Panasonic FZ-VKBQ11 Series User manual

OPERATING INSTRUCTIONS
Detachable Keyboard
Model No. FZ-VKBQ11 Series
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before using this product, and save this manual for future use.
●Before using the product, read this Operating Instructions and the relevant portions of the computer’s Operat-
ing Instructions - Reference Manual carefully.
Regulatory Information
For U.S.A.
Federal Communications Commission Radio
Frequency Interference Statement
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the Panasonic Service Center or an
experienced radio/TV technician for help.
Warning
To assure continued compliance, use only shielded
interface cables when connecting to a computer or
peripheral. Also, any changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
CD0117-0
DHQW1139YA/X1
© Panasonic Corporation 2017
Printed in Japan
Safety Precautions
To reduce the risk of injury, loss of life, electric shock,
re, malfunction, and damage to equipment or prop-
erty, always observe the following safety precautions.
Explanation of symbol word panels
The following symbol word panels are used to classify
and describe the level of hazard, injury, and property
damage caused when the denotation is disregarded
and improper use is performed.
CAUTION
Denotes a hazard that could result in minor
injury.
The following symbol are used to classify and
describe the type of instructions to be observed.
This symbol is used to alert users to a spe-
cic operating procedure that must not be
performed.
This symbol is used to alert users to a
specic operating procedure that must be
followed in order to operate the unit safety.
CAUTION
Fire or electric shock may result.
When Carrying the Computer, At-
tach the Computer To the Detachable
Keyboard Tightly Until Orange-colored
Signs (èpage 3) Near the Lock Lever
And Release Lever Are Concealed.

This device is Class B confirmed to comply with Part
15 of FCC Rules when used with Panasonic Notebook
Computer.
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza
Newark, NJ 07102
Support Contact:
http://business.panasonic.com/support-
computerstablets
For Canada
Canadian ICES-003
CAN ICES-3(B) / NMB-3(B)
7-M-2
For Europe
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this
Detachable Keyboard is in compliance with
the essential requirements and other relevant
provisions of EU Council Directives.”
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
18-E-0
Disposal of Old Equipment and Batteries Only for
European Union and countries with recycling systems
These symbols on the products, packaging,
and/or accompanying documents mean that
used electrical and electronic products and
batteries must not be mixed with general
household waste. For proper treatment,
recovery and recycling of old products and
batteries, please take them to applicable
collection points, in accordance with your
national legislation.
By disposing of them correctly, you will help
to save valuable resources and prevent any
potential negative effects on human health
and the environment.
For more information about collection
and recycling, please contact your local
municipality. Penalties may be applicable
for incorrect disposal of this waste, in
accordance with national legislation.
Note for the battery symbol (bottom symbol):
This symbol might be used in combination
with a chemical symbol. In this case it
complies with the requirement set by the
Directive for the chemical involved.
36-E-1
For India
Declaration of Conformity with the requirements of the
e-waste (Management and Handling) Rules, 2011.
(adopted by Notification S.O.1035(E) of Ministry of
Environment and Forests)
The Product is in conformity with the requirements of
Rule 13 of the e-waste Rules.
The content of hazardous substance with the
exemption of the applications listed in SCHEDULE II
of the e-waste Rules:
1. Lead (Pb) - not over 0.1% by weight;
2. Cadmium (Cd) - not over 0.01% by weight;
3. Mercury (Hg) - not over 0.1% by weight;
4. Hexavalent chromium (Cr6+) - not over 0.1% by
weight;
5. Polybrominated biphenyls (PBBs) - not over 0.1%
by weight;
6. Polybrominated diphenyl ethers (PBDEs) - not over
0.1% by weight.
For the purpose of recycling to facilitate
effective utilization of resources, please
return this product to a
nearby authorized collection center,
registered dismantler or recycler, or
Panasonic service center when
disposing of this product.
Please see the Panasonic website for further
information on collection centers, etc.
http://www.panasonic.com/in/corporate/sustainability/
panasonic-india-i-recycle-program.html
Service helpline: 1800 103 1333 or 1800 108 1333
2

Connecting/Disconnecting the Computer
Connecting
Connect the Detachable Keyboard to the computer
following the steps below.
AAlign the Connect Guide hole (D) of the
computer with the Connect Guide (A) of the
Detachable Keyboard.
C
A
B
Orange-colored
CAUTION
• Do not touch the expansion bus connector
(E) of the computer.
BInsert the computer from above the Detachable
Keyboard and push the upper center of the
computer all the way in.
CPush the Release Lever (B) of the Detachable
Keyboard in the direction of the arrow until the
orange-colored part is completely hidden.
DPush the Lock Lever (C) of the Detachable
Keyboard in the direction of the arrow to lock
until the orange-colored part is completely
hidden.
Disconnecting
APush the Lock Lever (C) of the Detachable
Keyboard in the direction of the arrow until the
orange-colored part completely appears.
BPush the Release Lever (B) of the Detachable
Keyboard in the direction of the arrow to
unlock until the orange-colored part completely
appears.
CPush the lever in and lift the computer up.
Specications
Item Description
Number of Keys 87 keys
Pointing Device Touchpad
LED Caps lock, Num lock, Scroll
lock
ED D
3

Panasonic Corporation
Osaka, Japan
Panasonic System Communications Company of North America
Two Riverfront Plaza
Newark, NJ 07102
Panasonic Canada Inc.
5770 Ambler Drive Mississauga,
Ontario L4W 2T3
Importer’s name & address pursuant to the EU legislation
Panasonic System Communications Company Europe, Panasonic Marketing Europe GmbH
Hagenauer Straße 43
65203 Wiesbaden
Germany
Web Site : http://panasonic.net/avc/pc/
