Panasonic KX-TGA830E User manual

Installation Manual
Additional Digital Cordless Handset
Model No. KX-TGA830E
Thank you for purchasing a Panasonic digital cordless phone.
Please read this installation manual before using the unit and
save it for future reference.
This unit is an additional handset for use with the following
series of Panasonic Digital Cordless Phone: KX-TG8321
You must register this handset with your base unit before it
can be used. This installation manual describes only the
steps needed to register and begin using the handset. Please
read the base unit’s operating instructions for further details.
Charge the batteries for about 7 hours before initial use.
TGA830E(e).fm Page 1 Thursday, February 14, 2008 10:50 AM

2 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
Supplied accessories
*1 Please read the base unit’s operating instructions for replacement
battery information.
*2 The handset cover comes attached to the handset.
Note:
LPlease read the base unit’s operating instructions for additional/
replacement accessories.
LThis equipment is designed for use in the UK and Republic of Ireland.
LIn the event of problems, you should contact your equipment supplier
in the first instance.
Sales and support information
Customer Care Centre
LFor customers within the UK: 0844 844 3898
LFor customers within the Republic of Ireland: 01289 8333
LVisit our website for product information: www.panasonic.co.uk
LE-mail: customer[email protected]
Direct Sales at Panasonic UK
LOrder accessory and consumable items for your product with ease and
confidence by phoning our Customer Care Centre Monday - Thursday
9:00am - 5:30pm, Friday 9:30am - 5:30pm (Excluding public holidays).
LOr go on line through our Internet Accessory ordering application at
www.panasonic.co.uk
Accessory item/Part number Quantity
Charger 1
AC adaptor for charger/PQLV209EU (PQLV209E) 1
Rechargeable batteries*1 2
Handset cover*2 1
Belt clip 1
TGA830E(e).fm Page 2 Thursday, February 14, 2008 10:50 AM

3 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
LMost major credit and debit cards accepted.
LAll enquiries transactions and distribution facilities are provided
directly by Panasonic UK Ltd.
LIt couldn’t be simpler!
LAlso available through our Internet is direct shopping for a wide range
of finished products, take a browse on our website for further details.
Connection/Wall mounting
Note:
LUse only the supplied Panasonic AC adaptor PQLV209E.
LThe AC adaptor must remain connected at all times. (It is normal for
the adaptor to feel warm during use.)
Battery installation/Battery charge
Important:
LUse the supplied rechargeable batteries (Part No. HHR-55AAAB).
LWhen installing the batteries:
– Wipe the battery ends (S, T) with a dry cloth.
– Avoid touching the battery ends (S, T) or the unit contacts.
– Confirm correct polarities (S, T).
LWhen replacing the batteries:
– USE ONLY rechargeable Ni-MH batteries AAA (R03) size.
– Do NOT use Alkaline/Manganese/Ni-Cd batteries.
(220-240 V AC,
50 Hz)
Hooks
25.4 mm
Screws
TGA830E(e).fm Page 3 Thursday, February 14, 2008 10:50 AM

4 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
– We recommend using the Panasonic rechargeable batteries noted
in the base unit’s operating instructions for replacement battery
information.
1Firmly press the notch on the handset cover and slide it in the
direction of the arrow.
2Insert the batteries negative (T) end first. Close the handset cover.
3Place the handset on the charger for about 7 hours before initial
use.
Note:
LThe handset display may show “Please Wait...”when the
handset is placed on the charger if it is not registered to the base unit.
LIf the batteries are fully charged, but the operating time seems to be
shorter, clean the battery ends (S, T) and the charge contacts with a
dry cloth and charge again.
Registering the handset to the base unit
Ensure that the handset is switched on. If it is not on, press and hold
{ih} for few seconds to turn the handset on.
1Handset:
Lift the handset and press {ih}.
2Base unit:
Press and hold {x} for about 5 seconds, until the registration tone
sounds.
LIf all registered handsets start ringing, press the same button to
stop. Then repeat this step.
TGA830E(e).fm Page 4 Thursday, February 14, 2008 10:50 AM

5 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
3Handset:
Place the handset on the base unit.
LContinue the operation even when the handset display shows
“Please Wait...”.
4With the handset still on the base unit, wait until a confirmation tone
sounds and wstops flashing.
Note:
LIf an error tone sounds, or if wis still flashing, register the handset
according to the base unit’s operating instructions.
For your safety
To prevent severe injury and loss of life/property, read this section
carefully before using the product to ensure proper and safe operation of
your product.
WARNING
Power connection
LCompletely insert the AC adaptor/power plug into the power outlet.
Failure to do so may cause electric shock and/or excessive heat
resulting in a fire.
LRegularly remove any dust, etc. from the AC adaptor/power plug by
pulling it from the power outlet, then wiping with a dry cloth.
Accumulated dust may cause an insulation defect from moisture, etc.
resulting in a fire.
LUnplug the product from power outlets if it emits smoke, an abnormal
smell, or makes an unusual noise. These conditions can cause fire or
electric shock. Confirm that smoke has stopped emitting and contact
an authorised service centre.
TGA830E(e).fm Page 5 Thursday, February 14, 2008 10:50 AM

6 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
Installation
LTo prevent the risk of fire or electrical shock, do not expose the product
to rain or any type of moisture.
LDo not place or use this product near automatically controlled devices
such as automatic doors and fire alarms. Radio waves emitted from
this product may cause such devices to malfunction resulting in an
accident.
CAUTION
Installation and relocation
LThe AC adaptor is used as the main disconnect device. Ensure that
the AC outlet is installed near the product and is easily accessible.
Battery
LWe recommend using the supplied batteries or additional/replacement
batteries noted in the base unit's operating instructions for
replacement battery information. USE ONLY rechargeable Ni-MH
batteries AAA (R03) size.
LDo not mix old and new batteries.
LDo not open or mutilate the batteries. Released electrolyte from the
batteries is corrosive and may cause burns or injury to the eyes or skin.
The electrolyte may be toxic if swallowed.
LExercise care when handling the batteries. Do not allow conductive
materials such as rings, bracelets or keys to touch the batteries,
otherwise a short circuit may cause the batteries and/or the conductive
material to overheat and cause burns.
LCharge the batteries provided with or identified for use with this
product only, in accordance with the instructions and limitations
specified in this manual.
LOnly use a compatible base unit (or charger) to charge the batteries.
Do not tamper with the base unit (or charger). Failure to follow these
instructions may cause the batteries to swell or explode.
TGA830E(e).fm Page 6 Thursday, February 14, 2008 10:50 AM

7 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
Other information
LOperating the product near electrical appliances may cause
interference. Move away from the electrical appliances.
LUse only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a fire. They may explode. Check with local
codes for possible special disposal instructions.
Routine care
LWipe the outer surface of the product with a soft moist cloth.
LDo not use benzine, thinner, or any abrasive powder.
Notice for product disposal, transfer, or return
LThis product can store your private/confidential information. To protect
your privacy/confidentiality, we recommend that you erase the
information such as phonebook or caller list entries from the memory
before you dispose of, transfer, or return the product.
Information on Disposal for Users of Waste Electrical & Electronic
Equipment (private households)
This symbol on the products and/or accompanying documents
means that used electrical and electronic products should not
be mixed with general household waste.
For proper treatment, recovery and recycling, please take
these products to designated collection points, where they will
be accepted on a free of charge basis. Alternatively, in some countries
you may be able to return your products to your local retailer upon the
purchase of an equivalent new product.
Disposing of this product correctly will help to save valuable resources
and prevent any potential negative effects on human health and the
environment which could otherwise arise from inappropriate waste
handling. Please contact your local authority for further details of your
nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in
accordance with national legislation.
TGA830E(e).fm Page 7 Thursday, February 14, 2008 10:50 AM

8 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact
your dealer or supplier for further information.
Information on Disposal in other Countries outside the European
Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities
or dealer and ask for the correct method of disposal.
Declaration of Conformity:
LPanasonic Communications Co., Ltd. declares that this equipment is in
compliance with the essential requirements and other relevant
provisions of Radio & Telecommunications Terminal Equipment
(R&TTE) Directive 1999/5/EC.
Declarations of Conformity for the relevant Panasonic products
described in this manual are available for download by visiting:
http://www.doc.panasonic.de
Contact to Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
TGA830E(e).fm Page 8 Thursday, February 14, 2008 10:50 AM

9 Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333
Notes
TGA830E(e).fm Page 9 Thursday, February 14, 2008 10:50 AM
