Panasonic FV-0511VQ1 User manual

Service Manual
PESMX1710004CE
Version:1902
Ventilating Fan
FV-0511VQ1
CONTENTS
1.Specifiaction
2.Parts Identification
3.Wiring Diagram
PAGE
2~4
1
5
4.Parts List 6~7
(North America Market)
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without the manufacturer’s approval.
.Please have a static electricity depletion process in place before handling these components.
. Please use gloves when handling PCB parts during the repair process.

1. Specification
1
Model No.
Air
direction
Voltage
(V)
Frequency
(Hz)
Duct
diameter
(Inches)
Air volume
at 0.1"WG
(CFM)
Noise
(sones)
Speed
(rpm)
Power
(W)
Weight
lb. (kg)
50 < 0.3 756 4.1
80 < 0.3 821 6.0
110 < 0.3 957 10.8
FV-0511VQ1 9.3 (4.2)Exhaust 120 60 4 or 6
HVI Certified performance based on HVI Procedures 915, 916, and 920.
1
Parts for Version A Parts for Version B
Motor Motor
Main PCB Section
MINEBEA
11QCL1M20B
DNN12M14L11F
MOTOR ASSEMBLY
DC29V / MADE IN CHINA
Label information
Top Cover view
Side viewSide view
Main PCB Section
0511VQL1
[ Serial No ] 0511VQL1
[ Serial No ] M
Motor Main PCB Judgment
Version A Version A ( OK ) Work
Version A Version B ( NG ) Do Not Work
Version B Version B ( OK ) Work
Version B Version A ( NG ) Do Not Work
Remark: We divide this model into Version A & Version B, because of different
motor and Main PCB Section, please put attention with identification
of parts when you request a service parts.
QR code
11QCL1M21 X
[ Serial No ]
11QCL1200 X
QR code
[ Serial No ]

2
1. Parts Identification
Main Body Section
1
2
3
4
5
6
7 A / 7 B
8
9
10
11
12 A / 12 B
13
A
B
(3pcs)
C
(5pcs)
B
D
C
(2pcs)
B
E
(2pcs)
FV-0511VQ1
Main PCB Section
17 A
Name Plate
17 B
or
New Motor
New PCB
80501 805 01 M

3
Main PCB Section
2. Parts Identification
FV-0511VQ1
Main Label
16
17A
18
19
20
21
14
15
F
(3pcs)
Part for Version A Part for Version B
17B
80501 80501M
8 Means Year: 2018
05 Means Month
01 Means Day
M: In House MOTOR
8 Means Year: 2018
05 Means Month
01 Means Day

4
2. Parts Identification
Packing Section
23
22
24
25
26
27
28
29
30
FV-0511VQ1

5
Main control circuit
Fan body
DC
Motor
Junction box
AC120V
60Hz
(Power supply)
White
Black
Live (Fan)
Neutral
Green
(Ground wire)
Main control
circuit
BLACK
WHITE
GREEN
Wire nuts
Junction
box
L
N
120 VAC
LINE IN
Switch box
Conduit
Ground wire
Live
Neutral
Ground wire

6
4. Parts List
Main Body Section
No. Part No. Part Name Q'ty Remark
1 FFV11QCL1900C Frame Assembly 1
2 FFV11VQC1910 Adapter Assembly 1
3 FFV08VKS3M915 Connector Plate 1
4 FFV11QCL1331 Ground Wire 1
5 FFV11QCL1301A Connector Assy 1
6 FFV11QCL1912A Junction Cover 1
7A FFV11QCL1M20A Motor 1 Version A
7B FFV11QCL1M21AX Motor 1 Version B
8 FFV11QCL1904C Motor Support 1
9 FFV0400114S Blade 1
10 FFV7020021S Nut 1
11 FFV11QCL1906B Casing 1
12A FFV0511VQL1UPCB Main PCB section 1 Version A
12B FFV11VQL1PCB Main PCB section 1 Version B
13 FFV1115VQ1A Grill Assembly 1
A FFVXYM4-E8FJ Screw (M4-8) 1
B FFVXTT4-8FFJ Screw (ST4-8) 5
C FFV7000089S Screw (ST4-12) 7
D FFVXYM4DC8BN Screw w/washer (M4-8) 1
E FFV7000065S Screw (M4-12) 2
Main PCB Section
No. Part No. Part Name Q'ty Remark
14 FFV15VQ10991D Main PCB Box 1
15 FFV11QCL1992C MAIN PCB Cover 1
F FFVXTN3-8GFJ Screw (M3-8) 3
!
!
!
!
!
!
!
!
!
!
!
FV-0511VQ1

7
4. Parts List
FV-0511VQ1
Main Label
No. Part No. Part Name Q'ty Remark
16 FFV11QCL1012A CFM Label 1
17A FFV11VQ10050 Name Plate 1 Version A
17B FFV11VQ10050M Name Plate 1 Version B
18 FFV0810011S Caution Label 1 1
19 FFV0810010S Caution Label 1
20 FFV6730045S Warning Label 1
21 FFV2260003S Holograph Label 1
Packing Section
No. Part No. Part Name Q'ty Remark
22 FFV11QCL1920 Hanger Assy 1
23 FFV4710381S Grill Pad Assy 1
24 FFV4650016S Poly Cover 1
25 FFV15VQ10420B Installation Inst 1 English / Spanish For USA Market
26 FFV15VQ10421 Installation Inst 1 English / French For CANADA Market
27 FFV11KSL1M031A Accessory A 1
28 FFV11QCL1891 Left Pad 1
29 FFV11QCL1892 Right Pad 1
!
