Panduit CJ6X88TG Series User manual

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2016 PN511F
Page 1 of 2
TX6A 10Gig UTP Jack Modules
Part Numbers: CJ6X88TG**, CJK6X88TG**, CJQ6X88TG**, CJH6X88TG**
Jack
Wire cap
Strain relief
collar
1
CJAST
NOTE: Use setting 9 of CJAST tool.
Tur n 2 t i m e s to cut through the
outer jacket and MaTriX tape only.
2MaTriX
tape
3
CWST
4
5
0.5"
(12.7mm)
6
2
8
9
10
Do not pre-arrange
conductors.
(OR)
11
EGJT
** Denotes color.
7

INSTALLATION INSTRUCTIONS
© Panduit Corp. 2015 PN511FINSTALLATION INSTRUCTIONS © Panduit Corp. 2016
Page 2 of 2
E-mail:
[email protected]m
Phone:
866-405-6654
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp www.panduit.com
13
REMOVAL STEPS
1
2
3
Notes:
1. For specified performance, follow TIA/EIA 568-C installation guidelines.
2. Jack modules can terminate 22-26 AWG solid or stranded IWC data cable with 0.062" (1.57mm) maximum insulated conductor outside diameter.
3. Jack modules may be re-terminated a minimum of 20 times.
4. For technical and performance information, consult Panduit technical support.
As with all Wiring Accessories, the following statements apply:
1. Never install communications wiring during a lightning storm.
2. Never install communications wiring in wet locations unless the jack is specifically designed for use in wet locations.
3. Never touch uninsulated communications wiring or terminals unless the communication line has been disconnected at the network interface.
4. Use caution when installing or modifying communication wiring.
14
15
EGJT
12 T568B Wiring
(OR)
1.
1. 2.
R
F
R
F
T568A Wiring
12
(OR)
1.
1.
R
F
R
F
2.
2.

4
Cable Prep for non-MaTriX Category 6A Cable
1
2
CWST
3
Continue with steps 8-15 on pages
1 and 2 to complete termination.
