Panasonic TH-42LFP30W User manual

© Panasonic Corporation 2011
Unauthorized copying and distribution is a violation
of law.
Order Number MTV1111122CE
FULL HD LCD Display
Model No. TH-42LFP30W
TH-47LFP30W
Manufacturing ID No. and Destination
TH-42/47LFP30WU : North and Latin America
TH-42/47LFP30WA : Oceania
TH-42/47LFP30W : Other
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Touch-Current Check ------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices---------- 4
2.2. About lead free solder (PbF)---------------------------- 5
2.3. Precautions for Installation ------------------------------ 6
3 Service Navigation ----------------------------------------------- 8
3.1. Manufacturing ID No. and Destination --------------- 8
3.2. Applicable signals ----------------------------------------- 9
4 Specifications ----------------------------------------------------11
5 Operating Instructions-----------------------------------------12
6 Service Mode -----------------------------------------------------14
6.1. Service Menu Function (1) -----------------------------14
6.2. Service Menu Function (2) -----------------------------15
6.3. Service Mode Function (1) -----------------------------16
6.4. Service Mode Function (2) -----------------------------17
7 Troubleshooting Guide ----------------------------------------18
8 Disassembly and Assembly Instructions--------------- 19
8.1. SERVICE INSTRUCTIONS --------------------------- 19
8.2. Disassembly Procedure Chart ------------------------ 20
8.3. Removing back plate------------------------------------ 21
8.4. Layout of boards and parts ---------------------------- 22
8.5. How to replace the main board ----------------------- 22
8.6. How to replace the jack board ------------------------ 22
8.7. How to replace the power board --------------------- 23
8.8. How to replace Fan A ----------------------------------- 23
8.9. How to replace Fan B ----------------------------------- 23
8.10. Removing the cabinet back---------------------------- 24
8.11. Replacing the RC+LED board ------------------------ 24
8.12. Replacing the gaskets ---------------------------------- 24
8.13. Removing the cabinet front---------------------------- 25
8.14. Replacing the Panasonic badge --------------------- 25
8.15. Replacing the LCD panel ------------------------------ 25
8.16. Replacing the main switch board -------------------- 26
8.17. Fitting the core for the main switch board
cable--------------------------------------------------------- 26

2
TH-42LFP30W / TH-47LFP30W
8.18. Removing the handles ---------------------------------- 26
8.19. Replacing humidity-control sheet -------------------- 27
8.20. Replacing the AV cover--------------------------------- 27
8.21. Replacing the pressure control cap ----------------- 27
8.22. Replacing the AV cover (bottom)--------------------- 28
8.23. Replacing the power cord------------------------------ 28
8.24. Replacing the waterproof nuts ------------------------ 29
8.25. Replacing the aluminium tape and gaskets ------- 29
8.26. Hook and tape for the cables-------------------------- 30
9 Block Diagram --------------------------------------------------- 31
9.1. Block (1 of 2) Diagram ---------------------------------- 31
9.2. Block (2 of 2) Diagram ---------------------------------- 32
10 Wiring Connection Diagram --------------------------------- 33
10.1. Wiring Connection Diagram (1)----------------------- 33
10.2. Wiring Connection Diagram (2) (42 inch) ---------- 35
10.3. Wiring Connection Diagram (3) (42 inch) ---------- 36
10.4. Wiring Connection Diagram (4) (42 inch) ---------- 37
10.5. Wiring Connection Diagram (5) (47 inch) ---------- 38
10.6. Wiring Connection Diagram (6) (47 inch) ---------- 39
10.7. Wiring Connection Diagram (7) (47 inch) ---------- 40
11 Exploded View and Replacement Parts List ----------- 41
11.1. Exploded View and Mechanical Replacement
Parts List --------------------------------------------------- 41
11.2. Mechanical Replacement Parts List (42 inch) ---- 54
11.3. Mechanical Replacement Parts List (47 inch) ---- 56
11.4. Electrical Replacement Boards list (42 inch)------ 58
11.5. Electrical Replacement Boards list (47 inch)------ 58
11.6. Boards Layout--------------------------------------------- 58

3
TH-42LFP30W / TH-47LFP30W
1 Safety Precautions
1.1. General Guidelines
1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials.
2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the
wires have been broken or disconnected, do not attempt to repair or re-wire the units. Replace the entire wiring unit instead.
3. When conducting repairs and servicing, do not twist the Fasten connectors but plug them straight in or unplug them straight
out.
4. When servicing, observe the original lead dress.If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
5. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
6. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.2. Touch-Current Check
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a measuring network for touch currents between each exposed metallic part on the set and a good earth ground
such as a water pipe, as shown in Figure 1.
3. Use Leakage Current Tester (Simpson 228 or equivalent) to measure the potential across the measuring network.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reserve the AC plug in the AC outlet and repeat each of the above measure.
6. The potential at any point (TOUCH CURRENT) expressed as voltage U1and U2, does not exceed the following values:
For a. c.: U1= 35 V (peak) and U2= 0.35 V (peak);
For d. c.: U1= 1.0 V,
Note:
The limit value of U2= 0.35 V (peak) for a. c. and U1= 1.0 V for d. c. correspond to the values 0.7 mA (peak) a. c. and 2.0
mA d. c.
The limit value U1= 35 V (peak) for a. c. correspond to the value 70 mA (peak) a. c. for frequencies greater than 100 kHz.
7. In case a measurement is out of the limits specified, there is a possibility of a shock hazard, and the equipment should be
repaired and rechecked before it is returned to the customer.
Figure 1

4
TH-42LFP30W / TH-47LFP30W
2Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensi-
tive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec-
trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor “chip” components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alumi-
num foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as “anti-static (ESD protected)” can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise ham less motion such as the brush-
ing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient
to damage an ES device).

5
TH-42LFP30W / TH-47LFP30W
2.2. About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work, we’d
suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol PbF stamped on the back of PCB.
Caution
• Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher. Please
use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
• Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb sol-
der. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
• After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto the
opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder. How-
ever, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.

6
TH-42LFP30W / TH-47LFP30W
2.3. Precautions for Installation

7
TH-42LFP30W / TH-47LFP30W

8
TH-42LFP30W / TH-47LFP30W
3 Service Navigation
3.1. Manufacturing ID No. and Destination
Destination can be confirmed by Manufacturing ID No. indicated in the Model Name Plate as following figure.
TH-42/47LFP30WU : North and Latin America
TH-42/47LFP30WA : Oceania
TH-42/47LFP30W : Other
The principal different points are AC power cord, Carton box, owners manual and set up guide.

9
TH-42LFP30W / TH-47LFP30W
3.2. Applicable signals

10
TH-42LFP30W / TH-47LFP30W

11
TH-42LFP30W / TH-47LFP30W
4 Specifications
TH-42LFP30W TH-47LFP30W
For USA, Canada and
Mexico
For Europe and Asia For USA, Canada and
Mexico
For Europe and Asia
Power Source 110 - 127 V AC, 50/60Hz 220 - 240 V AC, 50/60Hz 110 - 127 V AC, 50/60Hz 220 - 240 V AC, 50/60Hz
Power Consumption
Power on 250 W 240 W 300 W 290 W
Stand-by condition
(Winter Mode:Off)
Save off 0.2 W,
Save on 0.1 W
Save off 0.3 W,
Save on 0.2 W
Save off 0.2 W,
Save on 0.1 W
Save off 0.3 W,
Save on 0.2 W
Stand-by condition
(Winter Mode:On)
Backlight Off 40 W
Backlight On 80 W
Backlight Off 40 W
Backlight On 80 W
Backlight Off 40 W
Backlight On 100 W
Backlight Off 40 W
Backlight On 100 W
Power off condition 0.1 W 0.2 W 0.1 W 0.2 W
LCD Display panel 42 inch IPS panel, 16:9 aspect ratio 47 inch IPS panel, 16:9 aspect ratio
Screen size 36.6 inch (W) ×20.5 inch (H) ×42.0 inch (diagonal) /
930 mm (W) ×523 mm (H) ×1,067 mm (diagonal)
40.9 inch (W) ×23.0 inch (H) ×46.9 inch (diagonal) /
1,039 mm (W) ×584 mm (H) ×1,192 mm (diagonal)
(No. of pixels) 2,073,600 (1,920 (W) ×1,080 (H))
[5,760 ×1,080 dots]
2,073,600 (1,920 (W) ×1,080 (H))
[5,760 ×1,080 dots]
Operating condition
Temperature 32 °F - 104 °F / 0 °C - 40 °C (during Winter Mode:- 4 °F - 104 °F / - 20 °C - 40 °C)
Applicable signals
Colour System NTSC, PAL, PAL60, SECAM, NTSC 4.43, PAL M, PAL N
Scanning format 525 (480) / 60i 60p, 625 (575) / 50i 50p, 750 (720) / 60p 50p, 1125 (1080) /
60i 60p 50i 50p 24p 25p 30p 24sF
PC signals VGA, SVGA, XGA, SXGA
UXGA ..... (compressed)
Horizontal scanning frequency 30 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
AV IN VIDEO BNC 1.0 Vp-p (75-ohm)
AUDIO L-R RCA Pin jack ×2 0.5 Vrms
HDMI 1/2 TYPE A Connector
COMPONENT / RGB IN
G/Y BNC with sync 1.0 Vp-p (75-ohm)
B/PB/CBBNC 0.7 Vp-p (75-ohm)
R/PR/CRBNC 0.7 Vp-p (75-ohm)
AUDIO L-R RCA Pin jack ×2 0.5 Vrms
DVI-D IN DVI-D 24 Pin Compliance with DVI Revision 1.0
Content Protection Compatible with HDCP 1.1
AUDIO Stereo mini jack (M3) ×1 0.5 Vrms, Shared with PC IN
PC IN High-Density Mini D-sub 15 Pin G with sync 1.0 Vp-p (75-ohm)
G without sync 0.7 Vp-p (75-ohm)
B:0.7 Vp-p (75-ohm)
R:0.7 Vp-p (75-ohm)
HD / VD:1.0 - 5.0 Vp-p (high impedance)
AUDIO Stereo mini jack (M3) ×1 0.5 Vrms, Shared with DVI-D IN
SERIAL External Control Terminal
D-sub 9 Pin RS-232C compatible
EXT SP 8-ohm, 10 W [5 W + 5 W] (10 % THD)
Dimensions (W ×H ×D) 41.3 inch ×25.3 inch ×6.3 inch /
1,049 mm ×642 mm ×158 mm
45.8 inch ×27.8 inch ×6.3 inch /
1,162 mm ×706 mm ×158 mm
Mass (weight) approx. 83.8 lbs / 38.0kg approx. 99.2 lbs / 45.0kg
Accessories Supplied
Remote Control Transmitter N2QAYB000535
Batteries R6 (UM3) Size ×2
Notes:
• Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.
• This equipment complies with the EMC standards listed below.
EN55022, EN55024, EN61000-3-2, EN61000-3-3.

12
TH-42LFP30W / TH-47LFP30W
5 Operating Instructions

13
TH-42LFP30W / TH-47LFP30W

14
TH-42LFP30W / TH-47LFP30W
6 Service Mode
6.1. Service Menu Function (1)

15
TH-42LFP30W / TH-47LFP30W
6.2. Service Menu Function (2)

16
TH-42LFP30W / TH-47LFP30W
6.3. Service Mode Function (1)

17
TH-42LFP30W / TH-47LFP30W
6.4. Service Mode Function (2)

18
TH-42LFP30W / TH-47LFP30W
7 Troubleshooting Guide

19
TH-42LFP30W / TH-47LFP30W
8 Disassembly and Assembly Instructions
8.1. SERVICE INSTRUCTIONS

20
TH-42LFP30W / TH-47LFP30W
8.2. Disassembly Procedure Chart
