English
4 5
Operating Instructions
(Household use) Oral Irrigator
Model No. EW1614
Thank you for purchasing this Panasonic product.
Beforeoperatingthisunit,pleasereadtheseinstructionscompletelyandsavethemforfutureuse.
Safety precautions............. 7
Important information..............10
Partsidentication...................10
How to use................................11
Points of care............................13
After use....................................14
Specications...........................16
Troubleshooting.......................17
Changing the nozzle
(Soldseparately).......................18
Contents

6 7
English
WARNING
• Do not immerse the appliance in water or wash it with water.
Doing so may cause electric shock or re due to a short
circuit.
• Always unplug the power plug from a household outlet when
cleaning the power plug.
Failure to do so may cause electric shock or injury.
• The supply cord cannot be replaced. If the cord is damaged,
the appliance should be scrapped.
Failure to do so may cause an accident or injury.
• Oral irrigators can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
under supervision.
• Oral irrigators shall be used only with cold or warm water, or
specic solutions as dened in the manufacturer’s
instructions.
• Children shall not play with the appliance.

7
English
6 7
Safetyprecautions
To reduce the risk of injury, loss of life, electric shock,
re, and damage to property, always observe the
following safety precautions.
Explanationofsymbols
The following symbols are used to classify and describe
the level of hazard, injury, and property damage caused
when the denotation is disregarded and improper use is
performed.
WARNING Denotes a potential
hazard that could result
in serious injury or death.
CAUTION
Denotes a hazard that
could result in minor
injury or property
damage.
The following symbols are used to classify and describe
the type of instructions to be observed.
This symbol is used to alert users to a specic
operating procedure that must not be performed.
This symbol is used to alert users to a specic
operating procedure that must be followed in
order to operate the unit safely.
WARNING
►Preventing accidents
Do not store within the reach of children
under8yearsoldorinfants.Donotletthem
useit.
- Doing so may cause an accident or injury due to
accidental ingestion of removable parts.
►Powersupply
Do not connect or disconnect the power plug
toahouseholdoutletwithawethand.
- Doing so may cause electric shock or injury.
Do not use the appliance near a bath tub or
insideashowerroom.
Do not use when the cord or the power
plug is damaged or when the fitting into the
householdoutletisloose.
Donotdamagethepowerplug.
Donotdamage,modify,forcefullybend,pull,
twist,orbundlethecord.
Also,donotplaceanythingheavyonor
pinchthecord.
Do not allow pins or trash to adhere to the
powerplug.
- Doing so may cause electric shock or re due
to a short circuit.

8
English
WARNING
Donotuseinawayexceedingtheratingof
thehouseholdoutletorthewiring.
- Exceeding the rating by connecting too many
power plugs to one household outlet may
cause re due to overheating.
Alwaysensuretheapplianceisoperated
on an electric power source matched to the
ratedvoltageindicatedontheappliance.
Fullyinsertthepowerplug.
-
Failure to do so may cause re, electric shock.
►Incaseofanabnormalityormalfunction
Immediatelystopusingandremovethe
powerplugifthereisanabnormalityor
malfunction.
- Failure to do so may cause re, electric shock, or
injury.
<Abnormalityormalfunctioncases>
•Themainunitisdeformedorabnormally
hot.
•Themainunitsmellsofburning.
• There is an abnormal sound during use of
themainunit.
→
Immediately request inspection or repair at an
authorized service centre.
►This product
Donotmodify,disassembleorrepair.
-
Doing so may cause injury due to re or
malfunction.
→Contact an authorized service centre for repair.
Donotdroporsubjecttoshock.
- Doing so may cause electric shock or re.
►Cleaning
Before using the appliance again, wipe off
anymoisturefromthepowerplug.
- Failure to do so may cause electric shock or
injury.
Regularlycleanthepowerplugtoprevent
dustfromaccumulating.
- Failure to do so may cause re due to
insulation failure caused by humidity.
→Disconnect the power plug and wipe with a dry
cloth.
CAUTION
►Preventing damage to teeth and gums
People who are unable to operate should not
usethisappliance.
People with weak oral senses should not use
thisappliance.
- Doing so may cause injury or harm your teeth,
gums or tongue.
People who are suspected of having
periodontal disease or have discomfortable
symptomsintheirteethororalcavityshould
consultadentistbeforeuse.
- Doing so may cause injury or harm your teeth,
gums or tongue.

9
English
CAUTION
Observe the following precautions when
usingthetonguecarenozzle.
•Donotallowchildrentouseit.
•Donotbrushforcefully.
•Donotinserttoodeep(approx.3/4ofthe
visiblerange).
• If tongue inflammation occurs, stop using
the device and consult a doctor if the
inflammationpersistsafter3days.
- Doing so may cause injury or harm your teeth,
gums or tongue.
►This product
Never use for a purpose other than oral
cleaning.
- Doing so may cause an accident or injury when
the stream of water is pointed toward the eyes,
nose, ears, or throat.
Do not fill the tank with water warmer than
40°C.
- Doing so may cause burns.
Donotsharenozzlewithyourfamilyorother
people.
- Doing so may cause infection or inammation.
►Note the following precautions
Do not wrap the cord around the appliance
whenstoring.
-
Doing so may cause the wire in the cord to
break with the load, and may cause re due to
a short circuit.
Disconnect the power plug from the
household outlet when not using for
extendedperiodoftime.
- Failure to do so may cause electric shock or
re due to electrical leakage resulting from
insulation deterioration.
Disconnectthepowerplugbyholdingontoit
insteadofthecord.
- Failure to do so may cause burns, electric
shock, or fire due to a short circuit since a wire
break may occur if too much load is applied to
the power cord.
Cleananddrythewatertankandnozzleafter
eachuse.
- Failure to do so may cause damage to your
health if used without keeping it sanitized due
to propagation of mold and bacteria.

10
English
Important information
►Notice
•Do not put salt, mouthwash or other chemicals into the
water tank. Doing so may cause malfunction.
• Do not dry the main unit with a dryer or a fan heater.
Doing so may cause malfunction or deformation of the
parts.
• Store the appliance in a place with low humidity after
use. Failure to do so may cause malfunction.
• About tooth tartar
Please use together with a toothbrush.
It is hard to remove tooth tartar or dental calculus
attached to the tooth surface just by a water jet, so a
toothbrush is required to brush the teeth.
It is recommended to clean inside your mouth with the
water jet after brushing your teeth.
• About bleeding gums
Initially bleeding may occur even with healthy gums.
This is caused because the gums are not used to such
stimulation. The bleeding will normally stop within
1 or 2 weeks of use. There may be a problem with
the gums (periodontal disease, etc.) if the bleeding
continues for over 2 weeks. In such cases, stop using
the appliance andconsult a dentist.
Partsidentication
AHandle
1Stop/Jet switch
2Jet mode “”
3Stop mode “”
4Nozzle release button
5Nozzle
BMain unit
6Cord
7Power plug
8Suction hose
CWater tank
9Upper water level limit
Water tank cap
DOperation panel
Water pressure
level LED indicator
(1~10 levels)
(Level 1 is also the
Child mode “ ”.)
Power switch “”
Water pressure
regulator switch
E
Ultrasonicnozzle(x2)
qNozzle
wNozzle insertion port
FOrthodontic nozzle
qNozzle
wNozzle insertion port
eIdentication ring
rNozzle Handle
GTongue care nozzle
qNozzle
wNozzle insertion port
eIdentication ring
tCloth
• All of the nozzles are
consumables.
Accessory
HNozzle stand
There may be moisture inside the main
unit (water tank and suction hose) left
from the distilled water used for product
testing.
■Iftheidenticationringcomeso󰀨
(For orthodontic nozzle and
tonguecarenozzleonly)
Align the identification ring (in any
direction) with the nozzle, and
attach them without any inclination.
• Even if the identication ring is
not attached, it does not a󰀨ect the
performance of the nozzle.

11
English
How to use
1Insert the power plug into a household outlet,
andllthewatertankwithwater.
aInsert the power plug
into a household
outlet.
• The cord can be
pulled out from either
the right or the left.
❷
❺
❹
❶
❸
bOpen the water tank
cap.
cRemove the water
tank,andllitwith
water.
• When lling water, be
sure not to exceed the
upper water level limit.
dSet the tank to the
mainunitrmly.
eAttach the water tank
cap.
2Installthenozzle,andturnonthepower.
aInstallthenozzle.
• Choose a nozzle for
your purpose. (
See pages
13 and 14.
)
bEnsuretheStop/Jet
switch is set to “ ”
(stopmode).
cPress the power switch
“ ” to turn on the
power.
• The water pressure level
LED indicator lights on.
•
The power will be cut o󰀨
after about 10 minutes to
avoid forgetting to turn o󰀨.
(The function for avoiding
forgetting to turn o󰀨.)
a
b c
3Press the water pressure
regulator switch to select
thewaterpressurelevel.
aWith the nozzle facing
the basin, set the
Stop/Jetswitchto
“”(jetmode)to
jetwater.
Prepare
Place the main unit on a at and stable
surface.
Upper water
level limit
Press
Press in rmly until a
"click"is heard.
Click
Press
Stop/Jet switch

12
English
bPress “+” or “-” on
the water pressure
regulator switch
untilthedesiredow
intensityisreached.
• Keep pressing “+” or “-”
will continuously change
the water pressure.
cSettheStop/Jetswitchto“ ”(stopmode)to
stopjettingtemporarily.
■Waterpressurelevelmemoryfunction
The last selected water pressure level will be
remembered from the second time onward.
4Cleaninsideyourmouth
withwaterjet.
aPlace the nozzle in
yourmouth.
bCloseyourmouth
gently.
cSettheStop/Jetswitch
to “ ”(jetmode).
• If you want to pause the water jet, set the
Stop/Jet switch to “ ” (stop mode).
• You can switch the water pressure level by
pressing the water pressure regulator switch
even while using the appliance.
Operation time with full water:
approx.180seconds
(When the ultrasonic nozzle is used and the
water pressure level is set to 10)
►
To adjust the orientation of the
nozzle(Fororthodonticnozzleonly)
You can adjust the direction of water
jet by rotating the nozzle handle.
Notes
• Always use new tap water or lukewarm water.
• If water is cold, use lukewarm water with temperature
40 °C or below.
• Do not turn on the power switch “ ” when the water
tank is empty (except discharging the water inside the
main unit). (Doing so may cause malfunction.)
• The recommended operating temperature of the
appliance is 5 °C - 40 °C. If the indoor temperature is
over or lower than the recommended temperature, the
appliance may stop operating.
• When the Stop/Jet switch is set to “ ” (stop mode)
for more than 1 minute, turn o󰀨 the power switch “ ”.
(Doing so may cause malfunction.)
• When you use the appliance for the rst time, please
start with water pressure level 1 (Child mode “ ”).
• Do not push the tip of the nozzle too hard against the
teeth or gums. (Excluding the orthodontic nozzle.)
• When you feel that the irritation is strong, set the Stop/
Jet switch to “ ” (stop mode) and use the
appliance
from the water pressure level 1 (Child mode
“ ”) .
Keep your face
over the basin.
Weak Strong
(Level 10)
(Level 1)
(Child mode “ ” )

13
English
Points of care
If you are concerned about sensitive gums, stimulate
with a gentle water jet setting.
With the water jet and orthodontic nozzle, clean every
nook and cranny of areas that are hard to reach by the
toothbrush.
Change the way you use and move the unit depending
on the purpose and the area you want to clean.
Ultrasonic nozzle
To clean with the water jet.
Interdental cleaning
• Direct the water jet onto the space
between the teeth.
• Direct from the front and rear sides
of the teeth.
Periodontal pocket cleaning
• Aim the water jet at the space
between teeth and gums.
• Slowly shift the water jet along the
gums.
• Clean the front and back of the
teeth and behind the molars as well.
Gums care
• Stimulate the gums.
Orthodontic nozzle
When cleaning crooked teeth and orthodontic bracket
area with the brush and water ow.
Lightly place the brush tip on the teeth and wiggle the
brush.
For crooked teeth
• Place the brush tip on the area that
is di󰀩cult for a toothbrush to reach
and tends to remain unpolished.
• Wiggle the brush mainly in
interdental spaces.
For orthodontic bracket area
Ultrasonic nozzle
Orthodontic nozzle
• Insert the brush to the
gap between the teeth
and the orthodontic
bracket.
• Wiggle the brush tip.
• Direct the water jet
around orthodontic
brackets and bridges.

14
English
Tongue care nozzle
To clean the tongue surface with the cloth and
water ow.
Tongue cleaning
• Set the water pressure level to 10.
(To rinse the tongue clean.)
• While jetting water, apply the
tongue care nozzle lightly to the
tongue and move it slowly from the
back to the front repeatedly.
• Tongue cleaning is allowed at
most once a day.
• Excessive strength may hurt the
surface of the tongue.
• Do not go deep into your tongue.
• When you stick your tongue
forward while cleaning, the
vomiting reflection* will be less
likely to occur.
* Refers to the state of nausea.
Cleaning range
(approx. 3/4 of
the visible range)
From the
back to
the front
■To clean the tongue surface with the cloth
Occasionally, the cloth may be stuck in the
tongue surface.
→Please move the cloth slightly back to
remove it.
• After use, water may drip from the nozzle since some
water may remain in the cloth of the nozzle. Please
remove it after drainage. (See page 15.)
After use
Pleasecleantheapplianceaftereachuse.
• The main unit cannot be washed with water.
1To prevent the water from
splashing about, stop the
water jet while keeping the
nozzleinyourmouth.
aStopthewaterjetby
settingtheStop/Jetswitch
to “ ”(stopmode).
bPress the power switch
“”toturno󰀨thepower.
• The water pressure level
LED indicator keeps ashing
for 30 seconds and then
goes o󰀨.
押す
a
b
Press

15
English
2Throwawaytheremainingwater.
aRemove the water tank, and
throwawaytheremaining
water.
• While removing the water
tank, press the main unit by
hand.
• Change the water every
time when you use the
appliance.
bWashthewatertank.
3Remove the remaining water
fromthemainunit.
aInstall the water tank, and
turn on the power switch
“”.
bWith the nozzle facing the
basin,settheStop/Jet
switch to “ ”(jetmode)
to remove the remaining
waterfromthemainunit.
cWhen there is no water
coming out, set the
Stop/Jetswitchto“ ”
(stopmode),andturno󰀨
the power switch “ ”.
a
b
4Disconnect the power plug
fromthehouseholdoutlet.
5Cleanthehandle.
• Rinse the cloth of the tongue care nozzle with
running water.
• Do not bump it on the washbasin when swinging it
dry.
6Storeitafteritisdry.
aWipeo󰀨anymoisturewith
atowelanddryina
well-ventilatedshade.
bStoretheappliance.
• Mount the handle and water
tank to the main unit, and
place the nozzle on the
nozzle stand.
• When two or more nozzles
are placed on the nozzle
stand, make sure that they
do not come in contact with
each other.
Stop/Jet switch
Drainage
outlet
Pull out the
nozzle while
pressing the
button.
Nozzle release
button
Cloth

16 1716
English
Notes
• Remove the dirt inside the water tank with a
long handled sponge bottle brush. (Do not use
lukewarm water exceeding 80 °C.)
• Only the water tank can be washed in a dish
washer. The nozzle, the nozzle stand, and the
water tank cap cannot be cleaned in a dish washer.
• Do not wipe with thinners, benzine, alcohol etc.
(Doing so may cause malfunction, cracking or
discoloration of the parts.)
• Use neutral kitchen detergent and rinse well with
water to ensure no detergent remains after cleaning.
• Do not use lukewarm water exceeding 50 °C to wash
the nozzle, the nozzle stand, the water tank cap, and
the handle.
• Do not rub the cloth of the tongue care nozzle with
sharp-pointed objects or finger nails.
Clean the dirt on the main unit
When wiping stains away from
the main unit with a cloth that
has been soaked in soap water
and then wrung out.
(Do not wash the main unit with
water.)
• Use cotton swabs to clean any
part that is inaccessible to the
cloth.
Specications
Power Source See the name plate on the product
(Automatic voltage conversion)
Power
consumption 18 W
Water tank
volume
Approx. 600 mL
(For approx. 180 seconds of operation
when the ultrasonic nozzle is used and
the water pressure level is set to 10)
(For approx. 130 seconds of operation
when the orthodontic nozzle is used
and the water pressure level is set to 10)
(For approx. 75 seconds of operation
when the tongue care nozzle is used
and the water pressure level is set to 10)
Dimensions
Main unit:
300 (H) × 125 (W) × 140 (D) mm
(Including nozzle)
200 (H) × 125 (W) × 140 (D) mm
(Not including nozzle)
Suction hose
length Approx. 1
100 mm
Mass Main unit: Approx. 995 g
(Including nozzle)
Airborne
Acoustical
Noise 83 (dB (A) re 1 pW)
This product is intended for household use only.

16 17
English
Troubleshooting
Problem Possible cause Action
No water comes out, or the water
jet power is weak.
TheStop/Jetswitchisleftin“ ”(stopmode)whilethepowerison.
→Take the following steps:
a
Fill the water tank with water halfway.
b
Press the power switch “ ” to turn on the power and press “+” to set
the water pressure level 10.
c
Set the Stop/Jet switch to “ ” (jet mode).
d
Insert and remove the water tank for several times.
e
Install the water tank and wait for a few seconds until the water pressure
is restored.
* Repeat Steps
d
and
e
if the water pressure is not restored.
• Once the water pressure is restored, you can use the appliance as usual.
The nozzle is clogged.
Replace the nozzle.The outlet of nozzle is squashed.
The nozzle comes o󰀨 during use. The nozzle is deformed.
Fail to remember the water
pressure level. The power plug is pulled out from the household outlet before the power switch “ ” is turned o󰀨.
Before pulling out the power
plug from the household outlet,
turn o󰀨 the power switch “ ”.
Motor sound changes after the Stop/
Jet switch is set to “ ” (stop mode).
This is not an abnormality. →Please use the appliance as usual.
* It may occur particularly in a low-temperature environment.
The power is cut o󰀨 automatically.
The function for avoiding forgetting to turn o󰀨 is
activated. This is not an abnormality. (See page 11.)
The self-protection function is activated due to a
thunderstorm etc. Turn on the power switch “ ” again.
The water pressure level LED
indicator still ashes after the
power switch “ ” is turned o󰀨.
This is not an abnormality.
→The indicator will go o󰀨 after 30 seconds. (See page 14.)
The nozzle is hard to install. →Apply water to the nozzle insertion port.
If the problems still cannot be solved, contact the store where you purchased the unit or a service centre authorized by Panasonic for repair.
d
e
b
While using
Press

18
English
Changingthenozzle(Soldseparately)
Ultrasonic nozzle
• If the tip of the nozzle gets deformed, please replace
the nozzle with a new one.
• The nozzle should be replaced once every 6 months
or so due to hygiene reasons, even if it is not
deformed.
New nozzle (tip) Deformed (worn) nozzle (tip)
Orthodontic nozzle
• Replace the orthodontic nozzle in approx. 3 months.
If the brush bristles are bent out, replace it even
within 3 months.
New nozzle (tip) Nozzle with bent out bristles
Tongue care nozzle
• Replace the tongue care nozzle in approx. 6months.
If the brush cloth is discoloured, replace it even within
6months.
New nozzle (tip) Discoloured nozzle (tip)
Part number Replacement Nozzle for EW1614
WEW0986 Ultrasonic
nozzle
WEW0984 Orthodontic
nozzle
WEW0985 Tongue care
nozzle

19
English
Authorized Representative in EU:
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Importer:
Panasonic Marketing Europe GmbH
Hagenauer Strasse 43, 65203 Wiesbaden, Germany
Manufacturedby:
Panasonic Corporation
1006, Oaza Kadoma, Kadoma City, Osaka, Japan
Disposal of Old Equipment
OnlyforEuropeanUnionandcountrieswith
recyclingsystems
This symbol on the products, packaging,
and/or accompanying documents means that
used electrical and electronic products must
not be mixed with general household waste.
For proper treatment, recovery and recycling
of old products, please take them to
applicable collection points in accordance
with your national legislation.
By disposing of them correctly, you will help
to save valuable resources and prevent any
potential negative e󰀨ects on human health
and the environment.
For more information about collection and
recycling, please contact your local authority.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.

20 PB
