Panasonic KX-PD703UD User manual

Thank you for purchasing a Panasonic product.
●
This guide explains some basic features and operations, but not all of them. For further details,
see the Japanese operating instructions.
●This product is designed for use in Japan.
Panasonic cannot provide service for this product if used outside Japan.
●Any details given in this guide are subject to change without notice.
Table of Contents
Parts Descriptions .....................................................................................................................2
Basic Operations .......................................................................................................................3
Model No. KX-PD703UD KX-PD703SL
KX-PD703UW KX-PD703SW
Base unit
(KX-PD703)
Cordless handset
(KX-FKD602)
Base unit
(KX-PD703)
Cordless handset
(KX-FKD603)
●KX-PD703UD/KX-PD703SL includes 1 cordless handset and 1 base unit.
●KX-PD703UW/KX-PD703SW includes 2 cordless handsets and 1 base unit.
Quick Reference Guide
Facsimile
KX-PD703UD/KX-PD703UW KX-PD703SL/KX-PD703SW

2
かんたん発信
1
8
9
10111213141516
234
5
6
7
1728
33
32
18
30
29
19
20
21
23
24
25
22
26
27
Backside View
31
Cordless handset

Heat sensor
(KX-PD703SL, KX-PD703SW only)

Liquid crystal display

One-touch Dial buttons

Talk button

Off button

Numeral buttons

Flash/Clear button

Microphone

Redial button

Tone button (to switch to DTMF tone)

Hold/Intercom button

Earpiece

Function/Set button

Search phonebook button

Volume control button
Select button

Battery cover

Speaker
Touch panel
Phone book
Playback
Fax/Copy
Auto Answer button & indicator
Caller ID Log/Fax Print button &
indicator
Monitor button
Stop button
Speed Dialer button

Numeral/Character buttons

Tone button (to switch to DTMF tone)

Volume control

Intercom

Voice Memo

Redial

Function
Base unit
Parts Descriptions

3
After playing back the messages, touch 
(Yes:

) twice to erase the messages or touch
 (No:

) to keep the messages.
*Up to 50 messages can be recorded for approx.
12 minutes in total.
■To hear recorded messages while away from
home (Remote control)
Preparation before you leave home
Store a remote control number.
With the handset placed on the base unit, touch

(Function:

) press
󱯌󱯌󱯘
.
Enter the desired 4-digit number. Touch
 (Set:

), then press  
(Stop: ). When you leave home, press

to turn on the indicator.
To hear messages
Dial your home phone number. While the
outgoing message is played back, enter your
remote control number.
Announcement. Press 4. You will hear
recorded messages if any.
NOTE
●
This operation can be made only from
telephones which can send DTMF signals.
Cordless handset
■To make a call
Lift the cordless handset from the charger.
Dial the phone number (

). Talk. To
end the call, place the cordless handset on the
charger or press(Off:

).
■To receive a call
When the phone rings, lift the cordless handset
from the charger. Talk. To end the call,
place the cordless handset on the charger or
press.
●When:
– document reception is required,
– a fax calling tone (slow beep) is heard, or
– no sound is heard,
Press
【機能】
(Function:

)
▼ ▲
(

)
to select“ ファク ス 受 信 ” (Set:

)
.
■To place the current call on hold
Press(Hold:

) during a call.
■To retrieve the held call
Press.
●The number after the button shows the location of
the button described in the previous page.
Base unit
■To make a call
Lift the handset. Dial the phone number (

).
Talk.
■To receive a call
When the phone rings, lift the handset. Talk.
●When:
– document reception is required,
– a fax calling tone (slow beep) is heard, or
– no sound is heard,
Touch  (Flash/Fax:

)
 (Fax).
■To place the current call on hold
Touch    (Hold/Intercom:

) during a
call.
(You can place the handset on the base unit.)
■To retrieve the held call
●
If you have returned the handset on the base
unit, lift the handset.
●
If you have not returned the handset on the
base unit, touch  (Hold:

).
■
To transfer the held call to the cordless handset
Touch    (Hold/Intercom:

)
 (Intercom:

) during a call. When
you use multiple cordless handsets, press
󱯎
-
󱯘
(Intercom No.). Place the handset on
the base unit when the other party answers.
■
To use TAM (Telephone Answering Machine)
When you leave home, press(Auto
answer: 
) to turn on the indicator.
( To deactivate, pressagain to turn off the
indicator.)
When receiving a call while TAM is activated,
it answers the call automatically in Japanese,
and
records the incoming messages.
Then, theindicator starts flashing.
When you return home, pressto play
back the messages.
Theindicator turns off and the answering
mode is deactivated.
After playing back the messages, touch 
(Yes:

) twice to erase the messages or touch
 (No:

) to keep the messages.
To play back all messages while TAM is
deactivated, touch  (Playback:

)  (Playback all).
Basic Operations

PNQP1132ZA D0714KM0
Panasonic System Networks Co., Ltd. 2014
C
■To transfer the held call to the base unit
Press during a call. ( When you use
multiple cordless handsets, press
󱯌
.)
Place the cordless handset on the charger, or press
when the other party answers.
■To transfer the held call to another cordless handset
Press during a call. Press
󱯎
-
󱯘
(Intercom No.). Place the cordless handset on the
charger, or presswhen the other party answers.
Sending faxes/Copying documents
■Sending faxes
Touch    (Fax/Copy: 
), then touch
 (Fax). Insert the document.
Dial the fax number. Touch   (Fax:

).
■Copying documents
Insert the recording paper. Touch   
(Fax/Copy: 
), then touch  (Copy).
Insert the document. Touch  (Copy:

).
■Installing document
■Installing recording paper
Recording paper
●Printing side is
on the back.
1
Open the recording
paper tray, and set up the
recording paper stands.
2
Insert the recording paper
into the recording paper
tray. (Up to 15 sheets)
2
Adjust the width of the
document guides to the
size of the document.
1
Open the recording
paper tray, and set up the
recording paper stands.
3
Insert the document (up to
5 pages) FACE UP until a
single beep is heard.
