Pandora Professional v3 User manual

Pandora would like to thank you
for choosing our security-service system
Pandora Professional v3
Pandora Professional v3 is a car security-service system built for cars with on-board voltage of
12V. It is a complex engineering device, which includes unique and modern technological software and
hardware solutions.
While developing the Pandora Professional v3 we were using the most up-to-date electronics from
world’s best manufacturers. The device is built using high-precision mounting and control machinery;
thus, we guarantee highest possible quality, reliability and stable technical characteristics for the whole
operation period.
The system has a cryptographically strong authorization code with unique dialog algorithm and
individual encryption key on every device. It guarantees protection form electronic hacking for the
whole operation period.
The system is built for your convenience: it’s ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support. We are happy to provide
any support we can - feel free to use our online support.
! WARNING! It’sstRoNGly RecommeNded to INstAll AsecuRIty system by the skIlled AutomotIve techNIcIAN!
the INstAllAtIoN must be peRfoRmed AccoRdING to the pRovIded techNIcAl documeNtAtIoN, INstAllAtIoN GuIdes
ANd schemes. the fuNctIoNAlIty ANd feAtuRes of the system depeNd oN Its coRRect INstAllAtIoN/coNfIGuRAtIoN
ANd/oR the specIfIcs of the vehIcle.
This device has limited external factors resistance. It should be operated in a temperature outside from -400C to +850C range. All system
components must be installed only in a car interior. The base unit and remote controls are fulfilled with the IP40 category of protection
against water.
Our web-site: pandorainfo.com
Customer support: [email protected]
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC

3
2USER MANUALPANDORA PROFESSIONAL V3
Table of contents
General information 4
System set 5
Read before using 6
PIN-codes of the system 7
Owner’s personal card 7
External VALET button 8
System modules layout 8
Base unit 9
Information signals of the system 10
System functions and modes 12
Security mode 13
Controlled and security zones 14
Remote and automatic engine starts 14
Slave mode 16
Owner authorization devices and modes 16
Checking the number of paired devices 18
Immobiliser tag 19
Functions of the button 20
Indication of SEND LED 21
Installation/replacing a battery of a tag 21
Prompt entry/change of the main owner phone number 22
Updating firmware of the tag 22
Remote control 23
Switching on/off remote control 25
Displaying the connection status 25
Replacing the remote control battery 25
Diagnostic mode 26
Quick access functions 27
Icons of the remote control 28
Remote control menu 29
Control over the system by phone 35
Changing settings via a phone 39
Online service and mobile application 41
Registration 43
Login 43
Adding a system to your account 43
Writing a mobile device to the system memory 44
Control over the system 45
Arming 46
Disarming 47
Unlocking the trunk 48
Locking/unlocking doors when ignition is on 49
Delayed arming 50
Vehicle search function 50
PANIC mode 50
Remote engine start 51
Engine preheater 52
Ultra-low power consumption (Season storage) mode 54
Service mode 55
Control over the system in case of emergency 57
Emergency disarming/Beach mode 60
Emergency control of the code immobiliser 60
Additional devices 62
Warranty obligations 65
Installation certificate 67
Acceptance certificate 68
Warranty card 68

5
4USER MANUALPANDORA PROFESSIONAL V3
System set
1. User manual 1
2. Owner’s personal card 1
3. Remote control 1
4. Immobiliser tag 2
5. External VALET button 1
6. Beeper 1
7. Base unit 1
8. RMD cable 1
9. Piezo siren 1
10. Main cable of the base unit 1
11. Blocking relay Moto 1
12. IMMO-KEY interface cable 1
13. Fastening kit 1
14. Wiring diagram 1
15. Packaging 1
! The manufacTurer reserves The righT To change The sysTem seT and consTrucTion of The producT To improve iTs
Technological and operaTional parameTers wiThouT anoTificaTion.
General
information
1

7
6USER MANUALPANDORA PROFESSIONAL V3
Read before using
Carefully read this manual before starting installation and using the security-service system. Pay
attention to text marked with !
!The securiTy-service sysTem is acomplex Technical producT. sysTem insTallaTion and configuraTion musT be carried
ouT only by askilled professional.
!feaTures and sysTem modes, conTrol of The vehicle’szones depends on The Type of connecTion and sysTem seTTings,
original vehicle operaTion logic and Trim.
! The sysTem seT includes The «owner’spersonal card». This card conTains informaTion under The proTecTive layer
ThaT is inTended only for The owner of The sysTem. make sure ThaT The proTecTive layer on The owner’splasTic card is
inTacT afTer The insTallaTion of The sysTem. read The «owner’spersonal card» secTion of This manual before erasing
The proTecTive layer.
! when sysTem insTallaTion is finished:
• check The sysTem operaTion and funcTions wiTh aspecialisT.
werecommend ThaT you mark each working funcTion wiTh asign .
• check ThaT The «insTallaTion cerTificaTe» and «warranTy card» are filled ouT. These documenTs may be required
for conTacTing The cusTomer supporT.
• ask an insTaller To mark The layouT of The sysTem componenTs on The diagram. This informaTion may be required
for diagnosTic/configuring or emergency deacTivaTion of The sysTem.
• werecommend ThaT you change The defaulT value of The pin-codes of The sysTem. you can wriTe down The
changed pin-codes in The «pin-codes of The sysTem» secTion.
PIN-codes of the system
! iTis recommended ThaT you will wriTe down The changed or creaTed values of all pin-codes. eliminaTe Third-parTy
access To This informaTion.
The «Secret PIN-code»
(is written on the «Owner’s personal card»)
The «Service PIN-code»
(default value is 1-1-1-1)
The «Guest PIN-code»
(default value is 1-2-3-4)
The «Immobiliser PIN-code»
(is used for the Code Immobiliser (pin-to-drive) function)
The“Beach mode PIN-code”
(is used for Beach mode function)
Owners’s personal card
! erase The proTecTive layer carefully. donoT use any sharp objecTs To avoid damaging of ahidden informaTion
under The proTecTive layer. The informaTion on The owner’spersonal card could noT be changed or resTored in case of
damage or lose. eliminaTe Third-parTy access To This informaTion.
CANNOT BE CHANGED
The Owner’s personal card contains private information under
a protective layer:
• PIN (the «Secret PIN-code») is a 4-digit number. This code
can be used to disarm the system to deactivate Immobiliser
functions and to activate Service mode. It can be also used to
enter programming mode.
• LOGIN is a 10-digit number. This information is used to add
the system to the online service and mobile applications.
• PASS contains 8 characters and can consist of digits, lower-
and upper-case letters). This information is used to add the
system to the online service and mobile applications.
• Phone number is a phone number of the preinstalled SIM
card.
+7-9хх-ххх-хх-хх
1070000000 / Y34aC4vJ
2-2-2-2
LOGIN / PASS
PIN phone number

9
8USER MANUALPANDORA PROFESSIONAL V3
Base unit
Built-in LTE module (4G LTE/3G/2G | GPS/GLONASS) - provides a connection with our online
service pandora-on.com and mobile application, allows to control the system by a phone using DTMF
commands, voice and SMS notifications, LBS-coordinates (only by DTMF -command), automatic date
and time detection, precise GPS location (with Tracking function).
Built-in nano-SIM port is used to work with the built-in GSM modem.
!The sim-card can be changed. The sim-card should be replaced and The following seTTings should be performed
only by aqualified specialisT.
868MHz Antenna, LoRa modulation (dynamic dialog encryption AES 128 bit) supports up to 4
remote controls D-027.
2.4 GHz radio channel, Bluetooth 5.0 protocol (BT5.0) - supports up to 14 additional Bluetooth
devices (see the «Additional devices» section), including a mobile phone.
Built-in 3D accelerometer is used to detect shock/motion/tilt including 2 separate zones of shock
sensor (alarm and warning), the system allows to adjust sensitivity of each zone, to use data from the
accelerometer to lock the door locks and block the engine on movement.
Temperature sensors allow the system to measure temperature of different zones: interior
temperature - built-in sensor of the main unit, engine temperature - external temperature sensor (see
“System set” section of the manual), outside temperature - vehicle’s digital protocol. System allows to
change default sensor’s settings, use the information from the external peripheral devices (PS-331BT,
RHM-03BT, DMS-100 BT), program automatic engine start and stop, control engine preheater by
temperature conditions.
Built-in digital 2хCAN/LIN* interfaces allow the system to read status end execute commands via
digital buses, and work with engine preheaters Webasto Thermo Top Evo and Eberspaecher Hydronic
1/2/3.
Built-in digital IMMO-KEY port and Immobilser bypass* - hardware and software algorithms with
the special Pandora CLONE server allow the system to bypass original immobilisers for automatic and
remote engine starts.
Built-in micro-USB port - update and configuration of the system using the Pandora Specialist
application and Pandora Alarm Studio.
! *more informaTion is available on loader.pandorainfo.com
System modules layout
External VALET button
(VALET button by CAN)
Button for the Immobiliser
PIN-code
Button for Beach mode
PIN-code
Circuit being blocked
Base unit
Beeper
1
2
3
4
5
6
7
8
External VALET button
An external VALET button with a two-colour (red, green) status LED
indicator is placed inside a vehicle (see the “System modules layout”
section). The button is used for programming the system, arming/
disarming, activating/deactivating Immobiliser mode.

11
10 USER MANUALPANDORA PROFESSIONAL V3
Information signals of the system
LIGHT SIGNALS OF THE LED INDICATOR
SIGNALS DESCRIPTION
THE SYSTEM IS ARMED
Short red ashes System is armed
Short green ashes System is armed
(authorization devices are in the coverage zone)
Fast red ashes Alarm
THE SYSTEM IS DISARMED
Faded System is disarmed
Red System is preparing for automatic or delayed arming
Green (when turning on the ignition) System is in the Service mode
Green ashes (when turning on the ignition) Conrms the number of paired control devices (remotes,
tags, watches, bands)
Red ash (when turning on the ignition) Conrmes a paired mobile device
WHEN ENTERING THE «SECRET PIN-CODE» OR THE «SERVICE PIN-CODE»
Green ash Conrmes a VALET button pressed
Short red ash Conrms an input of a digit
PIN-code is incorrect
Red and green ashes Conrms correct PIN-code
SOUND / AND LIGHT SIGNALIZATION
SIGNALS DESCRIPTION
1х /1х Arming
2х /2х Disarming
5х /5х Vehicle search
30 sec. /30 sec. Alarm - alarm level of a sensor is triggered,
PANIC mode
3х Remote/automatic engine start procedure indication
3х /1х Warning level of a sensor is triggered
4х /4х «Sensors were triggered» signal when disarming
Parking lights are not turned o notication when arming
«Sensors are triggered» signal when arming
25 sec. /25 sec. Engine blocking warning in the Anti-Hi-Jack modes
BEEPER SOUND SIGNALS
SIGNALS DESCRIPTION
1 sound signal Activating the Service mode
2 sound signals Deactivating the Service mode
1 sound signal Correct input of the «Immobiliser PIN-code»
3 sound signals (3 times) A battery in a radio tag is discharged
(when switching ignition on)
4 sound signals (4 times) Absence of an authorization device when switching
ignition on
Fast sound signals Engine blocking warning in the Anti-Hi-Jack modes

13
12 USER MANUALPANDORA PROFESSIONAL V3
System functions
and modes
2
Security mode
The system confirms arming with 1х sound and 1х light signals. When the system is armed, the
system monitors security zones with separated warning and alarm level of triggering:
• Warning mode - this mode activates when there is a slight impact on the shock sensor or additional
senor. It is accompanied with 1х light and 3х sound signals;
• Alarm mode - this mode activates when a sensor or one of the security zones is triggered. It is 30
sec. light and 30 sec. sound signals. The alarm signals can be cancelled by an arming or
disarming command.
If one of the security zones is triggered the system:
• records this event in its non-volatile memory;
• activates the alarm or warning mode;
• informs an owner by all available means;
• blocks the engine (in accordance with the settings and connections).
If one of the security zones is opened at the moment of arming, the system will produce 4х
sound and 4х light warning signals.
If one of the security zones fails, the system will forcibly turn off this zone. If a switch triggers
more than 9 times in a row, it will be disabled until the next arming. The shock/tilt/motion sensor is
temporarily deactivated (15 sec.) if it has been triggered more than 3 times in a row.
The system confirms disarming with 2х sound and 2х light signals. The system deactivates
engine blocking (if the Immobiliser function and additional blocking are not used). If there were alarm
events (except warning level) during the armed period, the system will produce 4х sound and
4х light warning signals. The system continues to display all zones when it is disarmed, but the
information is not saved in the memory.
!for emergency disarming see «conTrol over The sysTem in case of emergency».

15
14 USER MANUALPANDORA PROFESSIONAL V3
Controlled and security zones
• Interior temperature (status)
• Engine temperature (status)
• Outside temperature (status) */**
• Voltage of the on-board circuits (status)
• Engine operation control - RPM (status)
• Heater operating control (status)
• Fuel level (status)
• Parking (automatic gearbox) /Handbrake (manual gearbox) status
• Parking light is not turned off notification (status)*
• Shock sensor (security zone - alarm and warning level)
• Motion sensor (security zone - alarm level)
• Tilt sensor (security zone - alarm level)
• OE alarm system status*
• Additional sensor (status, security zone - alarm and warning level)**
• Turning ignition on (status, security zone - alarm level)
• Opening doors (status, security zone - alarm level)
• Opening a hood (status, security zone - alarm level)
• Opening a truck body (status, security zone - alarm level)
• Pressing brake (status, security zone - alarm level)
* available via can-bus (see loader.pandorainfo.com).
** opTion (see “addiTional devices” secTion of This manual).
Remote and automatic engine starts
The system allows the remote engine start using the “remote engine start” command from a remote
control or preconfigured automatic engine start function. Remote start can be used to heat engine and
interior, charge battery or to cool the interior with air conditioning.
Remote and automatic starts can only be used when the system is armed . While the system
is in remote or automatic start mode, it keeps performing all security functions of all security zones
excluding a shock sensor and additional sensor (the system can be configured not to disable
sensors during a remote engine start). To compensate it, the motion sensor sensitivity will be
increased and its responsiveness will be reduced. If any security zone will be triggered, the engine
will be immediately stopped and alarm mode will be triggered.
When using the remote and automatic engine start functions, make sure that a car is secured with
handbrake or some other means of fixating the car on a parking position.
Remote and automatic engine start on automatic transmission cars will only occur, if a transmission
selector lever was left in the «P» position.
If a car has manual transmission, remote or automatic start will only occur if the program neutral
procedure was followed when the car was arming.
An example of the program neutral procedure
1. When the engine is running, fixate the car with the handbrake and put gear lever to the neutral
position. Program neutral procedure will be switched on automatically (by default system settings).
2. Turn the key in the ignition lock to the OFF position (the engine should still be running) and take it
out of the lock (skip this step for cars with a Start/Stop button).
3. Leave the car, close the doors.
4. Arm the system - the engine will be stopped. Now the system is ready to perform remote and
automatic engine start.
Automatic starts
The system allows configuring automatic engine start and stop conditions using a mobile application, some
options are available in a remote control. The following conditions can be specified for automatic engine
starts: schedule, time period, engine temperature, voltage. The engine will be stopped automatically after
specified time or when the engine temperature reaches a specified value. The engine can be also stopped
by a user command.
!auTomaTic engine sTarTs and sTops by TemperaTure are available only if engine TemperaTure daTa is available in digiTal
buses of The car, or if an exTernal engine TemperaTure sensor is connecTed. remoTe and auTomaTic engine sTarTs are
noT available if The hood is open.
afTer aseries of Three unsuccessful aTTempTs of auTomaTic sTarT, all following auTomaTic sTarTs will be canceled
unTil disarming/arming (This does noT affecT on remoTe engine sTarT).

17
16 USER MANUALPANDORA PROFESSIONAL V3
Slave mode
This mode allows arming and disarming vehicle control elements - factory key fob, buttons/sensors of
a keyless access entry system. Slave mode can be implemented using analog connections or a digital
protocol of a vehicle.
!This mode is disabled by defaulT - configuraTion of The sysTem should be made by aqualified Technician. iTis
recommended To acTivaTe The “prohibiT disarming when aTag is absenT” To increase securiTy feaTures of The slave
mode. ifThis mode is acTivaTed, iT will be possible To disarm The sysTem only when an auThorizaTion device is in The
coverage zone or using The “immobiliser pin-code” (see “code immobiliser” (pin-To-drive) funcTion).
Owner authorization devices and modes
Authorization devices
Authorization devices are Bluetooth devices paired with the system (radio tags, remote controls, mobile
phone with the app, band). The devices are used to recognize an owner in the radio coverage zone of
the base unit, to arm/disarm the system (Hands Free mode) and to implement Immobiliser or Anti-Hi-
Jack functions.
!iTis necessary To make addiTional configuraTion of The sysTem To use mobile device, remoTe conTrol, Tag, band as an
owner auThorizaTion device. configuraTion of The sysTem should be made by aqualified Technician.
when using auThorizaTion devices, iT is recommended To insTall beeper.
Hands Free arming/disarming
This mode is used for automatic arming/disarming when an owner with an authorization device is
distancing or approaching a vehicle.
!This mode is disabled by defaulT. The configuraTion should be made by aqualified Technician.
Immobiliser mode
This mode is used to recognize an owner using authorization devices when the system is disarmed.
When turning on the ignition, the base unit performs a search for authorization devices in the radio
coverage zone. If there is no authorization device in the radio coverage zone, the system will block
the engine. Engine blocking will occur immediately or at the time a motion sensor detects movement,
it depends on the system settings. When an authorization device appears in the coverage zone, the
system will exit blocking mode and will continue to work in normal mode.
!This mode is enabled by defaulT. iTs operaTion depends on The meThod of connecTion and sysTem configuraTion.
for emergency disarming see «conTrol over The sysTem in case of emergency»
Anti-Hi-Jack 1/2 modes
The Anti-Hi-Jack modes help to prevent aggressive seizure of a vehicle in case of disappearance of
authorization devices from the radio coverage zone when system is disarmed.
ANTI-HI-JACK 1 mode - The base unit checks if an authorization device is in the radio coverage zone
each time when ignition is on and a door is opening/closing.
ANTI-HI-JACK-2 mode - The base unit constantly checks if an authorization device is in the radio
coverage zone when ignition is on.
If the system cannot detect an authorization device, the base unit will perform a delayed engine
blocking. The siren will play the `Engine blocking warning’ ringtone before blocking. The engine will be
blocked immediately or at the time the car starts moving, it depends on the system settings. When an
authorization device appears in the coverage zone, the system will exit blocking mode and will continue
to work in normal mode.
!This mode is disabled by defaulT - configuraTion of The sysTem should be made by aqualified Technician.
for emergency disarming see «conTrol over The sysTem in case of emergency»
Code Immobiliser (pin to drive) function
This function allows to use the pre-programmed «Immobiliser PIN-code» to disable the engine blocking,
service mode, disarming the security system. The code must be entered using factory vehicle controls
(buttons/lever/pedal) and/or additionally installed elements.
In case of emergency, it is possible to disable code immobiliser by methods, described in «Control
the system in case of emergency».
AN EXAMPLE OF USING THE FUNCTION
• Turn on the ignition to disable engine blocking or service mode, turning on the ignition is not
required if you want to disarm the system or control time channels.
• Enter the «Immobiliser PIN-code», code can consist max of 4 digits from 1 to 9:
- Press the pre-programmed button/lever/pedal the number of times equals to the first digit.
- Pauses between presses should not exceed 1 second. More than 1 second pause will be interpreted
as the start of the next digit input.
• The system will confirm the correct input by a sound signal of the beeper and will activate a
programmed action.
!This mode is disabled by defaulT - configuraTion of The sysTem should be made by aqualified Technician.
for emergency disarming see «conTrol over The sysTem in case of emergency»

19
18 USER MANUALPANDORA PROFESSIONAL V3
Beach mode
This mode allows to use the pre-programmed «Beach mode PIN-code» for system arming/disarming.
The code must be entered using factory vehicle controls (buttons/sensors) or additionally installed
element.
AN EXAMPLE OF USING BEACH MODE
• Press the factory or additionally installed element until the single light flash, thereafter start to enter
• «Beach mode PIN-code».
• Enter the «Beach mode PIN-code», code can consist max of 4 digits from 1 to 9:
- Press the control element the number of times equals to the first digit.
- Pauses between presses should not exceed 1 second.
- More than 1 second pause will be interpreted as the start of the next digit input.
• After the correct input the system will confirm arming/disarming by the sound and light signals.
!This mode is disabled by defaulT - configuraTion of The sysTem should be made by aqualified Technician.
for emergency disarming see «conTrol over The sysTem in case of emergency»
Checking the number of recorded remote controls
The number of recorded remote controls can be checked by the number of flashes of the LED indicator on
the VALET button or on the base unit. The number of registered remote controls device can be checked
every time the ignition is switched on when the system is disarmed. The number of green LED flashes will
indicate the number of recorded control devices (remotes, tags, watches, bands), the red flash - paired
mobile device.
You can also check the number of recorded devices by taking off and putting back on battery
terminal (if possible). The system will emit short sound signals from a siren, with less than 1 sec.
interval.
Immobiliser tag
3

21
20 USER MANUALPANDORA PROFESSIONAL V3
A radio tag is a device used to control a vehicle/system on a distance of a Bluetooth connection. The
tag is also used as an authorization device for «Immobiliser/Anti-Hi-Jack/Hands Free» modes. The radio
tag has: a control button for arming/disarming and activating/deactivating Service mode, a built-in
accelerometer, which allows the tag to go in the energy saving mode when there is no movement and
LED indicator SEND.
!for correcT operaTion, iT is noT
recommended To place The radio Tag near
The meTal objecTs, magneTic and elecTronic
devices (crediT cards, phones, keys, remoTes,
eTc.). donoT expose The radio Tag wiTh high
TemperaTures, moisTure, or sTrong impacTs.
iTis recommended To place The radio Tag on
The belT in an individual case or in The fronT
pockeT of cloThing.
Functions of the button
PRESS DESCRIPTION
- short press
(when ignition is o) System arming/disarming
- press and hold for 1 sec.
(when engine is running) Activation of «Ignition hold on» mode
- press and hold for 2 sec.
(when system is disarmed) Change the «Main owner phone number»
- press and hold for 3 sec.
(when ignition is on) Activating/deactivating Service mode
- press and hold for 6 sec.
(in programming mode) Pairing a tag with the base unit
- press and hold for 10 sec. Firmware update
SEND
3D
LED indicator
Control button
Antenna 2,4GHz
(Bluetooth 4.2)
Built-in accelerometer
Battery CR2032
Indication of the SEND LED
SIGNALS DESCRIPTION
one ash conrmation of arming
low battery level (when installing a battery)
two ashes conrmation of disarming
three ashes high battery level (when installing a battery)
faded
constant light battery is discharged (when installing a battery, when the button is pressed)
Installation/replacing a battery of the tag CR2032
To install or replace the battery (CR2032), carefully follow these steps:
1. Turn the battery cover in the «OPEN» direction;
2. Remove the battery cover;
3. Remove the battery from the battery compartment and, observing the polarity, install a new one
(when installing a high-quality battery, the SEND indicator light will produce three red flashes);
4. Install and rotate the battery cover in the «CLOSE» direction. After completing the procedure, you
can continue to operate the radio tag in normal mode.
CR2032
battery
(+) side
+
СR2032
1 4
3
2

23
22 USER MANUALPANDORA PROFESSIONAL V3
Prompt entry/change of the main owner phone number
For a prompt entry/change of the main owner’s phone number follow next steps:
• Disarm the system, being near the vehicle call the system phone number, wait for the answer (Enter
the «Guest PIN-code if you are calling not from the owner’s phone number. Default value is 1-2-3-4);
• Press and hold button on the radio tag until two flashes of the SEND indicator, then release
button;
• System will save incoming phone number as the «Main owner’s phone number» and will repeat it;
• End call.
!The phone number could be also change using mobile device (see «changing seTTings via phone» secTion).
Updating rmware of the tag
Download the Pandora BT application (Android / iOS) or Pandora Specialist (Android) on the devices
equipped with a Bluetooth 4.0 Low Energy or higher module.
• Open the mobile app, find the system.
• Press and hold the button of the radio tag until the 10th flash of the SEND indicator, then release
the button.
• Select the found device and select one of the update options: FILE MANAGER - firmware will be
uploaded from the phone storage (only for Android). INTERNET - firmware will be uploaded by an
internet connection.
Remote control
4

25
24 USER MANUALPANDORA PROFESSIONAL V3
A two-way remote control is a mean to control and display system and vehicle state.The remote control
operates only when it is in the coverage zone of the system radio channel. All transmitted commands are
reliably protected against electronic hacking with a modern dynamic dialogue encryption algorithm.
!The remoTe conTrol is swiTched off when shipped, swiTch iT on according To The user manual.
The remoTe conTrol is aunified conTrol device - iTs operaTion depends of The securiTy sysTem and implemenTed
funcTional.
for maximum effecTiveness and operaTional range, iT is recommended noT To shield aerial area (see picTure) wiTh
fingers when using aremoTe conTrol
• control buttons – control and confguration of the system parameters;
• OLED display – visualization of the informtion icons;
• sound source – 16 sound melodies matching a particular event;
• vibration indicator – confirmation of the buttons
pressing and commands executing, accompanying
sound notifications of the alarm evets;
• light indicator SEND/ALARM – displaying the
communication status;
• battery slot – for the standard AAA type power source;
• antenna 868 MHz (LoRa HS / AES 128 Bit) – secured
control and receiving information on a long distance.
SEND
ALARM
868 MHz
OLED
Switching on/o the remote control
To switch on the remote, press and hold the button for 3 sound signals (3 sec.). The «REMOTE ON»
ringtone will play (change the battery if the remote control does not switch on). Pressing and holding
the button again for 3 seconds will cause the remote to switch off.
Displaying the connection status
To control the connection status the remote control is using the SEND/ALARM light indicator and
information icon .
When the system is armed the connection status is displayed automatically no more than once a
minute.
Connection status icons
– 868 MHz connection when system is armed
– flashing while connection missing when system is armed
– control command sent, waiting for response
– control command sent, response received
SEND/ALARM light indicator
Green indicator Red indicator
• Flashes if there is a connection with the base
unit
• Goes dark when there is no connection with
the base unit
• Flashes frequently if there is any notification
• Flashes occasionally when there is no connection
Replacing the remote control battery
The standard AAA type battery with a nominal voltage of 1,5V is used in the remote control.
Battery needs to be replaced if the remote control is not turning on or the icon has only one bar
left and starts flashing.

27
26 USER MANUALPANDORA PROFESSIONAL V3
To change the battery:
• move aside the battery cover;
• remove the battery from the battery compartment and, observing the polarity, insert a new one;
• close the battery cover;
• the remote is ready for use (switch the remote on by pressing for 3 seconds).
!iTis recommended To have aspare aaa baTTery in The car.
Diagnostic Mode
Diagnostic mode is used for the initial test of the remote control.The test is performed when the remote
control is switched off and the battery is charged:
• press and hold the button – display, sound source , SEND/ALARM indicator, vibration
indicator will turn on;
• press and hold the button – display will show technical information;
• press and hold the button – after 3 sec. the remote control will switch on.
Quick access functions of the remote control
System disarmed System armed
(no alarm events)
Ignition is switched on Ignition is switched o
(short press) Lock doors without arming Arming with a sound
conrmation
Search mode – ashes of
turn signals with sound
signals for 5 seconds
(1 sec.) Arming without sound
conrmation
Search mode – ashes of
turn signals without sound
signals for 5 seconds
(2 sec.) Switch on «Ignition
Hold on» mode
(3 sec.) Switch on «Programmed
neutral» Remote engine start
(short press) Unlock doors Unlock doors Disarming with sound
conrmation
(1 sec.) Disarming without sound
conrmation
(2 sec. and more) Switch o «Ignition
Hold on» mode
Switch o the ignition
during remote or
automatic engine start
procedure.
(short press) Switch on display
(1 sec.) Unlock trunk
(2 sec.) Switch on/o additional option
(3 sec.) Switch on/o remote
+ (short press) PANIC mode
+ (short press)
Arming when the
engine is running with
sound conrmation
Arming in 30 seconds
with sound notication
+ (sec.)
Arming when the
engine is running without
sound conrmation
Arming in 30 seconds
without sound
notication

29
28 USER MANUALPANDORA PROFESSIONAL V3
Remote control menu
You can control and manage all main settings and parameters of the system using the menu of the
remote control.
Briefly press the button to enter the menu. The following presses of the button will switch
between menu items. Press the or button to enter a selected item.
You can manually exit the menu by pressing the button for 1 second. If there are no any actions
within 5 seconds, the remote control will exit the main menu automatically.
PROCEED TO THE MENU
(briefly press)
GO TO THE NEXT ITEM
(press briefly)
GO TO THE NEXT ITEM
(press briefly)
EXIT THE MAIN MENU
(press briefly)
ENTER THE MAIN MENU
(press briefly)
F
F
GO TO THE NEXT ITEM
(press briefly)
F
F
F
or
ON or OFF
(briefly press)
or
PROCEED TO THE MENU
(briefly press)
or
PROCEED TO THE MENU
(briefly press)
or
car state
settings
information
heater
Icons of the remote control
Connection status
Security mode
status
Remote control
battery level
Current time
Battery voltage
Interior
temperature
Engine
temperature
Fuel level*
Engine operation icon
Ignition security zone
12 48
Shock sensor
Warning level
Shock sensor
Alarm level
Tilt sensor security zone
Motion sensor security zone
Doors security zone*
Hood security zone
Trunk security zone
Additional sensor
Warning level
Additional sensor
Alarm level /
Original alarm status*
Low voltage security zone
Brake pedal security zone
P
22
°
90
°
55
1
2
.4B
* Separate display indication of doors, original alarm status depends
on the information in CAN-bus digital protocol of specific car. Fuel
level indication depends on the information in CAN-bus digital
protocol, or on the original fuel level (require additional connection).
Engine temperature indication depends on the information in CAN-
bus digital protocol, or on the connected additional temperature
sensor (see system set).

31
30 USER MANUALPANDORA PROFESSIONAL V3
CAR STATE
To get information about engine temperature, interior temperature, battery voltage and fuel level,
select the CAR STATE menu by short presses of the button and briefly press the or button.
12 4V 22 °
90° 55
Battery
voltage
Interior
temperature
Engine
temperature
Fuel
level
HEATER
To enable/disable the engine preheater, select the HEATER menu by short presses of the button and
briefly press the or button.
ENABLING THE HEATER
(press briefly)
or
heater on
DISABLING THE HEATER
(press briefly)
or
heater off
SETTINGS
To change settings and parameters of the system, select the SETTINGS menu by short presses of the
button and briefly press the or button.
Briefly press or button to select a sub-menu, to enter the sub-level briefly press the
button.
PROCEED TO THE SETTINGS MENU
(press briefly)
or
PROCEED TO THE SETTNIGS/PARAMETERS
(press briefly)
MENU NAVIGATION
(press briefly)
up
down
EXIT THE MENU
(press for 1 sec.)
F
F
HISTORY
BACK
AUTOSTART
SENSORS
TRACKING
SIREN
HANDS FREE
CHANNELS
GPS RECEIVER
GSM MODEM
VALET MODE
SETTINGS
INFORMATION
decrease
enter/confirmation button
parameter
is enabled
parameter
is disabled
save parameter
exit a menu/sub-menu
navigation buttons
increase
up
down
HISTORY VIEW EVENT HISTORY
This menu allows viewing the event history stored in the remote control’s memory. The remote control
displays an event name and its time.
! The number of evenTs is limiTed by The memory of The remoTe conTrol.

33
32 USER MANUALPANDORA PROFESSIONAL V3
AUTOSTART AUTOMATIC ENGINE START SETTINGS
This menu allows configuring the automatic engine start and stop settings. A synchronized real
time clock in the remote control and the base unit and other autonomous system settings allow to
implement set of conditions of engine start and operation regardless of whether the remote control is
in the radio coverage zone or not.
• ENABLE - this submenu switches on/off all automatic engine starts.
• TIMER - this submenu allows starting an engine every day at the scheduled time.
• START TEMP - this submenu allows starting an engine automatically when the engine temperature is low.
• WORK TIME - this submenu determines the maximum engine operation time for automatic and
remote starts.
• PERIODICALLY - this submenu allows starting engine periodically with a configured time interval.
• STOP TEMP - this submenu determines the engine stop temperature.
SENSORS SETTING AND ADJUSTMENT OF THE SENSORS
This menu allows controlling and adjusting sensors (shock/motion/tilt) sensitivity. SHOCK and additional
EXTERNAL sensors have separate ALARM and WARNING sensitivity zones. Alarm zone triggers when there
is considerable impact on a sensor. If the alarm zone is triggered, the system will indicate it with light and
sound alarm for 30 sec. Warning zone triggers when there is a minor impact on a sensor (the sensitivity of
the warning zone should be higher than the alarm level sensitivity for correct operation). Warning level is
indicated by one light and three sound signals.
• SHOCK - This submenu allows adjusting sensitivity of the alarm and warning zones of the
shock sensor.
- warning and alarm zones are enabled.
- warning and alarm zones are disabled.
- warning zone is disabled.
• MOTION - This submenu allows adjusting sensitivity of the motion sensor.
- motion sensor is enabled.
- motion sensor is disabled.
• TILT - This submenu allows adjusting sensitivity of the tilt sensor.
- tilt sensor is enabled.
- tilt sensor is disabled.
• EXTERNAL - This submenu allows adjusting sensitivity of the alarm and warning zones of the
additional sensor.
- warning and alarm zones are enabled.
- warning and alarm zones are disabled.
- warning zone is disabled.
TRACKING TRACKING SETTINGS
This menu allows you to switch on and off the tracking function for online services.
SIREN OPTIONS OF THE SIREN SOUND SIGNALS
This menu allows configuring siren sound notifications.
- all sound signals are enabled.
- warning signals are disabled.
- warning and alarm signals are disabled.
HANDS FREE SETTINGS OF THE HANDS FREE MODE
This menu allows configuring the Hands Free mode for arming/disarming.
- enable arming in the Hands Free mode.
- enable disarming in the Hands Free mode.
- enable arming and disarming in the Hands Free mode.
- disable arming and disarming in the Hands Free mode.
CHANNELS TIME CHANNEL CONTROL
This menu allows switching on/off time channels. These channels are used to implement additional
functions and to control external devices.
GPS RECEIVER COORDINATES DETECTION
This menu allows you to switch on and off detection of GPS/GLONASS coordinates and Tracking.
GSM MODEM MANAGE THE BUILT-IN MODEM
This menu allows you to switch on and off the built-in LTE modem (GSM functions: online service and
mobile application, control and notifications by phone).
VALET MODE SERVICE MODE
This menu allows activating/deactivating the Service mode.
SETTINGS SETTING OF THE REMOTE CONTROL
This menu allows configuring the remote controls operation.
• souNd - this submenu allows switching on/off sound signals.
•vIbRo - this submenu allows switching on/off vibrations.
•bAcklIGht - this submenu allows adjusting LCD backlight brightness.
•Rfm lost - this submenu allows configuring sound notifications in case of losing connection between

35
34 USER MANUALPANDORA PROFESSIONAL V3
Control over the
system by phone
5
a remote control and a base unit.
- disable notification signals.
- enable notification by“Melody”ringtone. The notification will play once when system is armed.
- enable notification by“ALARM”ringtone.The“ALARM”ringtone will be played if the system is armed.
The system will notify you with a short signal one time per minute after the ringtone. The notifications
will come until the connection is established or the notification can be cancelled by a short press of the
button.
• DATE/TIME - this menu allows you to set time for the systems without GPS/GLONASS receiver. It is
required to arm and disarm the system after to send the changed value to the base unit.
• TIME ZONE - this menu allows you to set UTC time zone for automatic date and time detection by GPS/
GLONASS-coordinates.
SENSORS
To get technical information about the remote control, select the INFORMATION menu by short presses
of the button and briefly press the button or button.

37
36 USER MANUALPANDORA PROFESSIONAL V3
! for The correcT operaTion of The gsm funcTions, an owner should moniTor The sTaTus/balance of The sim card
insTalled in The sysTem. ifThe sim card is blocked or defecTive, gsm funcTions of The sysTem will be unavailable.
Call the system’s phone number from the“Owner’s main number”. When it answers, enter a command
code.
Default settings allow the system to receive calls only from the phone number programmed as an
“Owner’s main number”. If you call from any other numbers, including Additional owner’s numbers, it
will be necessary to enter the “Guest PIN-code”(default value is 1-2-3-4).
1
10 00 0*
*
1
12 23 3*
*
5
5
1
1*
*Tow truck mode
Request GSM account balance
Start the engine/prolong heating
3
32 21 1*
*Stop the engine
3
33 33 3*
*Switch on add. function using F via CAN
5
50 00 0*
*
4
45 56 6*
*
6
65 54 4*
*
7
75 53 3*
*
Request current coordinates
Switch on additional channel
Switch o additional channel
#
#
9
9*
*
*
*
1
15 59 9*
*
Return to previous menu/state
Repeat the last message
Silent arming
Help
0
0
0
0*
*
0
0
1
1*
*
Unlocking trunk
Silent disarming
1
1*
*Arming
0
0*
*Disarming
Force connection to the server
2
25 58 8
*
*
System information
1
15 56 6*
*
6
65 51 1*
*
Switch on engine preheater
Switch o engine preheater
6
66 66 6*
*
9
99 99 9*
*
Enable engine blocking
Disable engine blocking*
9
99 98 8*
*
8
88 88 8*
*
Disable authorization devices
4
42 24 4*
*Fuel level calibration
Enable authorization devices
2
22 22 2*
*Disable Hands Free mode
2
22 23 3*
*Enable Hands Free arming
2
22 24 4*
*Enable Hands Free disarming
2
22 25 5*
*Enable Hands Free disarming only with autom.start
7
78 89 9*
*Enable automatic engine start
9
98 87 7*
*Disable automatic engine start
2
29 97 7*
*End call
5
55 51 1*
*Enable Service mode*
5
55 52 2*
*Disable Service mode
*Enter the“Secret PIN-code”after dialling a command.
!iTis noT necessary To enTer The “guesT pin-code” when you are calling from any number, if The “owner’smain
number” is noT seT up. addiTional sysTem seTTings allow: make acall from The “addiTional owner’snumber” wiThouT
enTering The “guesT pin-code”, requesT The “guesT pin-code” from any numbers, prohibiT calls from any numbers
excepT The “owner’smain number”. configuraTion of The sysTem should be made by aqualified Technician.
DTMF commands
For example: To have simple access to the engine start function, create a new contact in the contact
list of your phone, name it `Engine start’, for instance, and add the number in the following format:
+XXXXXXXXXXX,123*,297* where “+XXXXXXXXXXX” - the system phone number, “,” - pause is a feature
of the phone (can be displayed as the `P’, see the instructions of the phone), “123*” - remote engine
start DTMF command, “297*” - end call DTMF command. Contact can be added as a speed dial to any
of the free button.
To have simple access to engine start function a phone other than the main owner’s phone, create
contact in the following format: +XXXXXXXXXXX,1234,123*,297* where `1234’ is the “Guest PIN-code”.
Repeat the last message
To repeat any message, press *during a voice call to the system.
Voice help
The system has a voice help menu. During a voice call to the system, dial 9* and listen to the
information about system control commands.
To end the session, hang up the phone.
Arming/disarming
1. Call the system number. Wait for the answer.
2. Dial the 1* DTMF command to arm the system, or the 0* for disarming. For the silent arming dial
the 10* DTMF command, for the silent disarming - the 00* DTMF command.
3. The system will confirm command with a voice message “System is armed/disarmed”.
To end session, hang up the phone.
Activate/deactivate Service mode
1. Call the system number. Wait for the answer.
2. Turn on the ignition, an authorization device (tag, Bluetooth remote control, watches, paired
mobile device) must be in the coverage zone if the Immobiliser or Anti-Hi-Jack modes are enabled. To
activate Service mode, dial the 551* DTMF command --“Activate Service mode”, then enter the “Secret
PIN-code”from the Owner’s personal card.
3. To deactivate Service mode, dial the 552* DTMF command --“Deactivate Service mode”.
4. The system will confirm execution of the command.
To end the session, hang up the phone.

39
38 USER MANUALPANDORA PROFESSIONAL V3
Enabling/disabling automatic engine starts
The system has a function of prompt disabling automatic engine start:
1. Call the system number. Wait for the answer.
2. Dial the 987* DTMF command to disable all automatic engine starts or the 789* to enable.
3.The system will confirm execution of the command.
To end the session, hang up the phone.
Request current coordinates
1. Call the system number. Wait for the answer.
2. Dial the 500* DTMF command.
3. The system will confirm: «Current coordinates are sent via text message» and will send text
message with LBS and GPS/GLONASS coordinates to your phone.
Request GSM balance
1. Call the system number. Wait for the answer.
2. Dial the 100* DTMF command.
3. The system will confirm: «Balance information is sent via text message» and will send text message
with account balance information to your phone.
To end the session, hang up the phone.
Tow truck mode
This mode is intended for vehicle transportation with preservation of arming function. Tow truck
mode can be activated only when the system is armed, it will be deactivated automatically when
disarming.
1. Call the system number. If the system is in ALARM mode, receive an emergency call. Wait for the
answer.
2. Dial the 15* DTMF command to enable the «Tow truck» mode, the system will disable motion,
shock and tilt sensors.
To end the session, hung up the phone.
Activating/deactivating engine blocking
You can block the vehicle engine using any phone. The engine will remain blocked until the phone
command «Unlock engine» will be sent and the «Secret PIN-code» will be entered. This blocking cannot
be disabled by any other means.
1. Call the system number and wait for the answer.
2. Dial the 666* DTMF command to block the engine or the 999* to unlock it (after dialling 999* you
should enter the «Secret PIN-code» that is located on the Owner’s personal card).
! all oTher commands can be enTered in The same manner.
Changing settings via a phone
Disarm the system, call the system number, wait for the answer, switch on the ignition for 1-3 seconds
(but no more than 5 seconds), then switch it off. The system will enter the settings mode.
An example of changing the owner’s main phone number:
1. Enter the setting menu via a phone according to the instruction above;
2. Dial the 1* DTMF command (phone number settings) and the 1* (owner’s main phone number);
3. Enter new owner’s main phone number in the format *XXXXXXXXXXX # (the system recognizes
“*“ as “+“);
4. To confirm, dial the 1*.
!There are 2 ways To change main owner’sphone number:
1. via aphone, using dTmf commands seTTings mode.
2. using radio Tag sand The valeT buTTon:
- disarm The sysTem, geT in The vehicle, call The sysTem phone number, waiT for The answer (dial The “guesT pin-code”
(defaulT value is 1-2-3-4) if you are calling noT from The main owner’snumber).
- press and hold The conTrol buTTon on The radio Tag unTil Two flashes of The led indicaTor (2 seconds) or
shorTly press The valeT buTTon.
- The sysTem will recognize The incoming phone number as The “main owner’sphone number”.
