Park Safe PSC40 User manual

Prior to Installation
Read the manual prior to installation. Technical knowledge is necessary for installation. Please
ensure you use the correct tools to avoid damage to the vehicle or product.
Parksafe can not be held responsible for the installation of this product.
Technical Support
Parksafe want to provide a fast and suitable resolution should you encounter any technical
issues. With this in mind, when contacting Parksafe, try to provide as much information as
possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: [email protected]
Rearview Camera
Image Sensor: 1099 HD CCD
TV Lines: 480
Lumen: 0.1 Lux
Horizontal Angle: 170 Degrees
Vertical Angle: 120 Degrees
TV System: PAL
Video Output: 1.0V p-p 75ohm
Operating Voltage: 12V DC (Negative Ground)
Current Consumption: 120mA @ 13.8V
Waterproof Rating: IP68
Operating Temperature: -20 Degrees C to +70 Degrees C
Parking Lines: Yes
Image: Mirror/Normal
Enhanced performance in low light: Yes
DISCLAIMER:
User Manual
PSC40
PRODUCT FEATURES:

PARKSAFEAUTOMOTIVE.COM
2
CONTENTS
-Camera with 1m cable to mini male 6 pin connector
-1m camera connection cable with mini female 6 pin connector and RCA
female connector
-6m Male to Male RCA extension cable
-18mm hole saw
-Instructions
INSTALLATION
1. Connect the Black wire to a suitable ground and the Red wire to a switched+12V supply.
2. If the camera is to be used in the rear of the vehicle, the Red wire should be connected
to the reversing light circuit or an interface which provides a reverse signal.
3. Select a suitable location for the camera and ensure that the area is free from all cables,
fuel & oil. Whenever possible, avoid locations that are subject to road dirt & water spray.
4. Aim to mount the camera preferably 45-60cm from the ground and cut a suitable hole
using the cutting tool provided.
5. Using the supplied video cable, connect the camera to the display screen and ensure
that the image is displayed correctly.
Setting functions
Parking lines:
Green Uncut = Parking lines ON
Green Cut = Parking lines Off
Mirror function:
White Cut = Front facing
White Uncut = Rear facing
