E-Series
Basic Setup/ Operation Guide
Panasonic System Networks Co., Ltd.
Security Systems Business Division
V1. 7th Nov 2014
V2. 30th Jan 2015

<NOTICE>
This document is supplementary to the
operation manual.
Depending on the firmware version used
for E-Series NVR or camera, the screens
may differ from the actual screens.

3
HDD Installation
Display and Power Supply connection
Set Up Flow
SYSTEM Log in
General Setting
Network Setting
Camera Registration
Recording Schedule Setting
Camera Encode Setting
Camera and PC LAN Connection
Camera NTSC Setting if required
<Startup Wizard on NVR> <Additional Settings on NVR>
(Camera Image Setting)
<AdditionalSettings on Camera>
<Hardware Setup of NVR>

Hardware Set up of NVR

5HDD Installation

6Display and Power Supply Connection
Display Output
(VGA or HDMI)
DC Power (12V)
USB Mouse
(front or back)
DC Power (48V)
Display Output
(VGA or HDMI)
K-NL304K/G
K-NL308K/G
AC Power (100 -240 V,) USB Mouse
(front or back)
LAN Port (192.168.0.x)
NOTE : 2 DC powers are required

Setup Wizard on NVR

8Startup Wizard(1/3)
Password : 12345
General Setting
Uncheckthe button,
the setup wizard is cancelled next time
General Setting / Date & Time
Recommendto set NTP server
if internet is available
Changeif necessary
Select local time

9Startup Wizard(2/3)
Camera Registration
<Step3>
“Device Search” and “Device Add”
are executed automatically.
Check channel # and Port# are same
Network Setting
<Step1>
Make sure you decide
which camera to
go to which channel.
<Step2>
Plug in the CH1 camera
into the PoE port1 first
Changeif necessary
CH1 CH2 CH3 CH4
Port1 Port2 Port3 Port4
After CH1 camera registration,
repeat step 2 & 3 for another cameras

10 Startup Wizard(3/3)
24/7 recording is set as default
Schedule Setting
End of Startup Wizard

Additional Setting
on NVR/ Camera

12 Additional Settings(1/6)
Click here to start additional setting

13 Additional Settings(2/6)
CBR is
recommended
Max 2M bps
recommended
Camera Encode Setting

14
Change if necessary
Additional Settings(3/6)
Camera Image Setting
Change if you want to keep color mode during night time
Video image adjustment

15
Camera and PC LAN Connection
Additional Settings(4/6)
Pull out LAN cable connected to camera
from PoE port Connect the camera and PC to LAN switch.
(Require to configure IP address setting
“10.1. 1. x” for PC)

16
Camera Browser Access
Additional Settings(5/6)
Right Click
Start Config.Tool
The Camera is listed together with another devices
connected the same LAN switch Right Click, then select “Open Device Web”
ID : admin
PWD: 12345

17
Select NTSC
If max 30 fps is required
• Factory Default is PAL
PAL: Max fps is 25
Additional Settings(6/6)
NTSC Setting if max 30fps is required

18
Easy Operation

19 Camera Preview (Live View) Interface
Preview control interface
Shortcut Menu
Right Click!
Real time Playback button : latest time playback
Digital Zoom button
Point cursor to
upper side
of the screen
Manual Record button : record on USB memory
Snapshot button
Playback and Search Mode

20 Playback and Search Interface
Video / Snapshotselection for playback
“Record” : Video select
“PIC” : Snapshotselect
Windowsplit mode(1/4/9)
Playback channel selection
Playback Control Pane
(Play/Pause/PlayBackwards/
Fast Playback/Rewind/Slow Play)
Time Line Bar Can change scale of time line
Display file list of the day
Calendar for playback
(Blue Highlighted date)
There is recorded data
(Yellow colored date)
Currently selectedfor playback
