Panasonic FV-07VF1 User manual

INSTALLATION
INSTRUCTIONS
Ventilating Fan
FV-05VF1 FV-07VF1
FV-09VF1 FV-11VF1
READ AND SAVE THESE INSTRUCTIOINS.
Please read these instructions carefully before attempting to install,
operate or service the Panasonic Ventilating Fan. Failure to comply
with instructions could result in personal injury and/or property
damage. Please retain this booklet for future reference.
III
II
I
Specifications
Dimensions
Description
9-12
Maintenance
Product Service
12-13
13-14
8-9
6-8
4
4-5
4
3
2
2
Table of Contents
Supplied Accessories
Unpacking
General Safety Information
Installation ( Joist Mounting )
Installation
( Wooden Header )
Installation
( In Existing Construction )

FV-05VF1
FV-07VF1
FV-09VF1
FV-11VF1
2
8
1
Thumb screw
Long screw
Quantity
Appearance
Part name
Grille
Suspension
bracket I
Suspension
bracket II
Screw
Suspension
bracket III
Clamp
Plate
3 inch adaptor
connector(optional
part for FV-05VF1
and FV-07VF1)
1
1
4
1
2
1
These Panasonic ceiling mount ventilating fan models use a low noise sirocco fan driven by a capacitor motor.
The motor is designed to have an extended service life with reduced energy consumption.
It also incorporates a thermal-cutoff for safety. The grille covering the main body is a spring-loaded,quick-remove
type. A damper for preventing couterflow is provided.
SUPPLIED ACCESSORIES
SUPPLIED ACCESSORIES
DESCRIPTION
DESCRIPTION

Suspension plate II
Junction box cover
Junction box
Adaptor
Grille
Part name
Part name
330 (13)
84 (3 5/16)
3
6
7
1
92
DIMENSIONS
177.4 (7)
265~385 (10 13/32~15 5/32)
FV-05VF1
FV-07VF1
FV-09VF1
FV-11VF1
300.6(1
1 27/32 )
252.6 (9 15/16 )
79.2 (3 1/8)
56.7 (2 1/4)
105(4 1/8)
94 (3 23/32)
73 (2 7/8)
4 5
( 1 25/ 32 )
1 3 9 ( 5 1 5 / 3 2 )
4
8
(411/32)
110
255.6 (10 1 / 16 )
148 (5 13/16)
12
5
11
10
Unit: mm(inches)
No. No.
Body
Damper
1
2
3
4
5
6
7
8
9
10
11
12
Connector
Suspension bracket I
Thumb screw
3 inch adaptor connector
(only for FV-05VF1 and
FV-07VF1)
Bracket cover

Adaptor
4.2 (9.2)
4.2 (9.2)
3.9 (8.6)
20.0
Hz
60
V
Air direction
SPECIFICATIONS
SPECIFICATIONS
GENERAL SAFETY INFORMATION
GENERAL SAFETY INFORMATION
UNPACKING
UNPACKING
Model No.
FV-05VF1
FV-07VF1
FV-09VF1
FV-11VF1
Exhaust
120
(W)
Power consumption
14.0
24.0
34.0
639
739
835
948
Speed
(RPM)
Air deliver at
0.1" WG(CFM)
50
70
90
110
Weight
Kg(Ib.)
4.1 (9.0)
* At 0.0" Static pressure, (Pa)
Unpack and carefully remove unit from carton.
Refer to the Supplied Accessories list to verify that all parts are present.
o o
1. Do not install this ventilating fan where air temperature may exceed 40 c (104 F).
2. Make certain that the electric service supply voltage is 120V, 60 Hz.
3. Follow all local electrical and safety codes, as well as the National Electrical Code (NEC) and
the Occupation Safety and Health Act (OSHA).
4. Always disconnect the power source before working on or near the fan, motor or junction box.
5. Protect the power cord from sharp edges, oil, grease, hot surfaces, chemicals or other objects.
6. Do not kink the power cord.
7. Do not install the unit where ducts are configured as shown in Fig. A.
8. Provide suction parts with proper ventilation.
9. This unit is approved for use over a bathtub or shower when installed in a GFCI protected
branch circuit.
Fig. A

Floor
GENERAL SAFETY INFORMATION CONTINUED
GENERAL SAFETY INFORMATION CONTINUED
CAUTION:
1. For general ventilating use only. Do not use to exhaust
hazardous or explosive materials and vapors.
2. Not for use in cooking area. (Fig .B)
3. This product must be properly grounded.
Do not install above or
(Cooking area)
inside this area
o
45
o
45
equipment
Cooking
Fig. B
WARNING:
To reduce the risk of fire, electric shock or injury to persons, observe the following;
A. Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer.
B. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
C. Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) of fuel burning
equipment to prevent backdrafting. Follow the heating equipment manufacture's guideline and safety standards
such as those published by the National Fire Protection Association (NFPA), and the American Society for Heating
Refrigeration and Air Conditioning Engineers (ASHRAE) and the local code authorities.
D. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
E. Ducted fans must always be vented to the outdoors.
F. These models are UL listed for tub and shower enclosures.
G. Solid state controls may cause harmonic distortion which can cause motor humming noise.
H. Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting
means to prevent power from being switched on accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning device, shch as a tag, to the service panel.
I. NEVER place a switch where it can be reached from a tub or shower.
J. Not to be installed in a ceiling thermally insulated to a value greater than R40.

B
3
Fig. 3
Adaptor flange
Long screw
Fig. 1
4 Inch
Adaptor
Neutral
Green
Red
M.C.
Live
Power Supply
AC120V 60Hz
Black
3 inch adaptor connector
Duct tape
Connection method for 3 inch adaptor connector
IMPORTANT:
Remove the tape from damper and adaptor before
installation. As shown in Fig.1.
INSTALLATION I (JOIST MOUNTING)
INSTALLATION I (JOIST MOUNTING)
1. Disconnect plug connector from receptacle before
starting installation.
2. Remove adaptor from body and secure to ceiling joists
using long screws. (Fig.2)
Keep the distance B (21.6mm,7/8 inch) for the thickness of
ceiling board.
Joist spacing A should be between 380mm(14 31/32inch) and
265mm(10 7/16 inch).
CAUTION:
Wiring diagram
3. Remove junction box cover and secure conduit to junction box
knock- out hole. (Fig.3)
4. Refer to wiring diagram below.
Using wire nuts, connect house power wires to ventilating fan
wires:black to black; white to white;green to green.
Replace the junction box cover.
5.Install circular duct (4 inch) or optional part (3 inch adaptor
connector) that is only for FV-05VF1 and FV-07VF1 and
secure it with duct tape.
CAUTION:
Mount junction box cover carefully so that lead wires are not
pinched.
Motor
Thermal Cutoff
Black Black
A.C.
Capacitor
White
Earth
White White
Green
Remove
tape
Damper
Suspension
bracket I
Ceiling joist
Adaptor
Ceiling joist
Duct
Junction box cover
Wire nut
Conduit
Junction box
Lead wires
Green wires
Fig. 2
1
2

Fan
Receptacle
Fig. 7
Thumb screw
Fig. 6
Ceiling joist
Claws
Adapter slots
Fan body
Adapter
Fig.5-5
Fig. 5-2
Fan body
Fig. 5-1
Adapter
When mounting
body and blower
separately
9. Connect plug connector to receptacle.(Fig.8)
Make sure that body "Claws" are property inserted into adaptor
slots.
IMPORTANT:
INSTALLATION I(JOIST MOUNTING)CONTINUED
INSTALLATION I(JOIST MOUNTING)CONTINUED
6. Remove ceiling section. (Fig.4)
7. Insert fan body into ceiling. (Fig.6)
8. Secure fan body to adaptor using two thumb screws.(Fig.7)
1.Loosen 4 screws (but do
not remove them from
blower).(Fig.5-1)
2. Remove blower section.
3.Remove adaptor from
fan body and secure to
ceiling joists as in Fig.2
4.Insert fan body (without
blower section) into
ceiling.(Fig.6)
5.Secure the adaptor and
fan body using one thumb
screw as shown in Fig.5-3.
6.Secure the fan body to
the ceiling joists as shown
in Fig.9 and Fig.10 of
page 8.
7.Insert the blower into the
fan body.(Fig.5-4)
8.Secure the blower by 4
screws as shown in
Fig.5-5.
9.Mount the fan body with
thumb screw (on the right
side of bottom of the
adaptor) as shown in
Fig.7.
(Fig.5-2)
of page 6.
Screw
Blower
Fan body
Fig. 5-3
Ceiling joist
Fan body
Ceiling joist
Fig. 5-4
Screw
Screw driver
Ceiling
Ceiling joist
260 (10 1/ 4)
mm (inches)
260 (10 1/ 4)
Fig.4
Plug connector
Fig. 8

Fig.12
Fan body
Thumb screws
Ceiling
Mounting spring
Ceiling joist
Suspension bracket II
Suspension bracket III
Suspension bracket II
4-Long screws Suspension bracket III
1.Before installation, secure fan body to adaptor using two
thumb screws. (Fig.12)
INSTALLATION I(JOIST MOUNTING)CONTINUED
INSTALLATION I(JOIST MOUNTING)CONTINUED
10. Secure fan body to ceiling joists using long screws in horizontal
direction with suspension bracket II and III.(Fig.9)
11. Secure suspension bracket II and III to the fan body using 2
screws(Fig.10)
12. Replace ceiling and insert mounting springs into slots as
shown and mount grille to fan body.(Fig.11)
INSTALLATION II (WOODEN HEADER)
INSTALLATION II (WOODEN HEADER)
Ceiling joist Fig.9
2-screws
Fig.10
Slot
Grille Fig.11

Live
Adaptor
mm (inches)
CAUTION:
Mount junction box cover carefully so that lead wires are not
pinched
INSTALLATION II (WOODEN HEADER) CONTINUED
INSTALLATION II (WOODEN HEADER) CONTINUED
2. Install header between ceiling joists using nails or screws.
3. Install the ventilating fan and secure with screws.(Fig.13 and Fig.14)
4. Insert the circular duct to the adaptor.
Remove the junction box cover and secure conduit to junction
box knockout hole (7/8 inch) (Fig.14 )
5. Refer to wiring diagram.
Using wire nuts,connect house power wires to ventilating fan wires:
black to black; white to white; green to green.
Replace the junction box cover.
Long screws
Junction box cover
Ventilating fan
Ceiling joist
Header
Ceiling joist
Wiring diagram
Adaptor
6. Finish ceiling work. Ceiling hole should be aligned with
edge of the flange. (Fig.15 )
7. Mount grille to fan body. (Fig.11, page 8.)
Circular duct
Fig.13
Fig.14
Ceiling
Flange
Fig.15
CAUTION:
To install the ventilating fan, follow the procedures described in lnstallation II. Take the following precautions before
installation.
,
1. Installation in existing construction.
Installing the ventilating fan in an existing building requires an accessible area (attic or crawl space) above the planned
installation location or existing ducting and wiring.
Check area above planned installation location to be sure that:
1. Duct work can be installed and that area is sufficient for proper ventilation.
2. Wiring can be run to planned location.
3. No wiring or other obstructions will interfere with installation.
Inspect duct work and wiring before proceeding with installation.
Plan suitable location for ventilating fan.(next to ceiling joist)
INSTALLATION III (IN EXISTING CONSTRUCTION)
Power Supply
AC120V 60Hz
Earth
Motor
Thermal Cutoff
Black Black Black
Red
Capacitor
White
Green
M.C.
A.C.
White White
Green
Neutral

Fig. 18
Ceiling
Adaptor
Long screws
Suspension bracket I
Fig. 17
Junction box cover
Conduit
Fig. 16
Ceiling joist
mm (inches)
Ceiling
Suspension bracket I
Secure adaptor to ceiling joists with 4 long screws inside
of the ceiling as shown in Fig.18.
Wiring diagram
CAUTION:
Check area above planned installation location to be sure that:
1. Ensure that the square hole size in ceiling should be sufficient according to Fig.16
2. Duct work can be installed and that area is sufficient for proper ventilation.
3. Wiring can be run to planned location.
4. No wiring or other obstructions will interfere with installation.
Before installation, provide inspection and maintenance access at a location that will not interfere with
installation work shown in installation II .
First, remove ceiling section according to Fig.4 of page 7.
Install ventilating fan.
2. Installation from accessible area above fan location.
Inspect duct work and wiring before proceeding with installation.
Remove ceiling section according to Fig.4 of page 7.
Install ventilating fan.
3. Installation without removing ceiling.
Loosen 4 screws (but do not remove them from blower) as
shown in Fig.5-1.
Remove blower from fan body as shown in Fig.5-2 of page 6.
remove adaptor from fan body.
Remove junction box cover and secure the existing conduit
to junction box knockout hole.(Fig.17)
Refer to wiring diagram on page 9.
Using wire nuts, connect house power wires to ventilating fan wires:
black to black; white to white; green to green.
Replace the junction box cover.
INSTALLATION III (IN EXISTING CONSTRUCTION) CONTINUED
Install circular duct(4 inch) or optional part (3 inch adaptor
connector) that is only for FV-05VF1 and FV-07VF1 and
secure it with duct tape as shown in Fig.17.
Live
Power Supply
AC120V 60Hz
Earth
Thermal Cutoff
Black
Red
Green
M.C.
A.C.
White
Neutral
Motor
Black Black
White White
Capacitor
If the location is in the middle between 2
joists, connect suspension bracket I and II
as shown below.
Suspension bracket II
260(10 1/4)
260(10 1/4)
Duct
Ceiling joist

2-Screws
Clamp plate
Ceiling joist
Fig. 21
Fig. 19
2-square knock-out
Secure the fan body to the adaptor by using one thumb screw
as shown in Fig.21
Insert fan body into ceiling as shown in Fig.20.
Remove the 2 square knock-out carefully from surface
of the frame by screw driver ( Fig.19) .And remove the
bracket cover on the other side of the frame body.
Replace with clamp plates(accessories) and secure the fan
body on ceiling board with 2 screws from inside of the frame.
(Fig.22)
INSTALLATION III (IN EXISTING CONSTRUCTION) CONTINUED
Hand driver
Fan body
Adapter slots
Claws
Fig. 20
Ceiling
Body
Fan body
Ceiling
Fig. 22

Grille
Glove Grille
Slot Mounting
spring
CAUTION:
Disconnect power source before working on unit. Routine
maintenance must be done every year.
WARNING:
MAINTENANCE
MAINTENANCE
Mount the fan body with thumb screw (on the right side of
bottom of the adaptor) as shown in Fig.7 of page 7.
Fig. 24
Screw driver Ceiling
Blower
Ceiling
Fan body
Fig. 23
Screw
INSTALLATION III (IN EXISTING CONSTRUCTION) CONTINUED
Connect plug connector to receptacle.(Fig.8 of page 7.)
Secure blower to fan body with screws that were loosen
before.(Fig.24)
Insert the blower into the fan body.(Fig.23)
Insert mounting springs into slots as shown and mount grille to
fan body.(Fig.11 of page 8.)
1. Never use petrol, benzene, thinner or any other such
chemicals for cleaning the ventilating fan.
2. Do not allow water to enter motor.
oO
3. Do not immerse resin parts in water over 60 C (140 F).
1. Remove grille. (Squeeze mounting spring and pull down
carefully.) ( Fig.25)
2. Wash and clean grille.(Use non-abrasive kitchen detergent,
wipe dry with new cloth.) (Fig.26)
Fig. 25
Fig. 26

Fig. 28
Fig. 27
Cleaner
Warning Concerning Removal of Covers.
PRODUCT SERVICE
PRODUCT SERVICE
MAINTENANCE CONTINUED
MAINTENANCE CONTINUED
3. Remove dust and dirt on fan body using a vacuum cleaner.
( Fig.27)
4. Using a cloth dampened with mild dish soap,remove
any dirt from fan body. Wipe dry with new choth.( Fig.28 )
5. Replace grille.
The unit should be serviced by qualiffied technicians only.No service information is provided for customers. Your product
is designed and manufactured to ensure a minimum of maintenance. However, should your unit ever require service, a
nationwide system of factory service centers and AUTHORIZED INDEPENDENT SERVICE CENTERS is maintained to
support your product's warranty.
(In the U.S.A.,call 1-866-292-7292 to locate the Panasonic Authorized Service Center nearest you.)

PANASONIC CONSUMER ELECTRONICS COMPANY
One Panasonic Way, Secaucus, NJ, 07094
PANASONIC CANADA INC.
5770 Ambler Drive, Mississauga, ON L4W 2T3
