“WARNING:

TO

PREVENT

FIRE

OR

SHOCK

HAZARD,

DO

NOT

EXPOSE

THIS

APPLIANCE

TO

RAIN

OR

MOISTURE.”

Technics

by

Panasonic

DIRECT

DRIVE

AUTOMATIC

PLAYER

SYSTEM

SL-1300

OPERATING

INSTRUCTIONS

Read

these

instructions

completely,

before

operating

this

set.

We

want

to

thank

you

for

selecting

the

SL-1300,

DIRECT

DRIVE

AUTOMATIC

PLAYER

SYSTEM.

For

optimum

performance,

we

recommend

that

you

read

these

instructions

carefully.

1

PARTS

IDENTIFICATION

AND

OPERATION

OF

FUNCTIONS

@AC

power

plug

@Hinges

OTransit

screws

(for

transformer)

@Screwing

holes

for

transit

screws

@Motor

shaft

(turntable

shaft)

@Strobo

illuminator/pilot

lamp

@Speed

selector

@Variable

pitch

controls

@Speed

adjustment

screws

Turntable

platter

@Turntable

sheet

@Strobo

dots

@Strobo

mark

@Tonearm

return

adjustment

screw

@Stylus

set-down

adjustment

screw

Output

terminals

@Arm

itt

Arm

lift

adjustment

screw

®Balance

weight

@Stylus

pressure

ring

@Anti-skating

force

contro!

knob

@Arm

rest

@Arm

clamp

@Cueing

lever

@MEMO-REPEAT

knob

@Record

size

selector

@Start/stop

lever

@Locking

nut

@Head

shell

@

AC

POWER

PLUG

Never

connect

the

AC

power

plug

until

assembly

has

been

completed!

center

of

the

arm

lift

bar.

Pushing

down

on

this

curved

bar

will

make

the

screw

accessible.

Clockwise

rotation

...Arm

height

lowers.

Counterclockwise

rotation...Arm

height

raises.

@

STROBO

ILLUMINATOR/PILOT

LAMP

@

ANTI-SKATING

FORCE

CONTROL

This

dual-function

illuminator

is

lit

only

when

the

player

is

“on”

and

the

turntable

platter

is

rotating.

VARIABLE

PITCH

CONTROLS

Turn

this

knob

clockwise

or

counterclockwise,

as

necessary,

to

reduce

or

increase

the

rotational

speed

of

the

turntable.

Clockwise

rotation

..

This

increase

the

speed

of

the

turntable

(+

direction)

platter.

Rotate

clockwise

if

the

strobo

dots

seem

to

be

“falling

back”;

i.e.,

seem

to

be

moving

counterclockwise.

When

the

dots

appear

to

be

stationary,

turntable

speed

is

accurate.

Counterclockwise

rotation

.

This

decreases

the

speed

of

theturn-

(=

direction)

table

platter.

Rotate

counterclockwise

it

the

dots

seem

to

be

“running

ahead”:

j.e.,

seem

to

be

moving

clockwise,

until

they

appear

stationary.

Each

of

the

two

turntable

speeds

(33-1/3

and

46

r.p.m.)

can

be

adjusted

within

a

range

of

10%

SPEED

ADJUSTMENT

SCREWS

If,

for

any

reason,

the

adjustment

cannot

be

successfully

made

by

the

variable

pitch

controls,

turn

these

screws

clockwise

or

counterclockwise

with

a

(—),

tip

screw

driver.

Clockwise

The

rotation

of

the

turntable

platter

will

be

slowed

down.

Counterclockwise...

The

rotation

will

be

speeded

up.

After

the

adjustment

has

been

made,

the

speed

will

not

change

and

re-adjustment

will

not

be

necessary.

@

TURNTABLE

PLATTER

The

turntable

platter

of

this

set

also

works

as

part

of

the

rotor

of

the

motor.

Never

remove

the

turntable

platter

unnecessarily.

Never

stick

dust

or

iron

filings

to

adhere

to

the

magnet

rotor.

@

STROBO

DOTS

These

strobo

dots,

set

on

the

tapered

rim

of

the

turntable

platter

to

make

strobo

reading

easier,

are

divided

into

four

and

45

r.p.m.)

at

50

Hz

and

60

Hz

AC

as

follows

45

r.p.m.

at

0

Hz

93-1/3

r.p.m.

at

50

Hz

45

r.p.m.

at

60

Hz

33-1/3

r.p.m.

at

60

Hz

@

TONEARM

RETURN

ADJUSTMENT

SCREW

In

some

cases,

the

tonearm

will

tend

to

return

to

its

rest

position

before

the

record

has

finished

playing.

In

other

cases,

it

will

to

return

to

the

rest

position

even

after

the

record

has

finished

Rotation

of

this

screw

in

the

proper

direction

will

correct

either

condition.

Clockwise

rotation

...The

tonearm

will

return

to

rest

lat

Counterclockwise

rotation...The

tonearm

will

return

to

rest

ear-

@®

STYLUS

SET-DOWN

ADJUSTMENT

SCREW

To

be

adjusted

if

the

tonearm

fails

to

set

down

at

the

right

start-

ing

point

at

the

beginning

of

the

record.

For

access

to

the

screw,

a

rubber

cap

above

it

must

be

removed.

Clockwise

rotation

...This

will

move

the

set-down

point

out-

ward,

away

from

the

record

center.

Counterclockwise

rotation...This

will

move

the

set-down

point

inward

toward

the

record

center.

®

ARM

LIFT

ADJUSTMENT

SCREW

When

the

tonearm

is

removed

from

the

record

surface

via

the

tonearm

lift,

the

space

between

the

stylus

tip

and

the

record

surface

should

be

between

5

and

10

mm

(between

3/16”

and

25/64"),

If

this

height

needs

adjustment,

turn

the

screw

along

the

KNOB

Turn

this

knob

to

the

same

number

as

the

stylus

pressure

ring

indicates.

Skating

force

is

the

frictional

force

caused

by

contact

between

the

tip

of

the

stylus

and

the

record

groove,

and

is

applied

to

the

stylus

as

a

side

pressure

depending

upon

the

relationship

of

the

geometrical

position

of

the

tonearm.

This

force

results

in

an

unbalance

of

the

contact

pressure

be-

tween

the

stylus

tip

and

each

groove

wall

of

the

record,

an

increase

of

distortion,

a

decrease

of

separation

characteristics

and

abnormal

wear

of

the

stylus

tip

and

the

record

grooves.

For

this

reason,

it

is

necessary

to

compensate

this

skating

force.

This

anti-skating

force

mechanism

performs

this

compensation

function.

The

quantity

of

anti-skating

force

is

in

proportion

to

the

stylus

pressure

and,

therefore,

it

should

be

adjusted

according

to

the

stylus

pressure.

@®

ARM

CLAMP

Be

sure

to

release

the

arm

clamp

before

operating

the

start/

stop

lever.

@

CUEING

LEVER

Move

this

lever

downward

or

upward,

then

the

tonearm

will

descend

or

ascend

on

the

record

surtac

Downward

movement...

The

tonearm

will

descend

slowly

on

the

record

surface

and

resume

playing

in

the

same

groove.

The

tonearm

will

raise

from

the

record

surface

and

interrupt

playing.

@®

MEMO-REPEAT

KNOB

Set

this

knob

to

the

desired

number

of

times

you

want.

(R)

is

continuous

play.

@

RECORD

SIZE

SELECTOR

Set

this

knob

to

the

diameter

of

the

record

to

be

played.

@

START/STOP

LEVER

Pull

this

lever

for

automatic

start

and

stop

functions,

NOTE

If

the

MEMO-REPEAT

knob

is

set

to

the

other

positions

than

(0),

then

the

unit

will

not

shut

off

and

will

continue

playing

until

the

times

which

you

set.

2

BEFORE

USING

@

CHECK

THE

PARTS

Player

unit

i

e

Turntable

platter

F

:

Turntable

sheet

Dust

cover.

45

r.p.m.

adaptor

Special

oi

(~)

tip

screw

driver

Screws

(for

cartridge)

(long).

Screws

(for

cartridge)

(short)

Auxiliary

weight

@

REMOVE

THE

TRANSIT

SCREWS

Remove

the

two

screws

for

transformer

and

place

them

in

the

screwing

holes

for

future

use,

as

when

the

player

must

again

be

transported.

@

APPLY

TWO

OR

THREE

DROPS

OF

OIL

TO

THE

MOTOR

SHAFT

To

lubricate,

open

the

tip

of

the

vessel

with

a

needle,

and

apply

two

or

three

drops

of

oil

to

the

motor

shatt.

(See

Fig.

1)

@

REMOVE

THE

PROTECTING

COVER

OF

THE

ROTOR

OF

THE

TURNTABLE

PLATTER

NoTE

NEVER

CONNECT

THE

AC

POWER

PLUG

UNTIL

THE

ASSEMBLY

HAS

BEEN

MADE!

Upward

movement,

3

HOW

TO

ASSEMBLE

INSTALLATION

OF

THE

TURNTABLE

PLATTER

Install

the

turntable

platter

to

the

motor

shaft.

Place

the

turntable

sheet

on

the

turntable

platter.

NOTE

This

set

is

especially

designed

for

a

direct

drive

player

system.

Therefore,

the

rotor,

which

is

rotating

part

of

the

motor,

is

con-

nected

directly

to

the

turntable

platter.

(The

magnet

of

the

motor

is

attached

to

the

turntable

platter),

For

this

reason,

to

maintain

the

high

performance

described

in

the

specifications,

care

should

be

taken

to

prevent

any

dust

or

iron

filings

from

getting

into

and

adhering

to

the

magnet.

Also

avoid

dropping

the

turntable

platter

onto

a

hard

surface,

as

this

may

break

the

magnet.

INSTALLATION

OF

THE

CARTRIDGE

Connect

the

lead

wires

to

the

cartridge

terminals.

White

(L

+)...Left

channel

+

Red

(R

+)...

Right

channel

+

Blue

(L

-)...Left

channel

—

Green

(R

—)

Right

channel

—

‘Overhang

adjustment

Screw

f

wi

Za

Shell

spacer

Cartridge

;

==

Screws

s

Fig.

2

Install

the

cartridge

to

the

spacer,

and

tighten

it

with

screws.

Adjust

the

overhang

position

so

that

the

spacing

between

the

stylus

tip

and

the

plug

is

52

mm

(2-1/16").

(See

Fig.

2,

3)

Insert

the

head

shell

in

the

end

of

the

tonearm,

and

secure

firmly

by

turning

the

locking

nut.

Overhang

adjustment

screw

Plug

—

—

Stylus

tip

52

mm

(241/16)

|

sa

ADJUSTMENT

OF

THE

HORIZONTAL

BALANCE

Insert

the

balance

weight

on

the

rear

shaft

of

the

tonearm

by

turning

the

balance

weight.

Release

the

arm

clamp,

and

turn

the

balance

weight

forward

or

backward

until

the

tonearm

is

approximately

balanced

(stylus

pressure

is

“O").

(See

Fig.

4)

‘When

horizontally

balanced,

set

the

stylus

pressure

ring

to

“O

position,

pushing

gently

with

fingers,

so

that

the

balance

weight

is

not

moved.

(See

Fig.

5)

Fig.

3

Turn

the

balance

weight

forward

to

set

the

stylus

pressure

ring

to

the

proper

stylus

pressure

of

which

you

use.

NOTE

If

the

weight

of

the

cartridge

is

over

8.5g,

mount

the

auxiliary

weight

to

the

rear

shaft

of

the

tonearm.

Stylus

pressure

ring

moves

to

gear

with

balance

weight

so

that

it

is

possible

to

set

the

stylus

pressure

ring

tothe

desired

position

by

turning

the

balance

weight.

Arm

rest

Balance

weight

Arm

clamp

Rear

shaft

Arm

pipe

Cueing

lever

ADJUSTMENT

OF

THE

ANTI-SKATING

FORCE

Turn

this

knob

to

the

same

number

as

the

stylus

pressure.

INSTALLATION

OF

THE

DUST

COVER

Raise

the

dust

cover

upward

and

place

it

securely

in

the

hinges.

NOTE

(See

Fig.

6)

We

recommend

that

you

take

off

the

dust

cover,

if

the

dust

cover

becomes

the

cause

of

“HOWLING”

from

the

vibration

of

the

speakers.

Dust

cover

4

PLACEMENT

©

Use

the

player

in

a

stable

and

horizontal

position,

where

there

Is

little

or

no

vibration.

@

Use

the

player

as

far

away

from

the

speakers

as

possible

and

isolate

the

player

from

sound

radiation

from

them.

This

player

is

equipped

with

audio-insulators

and

designed

for

the

utmost

absorption

of

vibration.

I

the

speakers

are

placed

too

near

the

player,

sound

vibration

may

be

transmitted

to

the

tonerarm

and

result

in

“HOWLING

Place

the

player

as

far

away

from

the

speakers

as

possible.

©

Do

not

place

the

player

where

it

is

exposed

to

direct

sun,

dust

or

moisture.

Also

keep

away

from

heating

equipment

in

order

to

protect

the

dust

cover.

5

CONNECTIONS

CONNECT

TO

THE

AC

POWER

SOCKET

Connect

the

AC

power

plug

to

the

AC

socket

of

120V.

This

set

is

designed

to

be

used

at

AC

120V.

Never

connect

to

the

DC

power

socket

or

other

voltage

socket

I

you

connect

the

power

plug

to

the

AC

outlet

such

as

amplifiers

have,

confirm

the

voltage

and

wattage

of

rating

at

the

outlet

CONNECT

TO

THE

AMPLIFIER

Connect

the

output

terminals

to

the

same

channels

of

the

ampli-

fier

OUTPUT

TERMINALS

AMPLIFIER

R

(U-shaped)

—

EMM

Channel

L

(White)

==

——

[EEE

Channel

E

(U-shaped)

—

NT}

NOTE

Be

sure

to

connect

the

ground

terminal

to

the

ampli

chassis,

Mf

this

connection

is

incomplete,

a

power

source

"HUM"

will

result,

6

OPERATION

AUTOMATIC

PLAYING

Release

the

arm

clamp,

so

that

the

tonearm

becomes

free

from

the

arm

rest.

Set

the

MEMO-REPEAT

knob

to

the

“0”

position.

“R”

position

is

continuous

repeat

play.

Set

the

record

size

selector

to

the

diameter

of

the

record

you

wish

to

play.

Set

the

speed

selector

in

the

same

manner

as

for

record

size

selector.

Pull

the

start/stop

lever

to

the

start

position,

then

playing

will

start

automatically.

(See

Fig.

7)

When

playing

has

finished,

the

tonearm

will

return

to

its

rest

and

the

unit

will

shut

off

automatically.

jer

or

to

the

MEMO-REPEAT

knob

Start/stop

lever

Fig.

7

MANUAL

PLAYING

Release

the

arm

clamp

and

raise

the

cueing

lever.

(See

Fig.

8)

Place

the

tonearm

over

the

lead-in

groove,

causing

the

turntable

platter

to

rotate.

Lower

the

cueing

lever,

then

the

tonearm

will

descend

to

the

record

surtace

slowly

and

playing

will

begin.

When

playing

has

finished,

the

tonearm

will

return

to

its

rest

and

the

unit

will

shut

off

automatically

Of

course,

it

is

possible

to

return

the

tonearm

to

its

arm

rest

‘manually,

then

the

unit

will

shut

off

automatically.

5-10

mm

(3/16”-25/64")

Cueing

lever

Cueing

lever

(Descend)

Fig.

8

TO

INTERRUPT

PLAYING

Raise

the

cueing

lever,

then

the

tonearm

will

ascend

and

inter-

rupt

playing.

It

you

lower

the

cueing

lever,

the

tonearm

will

descend

slowly

on

the

record

and

resume

playing

in

the

same

groove.

7

NOTES

@

BE

SURE

TO

RELEASE

THE

ARM

CLAMP

BEFORE

OPERATING

THE

START/STOP

LEVER

@

OPERATE

BY

MANUAL

FUNCTION

EXCEPT

FOR

STANDARD

SIZE

(17,

25,

30

cm),

(7",

10”,

12")

The

stylus

set-down

point

of

this

set

is

adjusted

for

standard

record

sizes

only.

©

DO

NOT

GRASP

OR

HOLD

THE

TONEARM

WHILE

AUTOMATIC

MECHANISM

IS

OPERATING

@

DO

NOT

CONNECT

THE

AC

POWER

PLUG

OR

TURN

THE

SWITCH

ON

(THE

STROBO

ILLUMINATOR/PILOT

LAMP

IS

LIT)

WHILE

REMOVING

TURNTABLE

PLATTER

For

any

reason,

if

you

remove

the

turntable

platter.

be

sure

to

disconnect

the

AC

power

plug

or

turn

the

switch

off

(The

strobo

illuminator/pilot

lamp

is

not

lit)

@

NEVER

REMOVE

THE

TURNTABLE

PLATTER

UNNECCESSARILY

The

turntable

platter

of

this

set

also

plays

the

part

of

the

rotor

of

the

motor.

Never

remove

the

turntable

platter

unneccessarily.

This

results

in

a

deterioration

of

characteristics

caused

by

at-

tracting

dust

or

iron

filings

to

the

magnet

rotor

8

MAINTENANCE

@

WIPE

THE

DUST

COVER

WITH

ONLY

A

SOFT,

DRY

CLOTH

Do

not

use

any

cleaner

containing

alchol,

benzine

or

thinner.

if,

for

any

reason,

oil

adheres

to

the

dust

cover,

first

discon-

nect

the

AC

power

plug

or

remove

the

dust

cover

and

wipe

the

dust

cover

with

a

cloth

containing

water,

@

APPLY

TWO

OR

THREE

DROPS

OF

OIL

TO

THE

MOTOR

SHAFT

Disconnect

the

AC

power

plug

and

remove

the

turntable

platter.

Lubricate

two

or

three

drops

of

oil

to

the

turntable

shat.

It

is

sufficient

to

lubricate

the

set

once

ater

approximately

2000

hours

of

use.

This

period

is

much

longer

than

the

ordinary

motors,

so

do

not

apply

too

much

oil,

nor

more

frequent

than

neccessary.

NOTE

Never

use

any

other

type

of

oil

The

bearing

parts

of

this

set

are

designed

with

an

ultra-precise

finish

to

prevent

the

generation

of

"WOW

and

FILUTTER”

A

special

oil

has

been

used

to

maintain

the

high

performance

jency

of

this

set

by

forming

a

uniform

film

of

oil

over

the

parts.

For

this

reason,

use

only

the

oil

included

with

this

set

for

its

lubrication

BPRS

EAM

GIRLS

LE

ISLS

RSIS

LS

MSI

V

SPSS

MS

MSDS

DGD

DDR

Ds

Des

DA DA

De

Dis

SDS

LACUS

LLL

LS

LS

VSI

9

SPECIFICATIONS

(TURNTABLE

SECTION)

Type

...Automatic

player

system

with

MEMO-REPEAT

Driving

method

Direct

drive

Motor

Ultra

low

speed

brushless

OC

motor

‘Turntable

platter

Aluminium

die-cast;

33

em

(13")

diameter

250

kg-cm?

(86.2

Ib-in?)

inertial

moment,

1.75

kg

(3.86

Ib)

weight

Turntable

speeds.

33-1/3

and

45

r.p.m.

‘Speed

change

method

.....

Electronic

change

Variable

pitch

controls

......Individual

adjustment

by

variable

resistor,

10%

adjustment

range

0.03%

(W.R.M.S.)

=50

dB

(DIN

A),

70

d8

(DIN

B)

Wow

and

flutter

Rumble

(GENERAL)

Power

supply

120

V,

50/60

Hz

Power

consumption

aw

6.5W

(While

automatic

mechanism)

is

operating

)

Dimensions

45.3

*36.6

X

13.9

cm

(W

xD

XH)

(17-3/8"

*

14-3/8"

5-1/2")

(WxDxH)

Weight

9.4

kg

(20.7

Ib)

(Ss

(TONEARM

SECTION)

Type

nee

Universal

“S"

shaped

pipe

arm,

static-balanced

type,

direct

read-

ing

stylus

pressure

adjustment,

with

anti-skating

force

contro!

device,

cueing

device

230

mm

(9-1/16")

«15

mm

(19/32

Within

+3°

(at

the

point

150

mm

(-1/8")

from

the

center)

+1*

(at

the

point

55mm

(2-3/16")

from

the

center)

Effective

length

Overhang

Tracking

error

angle

Offset

angle

eee

to

Adjustable

stylus

pressure...0-3

g

Cartridge

range

45-99

8.5-13

g

(with

auxiliary

weight)

Head

shell

weight

959

10

FEATURES

(TURNTABLE

SECTION)

@

TURNTABLE

PLATTER

ITSELF

THE

ROTOR

OF

THE

MOTOR

The

direct

drive

principle

innovated

by

TECHNICS,

which

has

altered

the

course

of

turntable

development,

has

now

been

car-

ried

a

step

further.

Not

only

does

the

SL-1300

feature

automatic

player

system,

but

it

incorporates

an

ingenious

redesign

of

the

direct

drive

motor

itself.

The

result

is

to

connect

the

motor

to

the

turntable

platter

directly,

of

course,

there

is

no

reduction

or

transmission

mechanism

such

as

a

belt

or

idler.

The

turntable

platter

itself

is

part

of

the

motor.

In

addition,

the

motor

rotates

at

the

same

speed

of

the

records.

Wear

of

parts

is,

therefore,

reduced

to

the

extreme

minimum,

and

high

performance

can

be

maintained.

Thus,

there

is

no"

WOW

and

FLUTTER"

caused

by

a

transmission

mechanism.

There

is

no

vibration

because

this

motor

has

no

high

speed

rotation

mechanism.

The

rumble

is

extremely

low.

@NO

EFFECT

FROM

FLUCTUATIONS

OF

THE

POWER

SUPPLY

FREQUENCY

Since

the

motor

is

the

OC

brushless

motor,

the

rotation

speed

does

not

depend

on

the

power

supply

frequency.

And,

the

motor

power

consumption

is

only

0.1

W,

which

is

less

than

1/100th

that

of

a

conventional

AC

motor,

theretore,

there

is

no

effect

from

electro

magnetic

vibration.

@

ELECTRONIC

STABILIZATION

CONTROL

This

set

includes

special

circuitry

to

stabilize

the

speed

electri-

cally.

Speed

stability

is

extremely

good.

@

NEW

AUTOMATIC

PLAYER

SYSTEM

CAN

BE

OPERATED

FIVE

FUNCTIONS

This

player

system

features

such

operations

as

auto-lead

in,

auto-return,

auto-cut,

auto-repeat

and

manual

operation.

And,

MEMO-REPEAT

mechanism

is

an

especially

outstanding

feature.

A

record

may

be

played

once

or

up

to

five

times—or

repeated

indefinitely.

This

unique

function

is

not

matched

by

any

other

type

of

repeat-play

record

system

in

a

home

player

Just

set

the

MEMO-REPEAT

knob

to

the

desired

number.

@

SMOOTH,

FEATHER-TOUCH

MECHANISM,

IN

COMBINATION

WITH

PRECISION

PARTS

AND

INGENIOUS

CONSTRUCTION

The

automatic

mechanism

uses

precision

molded

plastic

parts,

in

order

to

avoid

the

noise

caused

by

automatic

operation.

In

addition,

each

operation

knob

is

finished

precisely,

so

it

can

be

operated

by

a

feather

touch.

‘And,

there

is

no

skipping

or

skating

caused

by

operation.

@EASY-VIEW

STROBO

‘Two

sets

of

strobo

dots

appear

on

the

tapered

rim

for

33-1/3

and

45

r.p.m.

at

both

50

and

60

Hz

synchronization,

with

either

type

of

AC

source.

The

prism

strobo

illuminator

lights

when

switch

is

on,

thus

serving

as

a

pilot

lamp.

The

combination

of

prism

lamp

and

tapered

strobo

rim

results

in

easy

viewing

from

any

position.

@

ALUMINIUM

DIECAST

BASE

The

appearance

of

the

SL-1300

is

enhanced

by

the

attractively

styled

die-cast

aluminium

base

and

compact

finish.

(6)

@

EFFICIENT,

LOW-POWER

OPERATION

The

motor

power

consumption

is

only

0.1

W

and

total

power

consumption

is

less

than

4

W.

(While

automatic

mechanism

is

operating

is

6.5W)

This

is

most

important

in

terms

of

longer

life

and

reliability.

That

is

more

than

the

saving

of

a

few

pennies

of

electrical

power,

but

means

less heat,

less

vibration,

less

stress

on

the

control

circuitry

and

less

evaporation

of

lubricants.

The

result

is

not

merely

longer

motor

life,

which

may

be

a-

chieved

in

other

direct

drive

designs,

but

longer

life

of

the

entire

component

assembly.

(TONEARM

SECTION)

@

HIGH

QUALITY

UNIVERSAL

TONEARM

This

tonearm

is

especially

designed

for

the

SL-1300,

using

four

pairs

of

pivot

bearings

to

enhance

the

rotational

sensitivity

of

the

gimbal-suspended

type.

Thus

it

can

accept

any

cartridges,

stylus

pressure

of

which

is

at

0.25

gram.

@

SIMPLE

AND

EASY

STRUCTURE

OF

THE

HEAD

SHELL

The

head

shell

is

finished

of

die-cast

aluminium

to

prevent

vibration.

‘The

structure

of

this

shell

is

simple,

so

that

the

installation

of

the

cartridge

and

the

adjustment

of

the

overhang

are

easy

and

fool-

proot.

@

LOW-CAPACITANCE

PHONO

CABLES

High-frequency

audio

losses

are

eliminated

and

discrete

4-chan-

nel

(CD-4)

records

can

be

played

through

a

suitable

cartridge

with

no

deterioration

in

carrier

frequencies.

@

FEATHER-TOUCH

CUEING

Feather-touch

cueing

is

viscous-damped

in

both

directions

for

gentle

descent

and

ascent.

The

tonearm

will

be

set

down

exactly

on

the

groove

you

desired,

thus

protecting

the

stylus

tip

from

damage.

@EASY

ADJUSTMENT

OF

STYLUS

PRESSURE

The

stylus

pressure

adjustment

is

easy

because

of

helical

type

‘of

movement,

just

turning

the

balance

weight

can

adjust

the

stylus

pressure

accurately.

@

PRECISION

ANTI-SKATING

FORCE

CONTROL

DEVICE

By

precision

design,

the

inside

force

is

canceled

accurately.

Matsushita

Electric

Corp.

of

America

Pan

Am

Bldg.,

200

Park

Ave.,

New

York

Matsushita

Electric

of

Hawaii,

Inc.

320

Waiakamilo

Road,

Honolulu,

Hawaii

96817

Matsushita

Electric

of

Canada

Ltd.

40

Ronson

Drive,

Rexdale,

Ont.
