Panasonic CQ-C8303U - WMA/MP3/CD Player/Receiver With 4096 Color OEL... User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls (Bass/Treble) Bass: ±12dB at 60Hz
Treble: ±12dB at 16kHz
Equalizer Center Frequency 60, 160, 400, 1k, 3k, 6k, 16k (Hz)
Variable Range of Equalizer -12dB to 12dB (2dB step)
Current Consumption Less than 2.2A
(CD mode; 0.5W × 4-speaker)
Maximum Power Output 50W × 4(at 1kHz)
Speaker Impedance 4-8Ω
Pre-amp Output Voltage
<CQ-C8403U> 5V (CD mode; 1kHz, 0dB)
<CQ-C8303U> 2.5V (CD mode; 1kHz, 0dB)
Subwoofer Output Voltage
<CQ-C8403U> 5V (CD mode; 1kHz, 0dB)
<CQ-C8303U> 2.5V (CD mode; 1kHz, 0dB)
Pre-amp Output Impedance
<CQ-C8403U> 60Ω
<CQ-C8303U> 200Ω
Subwoofer Output Impedance
<CQ-C8403U> 60Ω
<CQ-C8303U> 200Ω
FM Stereo Radio
Frequency Range 87.9MHz - 107.9MHz
Usable Sensitivity 10.2dBf. (0.9µV, 75Ω)
50dB Quieting Sensitivity 15.2dBf. (1.6µV, 75Ω)
Frequency Response 30Hz-15kHz (±3dB)
Alternate Channel Selectivity 75dB
© 2005 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-C8403U
CQ-C8303U
WMA MP3 CD Player/Receiver
Stereo Separation 35dB (at 1kHz)
Image Response Ratio 75dB
IF Response Ratio 100dB
Signal to Noise Ratio 62dB
AM Radio
Frequency Range 530kHz - 1,710kHz
Usable Sensitivity 27dB/µV (S/N 20dB)
CD Player
Sampling Frequency 8 Times Oversampling
DA Converter 4 DAC System
Pick-up Type Astigma 3-Beam
Light Source Semiconductor Laser
Wave Length 790 nm
Frequency Response 20Hz-20kHz (±1dB)
Signal to Noise Ratio 96dB
Total Harmonic Distortion 0.01% (1kHz)
Wow and Flutter Below Measurable Limits
Channel Separation 75dB
Dimensions (W×H×D)** 7”×1-15/16”×6-1/8”
(178×50×155mm)
Weight** 3 lbs. 8oz (1.6 kg)
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
** Above specifications comply with EIA standards.
AUTOMOTIVE AFTERMARKET
Specifications*
ORDER NO. ACED051226C1
C4

1 ABOUT LEAD FREE SOLDER (PbF) 3
2 FEATUERS 3
3 REPLACEING THE FUSE 3
4 MAINTENANCE 3
5 NOTES 3
6 DIMENSIONS 3
7 LASER PRODUCTS 3
8 WIRING CONNECTION 4
9 DISASSEMBLY INSTRUCTIONS 6
10 TERMINALS DESCRIPTION 9
11 IC BLOCK DIAGRAM 12
12 PACKING PARTS LIST 14
13 REPLACEMENT PARTS LIST(Unit) 15
14 EXPLODED VIEW (Unit) 22
15 CD PLAYER PARTS LIST 23
16 EXPLODED VIEW (CD Deck) 26
17 WIRING DIAGRAM 27
18 SCHEMATIC DIAGRAM-1 32
19 SCHEMATIC DIAGRAM-2 33
20 BLOCK DIAGRAM 37
CONTENTS
Page Page
2
CQ-C8403U / CQ-C8303U

1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATUERS
• • •
• Hands Free Phone System. (The optional Bluetooth hands-
free kit: CY-BT100U)
• • •
• Expansion Module (The optional Hub unit: CY-EM100U)
• • •
• The optional adapter allows you to connect the optional
Panasonic DVD changer unit (CX-DH801U).
• • •
• The optional adapter allows you to connect the optional
Panasonic CD changer unit (CX-DP880).
• • •
• The optional adapter allows you to connect the optional
iPod®series.
• • •
• XM Satellite Radio. (The optional XM receiver: XMD-1000)
• • •
• Sirius Satellite Radio. (The optional Sirius Satellite receiver:
SIR-PAN1)
• • •
• SQ (Sound Quality).
• • •
• SQ7 (7-Band Sound Quality) .
• • •
• D.M(Direct Memory)
• • •
• Customize the Display (Customize Function)
• • •
• MP3/WMA Playback from CD-R/RW.
• • •
• This manual is for 2 models CQ-C8403U and CQ-C8303U.
The following table describes the differences between 2
models.
3 REPLACEING THE FUSE
Use fuses of the same specified rating 15 amps. Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to the stereo
unit.
4 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvent.
5 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit
6 DIMENSIONS
7 LASER PRODUCTS
3
CQ-C8403U / CQ-C8303U

8 WIRING CONNECTION
8.1. CQ-C8403U
4
CQ-C8403U / CQ-C8303U

8.2. CQ-C8303U
5
CQ-C8403U / CQ-C8303U

9 DISASSEMBLY INSTRUCTIONS
9.1. How to Remove the Flexible PCB(AP2)
6
CQ-C8403U / CQ-C8303U

9.2. How to Install the Main P.C.B. of the Electric Display
7
CQ-C8403U / CQ-C8303U

8
CQ-C8403U / CQ-C8303U

10.1. Main Block
IC601 : C2CBKG000034
Pin
No. Port Description (I/O )(V)
FM AM CD
1 PANEL OPEN Panel open detection I 0 5.2 5.2
2 PANEL
CLOSE Panel close detection I 0 0 5.2
3 SUBM CNT 3.3V power control for
Display O 5.0 - -
4 BATT Battery power check I 4.8 5.0 5.0
5 ACC Acc. power check I 4.8 5.0 5.0
6 SDA Serial data for electronic
volume I/O 4.9 4.9 4.9
7 SCLK Serial clock for electronic
volume O 4.9 4.9 4.9
8 CD MUTE Signal mute from CD deck I 5.0 5.0 5.0
9 Vss GND - 0 0 0
10 ST FM stereo detection I 5.1 5.2 5.2
11 PLL DI (MO) Serial data to PLL O 0.6 0 0
12 PLL DO (MI) Serial data from PLL I 5.2 5.2 5.2
13 PLL CLK Serial clock for PLL O 4.9 4.9 4.9
14 PLL CE Chip enable for PLL O 0 0 0
15 CD RESET Reset for CD deck O 4.9 4.9 4.9
16 SUB SI Serial data to Display CPU O 0.6 0.6 0.8
17 CD IN Disc-in detection I 5.0 5.0 5.0
18 SUB SO Serial data from Display
CPU I 4.4 4.4 4.4
19 CH DATA/ UP
SO XM SO/UP SO Serial data from Changer I 1.6 1.6 1.6
20 CH CLK/ UP
CLK Serial clock for Changer or Flash writer I 4.9 4.9 4.9
21 Vdd +5V power supply - 4.9 4.9 4.9
22 XM SI (MO)/
UP SI Serial data to Satellite or Flash writer O 0 0 0
23 CD SI (MO) Serial data to CD deck O 0 0 0
24 CD SCLK Serial clock for CD deck I/O 0 0.4 0
25 CONDENSOR Capacitor connection for
power - 3.3 3.3 3.3
26 CD SO (MI) Serial data from CD deck I 0 0 0
27 CH STB Strobe from Changer I 0 0 0
28 CH REM OUT Remote control codes to
Changer O 4.9 4.9 0.4
29 DECK V
CONT Power control for CD deck O 4.9 4.9 4.9
30 REMO INT Interrupt for remote control I 3.7 3.7 3.7
31 CD FS Frame sync. for CD deck O - - -
32 Avdd +5V power supply - 5.1 5.1 5.1
33 AVREF +5V power supply - 5.1 5.1 5.1
34 AVGND GND - 0 0 0
35 AVSS GND - 0 0 0
36 SD FM/AM signal level meter I 0.2 0 0.3
37 INIT A Model setting A by voltage
level I 0 0 0
38 INIT B Model setting B by voltage
level I 0 0 0
39 AIN Spectrum analyzer data I 0 0 0
40 Vss GND - 0 0 0
41 SYS ID1 Hub connection device
detection ID 1 I 0 0 0
42 SYS ID2 Hub connection device
detection ID 2 I 5.2 5.2 5.2
43 HUB EVENT Bluetooth incoming
detection I 5.2 5.2 5.2
44 HUB CNT Request of hub
connection check O 0 0 0
45 CD SW1 Disc detection switch 1 I 0 0 0
46 CD SW2 Disc detection switch 2 I 0 0 0
Pin
No. Port Description (I/O )(V)
FM AM CD
47 MOD0 Operating mode control 0
from Flash writer I 5.1 5.1 5.1
48 MOD1 Operating mode control 1:
pulled up to H - 5.1 5.1 5.1
49 MOD2 Operating mode control 2
from Flash writer I 0 0 0
50 H STANDBY Standby control from
external I 5.0 5.0 5.0
51 DCDC CONT Not connected - - - -
52 FP MOTOR1 Open/Close of Front panel
1O 4.9 5.0 4.9
53 FP MOTOR2 Open/Close of Front panel
2O 4.9 5.0 4.9
54 V CONT1 Reference voltage control
for motor driver O 0 0 5.0
55 REMO 1 Remote control data I 5.0 5.0 5.0
56 SA CLK Spectrum analyzer clock O 5.0 5.0 4.9
57 EXT MUTE Pulled up to H I 5.3 5.2 5.2
58 AMP CONT Power control for external
Amplifier O 4.9 5.0 4.9
59 BZ OUT Buzzer signal O 0 0 0
60 OEL VCONT Power control for OEL O 0 0 0
61 WOW MODE1 SRS WOW mode 1
(C8403U only) O 0 0 0
62 WOW MODE2 SRS WOW mode 2
(C8403U only) O 0 0 0
63 WOW MODE3 SRS WOW mode 3
(C8403U only) O 0 0 0
64 DIM1 Not connected - - - -
65 DIM2 Not connected - - - -
66 MAIN CNT2 Power control for Hub O 5.0 5.0 5.0
67 SRC KEY SOURCE key detection I 5.0 4.9 5.0
68 PANEL IN Panel attachment
detection I - - -
69 NC Not connected - - - -
70 NC Not connected - - - -
71 NC Not connected - - - -
72 MAIN CONT Main power control O 4.9 4.9 4.9
73 INV CONT Dimmer power control O 5.0 5.0 5.0
74 AF MUTE Audio mute O 5.0 5.0 5.0
75 RESET Reset I 5.0 5.0 5.0
76 FOCUS ELV Focus elevation for SRS
WOW (C8403U only) O - - -
77 X1A Oscillator clock O 2.1 2.1 2.1
78 X0A Oscillator clock I 1.6 1.6 1.6
79 Vss GND - 0 0 0
80 X1 Crystal oscillator clock I 2.0 2.0 2.0
81 X2 Crystal oscillator clock O 2.5 2.5 2.5
82 Vdd +5V power supply - 5.0 5.0 5.0
83 P00 Pulled down to L - 0 0 0
84 P01 Pulled up to H - 5.1 5.0 5.1
85 OFFSET DET Audio clipping level
detection from Power
amp.
I 0 0 0
86 STBY Standby for Power amp. O 5.0 5.0 5.0
87 MUTE Mute for Power amp. O 0 0 0
88 ILL SENS Pulled up to H - 5.0 5.0 5.0
89 NC Not connected - - - -
90 NC Not connected - - - -
91 NC Not connected - - - -
92 NC Not connected - - - -
93 SUB RESET Reset for display CPU O 4.9 5.0 4.9
94 DISPM CONT 5V power control for
Display O 0 0 0
95 NC Not connected - - - -
96 NC Not connected - - - -
10 TERMINALS DESCRIPTION
9
CQ-C8403U / CQ-C8303U

Pin
No. Port Description (I/O )(V)
FM AM CD
97 NC Not connected - - - -
98 S LED Security LED drive O 0 0 5.0
99 ANT CONT Power control for antenna
motor O 5.2 5.2 5.2
100 NC Not connected - - - -
10.2. Display Block
IC901 C2CBKJ000189
Pin
No. Port Part Name & Description I/O (V)
1 NC Not connected - -
2 DCLK SLV4 Slave D-CLK4 (Clock for
image data) I 1.5
3 UART SS4 GND - 0
4 UART SS3 GND - 0
5 D DIS Disable for Anode drive
(Disable for image signal) O 0
6 PADJ IO2 Anode output pulse width
adjusting data 2 (Image data) O 3.8
7 DCLK SLV3 Slave D-CLK 3 (Clock for
image data) I 1.5
8 NC Not connected - -
9 NC Not connected - -
10 NC Not connected - -
11 KS1 Key scan 1 O 0
12 KS2 Key scan 2 O 0
13 KS3 Key scan 3 O 0
14 NC Not connected - -
15 BUS BYTE GND - 0
16 CNVSS CPU rewrite mode/Single
CPU mode selection for
Flash writer
I 0
17 IADJ Anode output current
adjusting data (Luminance
control)
O 0
18 I CLK Clock for anode output
current adjusting data O 0
19 RESET Reset from main CPU I 4.4
20 X1 Ceramic oscillator clock
(8MHz) O 2.5
21 GND GND - 0
22 X0 Ceramic oscillator clock
(8MHz) I 2.2
23 VCC5.0V Power supply - 4.6
24 NMI Pulled up to H - 4.6
25 Y SYNC Cathode scan data and
Cathode latch control
(Vertical sync.)
O 0
26 NC Not connected - -
27 NC Not connected - -
28 X SYNC Clock for Cathode scan; or
Latch strobe for Anode
output pulse width adjusting
data and Anode output
current adjusting data
O 0
29 A CLK TA Anode output pulse width
adjusting clock O 2.7
30 NC Not connected - -
31 NC Not connected - -
32 S DIS Disable for Cathode drive O 2.4
33 NC Not connected - -
34 NC Not connected - -
35 NC Not connected - -
36 NC Not connected - -
37 NC Not connected - -
Pin
No. Port Part Name & Description I/O (V)
38 PADJ IO1/TXD Anode output pulse width
adjusting data 0 (Image
data); or Serial data for Flash
writer
O 1.2
39 VCC5.0V Power supply - 3.3
40 RXD Serial data from Flash writer I 1.3
41 GND GND - 0
42 DCLK MST/SCLK Master D-CLK (Clock for
image data);or Serial clock
from Flash writer
O/I 3.3
43 BUSY Busy for Flash writer O 1.5
44 OEL OE OEL output enable O 0
45 PADJ IO0 Anode output pulse width
adjusting data 0 (Image data) O 1.8
46 DCLK SLV0 Slave D-CLK 0 (Clock for
image data) I 2.7
47 UART SS0 GND - 0
48 NC Not connected - -
49 FLASH CE Chip enable for Flash
memory O 1.7
50 NC Not connected - -
51 NC Not connected - -
52 RY/BY Pulled up to H - 3.6
53 NC Not connected - -
54 EPM Program mode enable for
Flash writer I 2.3
55 NC Not connected - -
56 NC Not connected - -
57 GND GND - 0
58 NC Not connected - -
59 VCC3.3V Power supply - 3.6
60 NC Not connected - -
61 NC Not connected - -
62 NC Not connected - -
63 FLASH OE Output enable for Flash
memory O 3.6
64 NC Not connected - -
65 FLASH WE Write enable for Flash
memory O 3.6
66 NC Not connected - -
67 NC Not connected - -
68 NC Not connected - -
69 NC Not connected - -
70 FLASH A22 A22 in Address bus O 0
71 FLASH A21 A21 in Address bus O 3.6
72 FLASH A20 A20 in Address bus O 3.6
73 FLASH A19 A19 in Address bus O 0
74 VCC3.3V Power supply - 3.6
75 FLASH A18 A18 in Address bus O 3.6
76 GND GND - 0
77 FLASH A17 A17 in Address bus O 0
78 FLASH A16 A16 in Address bus O 2.5
79 FLASH A15 A15 in Address bus O 0
80 FLASH A14 A14 in Address bus O 0
81 FLASH A13 A13 in Address bus O 2.5
82 FLASH A12 A12 in Address bus O 2.5
83 FLASH A11 A11 in Address bus O 0
84 FLASH A10 A10 in Address bus O 0
85 FLASH A9 A9 in Address bus O 0
86 FLASH WP Write protect/Accelaration
from Flash memory O 0
87 NC Not connected - -
88 NC Not connected - -
89 NC Not connected - -
90 NC Not connected - -
91 VDD 3.3V Power supply - 3.4
92 FLASH A8 A8 in Address bus O 0
93 GND GND - 0
10
CQ-C8403U / CQ-C8303U
