Touch Panel Driver Software
Installation Manual
ƔPlease read this manual and the instructions for the touch panel carefully to use the
product correctly and safely.
Touch Panel
Model No. TY-TP42P30K
TY-TP50P30K
TY-TP60P30K
TY-TP65P30K
Thank you for your purchase of a Panasonic product.
English

2
Contents
Getting Started...................................................................................................... 3
1. Operating Environment ................................................................................... 4
2. Before Installation ........................................................................................... 4
3. Touch Panel Driver Installation ....................................................................... 5
4. Tpdrv Mouse Emulation Service Installation................................................. 9
5. TouchPanel Setting Program ........................................................................ 13
5-1. Operation Condition Display .................................................................................. 13
5-2. Mode Settings......................................................................................................... 14
5-3. View Settings.......................................................................................................... 17
5-4. Pen Settings ........................................................................................................... 18
5-5. Advanced Settings.................................................................................................. 19
5-6. Calibration .............................................................................................................. 19
5-7. Cursor Adjustment .................................................................................................. 20
6. Uninstallation.................................................................................................. 21
6-1. Windows XP ........................................................................................................... 21
6-2. Windows Vista........................................................................................................ 22
7. Troubleshooting ............................................................................................. 23

3
Getting Started
Thank you for your purchase of the Touch Panel.
To use the product connecting with a Windows XP or Vista computer, the touch panel driver must
be installed.
Install the driver according to this manual.
For Windows7, the driver does not need to be installed.
The touch panel driver enables the output data from the touch panel converted to the protocol
compatible with the Microsoft serial mouse to provide the application program a user interface
equivalent to a mouse. Therefore the existing application can be operated with the touch panel and
touch panel application developments can be carried out using a mouse.
The operation settings for the touch panel can be changed using the setting program.
This manual is intended to the users familiar with Microsoft Windows operations.
For details on the Windows operations, please refer to your Windows manual etc.
Note
1. Any part or all of this manual or driver software may not be copied without the prior consent of
Panasonic Corporation.
2. The contents of this manual or driver software may be changed for improvement without
notice.
3. Panasonic Corporation do not take any responsibilities for any failure of device, data
corruption, or damage caused by these failures due to improper use of this driver software by
the customer or a third party unless the liability is imposed by law.
4. The company and product names mentioned in this manual are the trademarks or registered
trademarks of their respective companies.
5. Every possible care has been taken to prepare this manual however if you ¿nd any mistake or
omission, please contact the address stated at the end of this document.
6. We will exchange any manual with the pages out of order or missing.
Microsoft, Windows XP, and Windows Vista are registered trademarks of Microsoft Corporation
in the USA and other countries.
Other company and product names mentioned in this manual are the trademarks or registered
trademarks of their respective owners.
™ and ® marks are not indicated in this manual.

4
1. Operating Environment
1) Computer: IBM PC/AT compatible with USB port(s) and CD-ROM drive. A model with any of
the following OS.
OS : Microsoft Windows XP 32 bit or 64bit version (SP2 or later), Windows Vista 32 bit
or 64 bit version
2) This product and a pointing device such as a PS/2 mouse which does not use a communication
port can be used concurrently without interfering each other.
3) A USB port must be operating successfully prior to the driver installation.
4) Other applications which use a communication port may not be used concurrently with this
product.
5) Log in to your Windows computer as an "Administrator" at installation or uninstallation.
6) The display or details of the screen may be different depending on the OS version or settings.
2. Before Installation
Installation procedure differs depending on the OS. Please follow the procedures below.
1) Install the touch panel driver.
2) Connect the USB cable for the touch panel to the computer.
Read the Touch Panel Instruction Manual for details on how to connect the cable.
3) Install the Tpdrv Mouse Emulation Service if using Windows Vista.
4) When the computer is restarted, the driver software starts up and the calibration screen
appears.
After the calibration, the touch panel is ready for use.
5) If any older version of the driver has been installed, uninstall the old one before installing the
newer version driver. Refer to "6. Uninstallation" for details on uninstallation.

5
3. Touch Panel Driver Installation
The dedicated installer is supplied for the touch panel driver.
The installation starts when "setup.exe" under the English folder of the supplied CD is started.
Note: If any older version of the driver is installed, uninstall the old one before installing the newer
version driver. Refer to "6. Uninstallation" for details on uninstallation.
To install on a Windows Vista computer, the User Account Control screen appears ¿rst.
Click [Allow].

6
Below is the screen to start up the setup program. Click the [OK] button.
Below is the screen to select the setup directory. Do not change the directory.
Click this button.

7
Below is the screen to select the program group. By default the program will be registered as a
startup program.
For both Windows XP and Windows Vista, the program is registered to "Startup".
This setting enables the driver software starts up automatically when the computer is started so
that the touch panel can be used.
Please note that if the program is registered in other than the Startup group, it will not start up
automatically.
Click [Continue].
Required ¿les will be set up.

8
Installation is completed. Click the [OK] button to complete the installation.
If using Windows XP, restart the computer. The driver software starts the operation after the
computer is restarted.
For Windows Vista, do not restart the computer but perform the installation procedures explained
in "4. Tpdrv Mouse Emulation Service".
When the touch panel driver is used for the first time, the calibration screen appears after the
driver software is started.
After the calibration, the touch panel is ready for use.
Refer to "5-6. Calibration" for more details about calibration.

9
4. Tpdrv Mouse Emulation Service Installation
If using Windows Vista, the Tpdrv Mouse Emulation Service must be installed.
The dedicated installer is supplied for the Tpdrv Mouse Emulation Service.
The installation starts when "setup.exe" under the TpMouEm folder in the English folder of the
supplied CD is started.
When Setup.exe is started up, the User Account Control screen appears ¿rst.
Click [Allow].
Below is the initial screen of the Setup Wizard. Click [Next].

10
Below is the screen to select the installation folder. Do not change the folder.
Click [Next].
Below is the screen to con¿rm installation. Click [Next].

11
Required ¿les will be installed.
Below is the installation completion screen. Click [Close].

12
At the end, a prompt screen for restart appears. Click [Yes] to restart the computer.
The driver software starts the operation after the computer is restarted.
When the touch panel driver is used for the first time, the Calibration screen appears after the
driver software is started.
After the calibration, the touch panel is ready for use.
Refer to "5-6. Calibration" for more details about calibration.

13
5. TouchPanel Setting Program
This software is a setting program to set communication port and to set and calibrate various
operation modes. Changed details will be saved in a setting ¿le so that the changed details are
effective at the subsequence restarts.
Pressing each button will display the corresponding setting window for changing the settings.
Changes for each item will be recorded to the setting ¿le upon closing the window by pressing the
[OK] button and reÀected to the running driver software.
When the [Close] button is pressed, the setting program will be minimized and stored in the
taskbar.
5-1. Operation Condition Display
In the main screen, the communication port number with which the touch panel is connected and
the click mode setting details are displayed.
When the touch panel is connected and the communication is enabled, the display for Port
becomes either "*** Auto Connected" or "*** Connected". When the display is still "Auto
Connecting" or "*** DisConnect" after a while, the connection to the touch panel is failed. Check if
the "Port" setting in "Mode Settings" is set correctly.
Display examples
The communication port is set to "Auto Connect" and the touch
panel is waiting to be connected.
The click mode is set to "Drag".
The communication port is set to "Auto Connect" and the touch
panel is connected. The port is "***".
The click mode is set to "Click on Touch".
The communication port is set to manual connection (other than Auto
Connect) of "***" and the touch panel is connected to the set port.
The click mode is set to "Drag".

14
5-2. Mode Settings
1) Port
Sets the communication port used for the touch panel connection.
If Auto Connect is selected, the driver software detects the port automatically to set. If the
automatic connection cannot be performed, select the communication port which is connected.
The default setting is "Auto Connect".
2) Click Mode
Selects the input mode for the touch panel. The relationship between the touch input and mouse
button pressing can be set. The default setting is "Drag".
1Drag
Touching operation to the panel is set as pressing down (button down) of the left mouse button and
lifting the ¿nger off the panel is set as releasing (button up) of the left mouse button.
Therefore when the ¿nger is lifted off the panel, a click event occurs. When the ¿nger is travelling,
the mouse cursor emulates the movement and drag operation can be performed.
Button down Drag Button up
Click event occurs

15
2Click on Touch
Touching operation to the panel is set as single clicking (button down/button up) of the left mouse
button.
When the ¿nger touches the panel, a click event occurs.
Button down
Button up
Click event occurs
No change No change
3Click on Release 1
When the ¿nger is lifted off the panel, a click event occurs. While the ¿nger is touching the panel, a
button down event will not occur.
No change No change Button down
Button up
Click event occurs
4Click on Release 2
When a ¿nger touches the panel, a button down event occurs and when the ¿nger is lifted off the
touch panel, a click event occurs. While the ¿nger is travelling, the cursor does not emulate the
movement.
Button down No change Button up
Click event occurs

16
3) Click Correction
Sets the click correction method. The default setting is "Normal".
The click area may be narrow and dif¿cult to click by touching depending on the application being
used. In this case, set Click Correction to "Special" so that the button down and button up positions
can be consistent under certain conditions and the click will be easily recognized.
Normal: Use this setting when handwriting characters etc. Usually use this setting.
Special: Use this setting for operations in a small click area made by HTML etc.
4) Double Click Correction
Sets the double click correction method. The default setting is "Normal".
Normal: Use this setting when handwriting characters etc. Usually use this setting.
Special: Use this setting to use double clicking mainly.
5) Correction Time
Sets the time to recognize the Click Correction and Double Click Correction. The setting can be
made in 0.2 second increment from 0.2 to 1.0 second. The default setting is "0.4 second".
To change this setting, set the Double-click speed to "Slow" (move the slide bar to the leftmost) in
Mouse Properties of the Control Panel.
Click : Sets the time from button down to button up.
Double click: Sets the time from the first touch to the second touch and lets the program to
recognize as a double click when the second touch is performed within the set
time.
6) Correction Area
Sets the effective area for clicking and double clicking. Setting to "Wide" makes the area wide and
"Narrow" makes it narrow. The default setting is "Normal".
Click : Sets the effective area from button down to button up.
Double click: Even when the ¿rst touch (click) and the second touch (click) are slightly apart, the
operations are recognized as a double click.

17
5-3. View Settings
1) Right Button Tool
Use this setting to perform the right mouse button operation with the touch panel. The default
setting is "Off".
On: Displays the Right Button Tool.
Off: Does not display the Right Button Tool.
When the Right Button Tool is touched, the next touch input will be operated as a right mouse
button down. After this, the operation returns to the normal left mouse button operation.
Display for left mouse button operation
On touch input, normal left mouse button operation is performed
according to the "Click Mode" setting.
Display for right mouse button operation
On touch input, a right mouse button operation is performed
according to the "Click Mode" setting.
2) Touch Error Noti¿cation
Use this setting to display a warning when an object is placed on the screen while the touch panel
is used. The default setting is "On".
On: Noti¿es error warnings.
Off: Does not notify error warnings.
3) Hide When Minimized
Use this setting to store the TouchPanel Setting Program in the task tray when it is closed. The
default setting is "Off".
On: Stores the TouchPanel Setting Program in the task tray.
Off: Leaves the TouchPanel Setting Program on the task bar.

18
5-4. Pen Settings
Pen Settings should be set only when a separately purchased electronic pen is used.
To use an electronic pen, refer to the instruction manual for the electronic pen for details.
1) Input Mode
Selects the input mode either to use handwriting or electronic pen. The default setting is "Normal".
Normal : The touch panel switches between the handwriting and electronic pen modes
automatically.
This is the normal mode.
Handwriting: Use this setting to input without using an electronic pen (such as ¿nger).
Use the "Normal" setting, when an electronic pen is used.
Pen : To input only with an electronic pen. Use this setting to disable any operations
without an electronic pen.
2) Touch Pen Switch
Sets the function switch of an electronic pen. The default setting is "Right Button".
Off : The function switch of the electronic pen does not work.
Right Button: Touching the display while pressing the function switch performs a right mouse
button click.
3) ID Setting
Synchronizes the ID set on the electronic pen with the touch panel driver. This setting is used to
prevent electronic pen errors in a case such as two touch panels are used side by side. The default
setting is "ID Prohibition".
ID Prohibition: Accepts any signal without checking the ID on the electronic pen.
No. 1 - 4 : Accepts only the signal from the electronic pen for which the same ID is set.
4) ID Display
When a signal from the currently used electronic pen is detected, the ID set on the electronic pen
is displayed.
For usage such as how to set an ID of electronic pen etc., refer to the instruction manual for the
electronic pen.

19
5-5. Advanced Settings
1) Calibration Mode
Sets the calibration mode. The default setting is "Normal".
Normal: Use this setting to have normal display for screen resolution and display method.
Special: Use this setting to display a special screen such as enlarged screen display or cutout
enlargement.
Corner : Use this setting to set the calibration target position for the "Normal" setting to a corner.
5-6. Calibration
Calibration (alignment) is performed to emulate the mouse cursor correctly to the touched position.
The calibration screen appears automatically when the touch panel is connected to the computer
when the driver is started up for the ¿rst time (restart after installation).
Touch the center of the targets displayed on the screen in order according to the instructions on
the screen. 3 target points are displayed.
To stop the calibration, press any key on the keyboard.
Once the calibration has performed the calibration values are saved in the setting ¿le. There is
no other calibration required as the calibration values are loaded from the setting ¿le at the next
startup.

20
5-7. Cursor Adjustment
Usually a calibration makes the touched position and the mouse cursor position synchronized.
However, when ¿ne-tuning is required due to disparity or other reason use these buttons.
