Panasonic EY37C1 User manual

© Panasonic Eco Solutions Power Tools Co., Ltd.
2012. All rights reserved. Unauthorized copying and
distribution is a violation of law.
Order Number PTD1208X03CE
Flashlight
Model No. EY37C1
Europe
Oceania
TABLE OF CONTENTS
PAGE PAGE
1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Troubleshooting Guide ----------------------------------------- 3
4 Disassembly and Assembly Instructions ---------------- 5
5 Schematic Diagram ---------------------------------------------- 6
6 Exploded View and Replacement Parts List ------------ 7

2
1Warning
Caution:
• Pb free solder has a higher melting point that standard solder; Typically the melting point is 50 - 70°F (30 - 40°C) higher. Please
use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder-
ing iron, please be careful not to heat too long.
• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
2 Specifications

3
3 Troubleshooting Guide
3.1. Troubleshooting Guide

4
3.2. Trial Operation (After Checking Troubleshooting Guide)

5
4 Disassembly and Assembly Instructions
4.1. Replace of a xenon bulb of chargeable light for construction
* Xenon bulb of chargeable light for construction is abbreviated to xenon bulb below.
Removing a xenon bulb by force might cause break of a socket.
Please follow things below for replace of a xenon bulb.
• Be sure to remove a battery pack before replace.
• Be sure to use a genuine xenon bulb.
• Attach a xenon bulb and a head cover firmly.

6
4.2. Caution for assembly
5 Schematic Diagram

Model No. : EY37C1 Exploded View
7
6 Exploded View and Replacement Parts List

Model No. : EY37C1 Parts List
Safety
Ref.
No. Part No. Part Name & Description Q'ty Remarks
1 WEY37C1L4018 HEAD COVER 1
2 WEY37C1X7778 XENON BULB 2 (12V,0.7A) (2PCS/PR)
3 WEY37C1L4008 BODY W/O BULB & HEAD COVER 1
4 WEY3740L0338 LOCKING SCREW 1
5 WEY3794K0227 SHOULDER STRAP 1
- WEY37C1L8108 OPERATING INSTRUCTIONS 1
8
