Parker Pneumatic MPS-2 Series Installation and maintenance instructions

Pneumatic Division
Richland, Michigan 49083
!
!
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.
• Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical
supplies (when necessary) should be connected and the product
tested for proper function and leakage. If audible leakage is present,
or the product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be covered
by paint, etc. If masking is not possible, contact your local
representative for replacement labels.
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF
THE PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR
RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND
PROPERTY DAMAGE.
This document and other information from Parker Hannifin Corporation,
its subsidiaries and authorized distributors provide product and/or
system options for further investigation by users having technical
expertise. It is important that you analyze all aspects of your application,
including consequences of any failure and review the information
concerning the product or systems in the current product catalog. Due
to the variety of operating conditions and applications for these products
or systems, the user, through its own analysis and testing, is solely
responsible for making the final selection of the products and systems
and assuring that all performance, safety and warning requirements
of the application are met.
The products described herein, including without limitation, product
features, specifications, designs, availability and pricing, are subject
to change by Parker Hannifin Corporation and its subsidiaries at any
time without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR
INCLUSION IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE
THESE PRODUCTS. CONTACT YOUR LOCAL REPRESENTATIVE.
Installation & Service Instructions
CVM-102P
MPS-2 Series Sensor
ISSUED: June, 2003
Supersedes: July, 2002
Doc.# CVM-102P, ECN030385, Rev. 2
ANSI
Introduction
Follow these instructions when installing, operating, or servicing
the product.
IP65 Kit (Included Parts)
1 Venting Nipple M3
1 Washer M3
21
!
DIN Rail Mounting Kit (Accessory Kit)
1 DIN Rail
2 Washer M3
2 Screws M3
21
Barb
Couplin
g
O-Ring
Ambient Air
Inlet Port
21
For 1/8 Inch Male Series Installation
Cautions
The MPS-2 Pressure Sensor is designed to monitor pressure
and is not a safety measure to prevent accidents.
The compatibility of the sensor is the responsibility of the
designer of the system and specifications.
Operating Environment
•Parker / Convum Sensors have not been investigated for
explosion- proof construction in hazardous environments.
•Do not use with flammable gases, liquids, or in hazardous
environments.
•Avoid installing the sensor in locations where excessive
voltage surges could damage or affect the performance of
the sensor.
Operations
•Dedicate a power supply of 10.8 to 30VDC to the sensor
and set the ripple to Vp-p10% or less. Avoid excessive
voltage. Avoid voltage surges.
•A small amount of internal voltage drop is possible. Ensure
the power supply minus any internal voltage drop exceeds
the operating load.
•Verify the operating media is compatible with the specified
sensor. Check the chemical make-up, operating
temperatures, and maximum pressure ranges of the system
before installing.
•Installation of air dryer system is recommended to remove
moisture.
Installation
•Never insert an object into the pressure port other than an
appropriate fluid connector.
•Avoid short-circuiting the sensor. Connect the brown lead
to V+ and blue lead to 0V.
•Do not connect the output lead wires (black / white) to the
power supply.
•Outputs not being used should be trimmed and insulated.
•Install as shown using the metal mounting base.
•To achieve IP65 rating, connect the o-ring and barb to a
normal environment with a 2mm I. D. tube as shown below.

MPS-2 Series Sensor CVM-102P
2
2
1
4
3
Sensor Pin Out
Pin #
1 Brown: 24VDC
2 White: NPN / PNP Open Collector Output
3 Blue: 0VDC
4 Black: NPN / PNP Open Collector Output
Output Modes
The MPS-2 Series Sensor has two independent NPN or PNP
open collector output signals. The Switch Output Mode has a
switch point programmed by the user at a specified pressure.
The Hysteresis Range (h) adjustment controls the output signal
0 to 100% below the Switch Point (H).
The Window Comparator Mode provides two Switchpoint Settings
(A) and (b) that control the output signals (NPN / PNP) between
two pressures. This is referred to as the “High / Low” setting.
h
H
off off
0
-30 in Hg
on on
A
b
off
off off
-30 in. Hg
0
on on
Switch Output
Window Comparator Output
Operating Pressure Range (V) Vacuum (0 to -30 inHg) (R) Compound (-14.7 to +72.5 PSI)
bar: 0.001 bar: 0.01
Units of Measure kPa: 0.1 kPa: 1
Display Resolution mmHg: 1 kgf/cm2: 0.01
inHg: 0.1 PSI: 0.1
Media Air and Non-Corrosive Gases
Pressure Port N: 1/8" NPT, R: 1/8" BSPT, G: 1/8" BSPP, M5: M5 Female
Proof Pressure V: 72.5 PSI, R: 116.0 PSI
Operating Temperature 32 to 122°F (0 to 50°C)
Storage Temperature 14 to 140°F (-10 to 60°C)
Humidity 35 to 85% RH
Electrical Connection C: 4-Pin, M8 Connector, G: 2m Grommet Open Lead
Power Supply 10.8 to 30VDC, Ripple Vp-p 10% Max., Reverse Voltage Protection
Display 3-Digit, 7-Segment LED
Display Refresh 0.1 to 3.0 sec. (Factory set at 0.1)
Output Circuit NPN (Sinking) or PNP (Sourcing) Output, Open Collector Transistor 30VDC, 125mA
Switch Output 2 Output Signals, NPN or PNP, Normally Open or Closed, LED Indicator
Output Modes Hysteresis or Window Comparator
Specifications
Brown V+
White Analog 1 to 5 VDC
Blue 0V
Black NPN / PNP Output
Lead Wiring

MPS-2 Series Sensor CVM-102P
3
Output Set Open
or Closed Selecting
Units of Measure
Easy Mode
Activation
Output Mode 1
Hysteresis or
Window
Comparator
Output Mode 2
Hysteresis or
Window
Comparator
Output 1 Setting Output 2 Setting Automatic Teach Mode
& Auto Surveillance
Display Refresh
Settings / Output
Response Time
Interval
Lock Unlock
Special Display
Features
Zero
Reset
Display Peak Value
Bottom Value or
Their Difference
Vacuum
Cycle
Release
Cycle
Peak
Value
Bottom
Value
1 2 3
4 5 6
7 8 9
10
11 12
21
21
21
21
21
21
21
21212121
21
21
21
21
Press 6x
Press for 3 Seconds
Press 1x
Hold
Press 1x
Press 7x Press 8x
Press 1x
Press 3x
Press 2x
Press 5x
Press 4x
Hold
Press
Hold
Press Press 1x
Window Comparator
Mode Window Comparator
Mode
Hysteresis
Mode Hysteresis
Mode
Low Low
High High
Programming

4
MPS-2 Series Sensor CVM-102P
Display Description Solutions
Err Zero Reset Error Reset Zero Below
3% of F.S.
Er1 System Error (Internal) Contact Factory
Er2 Auto Teach Mode Error Restart Function
CE1 Over current of Output 1 Load current exceeds
CE2 Over current of Output 2 maximum 125mA.
FFF Applied pressure exceeds Apply pressures with
–FF pressure range the rating of the sensor
Error Messages
Accessories
MPS-ACCK4
Din Rail
.38
(10)
.53
(13)
2.69
(88)
Cables
.196 (5) Dia
6.56 ft
(2m)
6.56 ft
(2m)
1.26
(32)
CB-M8-4P-2M
CB-M8-4P-5M CB-M8-4P-M8-2M
CB-M8-4P-M12-2M
CB-M8-4P-5M-90
.196 (5) Dia
.38
(9,7) Dia
16.40 ft
(5m)
1.26
(32)
.38
(9,7) Dia
.47
(12) Di
a
.38
(9,7) Dia
.196 (5) Dia
6.56 ft
(2m)
1.26
(32)
2.09
(53)
.196 (5) Dia
.38
(9,7) Dia
16.40 ft
(5m)
.87
(22)
.42
(10,7)
.75
(19)
Replacement Kit
MPS-2-IP65 ................................................................. IP65 Kit
