Panasonic SiriusXM CQ-RXBT490U User manual

11
CQ-RXBT490U
English
General
Power On/Off
Set your car’s ignition switch to the ACC or ON posi-
tion.
Power on: Press [SOURCE] (PWR).
Power off: Hold down [SOURCE] (PWR) for more
than 1 second.
Source Selection
Press [SOURCE] to change the source.
Radio (apage 15)
d
Disc player
(apage 16)
d
USB (apage 19)
d
AUX
The sound of connected audio device is output from
car speakers. d
Bluetooth®
(apage 26)
d
SiriusXM
(apage 36)
When the optional SiriusXM Connect Vehicle Tuner is
connected to this unit.
d
(Return to “RADIO”)
Volume Adjustment
(Setting Range: 0 to 40, Default: 18)
Turn [VOL] clockwise to increase the volume,
and counterclockwise to decrease the volume.
Volume level (0 to 40)
(default: 18)
AUX Connector (3.5 mm ø stereo)
From line output of external sound/audio device
(ex. Silicon audio player, HDD player, etc.)
Caution
Set the volume level to low enough before the AUX connection is completed.
Failure to observe this may generate loud noise and accordingly damage your speakers and your hear-
ing.
[SOURCE]
selects a source.
[PWR] (Power)
toggles power on/off.
Remote Control Sensor
[MENU]
selects items in the
other menu.
[VOL] (Volume)

12 CQ-RXBT490U
English
General (continued)
aPage 10
aPage 10
aPage 12
aPage 40
aPage 31
aPage 30
aPage 27
aPage 32
aPage 38
aPage 39
Press [MENU].
Turn [VOL] clockwise
or counterclockwise.
Press [VOL] (PUSH SEL).
Press [VOL] (PUSH SEL).
Press [VOL] (PUSH SEL).
Note: This “PHONE”
mode is selectable
only when switch to
Bluetooth®mode.
Note: This history mode is selectable
only when a device is paired and
connected to this unit.
Turn [VOL] clockwise
or counterclockwise.
Press [ ] (Return).
Press [ ] (Return).
Press [ ] (Return).
Note: This “SXM”
mode is selectable
only when switch to
SiriusXM mode.
Menu Operation
Display Color Selection
1Press [MENU].
2Press [VOL] (PUSH SEL), and turn [VOL]
clockwise or counterclockwise to select
“LIGHT SET”.
Display color selection
3Press [VOL] (PUSH SEL), and turn [VOL]
clockwise or counterclockwise to select
display color.
OCEAN (aqua blue)
cd
Variety: OCEAN (aqua blue), SKY (sky blue), FOREST
(green), ORANGE (amber), FIRE (red), PINK
(deep pink), ROSE (pink), STORM (7 colors)
Default: SKY (sky blue)
cd
STORM (7 colors)
Note: Once rotary operation is made, the setting is
activated.

13
CQ-RXBT490U
English
Audio Settings
[DISP] (Display)
exits from the audio menu.
[VOL]
selects a value in the audio
menu.
(PUSH SEL: Select)
selects items in the audio
menu.
[{] [}]
adjust the sound level in
the SQ setting mode.
Preset buttons [1] through [6]
select a SQ setting in the SQ selection mode or preset the current SQ adjustment in the
SQ adjustment mode (by holding down one of the buttons for more than 2 seconds).
1Press [VOL] (PUSH SEL) to open the audio menu.
Note: If no operation takes place for more than 5 seconds in audio setting, the display returns to the regular mode.
2Turn [VOL] clockwise or counterclockwise to select
a mode, and the press [VOL] to be adjusted. 3Turn [VOL] clockwise (q) or counter- clockwise (w) to adjust.
Volume
(Setting Range: 0 to 40, Default: 18) q/ w: Adjustment
Bass
(Setting Range: −12 dB to +12 dB by 2 dB, Default: 0 dB) q/ w: Adjustment
Treble
(Setting Range: −12 dB to +12 dB by 2 dB, Default: 0 dB) q/ w: Adjustment
SQ Adjustment
(Tone/SQ adjustable range : –12 dB to +12 dB (by 2 dB))
Setting range:
SQ Low/Bass: ±12 dB (at 60 Hz, 80 Hz, 100 Hz, 200 Hz)
SQ Mid: ±12 dB (at 500 Hz, 1 kHz, 2 kHz, 3 kHz)
SQ High/Treble: ±12 dB (at 10 kHz, 12 kHz, 15 kHz, 18 kHz)
Band
Frequency
Level
qAdjust each band.
q/ w: center frequency up/down
[BAND] : Band selection
[{] [}]: Level down/up
wHold down the numeric button [2] through
[6] for more than 2 seconds, and the setting
value is written into the desired SQ.
Note:
Only SQ presetting value cannot be saved
in [1] button.
Balance
(Setting Range: 15 levels each, Default: CNT (center)) q/ w: Adjustment
[SQ] (Sound Quality)
[BAND]
selects a band in the SQ setting mode.

14 CQ-RXBT490U
English
Audio Setting (continued)
SQ Selection
You have 6 preset modes (FLAT, ROCK, POP, VOCAL,
JAZZ, CLUB). You can customize your settings for
these (except FLAT) and save them for instant recall.
Press [SQ] to select the sound type as follows.
FLAT
d
ROCK
d
POP
d
VOCAL
d
JAZZ
d
CLUB
d
(Return to “FLAT”)
Notes:
¡After pressing [SQ] on the main unit, you can also
select a sound type by pressing the preset buttons
[1] to [6].
¡To return an adjusted SQ to the default setting,
select the SQ which to be returned to the default
setting, then hold down [BAND] for mote than 2
seconds.
Fader
(Setting Range: 15 levels each, Default: CNT (centre)) q/ w: Adjustment
Subwoofer Setting
(Selectable setting: SET ON/SET OFF, default: OFF) q/ w: Selection
The PRE-OUT(REAR) can be used as a substitutional subwoofer when a subwoofer is not connected.
Subwoofer Frequency Adjust-
ment
(Setting range: 55 Hz, 85 Hz, 120 Hz, 160 Hz), Default: 120 Hz. q/ w: Adjustment
Note: This function is selectable when above “Subwoofer Setting” is set to ON.
Subwoofer Gain Adjustment
(Setting range: 0 dB to +6 dB by 2 dB, Default: 0 dB) q/ w: Adjustment
Notes:
¡This function is selectable when above “Subwoofer Setting” is set to ON.
¡The gain setting is effective when volume level is below 25. (when volume level from 26 to 40, the gain set-
ting is ineffective.)
Notes:
¡The volume can also be adjusted directly using [VOL] on the main unit. (apage 11)
¡Do not activate SQ and Bass/Treble at the same time to avoid causing sound distortion.
¡If the fader is set to front, the pre-amp. output (rear) is decreased.
Flat frequency response: does not empha-
size any part. (Default)
Speedy and heavy sound:
exaggerates bass and treble.
Wide-ranged and deep sound:
slightly emphasizes bass and treble.
Clear sound:
emphasizes middle tone and slightly empha-
sizes treble.
Jazz-specific deep sound:
sound with emphasis on sharpness of high
hat and echo saxophone
Club and disco-specific sound:
reproduction of realism being in a club.

15
CQ-RXBT490U
English
Radio (AM/FM)
Operation Flow
1Press [SOURCE] to select the radio source.
2Press [BAND] to select a band.
3Select a station.
Frequency Adjustment
[6]: Lower / [7]: Higher
Note: For station search, hold down either of the but-
tons for more than 0.5 seconds and release it.
Preset Station Selection
Press the corresponding preset button from [1]
through [6] to tune in a preset station.
Radio Source Display
Band Frequency Preset Number
lights while receiving an FM stereo signal.
Display Change
Press [DISP] to change the display.
Radio mode display
(Frequency)
cd
Clock display S
Station Preset
Up to 6 stations can be preset in each of AM, FM1,
FM2, and FM3.
Preset stations can be simply called up by pressing [1]
through [6].
Auto Preset Memory (APM)
With this operation, stations with good receiving
conditions can be automatically stored in the preset
memory.
1Select a band.
2Hold down [BAND] (APM) for more than 2
seconds.
The preset stations under best receiving conditions
are received for 5 seconds each after presetting the
stations (SCAN). To stop scanning, press one of the
buttons from [1] through [6].
Note: New stations overwrite existing saved stations.
Manual Station Preset
1Tune into a station.
2Hold down one of the preset buttons from [1]
through [6] for more than 2 seconds.
(blinks once)
Note: New stations overwrite existing saved stations.
Caution
To ensure safety, never attempt
to preset stations while you are
driving.
[SOURCE]
selects a source.
[DISP] (Display)
switches the information
on the display.
[BAND]
selects a band in the radio source.
(APM) (Auto Preset Memory)
executes APM in the radio source
(by holding it down for more than 2
seconds).
[6] [7]
decreases/increases the frequency. (For seek tuning, hold it
down for more than 0.5 seconds and release it.)
Preset buttons [1] through [6]
select a preset station in the radio source,
preset the current station (by holding it down
for more than 2 seconds).

16 CQ-RXBT490U
English
Disc Player
Operation Flow
When a disc is already loaded, press [SOURCE]
to select the Disc player mode.
1Press [OPEN] to open the face plate.
2Load a disc with the printed side facing up.
Printed side up
[u](Eject)
3Close the face plate manually.
Notes:
¡The unit recognizes the disc and starts playing
automatically.
¡The power will be turned on automatically when a
disc is loaded.
Disc Eject
1. Press [OPEN].
2. Press [u]and take the disc out.
3. Close the face plate manually.
4Select a desired portion.
Track/File Selection
Press [6]/ [7].
Note: To perform fast reverse/forward, hold down
either of them.
Disc Player (CD-DA disc):
Previous/next track
Disc Player (MP3/WMA disc):
Previous/next file
Folder Selection (MP3/WMA)
[}] (FOLDER): Next folder
[{] (FOLDER): Preceding folder
Pause
Press [BAND] (5/h).
Press again to cancel.
[5] (RANDOM)/[6] (REPEAT)
toggles on/off each play mode.
[3] (SCROLL)
scrolls the information on the display.
[{] [}] (FOLDER)
skip to the previous/next folder.
[OPEN]
opens the face plate
[SOURCE]
selects a source.
[DISP] (Display)
switches the information on the display.
[BAND] (5/h)(Play/Pause)
toggles between pause and play with
the player source.
[6] [7]
skip to the previous/next track/file in the player mode.
For fast reverse/fast forward, hold down either of them.
Caution
¡A disc which has both CD-DA data and MP3/WMA data on it may not be reproduced normally.
¡Do not insert a disc when the indicator lights.
¡Refer to the sections of “Notes on Discs” (apage 41)and “Notes on MP3/WMA” (apage 42).
¡This unit does not support 8 cm {3”} discs.
¡Do not insert foreign objects into the disc slot.
