Pandora Camper v3 User manual

Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
Pandora would like to thank you for choosing
our service-security system Pandora Camper
Pandora Camper v3 is a car service-security system built for motorhomes with on-board voltage of
12V. It is a complex engineering solution, which includes unique and modern technological software
and hardware solutions.
When building the Pandora Camper v3 we were using the most up-to-date electronics from
best manufacturers. The device is built using high-precision mounting and control machinery, thus
we guarantee highest possible quality, reliability and stable technical characteristics for the whole
operation period.
The Pandora Camper v3 has a cryptographically strong authorization code with unique dialog
algorithm and individual encryption key on every device. It guarantees protection form electronic
hacking for the whole operation period.
The system is built for your convenience: it’s ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support. We are happy to provide
any support we can – feel free to use our online support.
!WARNING! It’s strongly recommended to install a security system by the skilled
automotive technician! The installation must be performed according to the provided technical
documentation, installation guides and schemes. The functionality and features of the system
depend on its correct installation/configuration and/or the specifics of the vehicle.
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40 to +85° C range. All system components must be installed only in a car interior.
The base unit and radio tags fulfil with the IP40 category of protection against water.
Our web-site: pandorainfo.com
Customer support: [email protected]

3
2USER MANUALPANDORA CAMPER V3
Table of contents
General information 4
System set 4
Read before using 5
PIN-codes of the system 6
Owner’s personal card 6
External VALET button 7
System modules layout 7
Base unit 8
Information signals of the system 10
System functions and modes 12
Security mode 12
Security and monitored zones 12
Stay Home mode 13
Remote and automatic engine starts 13
Slave mode 14
Owner authorization devices and functions 15
Beach mode 16
Checking the number of paired devices 17
Remote control (R-468BT) 18
Replacing the battery 19
Pairing a remote control 19
Firmware update 20
Remote control signals 20
Quick access functions of the remote control 21
Immobiliser radio tag 22
Functions of the button 22
Replacing an immobiliser tag battery 23
Light indication of SEND LED 23
Prompt entry/change of the main owner phone number 24
Updating firmware of the tag 24
Control the system by a phone 25
Changing settings via a phone 28
Online service and mobile application 30
Control the system 33
Arming 33
Activating Stay Home mode 34
Disarming 35
Unlocking the trunk 36
Locking/unlocking doors when ignition is on 37
Car search function 37
PANIC mode 37
Remote engine start 38
Engine preheater 39
Service mode 39
Control the system in case of emergency 42
Emergency disarming 44
Emergency control of the anti-theft functions 44
Additional devices 46
Warranty obligations 48
Installation certificate 51
Acceptance certificate 52
Warranty card 52

5
4USER MANUALPANDORA CAMPER V3
System set
1. User manual 1
2. Owner’s personal card 1
3. Remote control 1
4. Radio tag 1
5. DMS-100BT 2
6. External VALET button 1
7. Beeper 1
8. Base unit 1
9. Blocking relay 1
10. External temperature sensor 1
11. Wires and fastening kit 1
12. Piezo siren PS-330 1
13. Wiring diagram 1
14. Packaging 1
! The manufacTurer reserves The righT To change The sysTem seT and consTrucTion of The producT To improve iTs
Technological and operaTional parameTers wiThouT anoTificaTion.
Read before using
Carefully read this manual before starting installation and using the security-service system. Pay
attention to text marked with !
!The securiTy and TelemeTric sysTem is acomplex Technical producT. sysTem insTallaTion and configuraTion musT be
carried ouT only by askilled professional.
!feaTures and sysTem modes, conTrol of The vehicles zones depends on The Type of connecTion and sysTem seTTings,
original vehicle operaTion logic and Trim.
! The sysTem seT includes The “owner’spersonal card”. This card conTains informaTion under aproTecTive layer
ThaT is inTended only for The owner of The sysTem. make sure ThaT The proTecTive layer on The owner’splasTic card is
inTacT afTer The insTallaTion of The sysTem. read The “owner’spersonal card” secTion of This manual before erasing
The proTecTive layer.
! when sysTem insTallaTion is finished:
• check The sysTem operaTion and funcTions wiTh aspecialisT.
• werecommend ThaT you mark each working funcTion wiTh asign in The “conTrol The sysTem” secTion
• check ThaT The “insTallaTion cerTificaTe” and “warranTy card” are filled ouT. These documenTs may be required for
conTacTing The cusTomer supporT.
• ask an insTaller To mark The layouT of The sysTem componenTs on The diagram. This informaTion may be required for
diagnosTic/configuring or emergency deacTivaTion of The sysTem.
werecommend ThaT you change The defaulT value of The pin-codes of The sysTem. you can wriTe down The changed
pin-codes in The “pin-codes of The sysTem” secTion.

7
6USER MANUALPANDORA CAMPER V3
PIN-codes of the system
The “Secret PIN-code”
(is written on the “Owner’s personal card”
The “Service PIN-code”
(default value is 1-1-1-1)
The “Guest PIN-code”
(default value is 1-2-3-4)
The “Immobiliser PIN-code”
(is used for the Validator (pin-to-drive) function)
! iTis recommended ThaT you will wriTe down The changed or creaTed values of all pin-codes. eliminaTe Third-parTy
access To This informaTion
Owner’s personal card
! erase The proTecTive layer carefully. donoT use any sharp objecTs To avoid damaging of hidden informaTion under
The proTecTive layer.
The owner’s personal card contains private information under a
protective layer:
• PIN (the “Secret PIN-code”) is a 4-digit number. This code can
be used to disarm the system and to deactivate immobiliser
functions and to activate Service mode. It can be also used to
enter programming mode.
• LOGIN is a 10-digit number. This information is used to add
the system to the online service and mobile application.
• PASS contains 8 characters and can consist of digits, lower and
upper case letters). This information is used to add the system
to the online service and mobile application.
• Phone number is a phone number of the built-in SIM-card.
CANNOT BE CHANGED
+7-9хх-ххх-хх-хх
1070000000 / Y34aC4vJ
2-2-2-2
LOGIN / PASS
PIN Phone number
System modules layout
External VALET button
(VALET button via CAN)
Button
for the «Immobiliser PIN-code»
Button for the «Beach mode PIN-code»
Circuit being blocked
Base unit
Beeper
DMS-100BT
1
2
3
4
5
6
7
External VALET button
An external VALET button with a two-color status LED indicator is placed
inside a vehicle (see the system modules layout) The button is used for
programming the system, arming/disarming, activating/deactivating
Immobiliser mode.

9
8USER MANUALPANDORA CAMPER V3
! dms-100bT sensors from The kiT are already paired wiTh The base uniT. according To The insTallaTion place
you can change The defaulT logic of The alarm zone in pandora specialisT: ««advanced seTTings» -> «inpuTs and
ouTpuTs» -> «inpuTs seTTings». fill The Table wiTh The acTual logic:
DMS1 Window DMS6
DMS2 Window DMS7
DMS3 DMS8
DMS4 DMS9
DMS5 DMS10
Base unit
Built-in GSM modem (2G/3G/4G LTE) provides a connection with our online-service pandora-on.com
and Pandora Connect (iOS and Android) mobile application, allows to control the system by a phone
using DTMF-commands, voice and SMS notifications, automatic date and time detection. The modem
operates in a mobile network using the built-in nano-SIM.
Built-in slot for a nano-SIM used for owners SIM-card.
Built-in GPS/GLONASS-receiver is designed to determine current location and to automatically
determine UTS date and time.
2.4GHz radio channel, Bluetooth 5.0 protocol (BT5.0) supports up to 14 additional Bluetooth
devices (see the“Additional devices”section), including a mobile phone.
Built-in 3D accelerometer is used to detect shock/motion/tilt including 2 separate zones of shock
sensor (alarm and warning), the system allows to adjust sensitivity of each zone, to use data from the
accelerometer to block the engine and close the central lock on movement.
Temperature sensors allow the system to measure temperature of different zones to send this
information to the mobile apps.The following zones are available: interior temperature – built in sensor
of the main unit, engine temperature – external temperature sensor (see the “System set”), outside
temperature – digital car protocol*.
The system setting allow you to reassign sensor to different zones and use information from external
additional devices (PS-331BT, RHM-03 BT); to implement automatic engine or engine pre-heater starts
and stops by temperature.
Built-in digital 2хCAN* interface allows the system to read status end execute commands via digital buses.
Built-in digital IMMO-KEY port and immobiliser bypass* – hardware and software algorithms with
the special Pandora CLONE server allow the system to bypass original immobilisers for automatic and
remote engine starts. This port can be also used to control Webasto Thermo Top Evo and Eberspacher
Hydronic 1/2/3 heaters.
Built-in Type C USB port – update and configuration of the system using a PC and Pandora Specialist.
!*more informaTion is available in pandora specialisT.

11
10 USER MANUALPANDORA CAMPER V3
Information signals of the system
LED INDICATOR SIGNALS
SIGNALS DESCRIPTION
THE SYSTEM IS ARMED
Short red ashes System is armed
Short green ashes System is armed
(an authorization device is in the coverage zone)
Fast red ashes Alarm
THE SYSTEM IS DISARMED
Faded System is disarmed
Red System is preparing for automatic or delayed arming
Green
(when ignition is on) System is in Service mode
Simultaneous red and green ash (when switching
on ignition) System indicates the number of paired remote controls
Green ashes
(when switching on ignition) Conrms the number of paired radio tags
Red ash
(when switching on ignition) Conrms a paired mobile device
WHEN ENTERING THE“SECRET PIN-CODE”OR THE “SERVICE PIN-CODE”
Simultaneous red and green ash Conrms a VALET button press
Short red ash Conrms a digit input PIN-code is incorrect
Red and green ashes Conrms correct PIN code
SOUND AND LIGHT SIGNALIZATION
SIGNALS
(sound / light) DESCRIPTION
1х /1х Arming
2х /2х Disarming
5х /5х Car search
30 sec. /30 sec. Alarm, PANIC mode
3х Preparing for remote engine start
3х /1х Warning level of a sensor is triggered
4х /4х Sensors were triggered’signal when disarming /
Parking light is not turned o notication /
‘Sensors are triggered”signal when arming
25 sec. /25 sec. Engine blocking warning in Anti-Hi-Jack mode
BEEPER SOUND SIGNALS
SINGNAL DESCRIPTION
1 sound signal Activating Service mode
2 sound signals Deactivating Service mode
1 sound signal Correct input of the“Immobiliser PIN-code”
3 sound signals/3 times A battery in a radio tag is discharged
4 sound signals/4 times Absence of an authorization device when you switch
on ignition
Fast sound signals Engine blocking warning

13
12 USER MANUALPANDORA CAMPER V3
SYSTEM FUNCTIONS AND MODES
Security mode
The system confirms arming with 1х sound and 1х light signals. When the system is armed,
the system monitors security zones with separated warning and alarm level of triggering:
• Warning mode - this mode activates when there is a slight impact on the shock sensor or additional
senor. It is accompanied with 1х light and 3х sound signals;
• Alarm mode - this mode activates when a sensor or one of the security zones is triggered. It is
accompanied with 30 sec. light and 30 sec. sound signals. The alarm signals can be
canceled by an arming or disarming command. If one of the security zones is triggered the system:
• records this event in its non-volatile memory;
• activates the alarm or warning mode;
• informs an owner by all available means;
• blocks the engine (in accordance with the settings and connections).
If one of the security zones is opened at the moment of arming, the system will produce 4х
sound and 4х light warning signals.
If one of the security zones fails, the system will forcibly turn off this zone. If a switch triggers
more than 9 times in a row, it will be disabled until the next arming. The shock/tilt/motion sensor is
temporarily deactivated (15 sec.) if it has been triggered more than 3 times in a row.
The system confirms disarming with 2х sound and 2х light signals. The system deactivates
engine blocking (if the immobiliser function and additional blocking are not used). If there were alarm
events during the armed period, the system will produce 4х sound and 4х light warning
signals. The system continues to display all zones when it is disarmed, but the information is not saved
in the memory.
Security and monitored zones
• Interior temperature (status)
• Engine temperature (status)
• Outside temperature (status)*/**
• Voltage of the on-board circuits (status)
• Engine operation control - RPM (status)
• Heater operating control (status)
• Fuel level (status)
• Parking (automatic gearbox) /Handbrake (manual gearbox) status
• “Parking light is not turned off” notification (status)*
• Shock sensor (security zone – alarm and warning level)
• Motion sensor (security zone – alarm level)
• Tilt sensor (security zone – alarm level)
• OE alarm system status via CAN*
• Additional sensor (status, security zone – alarm and warning level)**
• Turning ignition on (status, security zone – alarm level)
• Opening front doors (status, security zone – alarm level)
• Opening side doors (status, security zone – alarm level)
• Opening camper windows (status, security zone – alarm level)
• Opening camper sunroofs (status, security zone – alarm level)
• Opening a trunk (status, security zone – alarm level)
• Opening a hood (status, security zone – alarm level)
• Pressing brake (status, security zone – alarm level)
! *sTaTuses are available in can-bus daTa or addiTional analog connecTion should be made
(see info in pandora specialisT).
**opTion (see «addiTional devices» secTion).
Stay Home mode
This mode is used to control the outer perimeter of a vehicle during parking when passengers are inside
the vehicle. This mode allows the system to protect your vehicle against intrusion through the parts of
the vehicle that can be opened.
• The system will be armed silently when you activate the “Stay Home” mode, it will be confirmed
with 1х light signal. The system controls vehicle security zones and an additional gas sensor (it is
not included in the set) in this mode, built-in sensors (shock/tilt/motion) are disabled in this mode.
• The system will be disarmed when you deactivate the “Stay Home” mode, it will be confirmed with
2х sound and 1х light signals.
Remote and automatic engine starts
The system allows for remote engine start using the «remote engine start» command from the
mobile application or preconfigured automatic engine start function. Remote start can be used to heat
engine and interior, charge battery or to cool the interior with air conditioning.

15
14 USER MANUALPANDORA CAMPER V3
Remote and automatic starts can only be used when the system is armed. While the system is in
remote or automatic start mode, it keeps performing all security functions of all of the security zones
excluding a shock sensor (the system can be configured to not disable the shock sensor during a remote
engine start). To compensate it, the motion sensor sensitivity and responsiveness will be increased. If
any security zone will be triggered, the engine will be immediately stopped and alarm mode will be
triggered.
When using the remote and automatic engine start functions, make sure that a car is secured with
handbrake or some other means of fixating the car on a parking position. Remote and automatic engine
start on automatic transmission cars will only occur, if a transmission selector lever was left in the «P»
position.
If a car has manual transmission, remote or automatic start will only occur if the program neutral
procedure was followed when the car was arming.
AN EXAMPLE OF THE “PROGRAM NETURAL” PROCEDURE
1. When the engine is running, fixate the car with the handbrake and put gear lever to the neutral
position. Program neutral procedure will be switched on automatically (by default system settings).
2. Turn the key in the ignition lock to the OFF position (the engine should still be running) and take it
out of the lock (skip this step for cars with a Start/Stop button).
3. Leave the car, close the doors.
4. Arm the system - the engine will be stopped. Now the system is ready to perform remote and
automatic engine start.
Automatic starts
The system allows configuring automatic engine start and stop conditions. Automatic starts can be
configured using the internet-service or mobile apps. The following conditions can be specified
for automatic engine starts: schedule, time period, engine temperature, voltage. The engine will be
stopped automatically after specified time or when the engine temperature reaches a specified value.
The engine can be also stopped by a user command.
!auTomaTic engine sTarTs and sTops by TemperaTure are available only if aTemperaTure sensor is connecTed. remoTe
and auTomaTic engine sTarTs are noT available if The hood is open. afTer Third failed consecuTive aTTempT of auTomaTic
sTarT all subsequenT auTomaTic sTarTs will be cancelled unTil arming/disarming of The car (iT doesn’TaffecT aT remoTe
sTarT feaTure).
Slave mode
This mode allows arming and disarming using original vehicle control – an original key, button/sensor
of a keyless access entry system.
Slave mode can be implemented using analog connections or a digital protocol of a vehicle
!This mode is disabled by defaulT for adigiTal proTocol. more informaTion in pandora specialisT. iTis recommended
To acTivaTe The “prohibiT disarming when aTag is absenT” To increase securiTy feaTures of The slave mode. ifThis
mode is acTivaTed, iT will be possible To disarm The sysTem only when aTag is in The coverage zone or using The “secreT
pin-code”.
Owner authorization devices and functions
Authorization devices
Authorization devices are Bluetooth devices paired with the system (radio tags, remote control
R-468BT, mobile phone with the app). The devices are used to recognize an owner in the radio
coverage zone of the base unit to arm/disarm the system (Hands Free mode) and to implement
immobiliser or Anti-Hi-Jack functions.
!insTall The beeper if you use auThorizaTion devices.
Hands Free mode
This mode is used for automatic arming/disarming when an owner with an authorization device is
distancing or approaching a vehicle.
!This mode is disabled by defaulT. iTis required To make addiTional seTTings using The pandora specialisT To use This
mode. quick access commands To manage hands free mode: 223* - acTivaTe hands free arming, 224* - acTivaTe hands
free disarming, 222* - deacTivaTe all hands free.
Immobiliser mode
This mode is used to recognize an owner using authorization devices when the system is disarmed.
When turning on the ignition, the base unit performs a search for authorization devices in the radio
coverage zone. If there is no any authorization device in the radio coverage zone, the system will block
the engine. Engine blocking will occur immediately or at the time a motion sensor detects movement,
it depends on the system settings. When an authorization device appears in the coverage zone, the
system will exit blocking mode and will continue to work in normal mode.
!This mode is enabled by defaulT. iTis required To make addiTional connecTions for This mode.

17
16 USER MANUALPANDORA CAMPER V3
ANTI-HI-JACK-1/2 modes
The Anti-Hi-Jack modes help to prevent aggressive seizure of a vehicle when authorization in case of
disappearance of authorization devices from the radio coverage zone when system is disarmed.
ANTI-HI-JACK-1 mode – The base unit checks if an authorization device is in the radio coverage zone
each time when ignition is on and a door is opened/closed.
ANTI-HI-JACK-2 mode – The base unit constantly checks if an authorization device is in the radio
coverage zone when ignition is on.
If the system cannot detect an authorization device, the base unit will perform a delayed engine
blocking. The siren will play the ‘Engine blocking warning’ ringtone before blocking. The engine will
be blocked immediately or at the time the car starts moving, it depends on the system settings. When
an authorization device appears in the coverage zone, the system will exit blocking mode and will
continue to work in normal mode.
!This mode is disabled by defaulT. This mode can be seT only by aprofessional specialisT.
Multi-button Сode immobiliser (pin-to-drive)
Multi-button ode immobiliser (pin-to-drive) is a function that allows disarming, disabling blocking
and controlling Service mode and time channels using original vehicle controls (button, lever or pedal)
and a pre-programmed PIN-code (the “Immobiliser PIN-code”).
AN EXAMPLE OF USING THE FUNCTION
• Turn on the ignition to disable engine blocking or enable Service mode, turning on the ignition is not
required if you want to disarm the system or control time channels.
• Enter the “Immobiliser PIN-code”. Press a programmed button/lever/pedal the number of times
equals to the first digit. Pauses between presses should not exceed 1 second. More than 1 second
pause will be interpreted as the start of the next digit input. The immobiliser code can consist max
of 4 digits from 1 to 9.
• The system will confirm the correct input by a sound signal of the beeper and a programmed
function will be performed.
!This mode is disabled by defaulT. This mode can be seT only by aprofessional specialisT.
Beach mode
This mode allows to use the pre-programmed «Beach mode PIN-code» for system arming/disarming.
The code must be entered using factory vehicle controls (buttons/sensors) or additionally installed
element.
When using the Beach mode system disarming is possible only by entering «Beach mode PIN-code»
or «Secret PIN-code» by a VALET button (see «Control the system in case of emergency»)
AN EXAMPLE OF USING BEACH MODE
• Press the factory or additionally installed element until the single light flash, thereafter start to enter
«Beach mode PIN-code».
• Enter the «Beach mode PIN-code», code can consist max of 4 digits from 1 to 9:
- Press the control element the number of times equals to the first digit.
- Pauses between presses should not exceed 1 second. More than 1 second pause will be interpreted
as the start of the next digit input.
• After the correct input the system will confirm arming/disarming by the sound and light signals.
!This mode is disabled by defaulT- configuraTion of The sysTem should be made by aqualified Technician.
emergency disabling of The sysTem is made wiTh The «secreT pin-code» and valeT buTTon (see «conTrol The sysTem
in case of emergency»).
Checking the number of paired devices
The number of paired radio remotes/tags/mobile device can be checked by the number of flashes of
the LED indicator. The number of remotes/tags/mobile device can be checked when switching on the
ignition (the system must be disarmed). The number of simultaneous red and green flashes will indicate
the number of paired remote controls, the number of green flashes will indicate the number of paired
radio tags, a following red flash will indicate a paired mobile device.
You can also check the number of paired radio tags/mobile device by taking off and
putting back on battery terminal. The system will emit short sound signals from a siren .

19
18 USER MANUALPANDORA CAMPER V3
REMOTE CONTROL R468BT
The R-468BT remote control is designed to control and monitor a state of a security system and
implementation of Immobilizer, Anti-hi-Jack1/2, HandsFree functions at a distance of a Bluetooth
connection.
!warning! Touse The remoTe conTrol as an owner auThorizaTion device iT is necessary To enable «use remoTe as
aradio Tag» funcTion in sysTem seTTings.
• Battery type: CR2032
• Operating range: from -10°C to+40°C
• Degree of protection: IP40
• Dimensions: 62x32x12 mm
• Compatibility with Bluetooth software of the system: v.2xx ->2.23 and higher; v.3->3.14 and higher;
v.4->4.07 and higher.
!warning! donoT shield The builT-in anTenna while using The remoTe conTrol (see picTure).
for The correcT operaTion of The remoTe conTrol as The owner auThorizaTion device do noT place iT near ameTal
objecTs, magneTs and elecTronic devices (crediT cards, phones, keys, remoTes, eTc.). you can place iT discreeTly on a
panTs belT or in The fronT pockeT of cloThing.
donoT expose The remoTe conTrol wiTh high TemperaTures, moisTure, or sTrong impacTs.
Replacing the battery
The CR2032 battery with a nominal voltage of 3V is used in the remote control. The battery should be
replaced if the sound and light indication is missing while pressing buttons.
An example of replacing the battery:
• remove the key ring;
• press the lock-button on the battery cover and slide cover down (pic.1);
• gently press the battery holder and release the battery (pic. 2);
• install the new battery observing the polarity (pic. 3);
• close the battery cover and install the key ring back.
Pairing a remote control
To pair a remote control with a system, enter the programming mode and enter the programming level
(10.2.1 / 10.2.2 / 10.2.3, see the Programming table of the system).
An example of pairing the remote control:
• enter the programming level;
• simultaneously press and hold three buttons on the remote control for 1 second or until the red flash
of the «SEND/ALARM» LED indicator;
• if pairing was successful, system will make a short beep with a Beeper/Siren;
• turn ignition ON and OFF to exit Programming mode.
2,4 GHz antenna,
Bluetooth 4.2
Low Energy
control buttons
LED indicator
sound indicator
SEND/ALARM
SEND
ALARM CR2032
Battery
+
CR2032
(+) side
1
2
3
