HD88
720P HD Outdoor Camera
Installation Manual
**Compatible with Insite
GOLD and SWAN Server**
Introduction
The HD88 is an outdoor 720P HD camera with built-in sound, pet
immune security motion detector, with Ethernet and WiFi. It
provides up to 30 minutes of internal Recording on Trigger memory
space, or 16GB to 256Gb SD card that can be added for additional
recording space.
Installing the HD88
Bracket Installation
If wall bracket tamper is connected, tamper will automatically be
detected by the camera. Tamper will follow recognition settings set
in the panel.
HD88 Bus / Ethernet Wiring
Wire the HD88 camera with a CAT5e or higher cable. Connect the two
twisted pairs to the Green (Data) and Clock (Y) of the panel bus and
two twisted pairs for the Ethernet lines. The maximum CAT5e cable
length is 50 meters. When using Ethernet do NOT use Green (Data)
and Yellow (Clock) in one twisted pair, but rather separate them into
different twisted pairs as shown below.
Use a separate minimum 18 gauge wire for the power. If your power is
not coming from the panel or a bus power supply then you will also
need to connect the solid blue of the CAT5e cable to the negative (-) of
the camera to have a common ground.
HD88 WiFi Wiring
Wire the HD88 camera with a standard 4-wire bus cable. Connect the
Yellow and Green to the Green (Data) and Yellow (Clock) of the panel
bus.
Use a separate 18 gauge (minimum) wire for the power. If your power
is not coming from the panel or a bus power supply then you will also
need to connect the Black of the 4-wire bus cable to the negative (-) of
the camera to have a common ground.
Unscrew and
remove cover
Lock and Tamper
Drill Out
Holes
Mount back on wall
or bracket
Terminal
Block
Anti-
Tamper
If you are installing the HD88 near any reflecting surface, please
note that it may affect the quality of the night vision due to the IR
reflection.
4-Wire
Spectra/EVO bus
CAT5E Connection
Ethernet
Router or Switch
12345678
Note: Green (Data) and Yellow (Clock) need to be on
separate pairs otherwise bus errors will occur.
18
AWG
18 AWG

HD88-EI01 12/2018 paradox.com
HD88 Wiring Table
Creep Zone/Pet Selection
Remove detector assembly. When selector is UP, Pet
Mode; when DOWN, Creep Zone is active and there is no
Pet Immunity. Above 2.4m Pet Immune should be OFF
(lever down Pet OFF, see installation height note*.
Installation Height:
Pet Immune ON - 2.0m/6.6ft to 2.4m/7.8ft
Pet Immune OFF - 2.0m/6.6ft to 2.8m/9ft (lever down)*
*For installations higher than 2.6m, when needed, tilt
the detector down a few degrees for best detection
results; use of a bracket is recommended.
Registration LED Status Indicators
SD Card Installation
An SD card can be inserted into the HD88 in order to provide
additional recording time. Please note that if using Record On
Trigger, an SD card must be inserted into the camera as shown.
LED Status Indicators
Other than PIR detection, LEDs are active when lock mechanism
is open.
*VOD On/Off LED is controlled by the Master ONLY, using
the Insite GOLD application.
Recommended Wire
Assignment Ethernet Connector
Bus Label Wire Color Ethernet
Connector Wire Color
RX- Orange 1 Green
striped
RX+ Orange striped 2 Green
TX- Green 3 Orange
striped
TX+ Green striped 4
Y Brown striped 5
G Blue striped 6 Orange
B- Black (18 AWG) 7
R+ Red (18 AWG) 8
WiFi Wire Assignment Bracket Wire Assignment
4-Wire Bus
Label Wire Color Bus Label Wire Color
Y Yellow TMP Blue
G Green B- Black
B- Black (18 AWG)
R+ Red (18 AWG)
UP - Pet DOWN - Creep
Network Status LED Functionality
HD88 is not connected to a local
WiFi network
LED and LED will flash
intermittently
HD88 is connected to a local
network but failed to poll the
SWAN Server
LED is set to On
and LED is Flashing
HD88 is connected to a local
network and succeeded in polling
the SWAN Server
LED is set to On
and LED is set to On
LED Functionality LED Display
TX
Digiplex/Spectra Data TX Flashing green: Data
transmission
Off: No data
transmission
RX
Digiplex/Spectra Data RX Flashing green: Data
reception
Off: No data reception
Firmware upgrade in
progress.
Flashing purple
VOD* Blue on
Power-up Flashing blue
Locate mode Flashing blue
No connection to panel bus Flashing red
Bus low power Flashing red
PIR detection Red on for 3 seconds
Active Wi-Fi Green on
LAN 10/100Mb link Green on: LAN active

HD88-EI01 12/2018 paradox.com
HD88 Camera Set Up and Configuration
5Select the WiFi network
that the camera will be
registered to.
6Enter the WiFi
password and press
continue.
7A QR code will be
generated. Present the QR
code to the camera lens.
Ensure tamper is open by
unscrewing screw at the
bottom of the HD88.
8The HD88 WiFi Camera will
then be displayed in the
modules list with a WiFi
symbol next to it. Press
Configure to modify settings.
1Launch the Insite Gold
app 2Select New Installation and then the Create button. 3Type in the Panel Serial Number, Site ID, Client’s
Email Address and
Installer Email.
4To add a WiFi Camera, press
Add WiFi Camera. If you are
not configuring a WiFi
Camera, skip to Step 10.
9Configure your settings
and press Save when
completed.
10 Press Create New Site. A
Site Created message will
appear. The system will send
you an email.
11 Retrieve your email and
click Activate. You will then
be prompted to choose the
type of activation for your
subscription.
12 Your site will then be created
and displayed in the app.

HD88-EI01 12/2018 paradox.com
PIR Detector Beam Patterns
Top View
Camera View
Side View
Camera View
Technical Specifications
16m
(52’)
100°
110°
1.5m
(3.3’)
1.5m
(3.3’)
3m
(10’)
3m
(10’)
5.5m
(16’)
5.5m
(16’)
10m
(33’)
10m
(33’)
12m
(40’)
12m
(40’)
16m
(52’)
0m
10m
(33’)
5.5m
(16’)
3m
(10’)
1.5m
(3.3’)
16m
(52’)
12m
(40’)
Detector 1 Detector 2 Both Detectors
2.1m
(6.8’)
Image Resolution 1280 x 720
Image Sensor Type 1.4 mega pixels, CMOS sensor,
7V/LUX.Sec
Streaming Video 720p H.264 10 FPS
HD Audio 16 bit, 24 KHz sampling rate, 32 Kb/s
mono
Pre-event
recording
-3.0 sec. pre-trigger
Internal storage
15 minutes alarm and 15 minutes
ROT/VOD
File length - 10 sec. 3 min. detection
dependent
PIR Sensor / Lens 2x dual element/Mironel lens
Pet Immune True Paradox Pet Immune
Detection Speed 0.2 m/s to 2.5 m/s (0.6 ft/s to 11.5 ft/s)
Voltage Input Nominal: 12VDC, range 9-16VDC
Current
Consumption Max
350mA - IR illumination ON
250mA - IR illumination OFF
100mA - System lost AC /
Battery operation
Dimensions
(H x W x D)
16.8 x 6.8 x 7.4 cm
(6.6 x 2.7 x 2.9 in)
Operating
Temperature
-40° C to +60° C (-40° F to 140° F)
Compliance CE, EN 50131-2-2 Grade 2
Environmental Class II
Installation Height 2.1m - 2.7m (7ft - 9ft)
Installation options Wall or corner, swivel bracket optional
Compatibility EVOHD, EVO192, SP5500, SP6000
and SP7000
Warranty
For complete warranty information on this product, please refer to the Limited Warranty Statement is found on the website:
www.paradox.com/terms or contact your local distributor. Specifications may change without prior notice.
