Panasonic SR-TML500 User manual

Order No. PAPTH140402CE
Service Manual
Multi-Cooker
SR-TML500
SR-TML510
SR-TMS520
© Panasonic Appliances (Thailand) Co., Ltd. 2014.
All rights reserved. Unauthorized copying and
distribution is a violation of law.
There are special components used in this equipment which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that
these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do
not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
The service information is designed for experienced repair technicians only and is not designed for use by the general
public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting
to service a product. Products powered by electricity should be serviced or repaired only by experienced professional
technicians. Any attempt to service or repair the product or products dealt within this service information by anyone
else could result in serious injury or death.
WARNING
Destination
Russia / Ukraine / Kazakhstan
Product Colour
Black (BO)
Silver (HS)
Dark Silver (HL)

- 2 -
CONTENT
Page
3
4
5
6 - 7
8
9
9
10
11
11
12
13
13
14
15
16 - 17
1. Specification
2. Schematic Diagram
2.1 Wiring Diagram
2.2 Circuit Diagram
3. Troubleshooting Guide
3.1 Table 1
3.2 Table 2
4. Testing Procedure
4.1 Bubbling Test
4.2 Evaporation Test
4.3 Heat reserving Test
5. Disassembly
5.1 Hinge cover removal
5.2 Inner enclosure and upper frame removal
5.3 Control unit A
5.4 Cast heater and Thermostat Ass’y
5.5 Side heater
6. Parts Exploded View and Replacement Parts List
6.1 Parts Exploded View : Body
6.2 Parts Exploded View : Packing
6.3 Replacement Parts List
SR-TML500 / SR-TML510 / SR-TMS520

- 3 -
1. SPECIFICATION
MODEL
Countries
Power Supply
* For power cord replacement and product repairing, please contact the authorized service center of Panasonic.
* The design and specifications are subjected to change without prior notice.
SR-TML500 SR-TML510
Russia, Ukraine, Kazakhstan
220V / 50Hz / SH-3
Colour Name SilverDark Silver Black
HL BO
Measuring cup, Yogurt cup,
Steam basket assy,
Pan lid, Porridge scoop
Colour Code HS
Body Material Steel / Pre-coating
Pan Material Aluminium / Non stick coating
Power Consumption Cooking
Warming
Cooking Capacity Milk Porridge
Pilaf
Buckwheat
Yogurt
Baking
Fry
Stew / Soup / Compote
Holodetz / Stuffed /
Confiteur
670W
108W
1 ~ 2 cups
Warming Capacity
2 ~ 3 cups
2 ~ 8 cups
600 g.
900 g.
1.2 Kg.
4.0 L
Steam / Permeni
Plain Rice
4.0 L
Re-heat 1.0 L
Express 4.0 L
3 ~ 10 cups
Cooked rice warming Temperature 71°C ~ 79°C
Thermal fuse Specification 172°C 250V / 10A
Keep Warm (in Buckwheat function) 12 Hours
Weight (Approx.) 3.3 Kgs.
Power Cord (Approx.) 1.0 m.
Accessories Measuring cup, Steam basket assy
TheProduct Dimension
(Width x Depth x Height)
276 x 275 x 274 (mm)
Temperature Detector Sensor thermistor
SR-TMS520
SR-TML500 / SR-TML510 / SR-TMS520

- 4 -
2. SCHEMATIC DIAGRAM
2.1 Wiring Diagram
Glass tape size 40 X 85 mm2
Inlet
Inlet
Shall be closely covered with tube to the bottom Body earth lead wire (Green)
PCB lead wire A (White)
Thermal fuse lead wire B (Orange)
The glass tape affixes it from a top and bottom direction, and make it sealing up structure. Impossible power do not be added to a terminal joint.
5mm, or more
(Tape sealing area)
PCB lead wire B (Black)
Glass tape shall be wraped around PCB
Thermistor lead wire (Red)
(Twisting 1 time) Thermostat earth lead wire (Green)
Detail 2 : 1
Thermistor lead wire (Red)
Side heater lead wire A (Blue)
- Twisted vinyly tie 2 times. - White, blue and black lead wire shall not over lap PCB base boss. - This blue wire shall be align in this portion.
Side heater lead wire D (White)
Side heater lead wire C (White)
Side heater lead wire B (Blue)
Terminal shall not be higher than head of sems screw.
Side heater lead wire C (Black)
PCB lead wireC (Red)
Side heater lead wire D (Red)
Hinge earth lead wire (Green)
Tapping screw for body earth lead wire
Should be above Thermal fuse lead wire A and then gose below terminal of side heater lead wire D
Stamping earth mark on PF.
5mm (around)
(Ø8)
- Twisted vinyly tie 2 times. - All lead wire must not touch Cast heater terminal.
Thermal fuse lead wire A (Black)
Thermostat earth lead wire (Green)
After twisted 2 times, wind down this direction. (Shall not touch Cast heater)
Vinyly tie
Lead wire
The clearance distance between terminal & sems screw to other dead metal part (Protecting frame, Cast heater pipe) Should minimum 3.6 mm. (Any direction) After inspection, screw head must be mark with marker.
(Note) 1. Tightening torque of tapping screw for body earth lead wire and
sems screw for internal wiring : 60 ~ 120N - m 2. Each lead wire shall not contacting with sharp edges, moving parts, high temperation portion. 3. All lead wire must not be hurt during assembly when apply 2N force.
Technical Regulation
WARNING
Body earth lead wire (Green)
Thermal fuse lead wire B (Orange)
PCB lead wire A (White)
SR-TML500 / SR-TML510 / SR-TMS520

- 5 -
SR-TML500 / SR-TML510 / SR-TMS520
2.2 Circuit Diagram

- 6 -
3. TROUBLESHOOTING GUIDE
3.1 Table 1
When receiving a rice boiler to be repaired, be sure to check that the main body is completely provide with the inner pan
and the inner lid, ask the condition (phenomenon) of the trouble in detail. Before troubleshooting single parts, be sure to
disconnect the power supply plug from the receptacle.
Condition
Rice boiling section
Plane rice.
• Rice is not boiling.
(The indicating lamp
does not come on)
• Rice is not boiling.
(The indicating lamp
is lit)
Troubleshooting Remedy
Is the power cord conductive? • Replace the cord.
• Make sure insert therminal is
fasten.
• Replace the P.C.B. complete.
• Replace the P.C.B. complete.
• Replace the cast heater.
• Replace the center thermostat.
• Replace the inner pan or the
cast heater.
• Seeing at Table 2
• Explain the proper operation.
• Isolate the cause which melt
the thermal fuse, correct
the cause and
• Earlier cut off.
• Poor boiling up.
• Too hard
• Too soft
• Insufficient boiling
• Immediately after the switch is turned
off, open the cap.
• Rice is excessive or insufficient.
• Rice has not been scooped and mixed
well.
• Water is excessive or insufficient.
• The switch is turned off once during
boiling.
Is the pan bottom properly contacted with
the cast heater?
Yes
No
Is the thermal fuse conductive?
Yes
No
Is the therminal conductive?
Yes
Are the parts on the P.C.B. mistake?
Are the parts on the P.C.B. mistake?
Improper operation
No
Yes
No
Yes
Yes
Yes
No
Is the cast heater conductive?
Yes
No
Are the parts on the P.C.B. mistake?
(Check with the bubbling test).
Does the center thermostat operate
properly?
Yes
No
(Check with the operation test).
Yes
SR-TML500 / SR-TML510 / SR-TMS520

- 7 -
Condition Troubleshooting Remedy
• Replace the center thermostat.
• Seeing at Table 2.
• Explain the proper operation.
• Excessive burning.
(More than light brown)
• The voltage is lower than specified.
• Rice is not washed sufficiently
• Water is excessive.
(Bran remains still)
• The pan bottom is conditioned to
generate burning easily.
Are the parts on the P.C.B. mistake?
Improper operation
No
Yes
Yes
Does the center thermostat operate
properly?
Yes
No
(Check with the evaporation test).
• To join it with CN5.
• Display of “Slow Cook”
and “Rice Cook/Steam”
are flashing light.
Check the sensor lead wire is connect
completely with control unit board. No
• Take off and join it with CN5
again.
Yes
• Check the connector of wiring.
• Display of “Start” and
“Timer” are flashing
light.
Is the relay operation ON/OFF alternately
after flashing light occur? No
• Replace the control unit
complete.
Yes
SR-TML500 / SR-TML510 / SR-TMS520

- 8 -
3.2 Table 2
Condition
• Rice is not boiling.
(The indicating lamp
does not come on)
• Rice is not boiling.
• The thermal fuse is
blown off.
• Earlier cut off.
• Poor boiling up.
• Excessive burning.
(The indicating lamp
is lit)
• Heat is not reserved.
(The indicating lamp
does not come on)
• Heat is not reserved.
(The indicating lamp
is lit)
Troubleshooting Remedy
Is the transformer operating?
• Replace the P.C.B. complete.
• Replace the transformer.
• Replace the relay.
• Replace the relay.
• Replace the transformer.
• Replace the relay.
• Replace the relay.
No
Is the relay operation? No
Is the relay cut off?
Is the relay operation?
Yes
• Replace the P.C.B. complete.
Yes
No
• Replace the P.C.B. complete.
Yes
No
• Replace the P.C.B. complete.
Yes
• Replace the P.C.B. complete.
Yes
• Replace the P.C.B. complete.
Yes
Is the relay operation? No
Is the transformer operating? No
• Replace the transformer.
• Replace the P.C.B. complete.
Yes
Is the trial operating? No
SR-TML500 / SR-TML510 / SR-TMS520

- 9 -
4. TESTING PROCEDURE
4.1 Bubbling test
Input the pan in the main body, lightly rotate the pan clockwise and counter clockwise to settle the pan on the
heating plate properly.
1. Fill water until center area of the pan bottom is dipped and close the lid. Then turn on the boiling switch.
4.2 Evaporation test
1. Check that bubbling is proper, open the lid and place a weight.
2. Fully cover 2 to 3 sheet of tissue paper (gauze is also applicable) on the pan bottom and continuously
flow electric current.
Note : To prevent plastic parts from deformation caused by steam, be sure to open the lid fully.
Note : To prevent tissue paper from floating because of bubbling, previously hole the paper.
3. Water on the pan bottom is completely evaporated to be empty. This timing is an follows :
Within 1 minute before the boiling switch is turned off.
Within 1 minute after the boiling switch is turned off.
Place a weight so that its gravity center may be aligned at the center
2. When it beings boiling to produce steam. Remove the lid immediately check the bubbling condition on
the pan bottom.
3. As show in the figture.
If it is improper, it may result from the insufficient contact between the pan bottom and heating plate.
Check the pan bottom and the heating plate for foreign material remainder. Clean off the foreign materials
or replace the parts.
Bubbles generate through out the circumference of the pan bottom...............................................Proper
Bubbles does not generate on more than one quater part of the pan bottom circumference..........Improper
Bubbling
SR-TML500 / SR-TML510 / SR-TMS520
5 cm
40 cm

- 10 -
4.3 Heat reserving test
The above conditions are proper.
1. Put approx. 1 liter of water and the thermometer [ repairing tool (mercury thermometer ASN-150H) ]
in the pan, close the lid and turn on the boiling switch.
2. When the beings boiling to generate steam turn off the boiling switch.
Within 69°C - 77°C .....................................Proper
If outside 69°C - 77°C, check triac mounting for irregularity, if it is proper, replace warming heater.
3. Add water or keep the lid opened until the reading of the thermometer falls to approx. 70°C.
4. When it becomes approx. 70°C, close the lid. After the warming heater is activated for 1 hour or more,
check the heat reserving temperature.
Top view of pan
Holes on the
tissue paper
Pan flange
Tissue paper
Mercury thermometer
Urethane foam blocks
Mercury thermometer
Inner Pan
SR-TML500 / SR-TML510 / SR-TMS520

- 11 -
5. DISASSEMBLY
5.1 Hinge Cover removal
1. Remove the Dew Collector.
2. Remove the Hinge Cover mounting screws.
3. As show in the figure, insert a narrow flat head screwdriver from just below and pry off the Hinge Cover.
5.2 Inner Enclosure and Upper Frame removal
1. As show in the figure, pry up three fastening hooks. Fixing the Upper Frame, turn the Inner Enclosure
in the arrow direction.
2. The Upper Frame will be seperated from the Inner Enclosure and the Upper Frame.
Note : When assembling, refer to the illustration without the position relationship between the Inner
Enclosure and the Upper Frame.
Inner Enclosure
Upper Frame
SR-TML500 / SR-TML510 / SR-TMS520
Hinge Cover
Flat Head Screwdriver
Hinge Cover
mounting screw
remove

- 12 -
5.3 Control Unit A
1. Use screwdriver take off Hinge Cover.
(PIC-1)
PIC-1
PIC-3
PIC-2
PIC-4
PIC-6
PIC-7
PIC-8
PIC-5
2. Pull out at Hinge Shaft. (PIC-2)
3. Pull out at Wiring of Lid Heater and then
pull out Outer Lid Assy. (PIC-3)
4. Loosen screw at Bottom Frame and
Body. (PIC-4)
5. Loosen screws at Bottom Frame and
PCB Base. (PIC-5)
6. Use screwdriver pry up between Bottom
Frame with Body.
7. Take off Body with Bottom Frame.
(PIC-6)
8. Lossen screw of Wiring. (PIC-7)
9. Loosen screw of PCB Control with
P.C.B. Base. (PIC-8)
SR-TML500 / SR-TML510 / SR-TMS520

- 13 -
5.4 Cast Heater and Thermostat Ass’y
1. Loosen a screw at cast heater.
PIC-1
PIC-2
2. Bending leg of thermostat.
3. Lift a thermostat.
Screw
5.5 Side Heater
1. Pulling out a side heater and after that
if will replace new side heater, keep a
distance between 23 ~ 27 mm.
(see a picture)
PIC-1
23~27 mm.
SR-TML500 / SR-TML510 / SR-TMS520

- 14 -
6. PARTS EXPLODED VIEW AND REPLACEMENT PARTS LIST
6.1 Parts Exploded View : Body
C
15
16
17
18
19
20
(For TMS520)
(For TMS520) (For TMS520)
21
22 F
G
28
1
2
4
3
5
6
7
9
8
14
13 12
29
34
3635 37 38 39 40
30
33
31
H
B
32
SR-TML500 / SR-TML510 / SR-TMS520
10
11
23
24
25 26
27

- 15 -
6.2 Parts Exploded View : Packing
1
3
6
2
7
8
4
5
MENU BOOK
OPERATING
INSTRUCTION
XXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXX
XXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXX
SR-TML500 / SR-TML510 / SR-TMS520

- 16 -
6.3 Replacement Parts List : SR-TML500, SR-TML510, SR-TML520
Important safety notice :
Parts List
COUNTRIES / Q’TY
TML510 TMS520TML500
111ARB01K996KCUOUTER LID ASSY1
111ARB19T9201KCSTEAM DOME2
111ARC00T9201KUSTEAM VENT ASSY3
111ARB31T9201STEAM VENT PACKING4
111ARE05H616-KCHOOK LEVER5
111ARE06H616HOOK LEVER SPRING6
111ARC31H616HOOK LEVER BASE7
111ARB15K996-KCHANDLE COVER8
111ARB10K996-KCHANDLE9
111ARB32K986-F S
S
S
S
S
S
LID CAUTION LABEL F10
111ARB32K9861LID CAUTION LABEL B
111ARB01K996-KCOUTER LID11
111ARE50K993PAN12
111ASLR-06VFRECEPTACLE HOUSING13
111ASLP-01VPLUG HOUSING14
111ARL20T908-0UCAST HEATER ASSY15
111ARS14K996-0UTHERMOSTAT ASSY16
111ARS61H616OUTER SPRING17
111ARE00A6161KC
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
SUMIFLON BLACK
BLACKUPPER FRAME18
222ARB74H616HINGE SHAFT19
111ARE20K996PROTECTING FRAME20
111
1
1
1
ARL10K996-0USIDE HEATER ASSY21
ARE10K996HLU
ARE10K996HSU
ARE10K996B0U
BODY ASSY22
1
1
1ARN01K996ZBU
ARN01K996ZCU
ARN01K996KCU
SWITCH ASSY23
1
1
1ARN21K997-ZB
ARN21K996-ZC
ARN21K995-KC
DECORATIVE PANEL A24
111ARN20K996-C0ACRYLIC COVER25
111ARN24K996-DEDECORATIVE PANEL B26
111ARN10K996-KCUSWITCH PANEL ASSY27
111ARE40H6161KCHINGE COVER28
111ARK10K996-KCDEW COLLECTOR29
111ARH30T934KCU
DARK SILVER
SILVER
BLACK
HAIR LINE SILVER
HAIR LINE SILVER
BLACK
HAIR LINE SILVER
HAIR LINE SILVER
BLACK
BLACK
BLACK
BLACKBOTTOM FRAME ASSY30
222ARH90H6631FOOT RUBBER31
REMARKSAFETYPART NO.PART NAME
REF.
NO.
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer’s specified part.
SR-TML500 / SR-TML510 / SR-TMS520

- 17 -
SR-TML500 / SR-TML510 / SR-TMS520
Parts List
COUNTRIES / Q’TY
TML510 TMS520TML500
1
1
1ARY30K997-HL
ARY30K996-HS
ARY30K995-B0
NAME PLATE32
111ARN32K986
SH-3
S
S
S
S
S
PCB COVER33
111ARG10T92010UINLET34
111ARQ00T920-0UPOWER CORD ASSY35
111ARK53K991W9USTEAM BASKET ASSY36
111ASR792-454BKMEASURING CUP37
1ARK58K993PORRIDGE SCOOP38
1ARK57K993PAN LID39
1ARK60K993-W9YOGURT CUP40
REMARKSAFETYPART NO.PART NAME
REF.
NO.
Packing List
COUNTRIES / Q’TY
TML510 TMS520TML500
1
1
1ARZ01K997-HL
ARZ01K996-HS
ARZ01K995-B0
INNER PACKING CASE1
111ARZ80K996-0U SET
SET
S
UPPER PAD ASSY2
111ARZ11T92010ULOWER PAD ASSY3
111ASR758T344BRUST PROOF PAPER4
111ARZ09K986EPE SHEET5
111
11
11
ASR761H915-KCORD PROTECTOR6
1ARZ19K996OPERATING INSTRUCTION7
ARZ20K996MENU BOOK8
1ARZ20K995
REMARKSAFETYPART NO.PART NAME
REF.
NO.
Screws
COUNTRIES / Q’TY
TML510 TMS520TML500
222XTB4+10GFJTAPPING SCREWA
111XYN4+C10FNS FOR CAST HEATER ASSY
FOR INTERNAL WIRING
FOR BOTTOM FRAME AND BODY
FOR HANDLE
SEMS SCREWB
333XYN4+C7FNSSEMS SCREWC
222ASR118-972-WTAPPING SCREWF
FOR HINGE COVER111XTN4+16AVWTAPPING SCREWG
FOR BOTTOM FRAME AND PCB BASE222XTB4+25CFJTAPPING SCREWH
REMARKSAFETYPART NO.PART NAME
REF.
NO.
