Panasonic ET-PKD120B User manual

TQZJ539-1
Model No. ET-PKD120B
Installation Instructions
Projector Mount Bracket
Thank you for purchasing this Panasonic product.
■To customers
The “Installation Instructions” is intended for use by installation personnel. Be sure to employ certified personnel to perform
the installation.
After installation, have the installation personnel return these “Installation Instructions” to you, and save it for future use.
When moving or removing the projector, give this manual to the certified personnel and have them perform the procedure.
■To installation personnel
Read the “Installation Instructions” thoroughly and then perform the operation correctly and safely.
Be sure to read through the section entitled “Read this first!” (page 3) before proceeding with the installation.
After installation, return these “Installation Instructions” to the customer.
* ThegureaboveshowsacombinationofthisproductandtheseparatelysoldET-PKD120Sceilingmountbracket(forlow
ceilings).
* Unlessspeciedotherwise,guresintheseinstructionsshowacombinationwiththeceilingmountbracket(forlowceilings).
 Theinstallationmethodisalsothesameasthatoftheceilingmountbracket(forhighceilings).

2 - ENGLISH
Contents
Read this rst! ................................................................................................... 3
Product description........................................................................................... 4
Standard installation dimensions.................................................................... 5
Installation........................................................................................................ 10
Settingupthescreen........................................................................................................ 10
Screwstighteningtorques ................................................................................................ 10
Installing the bracket to the projector................................................................................ 10
Attaching the drop prevention kit to the projector ..............................................................11
Specications .................................................................................................. 12

ENGLISH - 3
Read this rst!
WARNING:
Installation work should only be carried out by the certied personnel.
zIf this product is not installed correctly, serious accidents may result.
zFollowtheinstructionsspeciedin“Installation”ofthismanual,andperformsecureinstallation.
Do not install in a place which is not strong enough.
zIftheinstallationlocationisnotstrongenough,theceilingbracketmayfalldownandaninjurymayresult.
Make sure that your footing is safe and secure during installation.
zIfyourfootingisnotsecure,youmayfalldownordropthebracket,andaninjurymayresult.
Make sure that the ceiling bracket is installed correctly in accordance with the structure and materials
used at the installation location.
zIfamistakeismadeintheinstallationprocedure,theceilingbracketmayfalldownandaninjurymayresult.
Do not loosen or remove the ceiling mount bracket screws or bolts unnecessarily.
zTheprojectormayfalldownandinjurymayresult.
Do not set up the projector in humid or dusty places or in places where the projector may come into
contact with oily smoke or steam.
zUsingtheprojectorundersuchconditionsmayresultinre,electricshocksorplasticdeterioration.The
plasticdeteriorationmaycausethefallingdownoftheprojectorwhichismountedintheceiling.
Do not allow children to reach the attached metal ttings and screws.
zTheattachedmetalttingsandscrewscancausepersonalinjuryifswallowed.
zIfswallowed,seekmedicaladviceimmediately.
Mounting must be carried out by two or more persons.
zIncludingtheprojector,thisxtureweighsatleast20kg(44.1lbs).Makesurethatmountingiscarriedoutby
twoormorepersons.
Do not disassemble or modify the ceiling mount bracket.
zThe projector may be damaged or fall, causing injury.
CAUTION:
Install only the designated projector.
Install only using the designated method.
zOtherwise,theprojectormayfallandbecomedamaged,andcauseinjury.
Do not install the ceiling bracket in a place which may impede projector ventilation.
zIfthisisnotobserved,remayresult.
Do not hang from or hang objects on the projector or ceiling mount bracket.
zThe projector may fall and cause injury.
When installing, always use the supplied components.
zOtherwise,thismaycausedamagedprojectortofallandcauseinjury.
Install the mounting screws and power cable in such a way that they will not make contact with the
inside parts of the ceiling.
zElectricshocksmayresultfromcontactwithanymetalobjectsinsidetheceiling.
■Panasonic disclaims all liability for any accidents or any damage caused by the installation of the
ceiling mount bracket using methods that are not described in these Installation Instructions or
methods that do not use the parts specied in these Instructions.
■ If products are no longer being used, they should be dismantled and removed by the certied
personnel as soon as possible.
Alwaysfollowtheseprecautions

4 - ENGLISH
Product description
This is a ceiling mount bracket for installing projectors.
■Applicable ceiling mount brackets
ET-PKD120S/ET-PKD120H
■Structural components
Parts name Form (number of parts) Applications
Projector mount
bracket
×1
This is used to install the projector
itself.
It also includes a function for
adjustingtheleft/righttilt.
Screwsandbolts These are used to mount the
bracket onto the projector.
Hexheadbolt,captivewasher(M6×16) ×6
Droppreventionkit Prevents the ceiling mount
bracket from falling.
Flatwasher(M8) ×2 Wire rope ×1
zStoresmallpartsinanappropriatemanner,andkeepthemawayfromsmallchildren.
zTighteningtorqueforthescrewsareM6:4±0.5N•m,M8:10±1N•m.
zWhentighteningupthescrews,useatoolsuchasatorquescrewdriverortorquewrench.Donotuseelectric
screwdriversorimpactscrewdrivers.
Attention
zDisposeofthepackagingmaterialsproperlyaftertakingtheproductoutofit.

ENGLISH - 5
Standard installation dimensions
Thedimensionalrelationshipbetweenthescreenandtheprojectorisshownbelow.
Establishthedimensionsafterassessingtheareapossibleforinstallation.
■Ceiling mount brackets: ET-PKD120S / ET-PKD120H
zProjectors:PT-DZ870/PT-DW830/PT-DX100
(whenusingtheceilingmountbracketforlowceilings)
(whenusingtheceilingmountbracketforhighceilings)
(Note)Thisdrawingisnotinexactscale.
Attention
zInstalltheprojectorwithatleast500mm(19-11/16")gapfromthesurroundingwallsorobjectsinorderto
ensurethattheairintake/exhaustportsoftheprojectorwillnotbeblocked.
zAvoidsettingupinplaceswhicharesubjecttosuddentemperaturechanges,suchasnearanairconditioner
orlightingequipment.
Note
zDependingontheproduct,theappearancemaydifferfromtheillustrationsintheseinstallationinstructions.
SH
SH
L (LW/LT)
109
(4")
220.5
(8-11/16")
109
(4")
239
(9-13/32")
274
(10-25/32")
SW
SW
SD
218
(8-19/32")
107.5
(4-7/32")
215
(8-15/32")
L1
Projected image
Ceiling
<Units: mm (")>
Screen
SH
SH
L (LW/LT)
100
(3-15/16")
451.5 - 531.5
(17-25/32"-20-15/16")
244
(9-19/32")
269
(10-19/32")
L1
SW
SW
SD
200
(7-7/8")
100
(3-15/16")
200
(7-7/8")
Projected image
Ceiling
<Units: mm (")>
Screen

6 - ENGLISH
Standard installation dimensions (continued)
Theprojectiondistancecanbeadjustedusingthezoomlens.Checktheprojectedimagewhilemakingne
adjustments.
zInthecaseofPT-DZ870/PT-DW830/PT-DX100 Unit:m
Modelnumberofprojectionlens L1size(Approx.)
Standardzoomlens 0.043
ET-DLE055 0.028
ET-DLE085 0.084
ET-DLE150 0.045
ET-DLE250 0.045
ET-DLE350 0.051
ET-DLE450 0.095

ENGLISH - 7
Standard installation dimensions (continued)
■Projection distance according to the projector lens.
Fortheprojectiondistancesforprojectionlenses(optional),refertotheoperatinginstructions[Installation]
providedwiththeprojector.Orcheckthediagonaldimension(m)ofyourprojectedimageandcalculatethe
projectiondistanceusingthefollowingformula.
zInthecaseofPT-DZ870 Unit:m
Lenstype Modelnumberof
projection lens
Aspect
ratio Projectiondistance(L)formula
Standardzoomlens —
16:10 Minimum(LW) L=1.4906xSD(m)
- 0.0746
Maximum(LT) L=2.0814xSD(m)
- 0.0725
16:9 Minimum(LW) L=1.5320xSD(m)
- 0.0746
Maximum(LT) L=2.1393xSD(m)
- 0.0725
4:3 Minimum(LW) L=1.6874xSD(m)
- 0.0746
Maximum(LT) L=2.3563xSD(m)
- 0.0725
Fixed-focuslens ET-DLE055
16:10 —L=0.6893xSD(m)
- 0.0476
16:9 —L=0.7084xSD(m)
- 0.0476
4:3 —L=0.7803xSD(m)
- 0.0476
Ultra short focus zoom lens ET-DLE085
16:10 Minimum(LW) L=0.6865xSD(m)
- 0.0471
Maximum(LT) L=0.8498xSD(m)
- 0.0442
16:9 Minimum(LW) L=0.7056xSD(m)
- 0.0471
Maximum(LT) L=0.8735xSD(m)
- 0.0442
4:3 Minimum(LW) L=0.7772xSD(m)
- 0.0471
Maximum(LT) L=0.9621xSD(m)
- 0.0442
Shortfocuszoomlens ET-DLE150
16:10 Minimum(LW) L=1.1259xSD(m)
- 0.0540
Maximum(LT) L=1.6243xSD(m)
- 0.0498
16:9 Minimum(LW) L=1.1572xSD(m)
- 0.0540
Maximum(LT) L=1.6695xSD(m)
- 0.0498
4:3 Minimum(LW) L=1.2747xSD(m)
- 0.0540
Maximum(LT) L=1.8388xSD(m)
- 0.0498
Intermediate focus zoom lens ET-DLE250
16:10 Minimum(LW) L=1.9665xSD(m)
- 0.0800
Maximum(LT) L=3.1059xSD(m)
- 0.0792
16:9 Minimum(LW) L=2.0212xSD(m)
- 0.0800
Maximum(LT) L=3.1923xSD(m)
- 0.0792
4:3 Minimum(LW) L=2.2263xSD(m)
- 0.0800
Maximum(LT) L=3.5161xSD(m)
- 0.0792
Longfocuszoomlens ET-DLE350
16:10 Minimum(LW) L=3.1000xSD(m)
- 0.1351
Maximum(LT) L=4.6843xSD(m)
- 0.1346
16:9 Minimum(LW) L=3.1862xSD(m)
- 0.1351
Maximum(LT) L=4.8146xSD(m)
- 0.1346
4:3 Minimum(LW) L=3.5094xSD(m)
- 0.1351
Maximum(LT) L=5.3030xSD(m)
- 0.1346
Ultra long focus zoom lens ET-DLE450
16:10 Minimum(LW) L=4.6931xSD(m)
- 0.3017
Maximum(LT) L=7.4193xSD(m)
- 0.2991
16:9 Minimum(LW) L=4.8236xSD(m)
- 0.3017
Maximum(LT) L=7.6256xSD(m)
- 0.2991
4:3 Minimum(LW) L=5.3129xSD(m)
- 0.3017
Maximum(LT) L=8.3992xSD(m)
- 0.2991
Note
zThe values obtained from the above formulas may contain slight errors.
zThethrowratioisbasedonthevalueduringprojectionofa3.81m(150")sizeimage.
zWhenGEOMETRYorKEYSTONEadjustmentisused,compensationismadesothattheprojectedimagesize
becomessmallerthanthespeciedsize.

8 - ENGLISH
zInthecaseofPT-DW830 Unit:m
Lenstype Modelnumberof
projection lens
Aspect
ratio Projectiondistance(L)formula
Standardzoomlens —
16:10 Minimum(LW) L=1.5651xSD(m)
- 0.0746
Maximum(LT) L=2.1855xSD(m)
- 0.0725
16:9 Minimum(LW) L=1.6086xSD(m)
- 0.0746
Maximum(LT) L=2.2462xSD(m)
- 0.0725
4:3 Minimum(LW) L=1.7715xSD(m)
- 0.0746
Maximum(LT) L=2.4736xSD(m)
- 0.0725
Fixed-focuslens ET-DLE055
16:10 —L=0.7237xSD(m)
- 0.0476
16:9 —L=0.7438xSD(m)
- 0.0476
4:3 —L=0.8191xSD(m)
- 0.0476
Ultra short focus zoom lens ET-DLE085
16:10 Minimum(LW) L=0.7209xSD(m)
- 0.0471
Maximum(LT) L=0.8923xSD(m)
- 0.0442
16:9 Minimum(LW) L=0.7409xSD(m)
- 0.0471
Maximum(LT) L=0.9171xSD(m)
- 0.0442
4:3 Minimum(LW) L=0.8159xSD(m)
- 0.0471
Maximum(LT) L=1.0100xSD(m)
- 0.0442
Shortfocuszoomlens ET-DLE150
16:10 Minimum(LW) L=1.1822xSD(m)
- 0.0540
Maximum(LT) L=1.7055xSD(m)
- 0.0498
16:9 Minimum(LW) L=1.2151xSD(m)
- 0.0540
Maximum(LT) L=1.7529xSD(m)
- 0.0498
4:3 Minimum(LW) L=1.3381xSD(m)
- 0.0540
Maximum(LT) L=1.9304xSD(m)
- 0.0498
Intermediate focus zoom lens ET-DLE250
16:10 Minimum(LW) L=2.0649xSD(m)
- 0.0800
Maximum(LT) L=3.2612xSD(m)
- 0.0792
16:9 Minimum(LW) L=2.1223xSD(m)
- 0.0800
Maximum(LT) L=3.3519xSD(m)
- 0.0792
4:3 Minimum(LW) L=2.3371xSD(m)
- 0.0800
Maximum(LT) L=3.6912xSD(m)
- 0.0792
Longfocuszoomlens ET-DLE350
16:10 Minimum(LW) L=3.2550xSD(m)
- 0.1351
Maximum(LT) L=4.9185xSD(m)
- 0.1346
16:9 Minimum(LW) L=3.3455xSD(m)
- 0.1351
Maximum(LT) L=5.0553xSD(m)
- 0.1346
4:3 Minimum(LW) L=3.6842xSD(m)
- 0.1351
Maximum(LT) L=5.5671xSD(m)
- 0.1346
Ultra long focus zoom lens ET-DLE450
16:10 Minimum(LW) L=4.9277xSD(m)
- 0.3017
Maximum(LT) L=7.7903xSD(m)
- 0.2991
16:9 Minimum(LW) L=5.0647xSD(m)
- 0.3017
Maximum(LT) L=8.0069xSD(m)
- 0.2991
4:3 Minimum(LW) L=5.5775xSD(m)
- 0.3017
Maximum(LT) L=8.8174xSD(m)
- 0.2991
Note
zThe values obtained from the above formulas may contain slight errors.
zThethrowratioisbasedonthevalueduringprojectionofa3.81m(150")sizeimage.
zWhenGEOMETRYorKEYSTONEadjustmentisused,compensationismadesothattheprojectedimagesize
becomessmallerthanthespeciedsize.
Standard installation dimensions (continued)

ENGLISH - 9
zInthecaseofPT-DX100 Unit:m
Lenstype Modelnumberof
projection lens
Aspect
ratio Projectiondistance(L)formula
Standardzoomlens —
4:3 Minimum(LW) L=1.4571xSD(m)
- 0.0746
Maximum(LT) L=2.0346xSD(m)
- 0.0725
16:9 Minimum(LW) L=1.5875xSD(m)
- 0.0746
Maximum(LT) L=2.2167xSD(m)
- 0.0725
Fixed-focuslens ET-DLE055 4:3 —L=0.6738xSD(m)
- 0.0476
16:9 —L=0.7340xSD(m)
- 0.0476
Ultra short focus zoom lens ET-DLE085
4:3 Minimum(LW) L=0.6711xSD(m)
- 0.0471
Maximum(LT) L=0.8307xSD(m)
- 0.0442
16:9 Minimum(LW) L=0.7311xSD(m)
- 0.0471
Maximum(LT) L=0.9051xSD(m)
- 0.0442
Shortfocuszoomlens ET-DLE150
4:3 Minimum(LW) L=1.1006xSD(m)
- 0.0540
Maximum(LT) L=1.5878xSD(m)
- 0.0498
16:9 Minimum(LW) L=1.1991xSD(m)
- 0.0540
Maximum(LT) L=1.7299xSD(m)
- 0.0498
Intermediate focus zoom lens ET-DLE250
4:3 Minimum(LW) L=1.9224xSD(m)
- 0.0800
Maximum(LT) L=3.0361xSD(m)
- 0.0792
16:9 Minimum(LW) L=2.0943xSD(m)
- 0.0800
Maximum(LT) L=3.3078xSD(m)
- 0.0792
Longfocuszoomlens ET-DLE350
4:3 Minimum(LW) L=3.0304xSD(m)
- 0.1351
Maximum(LT) L=4.5791xSD(m)
- 0.1346
16:9 Minimum(LW) L=3.3015xSD(m)
- 0.1351
Maximum(LT) L=4.9888xSD(m)
- 0.1346
Ultra long focus zoom lens ET-DLE450
4:3 Minimum(LW) L=4.5876xSD(m)
- 0.3017
Maximum(LT) L=7.2526xSD(m)
- 0.2991
16:9 Minimum(LW) L=4.9981xSD(m)
- 0.3017
Maximum(LT) L=7.9015xSD(m)
- 0.2991
Note
zThe values obtained from the above formulas may contain slight errors.
zThethrowratioisbasedonthevalueduringprojectionofa3.81m(150")sizeimage.
zWhenGEOMETRYorKEYSTONEadjustmentisused,compensationismadesothattheprojectedimagesize
becomessmallerthanthespeciedsize.
Standard installation dimensions (continued)

10 - ENGLISH
Installation
Aftercheckingtheheight,width,andstructureoftheinstallationlocationwhilereferringto“Standardinstallation
dimensions” on pages 5to9, determine the appropriate positions for setting up the screen and installing the
projector.
Setting up the screen
Setupthescreenaccordingtothespeciedmethodinapositionwhichtakesintoaccounttheprojectiondistance
and angle and the type of screen being used.
Screws tightening torques
M6 ......... 4±0.5N•m
M8 ......... 10±1N•m
zUseatorquescrewdriverortorquewrenchtotightenscrewsandboltstotheirspeciedtighteningtorques.Do
notuseelectricscrewdriversorimpactscrewdrivers.
Installing the bracket to the projector
Attachtheprojectormountbrackettotheprojector(soldseparately).
1)Placetheprojectorupside-downontoapieceof
soft material.
2)Turntheadjustmentleg(seethegureonthe
left)clockwisetominimizethelengthoftheleg.
zIftheadjustmentleg(seethegureonthe
left) is long, the projector mount bracket
comesincontactwiththelegandcannotbe
mounted onto the projector.
Projector mount bracket
Arrow
Secure in six places
3)Securetheprojectormountbrackettothe
bottomoftheprojectorusingthesixsupplied
captivewasherscrews(M6x16)asillustrated
on the left.

ENGLISH - 11
Attaching the drop prevention kit to the projector
Attachthewireropetotheprojector(soldseparately).
Adjustment leg 1)Turntheadjustmentleg(one)counterclockwiseto
remove it from the projector.
2)Passthesuppliedatwasher(one)andwirerope
throughtheadjustmentleg(one)asillustratedon
the left.
3)Turntheadjustmentlegclockwisetosecureitto
the projector.
Note
zForinstallingtheceilingmountbrackets(forlow
andhighceilings)(soldseparately)tothisbracket
aswellasattachingthewireropetotheceiling,
refer to the respective installation instructions.
Wire rope
Flat washer
Adjustment leg
Installation(continued)

Specications
External dimensions Width: 380 mm (14-31/32"), Height: 56 mm (2-7/32"),
Depth: 362 mm (14-1/4")
Weight Approx. 2.5 (5.5 lbs.)
SS0513AM1047 -PS
Printed in Japan
https://panasonic.net/cns/projector/
