Panasonic CY-BT100N User manual

ORDER NO. ACED051235C8
AUTOMOTIVE AFTERMARKET
CY-BT100N
Hands-Free Kit featuring Bluetooth technology
SPECIFICATIONS
Specifications*
1

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
(Supplied from a head unit or a
Expansion Module)
Current Consumption Less than 1.0A
Communication Frequency 2402 MHz - 2480 MHz
Number of channels 79 channels
Channel width 1.0 Mhz
Communication mode Ferquency hopped spread
spectrum communication
RF Output -1 dBm (0.8 mW)
Service area Within 10 m
Applicable Bluetooth
version
Ver. 1.2
Microphone Impedance 600
Dimensions (W×H×D)** 72.8×102×24mm
(Excluding Switch Unit and
Microphone)
Weight** 0.5 kg
(Excluding Switch Unit and
Microphone)
* Specifications and the design are subject to possible
modification without notice due to improvements.
** Dimensions and Weight shown are approximate.
** Above specifications comply with EIA standards.
2005 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
2

1. ABOUT LEAD FREE SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF stamp on the PCB.
Caution :
- Pb free solder has a higher melting point than standard solder; Typically
the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering
iron with temperature control and adjust it to 700 ± 20°F (370 ± 10°C). In
case of using high temperature soldering iron, please be careful not to
heat too long.
- Pb free solder will tend to splash when heated too high (about 1100°F/
600°C)
- This lead free solder will be used for the products after serial No.
1,000,001.
2. FEATUERS
- Connection between this unit and head unit allows users to “receive
calls”, “call back”,and “reject incoming calls” without direct operation
of Bluetooth-ready mobile phone.
3. DIMENSIONS
3

4. WIRING CONNECTION
5. TERMINALS DESCRIPTION
4

IC601 : C2CBFD000155
Pin
No.
Port Description (I/O) (V)
1 P37/TXD10/
RXD1
Serial
communications
I 3.2
2 CNVss Connects by
resistance GND
- 0
3 RESET System reset input - 3.2
4 Xout/P47 Crystal oscillator
clock
- 1.5
5 Vss Digital GND PWR 0
6 Xin/P46 Crystal oscillator
clock
- 1.5
7 Vcc 3.3V in digital power
supply
PWR 3.2
8 P17/INT1/
CNTR0
Connects by
resistance GND
I 0
9 P16/CLK0 LED1 drive O 3.2
10 P15/RXD0 Serial
communications
between BT.
I 3.2
11 P14/TXD0 Serial
communications
between BT.
O 3.2
12 P13/KI3/
AN11
BT MODUDE RTS I 0
13 P12/KI2/
AN10/CMP02
BT MODUDE CTS O 0
14 P11/KI1/AN9/
CMP01
BT MODULE BOOT
MODE setting
O 3.2
15 P10/KI0/AN8/
CMP00
BT MODULE RESET O 3.2
16 P45/INT0 BT MODULE RF TEST O 3.2
17 P33/INT3/
TCIN
ALLION MODE O 0
18 P32/INT2/
CNTR1/
CMP12
No Connection - -
19 AVCC/VREF 3.3V in analog power
supply
PWR 3.2
20 P31/TZOUT/
CMP11
AF MUTE O 3.2
21 AVSS Analog GND PWR 0
22 P30/CNTR0/
CMP10
RESET O 0
23 IVCC Connects by
capacitor GND
O 2.4
24 P07/AN0 NC I 0
25 P06/AN1 NC I 0
5

Pin
No.
Port Description (I/O) (V)
26 P05/AN2 HUB CONT control
input
I 3.2
27 P04/AN3 HUB EVENT output O 0
28 MODE - - 3.2
29 P03/AN4 NC I 0
30 P02/AN5 KEY2 input I 3.2
31 P01/AN6 KEY1 input I 3.2
32 P00/AN7/
TXD11
Serial
communications
O 3.2
6. IC BLOCK DIAGRAM
6.1. Main Block
IC201 : C1BB00000860
IC301 : C1AB00002417
IC502 : C0JBAR000233
6

IC603, IC606 : C0JBAB000824
IC605 : C0JBAB000835
7

IC703 : C0DBAMH00013
7. REPLACEMENT PARTS LIST
Notes :
1. Be sure to make your orders of replacement parts according to this list.
2. Important safety notice: Components, identified by mark have
special characteristics important for safety. When replacing any of
these components, use only manufacturer's specified parts.
3. Location keys in the remarks column indicates the general location of
the parts shown in the exploded drawing, as in a road map.
4. The marking (RTL) indicates that Retention Time is limited for this item.
After the discontinuation of assembly in production, the item will
continue to be available for a specific period of time. The retention
8

period of availability is dependent on the type of assembly, and in
accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
- Order intake period is basically six months after the first shipment.
5. “T” marks in remarks colum are indicated supply parts of PTW.
9

Ref. No. Part No. Part Name & Description Remarks
[E-4C300] Main Block
IC's AND TRANSISTER
IC201 C1BB00000860 IC T
IC301 C1AB00002417 IC T
IC302 C0JBAE000333 IC T
IC501 C5ZBZ0000016 IC T
IC502 C0JBAR000233 IC T
IC601 C2CBFD000155 IC T
IC602 C0JBAR000233 IC T
IC603 C0JBAB000824 IC T
IC604 C0JBAZ002262 IC T
IC605 C0JBAB000835 IC T
IC606 C0JBAB000824 IC T
IC607 C0EBF0000467 IC T
IC703 C0DBAMH00013 IC T
Q251 B1GDCFNN0007 Transistor T
Q252 B1GBHBEA0003 Transistor T
Q352 B1GBHBEA0003 Transistor T
Q403 B1GDCFJJ0008 Transistor T
Q501 B1GBCFNN0009 Transistor T
Q601 B1GBCFNN0009 Transistor T
Q701 2SD0601AHL Transistor T
Q702 B1GBJCEJ0001 Transistor T
Q703 B1GBCFNN0009 Transistor T
Q705 B1GBCFNN0009 Transistor T
DIODEs
D201 B0ADCJ000025 Diode T
D602 B0BC5R6A0068 Zener Diode T
D603 B0BC5R6A0068 Zener Diode T
D604 MA2J72900L Diode T
D605 MA2J72900L Diode T
D606 B0BC4R700006 Diode T
D607 B0BC4R700006 Diode T
D608 B0BC4R700006 Diode T
D701 B0ECKP000002 Diode T
D702 B0JCPE000003 Diode T
D703 B0BC2R0A0068 Zener Diode T
D704 MA2J72900L Diode T
D705 MA2J72900L Diode T
D706 B0BC5R6A0068 Zener Diode T
CAPACITORs
C201 F1H0J1050010 Chip, 1 F 6.3WV T
Ref. No. Part No. Part Name & Description Remarks
C202 F1J0J106A038 Chip, 10 F 6.3WV T
C203 F1J0J106A038 Chip, 10 F 6.3WV T
C204 F1H0J1050010 Chip, 1 F 6.3WV T
C205 F1H1C104A107 Chip, 0.1 F 16WV T
C206 F1J0J106A038 Chip, 10 F 6.3WV T
C207 F1H1H102A842 Chip, 0.001 F 50WV T
C251 F1J0J4750003 Chip, 4.7 F 6.3WV T
C262 F1H1C104A107 Chip, 0.1 F 16WV T
C301 F1H1C104A107 Chip, 0.1 F 16WV T
C302 F1K0J476A003 47 F 6.3WV T
C303 F1H1C104A107 Chip, 0.1 F 16WV T
C304 F1H1H101A737 Chip, 100PF 50WV T
C305 F1H0J1050010 Chip, 1 F 6.3WV T
C306 F1H1H101A737 Chip, 100PF 50WV T
C307 F1H1H101A737 Chip, 100PF 50WV T
C308 F1K1A3350001 3.3 F 10WV T
C309 F1K1A3350001 3.3 F 10WV T
C310 F1K1A3350001 3.3 F 10WV T
C311 F1H1C104A107 Chip, 0.1 F 16WV T
C312 F1H0J1050010 Chip, 1 F 6.3WV T
C313 F1H0J1050010 Chip, 1 F 6.3WV T
C351 F1J0J4750003 Chip, 4.7 F 6.3WV T
C402 F1H0J2250007 Chip, 2.2 F 6.3WV T
C502 F1H1C104A107 Chip, 0.1 F 16WV T
C503 F1K0J476A003 47 F 6.3WV T
C504 F1H1C104A107 Chip, 0.1 F 16WV T
C508 F1H1C104A107 Chip, 0.1 F 16WV T
C511 F1H1HR50A260 0.5 F 50WV T
C601 F1H1C104A107 Chip, 0.1 F 16WV T
C602 F1H1C104A107 Chip, 0.1 F 16WV T
C603 F1K0J476A003 47 F 6.3WV T
C604 F1H1C104A107 Chip, 0.1 F 16WV T
C605 F1H1C104A107 Chip, 0.1 F 16WV T
C606 F1H1E103A086 Chip, 0.01 F 25WV T
C607 F1H1E103A086 Chip, 0.01 F 25WV T
C608 F1H1C104A107 Chip, 0.1 F 16WV T
C609 F1H1C104A107 Chip, 0.1 F 16WV T
C610 F1H1C104A107 Chip, 0.1 F 16WV T
C611 F1H1C104A107 Chip, 0.1 F 16WV T
C612 F1H1C104A107 Chip, 0.1 F 16WV T
C613 F1H1E103A086 Chip, 0.01 F 25WV T
C614 F1H1E103A086 Chip, 0.01 F 25WV T
10

Ref. No. Part No. Part Name & Description Remarks
C701 EEEFK1C221P Electrolytic, 220PF 16WV T
C702 F1H1H472A842 Chip, 4700PF 50WV T
C703 F1H1C104A107 Chip, 0.1 F 16WV T
C704 F1J1C105A173 Chip, 1 F 16WV T
C705 EEEFC0J101P Electrolytic, 100PF 6.3WV T
C706 F1J1C105A173 Chip, 1 F 16WV T
C707 EEEFC1C470P Electrolytic, 47 F 16WV T
C708 F1J1C105A173 Chip, 1 F 16WV T
C709 F1J0J106A038 Chip, 10 F 6.3WV T
C711 F1J1C105A173 Chip, 1 F 16WV T
C712 EEEFC0J101P Electrolytic, 100PF 6.3WV T
C713 F1K0J1060017 Chip, 10 F 6.3WV T
C714 F1H1H102A842 Chip, 0.001 F 50WV T
C715 F1H1C104A107 Chip, 0.1 F 16WV T
RESISTORs
R201 D0GB101JA008 Chip, 100 T
R202 D0GB682JA008 Chip, 6.8k T
R203 D0GB392JA008 Chip, 3.9k T
R204 D0GB333JA008 Chip, 33k T
R205 D0GB103JA008 Chip, 10k T
R251 D0GB561JA008 Chip, 560 T
R252 D0GB473JA008 Chip, 47k T
R253 D0GBR00JA008 Chip, 0 T
R254 D0GBR00JA008 Chip, 0 T
R301 D0GB470JA008 Chip, 47 T
R302 D0GB393JA008 Chip, 39k T
R303 D0GB393JA008 Chip, 39k T
R304 D0GB103JA008 Chip, 10k T
R305 D0GB103JA008 Chip, 10k T
R306 D0GB243JA008 Chip, 24k T
R307 D0GB103JA008 Chip, 10k T
R308 D0GB243JA008 Chip, 24k T
R309 D0GB102JA008 Chip, 1k 1/10W T
R310 D0GB103JA008 Chip, 10k T
R351 D0GB561JA008 Chip, 560 T
R352 D0GB473JA008 Chip, 47k T
R353 D0GBR00JA008 Chip, 0 T
R354 D0GBR00JA008 Chip, 0 T
R401 D0GB562JA008 Chip, 5.6k T
R402 D0GB221JA008 Chip, 220 T
R501 D0GB472JA008 Chip, 4.7k T
R502 D0GB471JA008 Chip, 470 T
R503 D0GB472JA008 Chip, 4.7k T
R504 D0GB472JA008 Chip, 4.7k T
R505 D0GB472JA008 Chip, 4.7k T
Ref. No. Part No. Part Name & Description Remarks
R506 D0GB472JA008 Chip, 4.7k T
R507 D0GB472JA008 Chip, 4.7k T
R511 D0GB103JA008 Chip, 10k T
R601 D0GB103JA008 Chip, 10k T
R602 D0GB473JA008 Chip, 47k T
R603 D0GB473JA008 Chip, 47k T
R604 D0GB472JA008 Chip, 4.7k T
R605 D0GB473JA008 Chip, 47k T
R606 D0GB102JA008 Chip, 1k 1/10W T
R607 D0GB103JA008 Chip, 10k T
R608 D0GB473JA008 Chip, 47k T
R609 D0GB473JA008 Chip, 47k T
R610 D0GB102JA008 Chip, 1k 1/10W T
R611 D0GB102JA008 Chip, 1k 1/10W T
R612 D0GB473JA008 Chip, 47k T
R613 D0GB102JA008 Chip, 1k 1/10W T
R614 D0GB473JA008 Chip, 47k T
R615 D0GB101JA008 Chip, 100 T
R616 D0GB102JA008 Chip, 1k 1/10W T
R618 D0GB220JA008 Chip, 22 T
R619 D0GB220JA008 Chip, 22 T
R620 D0GB221JA008 Chip, 220 T
R621 D0GBR00JA008 Chip, 0 T
R622 D0GBR00JA008 Chip, 0 T
R623 D0GB472JA008 Chip, 4.7k T
R624 D0GBR00JA008 Chip, 0 T
R625 D0GB102JA008 Chip, 1k 1/10W T
R626 D0GB102JA008 Chip, 1k 1/10W T
R627 D0GB103JA008 Chip, 10k T
R628 D0GB103JA008 Chip, 10k T
R701 D0GN3R3JA005 Chip, 3.3 1/2W T
R702 D0GB473JA008 Chip, 47k T
R703 D0GB223JA008 Chip, 22k T
R704 D0GB513JA008 Chip, 51k T
R705 D0GB221JA008 Chip, 220 T
R706 D0GB154JA008 Chip, 150k T
NETWORK RESISTOR
RA501 D1H847040001 Network Resistor T
RA502 EXBV8V221JV Network Resistor T
RA601 EXBV8V473JV Network Resistor T
CONNECTORs
CN1 K1AB113B0002 13P Connector T
CN2 K1KB08AA0201 8P Connector T
CN3 K1CB108B0055 8P Connector T
CN4 K1QZB1AD0009 Jack T
11

Ref. No. Part No. Part Name & Description Remarks
JK1 K2HD103B0003 Jack T
FILTER
XL601 H2C184500002 Band pass Filter T
COILs
L501 J0JGC0000018 Coil T
L502 G1C100J00001 Coil T
L700 G1C220MA0077 Coil T
L701 G1C220MA0077 Coil T
L702 G1C100J00001 Coil T
L704 G1C101J00002 Coil T
L705 G1C221JA0036 Coil T
[E-4C301A] Switch Block
TRANSISTERs
Q2 2SD0601AHL Transister T
Q3 2SD0601AHL Transister T
Q4 2SD0601AHL Transister T
DIODEs
D2 B3AEB0000083 LED(Blue) T
D3 B3AAB0000252 LED(Red) T
D4 B3AEB0000083 LED(Blue) T
RESISTORs
R2 D0GF221JA017 Chip, 220 1/4W T
R3 D0GF271JA017 Chip, 270 1/4W T
R4 D0GF271JA017 Chip, 270 1/4W T
CONNECTOR
CN10 K1KA07BA0014 7P Connector T
SWITCHs
SW1 K0H1BA000445 Tact Switch T
SW2 K0H1BA000445 Tact Switch T
Accessories
PRINTINGs
YFM284C530ZA Operating Instructions T
COMPONENTs
ASMYSW100N Switch Unit (2m) T/RTL
L0FBBB000005 Microphone with Bracket (5m) T
YEAJ011812 System-up connecting cable (3m) T
YFX994C128ZA Double-sided Tape T
YFX994C129ZA Double-sided Tape T
YEPFZ8466 Cable Clamp T
Ref. No. Part No. Part Name & Description Remarks
Mechanical Parts
MISCELLANEOUS
ANT1 N1LBGJ000001 Anntena T
CP10 YEAJ071813 Cable (BT100) T
1 YFE134C526ZA Button T
2 YFC034C036ZA Top Cover T
3 YFX074C017ZA Cord Clamp T
4 AAPB301A0 SW w/Component T/RTL
5 YFX014C096ZA Indicator T
6 YFC034C037ZA Bottom Cover T
10 YFC034C033ZA Upper Case T
11 YFX214C419ZA CN Bracket T
12 AAPB300A0 Main w/Component T/RTL
14 YFC034C031ZA Bottom Case T
15 XTB2+8GFZ Screw T
16 XTB2+6GFZ Screw T
12

8. EXPLODED VIEW
9. WIRING DIAGRAM
9.1. Main Block (Top View)
13

9.2. Main Block (Bottom View)
10. SCHEMATIC DIAGRAM-1
10.1. SW Block
11. SCHEMATIC DIAGRAM-2 & BLOCK DIAGRAM
11.1. Main Block
11.2. BLOCK DIAGRAM
12. SCHEMATIC DIAGRAM for Printing with A4 Size
12.1. Main Block (Left Side)
12.2. Main Block (Right Side)
14

CY-BT100N
13

11 SCHEMATIC DIAGRAM-2 & BLOCK DIAGRAM
11.1. Main Block
13
