Panduit ATLONA AT-UHD-CLSO-601 User guide

Atlona Manuals
Switchers
AT-UHD-CLSO-601
Application Programming Interface
Multi-Format Switcher
w/Mirrored HDMI and HDBaseT Outputs
4K/UHD 6 Input

AT-UHD-CLSO-601 2
Version Release Date Notes
1 Aug 2022 Initial release
Version Information

AT-UHD-CLSO-601 3
Commands
Command Description
APwrOTime Set the time interval before the command to power-o the display is sent
Aspect Sets the aspect ratio of the output signal
ASwOutTime Sets the time interval for auto-switching when no signal is detected
ASwPrePort Sets the default fallback input for auto-switching
AUD Selects the audio input to be output
AutoDispO Sends the power-o command to the display when a no source is detected
AutoDispOn Sends the power-on command to the display when a source signal is received
AutoPwrMode Sets the auto-power mode
AutoSW Sets the auto-power display mode
Blink Enables or disables blinking of the POWER LED indicator on the front panel
BNR Adjusts the block video noise reduction setting
Broadcast Enables or disables broadcast mode
CliIPAddr Sets the IP address of the controlled device
CliMode Sets the login mode of the controlled device
CliPass Sets the password for the controlled device
CliPort Sets the listening port for the controlled device
CliUser Sets the username for the controlled device
CSpara Sets the baud rate, data bits, parity bit, and stop bits for the local serial port
CtlType Sets the control protocol used to communicate with the display device
DispCEC Activates CEC control
DispIP Activates IP control
DispRS Activates serial (RS-232) control
EQB Adjusts the bass EQ setting
EQT Adjusts the treble EQ setting
HDCPSet Sets the HDCP mode on the desired input
help Displays the list of available commands
Input Sets the input source
InputBroadcast Invokes the InputStatus command
InputStatus Displays the status of the inputs as either a 0 or 1
IPAddUser Adds a user for Telnet control
IPCFG Displays the current network settings for the AT-UHD-CLSO-601
IPDelUser Deletes the specied Telnet user
IPDHCP Enables or disables DHCP mode on the AT-UHD-CLSO-601
IPLogin Enables or disables login credentials when starting a Telnet session
IPPort Sets the Telnet listening port for the AT-UHD-CLSO-601
IPQuit Terminates the current TCP/IP session
IPStatic Sets the static IP address, subnet mask, and gateway for the AT-UHD-CLSO-601
IPTimeout Species the time interval of inactivity before the Telnet session is closed
Lock Locks the buttons on the front panel
IMPORTANT: Each command is terminated with a carriage-return (0x0d) and the feedback is
terminated with a carriage-return and line-feed (0x0a).
The following tables provide an alphabetical list of commands available on the AT-UHD-CLSO-601. All commands
are case-sensitive and must be entered as documented. If the command fails or is entered incorrectly, then the
feedback is “Command FAILED”.

AT-UHD-CLSO-601 4
Commands
Command Description
LVOL Adjusts the line volume
Menu Provides remote operation of the On-Screen Display (OSD)
MIC Adjusts the microphone ducking settings
MNR Congures Mosquito Noise reduction
Mreset Resets the AT-UHD-CLSO-601 to factory-default settings
MVOL Adjusts the microphone volume
OSD Sets the OSD status
OutAMute Sets the output audio mute status of HDMI and HDBT
PollAddIn Adds source for analog polling
PollDelIn Deletes source for analog polling
PrefTimg Sets the preferred timing for the HDMI port
ProjSWMode Sets the projector lamp cool-down timer, in seconds
ProjWarmUpT Sets the projector lamp warm-up timer, in seconds
PWOFF Power-o the AT-UHD-CLSO-601
PWON Power-on the AT-UHD-CLSO-601
PWSTA Displays the current power state of the AT-UHD-CLSO-601
RepCmdTime Sets the number of times a command will be sent
RepeatCmd Enables / disables the RepCmdTime feature
RHostName Displays the hostname of the AT-UHD-CLSO-601
RNR Congures video random noise reduction
RS232para Sets the baud rate, data bits, stop bits, and parity for the RS-232 port
RS232zone Send a command to the RS-232 device connected to the RS-232 port on the receiver
SetCmd Assigns the Command parameter to the specied command string
SHostName Sets the hostname of the AT-UHD-CLSO-601
SnVOL Increases or decreases the volume on the specied output
System Displays the status of the AT-UHD-CLSO-601
TrigCEC Sends the specied command to the display using the CEC protocol
TrigIP Sends the specied command to the display using the IP protocol
TrigRS Sends the specied command to the display using the serial (RS-232) protocol
Type Displays the model of the transmitter
Unlock Unlocks the buttons on the front panel
Version Displays the current rmware version of the AT-UHD-CLSO-601
VFmtRes Sets the output video format to the specied resolution
VGAPrefT Sets the preferred VGA timing to the specied EDID
VOL Sets the master volume to the specied level
VOLMute Toggles volume output muting

AT-UHD-CLSO-601 5
Commands
APwrOTime
Set the time interval, in seconds, before the command to power-o the display is sent, once an A/V signal is no
longer detected. Use the sta argument to display the current setting.
Example
APwrOTime 120
Syntax
APwrOTime X
Parameter Description Range
X Time interval 5 ... 3600, sta
Feedback
APwrOTime 120
Aspect
Sets the output aspect ratio. Use the sta argument to display the current setting.
Syntax
Aspect X
Parameter Description Range
XSetting full, overscan, underscan, letterbox, panscan, follow, sta
Example
Aspect 1 ll
Feedback
Aspect 1 ll
ASwOutTime
Sets the time interval, in seconds, before the unit automatically switches to another active input if no signal is
received from the current input. Use the sta argument to display the current setting.
Syntax
ASwOutTime X
Parameter Description Range
X Time interval 3 ... 600, sta
Example
ASwOutTime 10
Feedback
ASwOutTime 10

AT-UHD-CLSO-601 6
Commands
ASwPrePort
Sets the default fallback port for auto-switching.
AUD
Embeds the selected audio input on to the desired HDMI or VGA input. To pass-through audio, normally, specify AiP
as the second argument.
Syntax
ASwPrePort X
Syntax
AUD InX AiY
Parameter Description Range
XVideo Port HDMI1, HDMI2, HDMI3, HDMI4,
VGA1, VGA2, PREVIOUS
Parameter Description Range
XVideo Port 1 ... 6
YAudio Port 5, 6, P
Example
ASwPrePort HDMI1
Example
AUD In2 Ai6
Feedback
ASwPrePort HDMI1
Feedback
AUD In2 Ai6
AutoDispO
Sends the power-o command to the display when a no source is detected. Specify the sta argument to display the
current setting.
Syntax
AutoDispO X
Parameter Description Range
XState on, off, sta
Example
AutoDispO on
Feedback
AutoDispO on

AT-UHD-CLSO-601 7
AutoDispOn
Sends a power-on command to the display when a source signal is received. Specify the sta argument to display the
current setting.
Syntax
AutoDispOn X
Parameter Description Range
XState on, off, sta
Example
AutoDispOn on
Feedback
AutoDispOn on
Commands
AutoPwrMode
Sets the auto-power mode. Specify the sta argument to display the current setting.
Example
AutoPwrMode DISPAVON
Syntax
AutoPwrMode X
Parameter Description Range
XMode DISPAVON, DISPAVSW, AVSW, sta
Feedback
AutoPwrMode DISPAVON
AutoSW
Enables or disables auto switching or display auto switching status.
Example
AutoSW on
Syntax
AutoSW X
Parameter Description Range
XValue on, off, sta
Feedback
AutoSW on

AT-UHD-CLSO-601 8
Blink
Enables or disables blinking of the POWER button on the front panel. When set to on, the POWER button will ash,
alternating between red and blue, and can be used to physically identify the unit on a network. The POWER button
will ash until the Blink o command is executed. on = enables blinking; o = disables blinking; sta = displays the
current setting. The default setting is o.
BNR
Congures the video block noise reduction. The default setting is o. Specify the sta argument to return the current
value.
Syntax
Blink X
Syntax
BNR X
Parameter Description Range
XValue on, off, sta
Parameter Description Range
XSetting off, low, medium, high, sta
Example
Blink on
Example
BNR medium
Feedback
Blink on
Feedback
BNR medium
Commands
Broadcast
Enables or disables broadcast mode. By default, broadcast mode is set to o. When set to on, changes in the web
GUI will also be aected on the control system (if connected), via TCP/IP. To separate control between web GUI and
Telnet, set this feature o. on = enables broadcast mode; o = disables broadcast mode; sta = displays the current
setting.
Syntax
Broadcast X
Parameter Description Range
XValue on, off, sta
Example
Broadcast on
Feedback
Broadcast on

AT-UHD-CLSO-601 9
Commands
CliIPAddr
Sets the IP address of the controlled device. The IP address must be specied in dot-decimal notation. Use the sta
argument to display the IP address of the device. DHCP must be disabled before using this command. Refer to the
IPDHCP command for more information.
Example
CliIPAddr 192.168.1.61
Syntax
CliIPAddr X
Parameter Description Range
XIP address 0 ... 255 (per byte)
Feedback
CliIPAddr 192.168.1.61
CliMode
Sets the login mode of the controlled device. login = requires login credentials, non-login = no login credentials
required. Use the sta argument to display the current setting.
Example
CliMode login
Syntax
CliMode X
Parameter Description Range
XValue login, non-login, sta
Feedback
CliMode login
CliPass
Sets the password for the controlled device. Execute the CliPass command without arguments to display the current
password. The default password is Atlona.
Example
CliPass R3ind33r
Syntax
CliPass X
Parameter Description Range
XPassword 20 characters (max.)
Feedback
CliPass R3ind33r

AT-UHD-CLSO-601 10
Commands
CliPort
Sets the listening port for the controlled device. Use the sta argument to display the current listening port.
The default port is 23. Use the sta argument to display the current setting.
Example
CliPort 50
Syntax
CliPort X
Parameter Description Range
XPort 0 ... 65535, sta
Feedback
CliPort 50
CliUser
Sets the username for the controlled device. Execute the CliUser command without arguments to display the current
username.
Example
CliUser BigBoss
Syntax
CliUser X
Parameter Description Range
XUsername 20 characters (max.)
Feedback
CliUser BigBoss
CSpara
Sets the baud rate, data bits, parity bit, and stop bits for the serial port. Use the sta argument to display the current
serial port settings. Each argument must be separated by a comma; no spaces are permitted. Brackets must be
used when executing this command.
Syntax
CSpara[W,X,Y,Z]
Example
CSpara[115200,8,0,1]
CSpara[sta]
Feedback
CSpara[115200,8,0,1]
CSpara [115200,8,0,1]
Parameter Description Range
W Baud rate 2400, 4800, 9600, 19200, 38400, 57600, 115200
XData bits 7, 8
Y Parity bit None, Odd, Even
ZStop bits 1, 2

AT-UHD-CLSO-601 11
Commands
CtlType
Sets the control protocol used to communicate with the display device. Use the sta argument to display the current
setting.
Syntax
CtlType X
Example
CtlType ip
Feedback
CtlType ip
Parameter Description Range
XValue rs-232, ip, cec, sta
DispCEC
Turns the display on or o using the CEC protocol. Unlike the TrigCEC command, this command will wait until the
warm-up and cool-down timers have expired. Refer to the ProjWarmUpT and ProjSWMode commands for setting
these timers. on = power on the display, o = power-o the display. Use the sta argument to display the current
setting.
Syntax
DispCEC X
Example
DispCEC on
Feedback
DispCEC on
Parameter Description Range
XValue on, off, sta
DispIP
Turns the display on or o using the IP protocol. Unlike the TrigIP command, this command will wait until the warm-
up and cool-down timers have expired. Refer to the ProjWarmUpT and ProjSWMode commands for setting these
timers. on = power on the display, o = power-o the display. Use the sta argument to display the current setting.
Syntax
DispIP X
Example
DispIP on
Feedback
DispIP on
Parameter Description Range
XValue on, off, sta

AT-UHD-CLSO-601 12
DispRS
Turns the display on or o using the RS-232 (serial) protocol. Unlike the TrigRS command, this command will wait
until the warm-up and cool-down timers have expired. Refer to the ProjWarmUpT and ProjSWMode commands for
setting these timers. on = power on the display, o = power-o the display. Use the sta argument to display the
current setting.
EQB
Adjusts the bass equalizer to the specied level. Levels can also be increased or decreased by increments of 1.
When incrementally increasing or decreasing the current bass level, do not specify the parentheses as part of the
command. Refer to the examples below.
Syntax
DispRS
Syntax
EQB(X)
Example
DispRS on
Example
EQB(-10)
EQB+ // increment bass by 1
EQB- // decrement bass by 1
Feedback
DispRS on
Feedback
EQB(-10)
EQB+
EQB-
Parameter Description Range
XValue on, off, sta
Parameter Description Range
XValue -96 ... 120, +, -
Commands

AT-UHD-CLSO-601 13
EQT
Adjusts the treble equalizer to the specied level. Levels can also be increased or decreased by increments of 1.
When incrementally increasing or decreasing the current treble level, do not specify the parentheses as part of the
command. Refer to the examples below.
Syntax
EQT(X)
Example
EQT(-10)
EQT+ // increment treble by 1
EQT- // decrement treble by 1
Feedback
EQT(-10)
EQT+
EQT-
Parameter Description Range
XValue -96 ... 120, +, -
Commands
HDCPSet
Set the HDCP reporting mode of the specied HDMI port. Some computers will send HDCP content if an HDCP-
compliant display is detected. on = reports to the source device that the display (sink) is HDCP-compliant, o =
reports to the source device that the display (sink) is not HDCP-compliant (HDCP content will not be sent), auto =
uses the attributes of the display device to accept or not accept HDCP content. Setting this value to o does not
decrypt HDCP content. Use the sta argument to display the current setting.
Syntax
HDCPSetX [Y]
Parameter Description Range
XHDMI port 1 ... 4
YMode on, off
Example
HDCPSet 1 on
Feedback
HDCPSet 1 on

AT-UHD-CLSO-601 14
help
Displays the list of available commands. To obtain help on a specic command, enter the help command followed
by the name of the command.
Input
Selects the input source.
Syntax
help [X]
Syntax
Input X Y
Parameter Description Range
XCommand name (optional) Command
Parameter Description Range
XInterface HDMI, VGA
YIndex 1, 2, 3, 4 (HDMI)
5, 6 (VGA)
Example
help
Example
Input HDMI 2
Feedback
help
SHostName
RHostName
PWON
PWOFF
PWSTA
...
...
Feedback
Input HDMI 2
Commands

AT-UHD-CLSO-601 15
InputBroadcast
Enabling this feature will invoke the InputStatus command, when a new source is connected, and will return the state
of all inputs. This also applies when auto-switching occurs. on = enable; o = disable; sta = displays the current
setting.
Example
InputBroadcast on
Syntax
InputBroadcast X
Parameter Description Range
XState on, off, sta
Feedback
InputBroadcast on
Commands
InputStatus
Displays the status of the specied input as either a 0 or 1. If a source is detected on the input, then a 1will be
displayed. Inputs with no source connected will display a 0.
Example
InputStatus1
Syntax
InputStatusX
Feedback
InputStatus1 1
Parameter Description Range
XPort 1 ... 2, Null
IPAddUser
Adds a user for web GUI login and Telnet sessions. This command performs the same function as adding a user
within the web GUI. Refer to User Manual for more information.
Example
IPAddUser BigBoss b055man
Syntax
IPAddUser X Y
Parameter Description Range
XUser name 20 characters (max)
YPassword 20 characters (max)
Feedback
IPAddUser BigBoss b055man
TCP/IP user was added

AT-UHD-CLSO-601 16
Commands
IPCFG
Displays the current network settings for the AT-HDVS-SC-RX.
Example
IPCFG
This command does not require any parameters
Syntax
IPCFG
Feedback
IP Addr 192.168.11.176
Netmask 255.255.255.0
Gateway 192.168.11.1
IP Port 23
IPDelUser
Deletes the specied user. Deleted users will no longer be able to access the web GUI or initiate Telnet sessions.
This command performs the same function as removing a user within the web GUI. Refer to the User Manual for
more information.
Example
IPDelUser Minion2
Syntax
IPDelUser X
Parameter Description Range
XUser User name
Feedback
IPDelUser Minion2
TCP/IP user was deleted
IPDHCP
Enables or disables DHCP mode on the AT-UHD-CLSO-601. on = DHCP mode ON; o = DHCP mode OFF; sta =
displays the current setting. If this feature is disabled, then a static IP address must be specied. The default setting
is DHCP = ON.
Example
IPDHCP on
Syntax
IPDHCP X
Parameter Description Range
XValue on, off, sta
Feedback
IPDHCP on

AT-UHD-CLSO-601 17
Commands
IPLogin
Enables or disables the use of login credentials when initiating a Telnet session on the AT-HDVS-SC-RX. If this
feature is set to on, then the AT-UHD-CLSO-601 will prompt for both the username and password. Use the same
credentials as the web GUI. on = login credentials required; o = no login required. Use the sta argument to display
the current setting. The default setting is on.
Example
IPLogin o
Syntax
IPLogin X
Parameter Description Range
XValue on, off, sta
Feedback
IPLogin o
IPPort
Sets the TCP/IP listening port for the AT-UHD-CLSO-601.
Example
IPPort 230
Syntax
IPPort X
Parameter Description Range
XPort 0 ... 65535, sta
Feedback
IPPort 230
IPQuit
Closes the current Telnet session.
Example
IPPort 230
Syntax
IPQuit
Feedback
IPPort 230
This command does not require any arguments

AT-UHD-CLSO-601 18
Commands
IPStatic
Sets the static IP address, subnet mask, and gateway (router) address of the AT-HDVS-SC-RX. Before using this
command, DHCP must be disabled on the AT-HDVS-SC-RX. Refer to the IPDHCP command for more information.
Each argument must be entered in dot-decimal notation and separated by a space. The default static IP address of
the AT-HDVS-SC-RX is 192.168.1.254.
Example
IPStatic 192.168.1.112 255.255.255.0 192.168.1.1
Syntax
IPStatic X Y Z
Parameter Description Range
XIP address 0 ... 255 (per byte)
YSubnet mask 0 ... 255 (per byte)
Z Gateway (router) 0 ... 255 (per byte)
Feedback
IPStatic 192.168.1.112 255.255.255.0 192.168.1.1
IPTimeout
Species the time interval of inactivity before the TCP/IP session is terminated. When terminated, both the Telnet
and web GUI session will be closed. The default setting is 300 seconds.
Example
IPTimeout 300
Syntax
IPTimeout X
Parameter Description Range
XInterval (in seconds) 1 ... 60000
Feedback
IPTimeout 300
Lock
Locks the buttons on the front panel. This feature is useful when the unit is installed in a rack environment or other
remote location, to prevent accidental pressing of the front-panel buttons. Also refer to the Unlock command.
Syntax
Lock
Example
Lock
Feedback
Lock
This command does not require any parameters

AT-UHD-CLSO-601 19
Commands
LVOL
Adjusts the line volume level to the specied level. Volume levels can also be increased or decreased by increments
of 1. When incrementally increasing or decreasing the current line level, do not specify the parentheses as part of the
command. Refer to the examples below.
Menu
Provides remote operation of the On-Screen Display (OSD). For example, to select an option on the OSD, use the
Menu[Sel] command.
MIC
Congures the microphone ducking settings. atime = attack time, rtime = release time, sens = trigger level, reduce =
program decrease.
Syntax
LVOL(X)
Syntax
MenuX
Syntax
MICX Y
Example
LVOL(-10)
LVOL+ // increment level by 1
LVOL- // decrement level by 1
Example
MenuSel
Example
MICatime 20
Feedback
LVOL(-10)
LVOL+
LVOL-
Feedback
MenuSel
Feedback
MICatime 20
Parameter Description Range
XValue -80 ... 0, +, -
Parameter Description Range
XOperation Sw, Up, Down, Left, Right, Info, Sel
Parameter Description Range
XSetting on, off, sta, atime, rtime, sens, reduce
YValue 0 ... 20

AT-UHD-CLSO-601 20
Commands
MNR
Congures video mosquito noise reduction. Use the sta argument to return the current setting.
Syntax
MNR X
Example
MNR low
Feedback
MNR low
Parameter Description Range
XSetting off, low, medium, high, sta
Mreset
Resets the AT-UHD-CLSO-601 to factory-default settings.
Example
Mreset
Syntax
MReset
Feedback
Mreset
This command does not require any parameters
MVOL
Adjusts the microphone to the specied level. Microphone levels can also be increased or decreased by increments
of 1. When incrementally increasing or decreasing the current microphone level, do not specify the parentheses as
part of the command. Refer to the examples below.
Syntax
MVOL(X)
Example
MVOL(-10)
MVOL+ // increment level by 1
MVOL- // decrement level by 1
Feedback
MVOL(-10)
MVOL+
MVOL-
Parameter Description Range
XValue -80 ... 0, +, -
