nDaylight View technology
-Image performance rivaling 2,400-lumen projectors*1
-Vivid colors in a bright room
-Auto operation with ambient light sensor
nQuick operation
-2-second speed start
-One-touch auto setup with digital
keystone correction
-Direct power off
nPortability
-Compact notebook-size body
-Ultra-lightweight: 4.6 lbs (2.1 kg)
*1 In comparison with our product
Presentations in Light
Micro Portable XGA LCD Projector
PT-LB20VU
XGA
1600lm

Many people want to use spe-
cial colors and designs in
their presentations, but these
colors change when they’re
projected onto the screen in a lighted
room. So they just use plain, basic colors.
As a result, the presenta-
tion is visually
boring and looks
just like their
competitor’s.
Panasonic
solves this prob-
lem with our
micro-portable pro-
jector featuring
innovative Daylight
View technology. The
PT-LB20VU greatly
improves image per-
formance in brightly lit
places. In fact, the
1,600-lumen brightness
of the PT-LB20VU achieves a level of image
performance that equals many 2,400-
lumen projectors.*1*2
Image Performance Rivaling
2,400-Lumen Projectors
Daylight View technology significantly improves
image performance. Our new 1,600-lumen pro-
jector has attained a level of image performance
that equals or exceeds that of our previous
2,400-lumen models
in brightly lit envi-
ronments.*2
Vivid colors in a Bright Room
Panasonic’s unique Daylight View technology
greatly improves color perception in bright rooms.
Pale colors are divided into six basic color com-
ponents (red, green, blue, yellow, cyan and
magenta) for more precise control. Daylight View
achieves a superb level of image performance
that produces less of a difference between PC
display images and projected images.
Auto Operation with Ambient
Light Sensor
The top panel of the unit is equipped
with an ambient light sensor (ALS). The
ALS detects changes in the ambient
light intensity and optimizes color
compensation in four steps according
to the environment. The Daylight
View mode also provides white bal-
ance adjustment settings for both
fluorescent and incandescent lamps
to match the room lighting.
Ambient Light
Sensor (ALS)
Daylight View
Circuit
LCD Panels
The Daylight View Process
Controls on the top
Daylight View Technology
Conventional
1,600-lumen
projectors
The Panasonic
PT-LB20VU with
Daylight View
Daylight View technology
enables Panasonic projectors to
achieve the same image per-
formance as projectors a class above
them, while consuming less power. This
helps to save energy resources that
would otherwise be wasted.
Colors
turn
whitish
Projector

*1In comparison with our product, under room lighting condi-
tions of 400 lux, when projecting an 80-inch image (meas-
ured diagonally)
*2The Daylight View effect may vary depending on screen size,
screen gain, and surrounding brightness.
*3The projector cannot be placed into a bag until the
cooling fan stops operating.
2-Second Speed Start
Speed Start slashes the time it takes to get your
presentation under way. The image appears with-
in two seconds after you press the power button.
Behind this breakthrough is Panasonic’s high-pre-
cision lamp and lamp power supply—an
advantage made possible by our
advanced production technology.
One-Touch Auto Setup with
Digital Keystone Correction
This function assures quick and easy
setup. The projector handles the basic
image adjustments, from phasing to
vertical and horizontal position. The built-in gravi-
ty sensor detects the projector’s angle relative to
the floor and corrects for vertical keystone distor-
tion accordingly.
Direct Power Off
When the presentation is completed, Direct Power
Off lets you disconnect the power cable and move
the projector right away*3because the cooling fan
keeps operating until the lamp is cooled.
Notebook-Size Compact Body
PT-LB20VU is 11-11/16˝ wide by 8-1/4˝ deep—
about the size of a sheet of paper—and only
2-9/16˝ high. It slips easily into a bag or brief-
case. The compact size makes the PT-LB20VU
highly mobile and minimizes the space required
for presentations or storage.
Ultra-Lightweight: 4.6 lbs (2.1 kg)
At only 4.6 lbs, PT-LB20VU won’t weigh you
down — even when you’re toting along a note-
book PC as well. Convenient size and weight are
just two reasons why the PT-LB20VU is the logi-
cal choice for mobile presentations.
• Short-throw zoom lens
• Anti-theft features: User password, control panel
lock and text superimposing
• Projector AI
• Index Window
• Auto power off
• Two RGB inputs
• RGB 2 IN can be switched to RGB 1 OUT for
loop-through monitoring
• Auto Search
•Automatic input signal detector
• HDTV compatibility
• Full compatibility with sRGB color space for
accurate color reproduction (in natural mode)
• Picture mode selection (standard/dynamic/ natu-
ral)
• Blackboard mode allows you to project images
onto an ordinary classroom or conference room
blackboard
•3x digital zoom
• Freeze
• Shutter function for image/sound muting
• Selectable 17-language on-screen menu
(English, French, German, Spanish, Italian,
Korean, Russian, Chinese, Japanese, Swedish,
Norwegian, Danish, Portuguese, Polish,
Hungarian, Czech, Thai)
•Discrete S-Video and video inputs allow connec-
tion of two DVD/video sources at a time
• Ceiling mountable (option)
•Lamp power high/low selection
• Temperature warning indication
• Lamp replacement warning indication
Quick Operation Portability More Valuable Features
8-1/4˝
(210 mm)
2-9/16˝
(65 mm)
11-11/16˝ (297 mm)
Optional ceiling
mount bracket:
ET-PKB30
Ecology-Conscious Design
Panasonic meticulously works to minimize environmental impact in the prod-
uct design, production and delivery processes, and in the performance of the
product itself over its life cycle. The PT-LB20VU reflects the following ecologi-
cal considerations.
•Lead-free solder is used to mount components to the printed circuit boards.
• No halogenated flame retardants are used in the cabinet.
•No styrofoam is used in the packing materials.
• Lead-free glass is used for the lens.
• The packing case and operating manual are made from recycled paper.

Specifications
Power supply
Power consumption
Amps
LCD panel
Panel size
Display method
Drive method
Pixels
Pixel configuration
Lens
Lamp
Colors
Brightness
Uniformity
Contrast
Scanning frequency
RGB
YPBPR
S-Video/Video
Projection size
Throw distance
Optical axis shift
Keystone correction range
On-screen menu
Installation
Built-in speakers
Terminals
RGB1 IN
RGB signal
100–240 V AC, 50/60 Hz
220 W (Approx. 4 W in standby mode
with fan stopped)
2.5 A–1.3 A
4:3 aspect ratio, micro lens array
0.6˝ (15.24 mm) diagonal
Transparent LCD panel (x 3, R/G/B)
Active matrix
786,432 (1,024 x 768) x 3,
total of 2,359,296 pixels
Stripe
Manual zoom (1:1–1:1.2), manual
focus, F 1.7–1.9, f 21.5–25.8 mm
155 W UHM™ lamp
Full color (16,777,216 colors)
1,600 lumens
90%
400:1*1(full on/full off)
Horizontal: 15–91 kHz,
Vertical: 50–85 Hz
480i (525i): fH15.75 kHz; fV60 Hz
576i (625i): fH15.63 kHz; fV50 Hz
480p (525p): fH31.5 kHz; fV60 Hz
576p (625p): fH31.25 kHz; fV50 Hz
720p (750p): fH45 kHz; fV60 Hz
1080i (1125i): fH33.75 kHz; fV60 Hz
1080i (1125i): fH28.125 kHz; fV50 Hz
NTSC, NTSC4.43, PAL-M, PAL60:
fH15.75 kHz; fV60 Hz
PAL, SECAM, PAL-N: fH15.63 kHz;
fV50 Hz
838–7,620 mm/33–300 inches
diagonally
4´7˝–41´8˝ (1.4 m–12.7 m)
12:1 (fixed)
Vertical: approx. ±30°
17 languages: English, French,
German, Spanish, Italian, Korean,
Russian, Chinese, Japanese, Swedish,
Norwegian, Danish, Portuguese, Polish,
Hungarian, Czech, Thai
Front/rear ceiling/desk
(menu selection)
1.0 W (monaural) output power
D-sub HD 15-pin x 1
R, G, B: 0.7 Vp-p, 75 ohms, Sync on
green: 1.0 Vp-p, 75 ohms
HD/SYNC, VD: TTL (positive/negative
polarity compatible)
YPBPRsignal
RGB2 IN/RGB1 OUT
RGB signal
YPBPRsignal
VIDEO IN
S-VIDEO IN
AUDIO IN
SERIAL
Power cord length
Cabinet material
Dimensions (W x H x D)
Weight
Operating environment
Temperature
Humidity
Remote Control Unit
Power supply
Operation range*3
Dimensions (W x H x D)
Weight
Y: 1.0 Vp-p (including sync signal),
75 ohms; PB, PR:0.7 Vp-p, 75 ohms
D-sub HD 15-pin x 1 (input/output
selectable using on-screen menu)
R, G, B: 0.7 Vp-p, 75 ohms, Sync on
green: 1.0 Vp-p, 75 ohms
HD/SYNC, VD: TTL (positive/negative
polarity compatible)
Y: 1.0 Vp-p (including sync signal),
75 ohms; PB, PR:0.7 Vp-p, 75 ohms
RCA pin x 1, 1.0 Vp-p, 75 ohms
Mini DIN 4-pin x 1,
Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
RCA (L, R) x 1, 0.5 Vrms (for
RGB/VIDEO/ S-VIDEO)
Mini DIN 8-pin x 1 (RS-232C)
6´7˝ (2 m)
Molded material (ABS/PC)
11-11/16˝ x 2-9/16˝ x 8-1/4˝
(297 x 65 x 210 mm)*2
4.6 lbs. (2.1 kg)
32°–104°F (0°–40°C)
20%–80% (no condensation)
3 V DC (button battery x 1)
Approx. 7 m (23 feet) when operated
from directly in front of the signal
receptor
1-9/16˝ x 3-3/8˝ x 1/4˝
(40 x 86 x 6.5 mm)
0.6 oz. (18 g) (including a battery)
Projection Distance
81.2
3-3/16˝
297
11-11/16˝
210
8-1/4˝
73
2-27/32˝
65
2-9/16˝
41.8
1-5/8˝
Unit: mm / inch
–
1.4 m /
1.7 m /
2.1 m /
2.4 m /
2.8 m /
3.1 m /
3.5 m /
4.2 m /
5.2 m /
7.0 m /
8.7 m /
10.5 m /
Diagonal image size
(4:3 aspect ratio)
Distance to screen Height from the
edge of screen
to center of lens
min. max.
33˝
40˝
50˝
60˝
70˝
80˝
90˝
100˝
120˝
150˝
200˝
250˝
300˝
/
/
/
/
/
/
/
/
/
/
/
/
/
4.6´
5.6´
6.9´
7.9´
9.2´
10.2´
11.5´
13.8´
17.0´
22.9´
28.5´
34.4´
1.4 m /
1.7 m /
2.1 m /
2.5 m /
2.9 m /
3.4 m /
3.8 m /
4.2 m /
5.0 m /
6.3 m /
8.4 m /
10.6 m /
12.7 m /
4.6´
5.6´
6.9´
8.2´
9.5´
11.2´
12.5´
13.8´
16.4´
20.7´
27.6´
34.8´
41.7´
4 cm /
5 cm /
6 cm /
7 cm /
8 cm /
9 cm /
11 cm /
12 cm /
14 cm /
18 cm /
23 cm /
29 cm /
35 cm /
1.6˝
2.0˝
2.4˝
2.8˝
3.1˝
3.5˝
4.3˝
4.7˝
5.5˝
7.1˝
9.1˝
11.4˝
13.8˝
0.84 m
1.02 m
1.27 m
1.52 m
1.78 m
2.03 m
2.29 m
2.54 m
3.05 m
3.81 m
5.08 m
6.35 m
7.62 m
/
/
/
/
/
/
/
/
/
/
/
/
/
2.7´
3.3´
4.2´
4.9´
5.8´
6.7´
7.5´
8.3´
10.0´
12.5´
16.7´
20.8´
25.0´
Supplied Accessories
• Card remote control
• Lithium battery for remote control
•Power cord
• RGB signal cable
• Carrying bag
Optional Accessories
ET-LAB10 Replacement lamp unit
ET-PKB30 Ceiling mount bracket
ET-RM300 Full-function wireless remote control
ET-ADSER Serial adapter (DIN 8-pin/D-sub 9-pin)
Dimensions
NOTES ON USE
•The projector uses a high-voltage mercury lamp that contains high
internal pressure. This lamp may break, emitting a large sound, or fail
to illuminate, due to impact or extended use. The length of time that it
takes for the lamp to break or fail to illuminate varies greatly depending
on individual lamp characteristics and usage conditions.
•The brightness of the lamp will gradually decrease with use.
• The lamp, LCD panel, polarizing plate, and polarizing beam splitter
(PBS) are consumable parts. These parts may need to be replaced dur-
ing the guarantee period if the projector is used for six or more hours
per day.
• The replacement cycle of the LCD panel, polarizing plate, and polarizing
beam splitter (PBS) will be shortened if the projector is subjected to
continuous use for six or more hours. Likewise, the replacement cycle
of the lamp will be shortened if the power is frequently turned on and
off or the projector is subjected to continuous use for 10 or more hours.
*1: In AI mode.
*2: Height including protruding parts and legs: 2-27/32˝ (73 mm).
*3: Operation range differs depending on the environment.
Weights and dimensions shown are approximate. Specifications are subject to change without notice. This product
may be subject to export control regulations. UHM is a trademark of Matsushita Electric Industrial Co., Ltd. VGA and
XGA are trademarks of International Business Machines Corporation. Windows and PowerPoint are either registered
trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. All other trademarks
are the property of their respective trademark owners. Projection images simulated.
Please contact Panasonic or your dealer for a demonstration.
Panasonic Broadcast & Television Systems Company
Presentation Systems Group
1 888 843 9788
www.panasonic.com/projectors
Headquarters
1 Panasonic Way, 4E-7
Secaucus, NJ 07094
201 348 5300
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
Canada L4W 2T3
905 624 5010
PT-LB20VU1-05MAR12K Printed in Japan.
Rear View
