panthera S3 User manual

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, [phone], www.panthera.se
ASSEMBLY INSTRUCTION
art.nr. mont-S3-körhandtag-HS-eng
Rev.2017-02
PUSH HANDLE S3 HEIGHT ADJUSTABLE
1) Open up one of the attachments and
place it around the backrets tube and t
the hole in the attachment over the knob
on the tube. Note that there is a left and a
right versions av the attachment.
2) Stick the push handle tube into the at-
tachment and lock it..
3) Squeeze the attachment to help t the
screw into the threaded hole. Tighten the
screw a few turns by hand.
Assembly instruction(adjustment page 2) for:
Push handle S3 Height adjustable
art.no. 4252060
Tools needed:
Allen key 4 mm
Allenkey 2.5 mm
Spanner 8 mm
4) Finaly tighten the screw rmly with al-
len key 4 mm using a wrench
5) Done.

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, [phone], www.panthera.se
1) If the locking of the push handle is in-
sufcient. you can adjust this according
to the following instructions..
2) Disassemble the push handle. Loose
this screw a few turns with allen key 2.5
mm.
3) Push the screw downwards until the
nut on the underside gets visible
ADJUSTMENT OF LOCKING LEVER
4) Adjust the locking force by turning the
nut anti-clockwise (seen from the top) to
encrease it, and clockwise to decrease
the locking force. Turn the nut a quarter
of a turn, using a 8 mm spanner, tighten
the screw and test it..
5) Tighten the screw and make sure that
the nut slides into the attachmnet pro-
perly.
6) Mount the push handle and check the
locking force.
Repeat step 3-5, if adjustment is needed.
