Panasonic FZ-N1 Series User manual

Operating I nstructions
Smart Handheld
EB-3901
Tablet Computer
Model No. FZ-N1 series
Licenses/Lizenzen/Licences/Licenze/Licencias/Lisenssit/Licenser/
Licence/Licencie/Licencje/Licenças ................................................... 233
Refer to the Reference Manual by
downloading from the URL below
Beachten Sie das Bedienung-
shandbuch durch den Download von
der folgenden URL
Reportez-vous au Manuel de
référence en le téléchargeant à partir
de l’URL ci-dessous.
Consultare il Manuale di riferimento
scaricabile all’URL indicata sotto
Consulte el Manual de referencia
descargándolo en la siguiente URL
Katso viiteopas lataamalla se alla
olevasta osoitteesta
Se referenshandbok genom att hämta
den via URL-adressen nedan
Nahlédněte do příručky Reference
Manual, která je ke stažení v odkazu
níže
Stiahnite si Referenčnú príručku z
adresy URL uvedenej nižšie a pozrite
sa do nej
Patrz Podręcznik referencyjny, do
pobrania z poniższego adresu URL
Consultar o Manual de Referência
transferindo do URL abaixo
Operating Instructions -
Read Me First ..................... 2
Bedienungsanleitung -
Wichtige Hinweise ............... 23
Instructions d’utilisation -
Lisez-moi ........................... 44
Manuale d’uso -
Leggimi prima ..................... 65
Manual de instrucciones -
Leer antes de usar el producto ... 86
Käyttöohjeet -
Lue tämä ensin ............... 107
Bruksanvisning -
Viktigt .............................. 128
Návod k obsluze -
Čtěte jako první ............... 149
Návod na obsluhu -
Základné informácie ......... 170
Instrukcja obsługi -
Informacje wstępne ......... 191
Instruções de funcionamento -
Ler primeiro ..................... 212
URL:- https://pc-dl.panasonic.co.jp/itn/manual/menu_en.html

2
Operating Instructions - Read Me
First (English)
Introduction
Thank you for purchasing a Panasonic product.
Before operating this product, please read these instructions and
precautions, and save them for future use.
Safety precautions
To reduce the risk of injury, loss of life, electric shock, fire,
malfunction, and damage to equipment or property, always
observe the following safety precautions.
Explanation of symbol word panels
The following symbol word panels are used to classify and
describe the level of hazard, injury, and property damage caused
when the denotation is disregarded and improper use is
performed.
The following symbols are used to classify and describe the type
of instructions to be observed.
Introduction
Safety precautions
Denotes potential hazards that will result
in serious injury or death.
Denotes potential hazards that could
result in serious injury or death.
Denotes potential hazards that could
result in minor injury.
This symbol is used to alert users to specific operating
procedures that must not be performed.
DANGER
WARNING
CAUTION

3Operating Instructions - Read Me First (English)
Battery
This symbol is used to alert users to specific operating
procedures that must be followed in order to operate the
product safely.
This symbol is used to alert users to specific operating
procedures for which special attention is required.
The battery is for use solely with this product. Do
not use it with any other products.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Charge the battery using the specified method.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
Do not throw the battery into a fire or expose it to
excessive heat.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Do not disassemble, modify, or insert sharp foreign
objects into the battery.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Do not short the positive (+) and negative (–)
contacts. Do not carry the battery around or store it
together with necklaces, hairpins, etc.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
DANGER

4
Keep the battery away from extreme heat, such as
fire and direct sunlight.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
Do not expose the battery to water or other liquids.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
Do not throw the battery or subject it to strong
impact such as dropping or applying high pressure.
Electrolyte leakage, overheating, smoke, rupture, or fire
may result.
• Stop using the product if the battery is subjected to
strong impact or if the battery is noticeably damaged
or deformed.
If the battery deteriorates, replace it with a new one.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
Do not directly touch electrolyte that has leaked
from the battery.
Electrolyte may enter the eyes and cause blindness, or
may come into contact with skin or clothing and cause
rashes.
• Flush with clean water without rubbing and seek
medical advice.
WARNING

5Operating Instructions - Read Me First (English)
This product, AC adaptor, and USB connection
cable
Do not place the battery in microwave ovens or
pressurized containers.
Sudden application of heat or pressure may damage the
battery, resulting in electrolyte leakage, overheating,
smoke, rupture, or a fire.
If the battery smells or leaks electrolyte, keep the
battery away from fire.
Failure to do so may result in electrolyte leakage,
overheating, smoke, rupture, or a fire.
When using the product for extended periods, do
not expose your skin to the product or AC adaptor
for a prolonged period.
Generated heat can cause low-temperature burns.
Do not disassemble, repair, or modify the product.
This may cause the battery to short circuit or overheat,
which may result in a fire or electric shock.
Do not insert foreign objects into the product.
This may cause the battery to short circuit or overheat,
which may result in a fire or electric shock.
Do not allow conductive materials such as metal
objects to touch the expansion bus connector.
This may cause a short circuit and overheating, which
may result in battery electrolyte leakage, overheating,
smoke, rupture, or a fire.
WARNING

6
Do not place the product in microwave ovens or
electromagnetic cookers.
Doing so may cause overheating, smoke, or rupture,
which may result in a fire.
Do not expose the AC adaptor or USB connection
cable to water or other liquids.
Doing so may cause a short circuit, generation of heat,
overheating, or rupture, which may result in a fire,
electric shocks, or injury.
• If the product gets wet, immediately unplug the AC
plug, and then contact your technical support
representative.
Do not leave metal objects around or insert them
into the AC adaptor, USB connection cable plug, or
USB port.
Doing so may cause a fire, burn, injury, or electric shock.
Do not touch the product, AC adaptor, or USB
connection cable during lightning storms if the
product is connected to an AC adaptor.
There is a remote chance of electric shock.
Do not turn the volume up too loud when using
headphones, etc.
Listening at high volumes for extended periods may
result in loss of hearing. Also, turn down the volume
before connecting headphones, etc. to prevent sudden
loud sounds.
Keep SD cards and SIM cards out of the reach of
infants and small children.
Small objects are suffocation and choking hazards. In
the event of accidental swallowing, seek medical help
immediately.

7Operating Instructions - Read Me First (English)
Do not operate the product while walking, driving,
riding a bicycle, etc.
Being distracted while engaging in these kinds of
activities can cause accidents or falls.
Do not use headphones, etc. while driving or in
potentially dangerous areas or situations.
Your inability to hear the sounds around you can cause
accidents. Take special care at rail crossings, station
platforms, roads, construction sites, etc.
Use only specified batteries.
Use of unspecified batteries may result in electrolyte
leakage, overheating, smoke, rupture, or a fire.
Immediately stop using the product if any of the
following occurs.
–Product is damaged
–Water or foreign objects enter the product
–Product emits smoke
–Product emits unusual smell or sound
–Product becomes unusually hot
Continuing use may result in a fire or electric shock.
Immediately turn the product off, disconnect it from the
power supply, remove the battery, and then contact your
technical support representative.
Close the headset jack cover and interface cover
when using the product near water or other liquids,
and in areas with a high concentration of moisture,
steam, dust, oily vapors, etc.
Foreign material that enters the product may cause fire
or electric shock. If foreign material enters the product,
turn the product off, disconnect it from the power supply,
and then remove the battery. Contact your technical
support representative for support or repair.

8
Stop using the product immediately and consult
your doctor if you feel any discomfort when staring
at flashing lights on the screen.
A very small percentage of individuals may experience
seizures or blackouts when exposed to certain light
patterns or flashing lights for extended periods.
Do not look directly at the laser beam or point the
barcode reader at another person's eyes.
This may damage the eyes.
Do not do anything that may damage the AC adaptor
or the USB connection cable.
Do not damage or modify the cable, place it near hot
tools, bend, twist, or pull it forcefully, place heavy
objects on it, or bundle it tightly.
Continuing to use a damaged AC adaptor or USB
connection cable may result in a fire or electric shock.
• Contact your technical support representative if any
malfunction occurs.
Clean dust and other debris on the AC plug
regularly.
If dust or other debris accumulates on the plug, humidity,
etc. may cause a defect in the insulation, which may
result in a fire.
• Pull the plug, and wipe it with a dry cloth.
• Pull the plug if the product is not being used for a long
period of time.
Insert the AC plug completely.
If the plug is not inserted completely, fire due to
overheating or electric shock may result.
• Do not use a damaged plug or loose AC outlet.
Do not pull or insert the AC plug if your hands are
wet.
Electric shock may result.

9Operating Instructions - Read Me First (English)
Do not connect the AC adaptor to a power source
other than a standard household AC outlet.
Otherwise, a fire due to overheating may result.
Connecting to a DC/AC converter (inverter) may
damage the AC adaptor. On an airplane, only connect
the AC adaptor/charger to an AC outlet specifically
approved for such use.
Do not use the product near automatic control
equipment such as automatic doors, fire alarms, etc.
RF signals generated by the product may interfere with
the proper operation of such equipment.
Do not leave the product in areas with a high
concentration of moisture, steam, dust, oily vapors,
etc. for extended periods.
Foreign material that enters the product may cause a fire
or electric shock.
Do not move the product while the USB connection
cable is connected.
This may result in a fire or electric shock.
Do not subject the AC adaptor to any strong impact.
Using the AC adaptor after a strong impact such as
being dropped may result in a fire or electric shock.
• Contact your technical support representative if any
malfunction occurs.
Make sure not to charge the product when it is wet.
This may result in a fire or electric shock.
CAUTION

10
Do not leave the product in extremely high
temperature environments for an extended period.
Leaving the product where it will be exposed to
extremely high temperatures, such as near fire or in
direct sunlight, may deform the product or cause
damage or malfunction to its internal components. Using
the product in these conditions may cause short circuit,
insulation defects, etc., which may in turn cause a fire or
electric shock.
Do not expose the skin to the product when using
the product in hot or cold environments.
Burns, low-temperature burns, or frostbite may result. If
direct contact with the skin is necessary, perform the
operation as quickly as possible.
Do not place the product on an unstable surface.
The product may drop, resulting in an injury.
Do not stack the product.
If balance is lost, the product may fall over or drop,
resulting in an injury.
Do not look directly at the light emitter, or point the
flash or barcode reader at another person's eyes.
This may damage the eyes or cause temporary loss of
eyesight which could result in an accident.
Keep away from magnetic sources such as watches
and magnetic cards.
Failure to do so may cause data corruption or device
malfunction.
Use the supplied AC adapter and USB connection
cable.
Failure to do so may result in a fire or electric shock.

11Operating Instructions - Read Me First (English)
For safety purposes, pull the plug when cleaning the
product or if you will not use it for extended periods.
Failure to do so may result in a fire or electric shock.
If the display is damaged, be careful of broken glass
or internal components that may become exposed.
Failure to do so can cause injury.
Take a 10–15 minute break every hour when using
the product.
Using the product continuously for extended periods
may cause strain injuries and may have detrimental
health effects on your eyes, hands, or other parts of your
body.

12
Regulatory informatio n
This product and your health
This product, like other radio devices, emits radio frequency
electromagnetic energy. Because this product operates within the
guidelines found in radio frequency safety standards and
recommendations, we believe this product is safe for use by
consumers. These standards and recommendations reflect the
consensus of the scientific community and result from
deliberations of panels and committees of scientists who
continually review and interpret the extensive research literature.
In some situations or environments, the use of this product may
be restricted by the proprietor of the building or responsible
representatives of the organization. These situations may for
example include:
• Using this product on board of airplanes, or
• In any other environment where the risk of interference to other
devices or services is perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of
wireless devices in a specific organization or environment (e.g.
airports), you are encouraged to ask for authorization to use this
product prior to turning on the product.
Information to the user
We are not responsible for any radio or television interference
caused by unauthorized modification of this product. The
correction of interference caused by such unauthorized
modification will be the responsibility of the user. We and our
authorized resellers or distributors are not liable for damage or
violation of government regulations that may arise from failing to
comply with these guidelines.
Regulatory information

13Operating Instructions - Read Me First (English)
Additional safety precautions
Posted facilities
• Turn off the product when in hospitals, health care facilities, or
any facility where posted notices require you to do so.
Hospitals and health care facilities may be using equipment
that could be sensitive to external RF energy.
Pacemakers
• Medical device manufacturers recommend a minimum
separation of 15 cm between a wireless device and an
implanted medical device, such as a pacemaker or implanted
cardioverter defibrillator, to avoid potential interference with the
medical device.
• Persons with pacemakers:
– Should ALWAYS keep this product more than 15 cm from
their pacemaker when this product is turned ON;
– Should use the ear opposite the pacemaker to minimize the
potential for interference;
– Should not carry this product in a breast pocket;
– Should turn off the product immediately if there is any reason
to suspect that interference is taking place.
Hearing aids
• Some digital wireless products may interfere with some hearing
aids. In the event of such interference, consult the
manufacturer of your hearing aid to discuss alternatives.
Other medical devices
• If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able
to assist you in obtaining this information.

14
Aircraft
• Turn off the product after boarding an aircraft, when instructed
by flight staff. Obey instructions from flight staff regarding the
use of the product in flight. Using this product in an aircraft may
be hazardous to the aircraft’s operation and disrupt wireless
communication, and may also be illegal.
Potentially explosive atmosphere
• Turn off the product in areas where a potentially explosive
atmosphere exists and obey all signs and instructions. Sparks
in such areas could cause an explosion or fire resulting in injury
or even death.
• Areas with potentially explosive atmosphere may include
fueling areas, chemical plants, below deck on boats, fuel or
chemical transfer or storage facilities, vehicles using petroleum
or natural gas, or areas where the atmosphere contains
particles such as grain, dust, or metallic powders, and any
other area where you would normally be advised to turn off
your vehicle engine.
Electronic devices
• This product receives and transmits radio frequency signals
while switched on. Most electronic equipment is shielded from
RF signals. However, certain electronic equipment may not be
shielded against the RF signals from this product. Therefore,
the use must be restricted in certain situations to avoid
interference.
Driving
• Give full attention to driving. Driving safely is your first
responsibility.
• Pull off the road and park before placing or answering a call. It
is unsafe to operate the product while driving.
• Check the laws and regulations in the areas where you drive,
and always obey them.

15Operating Instructions - Read Me First (English)
• Only qualified personnel should install the product in a vehicle.
Check regularly that the product is securely mounted in your
vehicle and operating properly.
• Do not place or install the product in the area over the air bag
or in the air bag deployment area. If the air bag inflates, serious
injury and/or damage could result.
• RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Consult the
manufacturer (or its representative) of the vehicle and any
equipment that has been added to the vehicle regarding the
use of mobile products.
• Use hands-free operation, if available and legally permitted.
Emergency communications
• Never rely solely on a mobile product for essential or
emergency communications. Network connections can be
affected by remaining battery level, radio signals, service
networks, and other conditions, and as a result, emergency
communications cannot be guaranteed in all conditions.
Antenna
• Do not replace the antenna. Unauthorized antennas,
modifications, or attachments could damage the product and
may violate regulations.
• Do not touch or cover the antenna area while the product is on.
Call quality, power levels, and the overall performance of the
product may be affected.
Volume
• Do not turn the volume up too loud when using headphones
and earphones.
• Exposure to excessive sound pressure levels for
extended periods may cause hearing damage.

16
• Being unable to hear sounds in your environment may lead to
accidents.
AC adaptor
• The AC adaptor is used as the main disconnect device. Ensure
that the AC outlet is installed near the product and is easily
accessible.
Laser device caution
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
This product is using lasers that comply with IEC60825-1:2014
regulations.
This product utilizes a “Class 2” laser.
Class 2 laser readers use a low power, visible diode. As with any
very bright light source, such as the sun, the user should avoid
staring directly into the light beam. Momentary exposure to a
Class 2 laser is not known to be harmful.
Caution: Procedures other than those specified herein may result
in hazardous radiation exposure.

17Operating Instructions - Read Me First (English)
Labeling and device location
(The product illustration is shown with the Battery Pack (FZ-
VZSUN110U) installed.)
When the Battery Pack (FZ-VZSUN110U) is installed:
When the Extended Life Battery Pack (FZ-VZSUN120U) is
installed:
Barcode reader

18
Laser radiation information
• Wavelength: 630-680 nm
• Pulse duration: approx. 10 msec
• Repetition rate: approx. 1000/18 Hz
• Maximum power: 1 mW max
• Aiming pattern angle: 48.0° horizontal, 38.0° vertical
Intended use
• This product is not intended for use as, or as part of, nuclear equipment/
systems, air traffic control equipment/systems, aircraft cockpit equipment/
systems, medical devices or accessories
*1
, life-support systems or other
equipment/devices/systems that are involved with ensuring human life or
safety. Panasonic will not be responsible for any liability resulting from the
use of this product arising out of the foregoing uses.
*1 As defined by the European Medical Device Directive
(MDD) 93/42/EEC.
• Panasonic cannot guarantee any specifications, technologies,
reliability, safety (e.g., Flammability/Smoke/Toxicity/Radio
Frequency Emission, etc.) requirements related to aviation
standards and medical equipment standards that differ from the
specifications of our COTS (Commercial-Off-The-Shelf) products.
• This product is not intended for use in medical equipment including life-
support systems, air traffic control systems, or other equipment, devices
or systems that are involved with ensuring human life or safety.
Panasonic cannot be held responsible in any way for any damages or loss
resulting from the use of this unit in these types of equipment, devices or
systems, etc. This product has been designed so as to minimize shock to
the LCD, the leakage of liquid (e.g., water) on to the buttons, etc., but no
warranty is provided against such trouble. Therefore, as a precision
instrument, be extremely careful in the handling of the product.
General information
Caution
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.

19Operating Instructions - Read Me First (English)
Explanation of graphical symbols on nameplate
: Alternating current
: Direct current
: Class II equipment
For Europe
SAR (Specific Absorption Rates)
For body-worn operation, this product has been tested and meets RF
exposure guidelines when used with a Panasonic accessory designated
for this product and when used with an accessory that contains no metal
and that positions the product a minimum of 5 mm from the body.
Use of other accessories may not ensure compliance with RF
exposure guidelines.
The highest SAR value for this product can be found under Reference
Manual of https://pc-dl.panasonic.co.jp/itn/manual/menu_en.html.
Wi-Fi use
Operation of the device in the 5 GHz frequency band is restricted
to indoor use only in the following countries.
AT BE BG CH CY CZ DE DK EE EL ES
FI FR HR HU IE IS IT LI LT LU LV MT
NL NO PL PT RO SE SI SK TR UK
Declaration of Conformity (DoC)
Hereby, Panasonic declares that the radio equipment type FZ-N1
(Model No. FZ-N1EF, FZ-N1EG) is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address:
http://www.ptc.panasonic.eu
Contact to Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany

20
Maximum radio-frequency power transmitted in the frequency bands
*1 For models supporting cellular transmission
Frequency band Maximum transmit
power
Wi-Fi
2.4 GHz TX/RX 2412 MHz - 2472 MHz 18.0 dBm (e.i.r.p.)
Wi-Fi
5 GHz TX/RX 5180 MHz - 5700 MHz 18.0 dBm (e.i.r.p.)
Bluetooth TX/RX 2402 MHz - 2480 MHz 6.0 dBm (e.i.r.p.)
NFC TX/RX 13.56 MHz -16.61 dBuA/m at
10 m
GNSS RX L1 1575.42 MHz (GPS),
1598.0625 MHz - 1605.375
MHz (GLONASS)
-
GSM*1 TX 880.2 MHz - 914.8 MHz,
RX 925.2 MHz - 959.8 MHz 32.0 dBm (Power class 4)
DCS*1 TX 1710.2 MHz - 1784.8 MHz,
RX 1805.2 MHz - 1879.8 MHz 29.5 dBm (Power class 1)
WCDMA
FDD I*1 TX 1922.4 MHz - 1977.6 MHz, RX 2112.4 MHz - 2167.6 MHz 23.0 dBm (Power class 3)
WCDMA
FDD VIII*1 TX 882.4 MHz - 912.6 MHz, RX 927.4 MHz - 957.6 MHz 23.0 dBm (Power class 3)
LTE
Band 3*1 TX 1710.7 MHz - 1784.3 MHz, RX 1805.7 MHz - 1879.3 MHz 23.0 dBm (Power class 3)
LTE
Band 7*1 TX 2502.5 MHz - 2567.5 MHz, RX 2622.5 MHz - 2687.5 MHz 23.0 dBm (Power class 3)
LTE
Band 20*1 TX 834.5 MHz - 859.5 MHz, RX 793.5 MHz - 818.5 MHz 23.0 dBm (Power class 3)
LTE
Band 28*1 TX 704.5 MHz - 746.5 MHz, RX 759.5 MHz - 801.5 MHz 23.0 dBm (Power class 3)
