive, contact your dealer.
High-definition image monitoring is available
Live images from up to 16 cameras with the image capture size of SXVGA (1280 x 960) can be displayed simultaneously.
In addition, this recorder supports the H.264 video compression format that can achieve recording at a high frame rate for a long
time.
This recorder also supports the Full HD output (HDMI) that can display recorded images and live images from the cameras in high
definition.
Quick setup and operations
By connecting the mouse (accessory) to this recorder, quick operations are available while viewing a monitor.
By using "Easy Start", the network cameras are automatically recognized without operations from the PC. Setup is available by
following the guidance.
Quick search is also available using a calendar or the timeline.
Real-time face matching function
By matching registered face images with a face displayed on live images in real time and by notifying the matching result, it will
be possible to check guests or discover suspicious people. That can be an aid to crime prevention.
Compatible with ecological monitor
By connecting with the Panasonic wide LCD color monitor (WV-LW1900, WV-LW1900/G, WV-LW2200, WV-LW2200/G: option),
the brightness control function, synchronized with mouse operations, the monitor can save the power consumption to 30 % -
60 % of that during normal use.
SDHC/SD memory card slot equipped
It is possible to save images recorded from cameras on a SDHC/SD memory card. Images copied on the SDHC/SD memory
card can be played back, printed or saved using the optional dedicated software.
(Recommended SDHC/SD memory card ☞page 92)

8
System configuration
・・・
PC
Main monitor Live monitor
Powered
speaker
Network camera (x 16 max.)
Network

9
About the user manuals
There are 3 sets of operating instructions for the WJ-NV200K, WJ-NV200K/G as follows.
Installation Guide (this document): Contains descriptions of how to install/connect this product and how to configure the required
settings.
Operating Instructions (PDF): Contains descriptions of how to operate this product.
(Both operations using the interface on the product and using a PC via a network are provid-
ed)
Quick Reference Guide: Contains descriptions of how to operate functions frequently used.
Adobe®Reader®is required to read the PDF files on the provided CD-ROM. When Adobe®Reader®is not installed on the PC,
download the latest Adobe®Reader®from the Adobe web site and install it.
Depending on descriptions, the model name of this recorder may be omitted as "NV200" in the manuals and on the setup.
The screens used in these operating instructions show the case in which WJ-NV200K is used and 16 cameras are connected.
Refer to "readme.txt" on the provided CD-ROM for further information about the optional dedicated software that receives and
displays the event and error information, compatible cameras and their versions.
System requirements for a PC
It is recommended to operate this product using a PC that meets the following system requirements.
OS and web browser: Windows®Internet Explorer®8.0*1
(Microsoft®Windows®7 Professional (32-bit)*2
Windows®Internet Explorer®7.0
(Microsoft®Windows Vista®Business SP1 (32-bit))
CPU: Intel®Core™ 2 Duo 2.66 GHz or faster
Memory: 1 GB or more
Monitor: 1 024 x 768 pixels or more, 24-bit True color or better
Network interface: 10BASE-T/100BASE-TX/1000BASE-T 1 port
Audio: Sound card (When using the audio function)
Others: CD-ROM drive: It is necessary to refer to the operating instructions on the provided CD-ROM.
DirectX®9.0c or later
Adobe®Reader®: It is necessary to refer to the operating instructions on the provided CD-ROM.
*1 Windows®Internet Explorer®8.0 (64-bit) is unavailable.
*2 Windows®XP compatibility mode is unavailable.
Important:
 • WhenusingaPCthatdoesnotmeettheaboverequirements,displayingofimagesmaybecomeslowerorthewebbrowser
may become inoperable.
 • AudiomaynotbeheardifasoundcardisnotinstalledonaPC.
Note:
 • Referto"NotesonWindowsVista®/ Windows®7" (PDF) for further information about system requirements for a PC and
precautions.

10
Trademarks and registered trademarks
Abbreviations
 • Adobe,theAdobelogo,andReaderareeitherregisteredtrademarksortrademarksofAdobeSystemsIncorporatedinthe
United States and/or other countries.
 • Microsoft,Windows,WindowsVista,InternetExplorer,ActiveXandDirectXareeitherregisteredtrademarksortrademarksof
Microsoft Corporation in the United States and other countries.
 • Microsoftproductscreenshot(s)reprintedwithpermissionfromMicrosoftCorporation.
 • IntelandIntelCorearetrademarksorregisteredtrademarksofIntelCorporationintheUnitedStatesandothercountries.
 • HDMI,theHDMIlogoandHigh-DefinitionMultimediaInterfacearetrademarksorregisteredtrademarksofHDMILicensing
LLC in the United States and other countries.
 • SDHCLogoisatrademarkofSD-3C,LLC.
 • All other trademarks identified herein are the property of their respective owners.
The following abbreviations are used in this manual.
Microsoft®Windows®7 Professional (32-bit) is described as Windows 7.
Microsoft®Windows Vista®Business SP1 (32-bit) is described as Windows Vista.
Windows®Internet Explorer®8.0 and Windows®Internet Explorer®7.0 are described as Internet Explorer.
SDHC/SD memory card is described as SD card or SD memory card.
Network cameras are described as cameras.
Copyright
Except for open source software licensed base on GPL/LGPL and so on, distributing, copying, disassembling, reverse compiling,
reverse engineering, and also exporting in violation of export laws of the software provided with this product are all expressly pro-
hibited. In addition, exporting any software provided with this product violating export laws is prohibited.
This product incorporates copy protection technology that is protected by U.S. and foreign patents, including patent numbers
5,315,448 and 6,836,549, and other intellectual property rights. The use of Macrovision's copy protection technology in the
product must be authorized by Macrovision. Reverse engineering or disassembly is prohibited.
GPL/LGPL
 • ThisproductcontainssoftwarelicensedunderGPL(GNUGeneralPublicLicense),LGPL(GNULesserGeneralPublic
License), etc.
 • Customerscanduplicate,distributeandmodifythesourcecodeofthesoftwareunderlicenseofGPLand/orLGPL.
 • Refertothe"readme.txt"fileontheprovidedCD-ROMforfurtherinformationaboutthesourcecodeofthesoftwarecon-
tained in this product and copyright notice comprised in the GPL/LGPL software.
 • PleasenotethatPanasonicshallnotrespondtoanyinquiriesregardingthesourcecode.

11
Network security
As you will use this product connected to a network, your attention is called to the following security risks.
qLeakage or theft of information through this product
wUse of this product for illegal operations by persons with malicious intent
eInterference with or stoppage of this product by persons with malicious intent
It is your responsibility to take precautions such as those described below to protect yourself against the above network security
risks.
 • Usethisproductinanetworksecuredbyafirewall,etc.
 • IfthisproductisconnectedtoanetworkthatincludesPCs,makesurethatthesystemisnotinfectedbycomputervirusesor
other malicious entities (using a regularly updated anti-virus program, anti-spyware program, etc.).
 • Protectyournetworkagainstunauthorizedaccessbyrestrictinguserstothosewhologinwithanauthorizedusernameand
password.
 • Aftertheproduct is accessed by the administrator, make sure to close the web browser.
 • Changethepasswordperiodically.
 • Applymeasuressuchasuserauthenticationtoprotectyournetworkagainstleakageortheftofinformation,includingimage
data, authentication information (user names and passwords), alarm mail information and FTP server information.

12
This recorder (WJ-NV200K or WJ-NV200K/G) has the face matching function that compares the registered face images with a
face displayed on live images to detect a person with a closer match. When the person is detected, it is possible to activate an
alarm notification.
To use the face matching function, there are following restrictions.
 • OnlyCamera1isavailable.
 • Acamerasupportingthefacedetectionfunctionisrequired.
Refer to the "readme.txt" on the provided CD-ROM about the available cameras.
The maximum number of faces that can be detected simultaneously depends on the detection performance of the camera.
 • Whenthefacematchingfunctionisactivated,thesettingson the "Advanced recording setup" page (☞page 52) for Camera
1 will automatically be changed as follows.
Compression: H.264
Image capture size: SXVGA (1280 x 960)
Frame rate: 5 ips
Image quality: SF
HDD saving mode: Except
 • Thefacematchingfunctionisunavailablewhilerecordedimagesarebeingplayedback.
 • Whilethefacematchingfunctionisbeingactivated,themaximumnumberofmulti-screensegmentsis4.
 • Theperformanceofthefacematchingfunctiondependsonthedetectionperformanceofthecameraandrecorder.When
many people appear on images at the same time, the following problems may happen: It may take time for face matching or
several face images may not be matched.
 • Faceimagescanberegisteredonlyonrecordedimagesplayedbackontherecorder.Itisimpossibletoregisterfaceimages
displayed on images from the camera while recording is not being performed. It is recommended to perform settings to
record images for 24 hours.
Notation about the installation and setup of the camera
When performing the installation and setup of the camera, note the following so that the performance of the face matching func-
tion is maintained.
 • Install the camera so that the width ("a" in the illustration) of a face image becomes 125 pixels or more.
Example) When the image capture size is "1280 x 960", the width of the face image should be 1/10 or more of the whole
screen.
About the face matching function
960 a
1280

13
 • Adjusttheheight,angleofdepressionandvertical angular field of view of the camera so that the angle between the camera
and face ("θ" in the illustration) becomes 15° or less.
Example of camera adjustment (When shooting a person whose height is 170 cm {5.58'})
Height Angle of depression Vertical angular field of view
(Zoom ratio) Distance between the camera and a person
2.3 m {7.55'} 10° 12° (6x) 3.3 m - 8.5 m {10.83' - 27.89'}
2.3 m {7.55'} 15° 18° (4x) 3.0 m - 5.5 m {9.84' - 18.04'}
 • When the face matching function is activated by the setting, the settings for Camera 1 will automatically be changed as fol-
lows. (Refer to the operating instructions of the connected camera for further information.)
Video encoding format H.264
Compression 1280×960
Frame rate 5 ips
Max bit rate (per client) 4096 kbps (as indication)
Refresh interval 5 s
Super Dynamic(SD) Off
Adaptive black stretch Off
Back light compensation(BLC) Off
Shutter speed (Light control mode) 1/100 fix
AGC On(High)
Black & white mode Off
DNR Low
•By masking an area with remarkable illuminance change, it is possible to shoot images on which faces can be recognized
more accurately.
When shooting images on a place where strong light sources may affect from outside, the following settings can reduce the
light influence.
Camera
Angle of depression Camera
Person
Vertical angular
field of view
θ(Angle between the
camera and face)
Height
Glass
<Example of image (Near the entrance)> <Example of mask area setting for the image>
Poster
Around the poster Not masked Masked (White)

14
Cases not suited for face matching
The performance of the face matching function varies depending on such conditions as the camera installation, camera settings,
camera adjustment, surroundings and photographic subjects. Therefore, face matching may not be performed in the following
cases.
 • Illuminancelevelsaredispersed.(Example:Outdoors)
 • Facesareinterruptedbysuchobjectsasmedicalmasks,sunglassesorhelmets.
 • Facesarenotdirectedtothefrontside.
 • Photographicsubjectsaremovingquickly.
 • Stronglightsources(suchastheheadlightsofacar,risingsunlightorsettingsunlight)mayaffecttheshootingplacefrom
outside.
To improve the performance of face matching
 • Registerthetargetfaceimagesfromtheimagesrecordedbythecamerainstalledinthesameconditions.
 • Performsettingsforthecamerasothatthecameracanshootfaceimagesatabalancedilluminancelevelbothintheday-
time and nighttime.
 • Installthecamerasothatthecameracanmovewithintheassumedmovingpathwayofphotogenicsubjects.
 • Ifpeople'sfacesareprintedonaposter,performthesettingfor"Setuparea"(☞page 58) so that these faces are not target-
ed for face matching.

15
Power source
The input power source for this product is 120 V AC 60 Hz
(WJ-NV200K), 220 V – 240 V AC 50 Hz/60 Hz
(WJ-NV200K/G). Do not connect to the outlet that provides
the power to equipments that requires a measurable amount
of power (such as a copy machine, air conditioner, etc.).
Avoid placing this product in locations where is subject to
water.
* The provided power cord(s) is (are) dedicated to the use
with this product.
Ambient operating temperature
Use this product at temperatures between +5 °C to +45 °C
{41 °F to 113 °F}. Failure to do so may damage the internal
parts or cause malfunction. Performance and lifetime of hard
disk drives are easily affected by heat (used at high tempera-
ture). It is recommended to use this product at temperatures
between +20 °C to +30 °C {+68 °F to +86 °F}.
To cut the power supply
This product has no power switch. To cut the power supply,
unplug the power plug of the product from the AC outlet. If it
is hard to unplug the power cord due to the installation con-
ditions, connect the power cord of the product to the AC
outlet via the circuit breaker of a distribution board or to the
AC inlet socket of a power supply control unit.
Built-in backup battery
 • Beforethefirstuse,chargethebuilt-inbackupbattery
(lithium battery) by turning on the power for 48 hours or
more. If it is not charged enough, in a case where the
power goes down, the internal clock may keep bad time
or the operative condition may be different to that before
the electric power failure.
 • Thebuilt-inbatterylifeisapprox.5yearsasanindication
of replacement. (The built-in battery life may become
shorter depending on the use condition.) Replace the
built-in battery after 5 years of use. ("5 years of use" is
just an indication of replacement. We are not providing
any guarantee of the built-in battery lifetime.) When the
built-in battery life runs out, some settings such as the
time and date setting will not be saved once the power
is turned off.
 • Askyourdealerwhenreplacementofthebatteryis
required.
Hard disk drive (HDD)
 • Harddiskdrivesarevulnerabletovibration.Handlethem
with care. It is possible to damage them if they are
moved while their motors are still running.
 • Donotmoveorinstallthisproductjustafterturningthe
power on or off (for around 30 seconds.) The hard disk
drives are running.
 • Thelifetimeofharddiskdrivesislimitedbyuse.Write
errors may occur frequently after around 20 000 hours of
operation, and the head and motor deterioration may
occur after around 30 000 hours of operation. They will
reach the end of their lifetime after 30 000 hours of oper-
ation if they have been used at the recommended ambi-
ent temperature (approx. +25 °C {77 °F}).
 • Topreventdatalossfromdiskclashes,itisrecommend-
ed to keep the ambient operating temperature below
+25 °C {77 °F} and to replace them after around 18 000
hours of operation.
 • Whenharddiskdrivetroubleoccurs,replaceitimmedi-
ately. Contact your dealer about servicing.
About SDHC/SD memory card
 • WhenusinganunformattedSDHC/SDmemorycard,
format it using this product. Recorded data on the
SDHC/SD memory card will be deleted when formatted.
If an unformatted SDHC/SD memory card or an SDHC/
SD memory card formatted with other devices is used,
the product may not work properly or performance dete-
rioration may be caused. Refer to the Operating
Instructions (PDF) for how to format a SDHC/SD memo-
ry card.
 • WhensomeSDHC/SDmemorycardsareusedwiththe
product, the product may not work properly or perfor-
mance deterioration may be caused. Use the SDHC/SD
memory cards recommended in page 92.
 • Refertopage19 for how to insert/remove a SDHC/SD
memory card.
Prevent condensation from forming
If this happens, it can cause malfunction.
Leave it switched off for around 2 hours in the following
cases.
 • Whenthisproductisplacedinanextremelyhumid
place.
 • Whenthisproductisplacedinaroomwhereaheater
has just been turned on.
 • Whenthisproductismovedfromanair-conditioned
room to a humid and high-temperature room.
About the monitor
When displaying the same image on the monitor for a long
time, the monitor may be damaged.
When this product is not supposed to be used for a
certain period
Turn on the power (approximately once a week), and per-
form recording/playback to prevent interferences with func-
tions.
Cleaning
Turn the power off, and then use a soft cloth to clean this
product. When the dirt is hard to remove, use a mild deter-
gent and wipe gently. Wipe out the detergent completely
using a soft cloth.
Do not use strong or abrasive detergents when cleaning the
body.
When using a chemical cloth for cleaning, read the caution
provided with the chemical cloth product.
Indication label
Refer to the indication label placed on the surface of this
product for the equipment classification and power source,
etc.
Precautions

16
MPEG-4 Visual Patent Portfolio License
This product is licensed under the MPEG-4 Visual Patent
Portfolio License for the personal and non-commercial use
of a consumer for (i) encoding video in compliance with the
MPEG-4 Visual Standard ("MPEG-4 Video") and/or (ii)
decoding MPEG-4 Video that was encoded by a consumer
engaged in a personal and non-commercial activity and/or
was obtained from a video provider licensed by MPEG LA to
provide MPEG-4 Video. No license is granted or shall be
implied for any other use. Additional information including
that relating to promotional, internal and commercial uses
and licensing may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.
AVC Patent Portfolio License
This product is licensed under the AVC Patent Portfolio
License for the personal and noncommercial use of a con-
sumer to (i) encode video in compliance with the AVC
Standard ("AVC Video") and/or (ii) decode AVC Video that
was encoded by a consumer engaged in a personal and
non-commercial activity and/or was obtained from a video
provider licensed to provide AVC Video. No license is grant-
ed or shall be implied for any other use. Additional informa-
tion may be obtained from MPEG LA, LLC.
See http://www.mpegla.com.
Handle this product with care
Do not strike or shake, as this may damage this product.
Do not strike or give a strong shock to this product
It may cause damage or allow water to enter this product.
About reboot of this product
In the following cases, this product will automatically reboot
to continue recording.
 • WhenanHDDisremovedinadifferentwayfromthe
description of "Installation or replacement of the hard
disk drives" (☞page 29).
 • Whenthesoftwareofthisproducthasdetectedthe
internal error and reboot becomes necessary.

17
This product is designed to be used indoors.
Do not place this product in the following places:
 • Locationsexposedtodirectsunlight
 • Locationssubjecttohavingstrongvibrationorimpact
 • Locationsnearmagneticfieldsourcessuchasatelevi-
sion or speakers
 • Locationswherecondensationformseasily,wheretem-
perature changes greatly or where humidity level is high
 • Locationssubjecttosteamandoilsmokesuchasa
kitchen
 • Locationswhicharenotlevel
 • Locationssubjecttodust
 • Locationswhereitmaygetwetfromrainorwatersplash
Do not install this product in locations where the prod-
uct or the cables can be destroyed or damaged by
persons with malicious intent.
Place this product horizontally on a level surface.
Do not place this product in an upright position. When
stacking multiple recorders, clear a space of more than 5 cm
{2 inches} from both sides, the top, the bottom and the rear
of them.
Heat dissipation
To prevent this product from overheating, heed the following.
Failure to observe this may cause fire or trouble.
 • Donotblocktheventilationopenings.Maintaintheprod-
uct periodically to prevent dust from blocking openings.
 • Thelifetimeofthecoolingfanislimitedbyuse.Itisrec-
ommended to replace them after approx. 30 000 hours
of operation. Contact your dealer for replacement of the
cooling fans.
 • Clearaspaceofmorethan5cm{2inches}fromboth
sides, the top, and the rear of the product. Do not block
the ventilation openings on the front side since this prod-
uct is designed to cool the hard disk drives by inhaling
air from the front.
Avoid placing this product near noise sources
If the cables are placed near noise sources such as fluores-
cent lamps, noises may be produced. In this case, rewire
avoiding the noise sources, or move the product to a place
far from the source.
Grounding
Confirm that the wire is connected from the SIGNAL GND
terminal to earth ground.
A grounding connection must be made before connecting
the power plug or this product to the main power supply.
When disconnecting the grounding wire, make sure that the
power plug of this product is disconnected from the main
power supply.
For BNC cable connection
Use only the recommended plug below when connecting the
BNC plug to the connectors on the rear panel of the record-
er.
Applicable plug MIL-C39012C, MIL-C39012/16F or BS
CECC2212: 1981
* Suffixes attached to the standards may be updated.
Tip dimensions inside the recommended BNC plug
Important:
 • Acompatibleplugshallbeused.Failuretoobservethis
may cause trouble such as poor contact. At worst, the
connector of this product may be damaged.
Avoid placing receptacles that contain liquids such as
water near this product.
If liquid spills onto this product, it may cause fire or an elec-
tric shock.
"
More than
5 cm {2 inches}
More than
5 cm {2 inches} More than
5 cm {2 inches}
Precautions for installation
Plug (locally procured)
BNC cable (locally procured)
ø1.32 mm - ø1.37 mm
{ø0.052" - ø0.054"}
ø0.13 mm - ø0.69 mm
{ø0.005" - ø0.027"}
Plug (locally procured)
BNC cable (locally procured)
ø1.32 mm - ø1.37 mm
{ø0.052" - ø0.054"}
ø0.13 mm - ø0.69 mm
{ø0.005" - ø0.027"}

18
Major operating controls and their functions
Front view
qStatus indicators
ERROR: Blinks when an error that can become a prob-
lem for the recorder to run the system occurs.
Blinks red: System error
Blinks orange: Thermal error, cooling fan malfunc-
tion, etc.
OPERATE: Lights when the power is on.
HDD [HDD1]/[HDD2]: Indicates the operational status
(access/failure) of the respective hard disk drive.
Blinks green: Indicates that the respective hard disk
drive is being accessed.
Lights red: Indicates that a fault (or an error) has
occurred on a hard disk drive.
Off: Indicates that the respective hard disk drive is
not being accessed.
REC: Lights orange when recording is being performed.
ALARM: Blinks when an alarm occurs, and lights when
the alarm output stops. This indicator will go off
when the [Reset] button (☞Operating Instructions
(PDF)) is clicked.
wBuzzer stop button [BUZZER STOP]
Press this button to stop the buzzer that started sound-
ing at an alarm/error occurrence. Refer to the operating
instructions (PDF) for further information about alarms
and errors.
eMouse connection port [MOUSE]
The provided mouse is connected to this port.
rRestart button [RESTART]
Press this button to reboot the recorder. When pressing
this button, use a sharp object such as a clip.
tSDHC/SD memory card slot
Recorded images can be saved on an optional SD
memory card. (☞Page 19)
* It is impossible to connect a mouse to the mouse connection port if the
connector from the mouse is upside down. When it is hard to connect,
check the upside down position of the connector from the mouse.
tSDHC/SD memory card slot
rRestart button
eMouse connection port
wBuzzer stop button
qStatus indicators

19
Insert an SD memory card (option)
Step 1
Open the SDHC/SD memory card slot cover.
Step 2
Insert a SD memory card all the way into the slot until it
clicks.
Step 3
Close the SDHC/SD memory card slot cover.
Note:
 • WhenremovingtheSD memory card from the slot, push
the card until it clicks and pull it up straight.
Pull the tab
down.
SDHC/SD memory
card slot cover
When inserting an SD memory card,
confirm that the label on the SD
memory card is upside and only the
upper right corner of the card has
different shape.

20
Rear view
yPower cord inlet [AC IN]
Connect the provided power cord to this inlet.
uAlarm/control connector [ALARM/CONTROL]
(D-sub 25-pin)
Connect a control switch to control the recorder using
an external device such as a sensor or a door switch or
an external alarm device such as a buzzer or a lamp.
iNetwork port [10/100/1000BASE-T]
Use this port to connect the recorder to a network com-
patible with 10BASE-T, 100BASE-TX or 1000BASE-T to
connect with a camera via a network. When the port is
being accessed, the access indicator (green) blinks.
When the port is being linked, the link indicator (orange)
lights.
oSpot output connector (BNC) [SPOT OUT]
Connect the live monitor. Camera images are output to
be displayed on a 1-screen.
!0 Audio output connector (RCA pin jack) [AUDIO
OUT]
Audio from live images or recorded images is output.
Connect such device as a speaker with amplifier.
!1 Monitor output connector (HDMI) [AV OUT]
This connector is used to connect to an HDMI-ready
monitor (the main monitor).
!2 HDD slots [HDD1/HDD2]
Hard disk drives (locally procured) can be installed into
these slots. Contact your dealer for installing/replacing
the hard disk drives.
!3 SIGNAL GND terminal [SIGNAL GND]
Connect this terminal with the SIGNAL GND terminals of
the devices in the system for signal ground. When oper-
ating the recorder and the devices in the system without
signal ground, oscillation or noise may be produced.
yPower cord inlet
!3 SIGNAL GND terminal
!2 HDD slots
uAlarm/control
connector
(D-sub 25-pin)
iNetwork port
Access indicator
Link indicator
o Spot output connector (BNC)
!0 Audio output connector
(RCA pin jack)
!1 Monitor output
connector (HDMI)
How to use the power cord plug brace
Put the hooks of the power cord plug brace on the power
cord inlet to fix the power cord plug.
Power cord plug brace
