PM-81HYR

USER MANUAL

Heavy Duty Hybrid Camera

with AHD and TVL Resolution

YOUR SAFETY COMES FIRST™

1

CONTENTS

1.0 INTRODUCTION .............................................................................2

1.1 COMPONENT LIST ..............................................................2

1.2 TECHNICAL SPECIFICATIONS:...........................................3

2.0 WIRING DIAGRAM .........................................................................3

3.0 TESTING.........................................................................................4

3.1 HOW TO TEST......................................................................4

4.0 TROUBLESHOOTING ....................................................................4

5.0 CARE AND MAINTENANCE ..........................................................5

6.0 USING CONTROLLER TO CHANGE OUTPUT RESOLUTION.....5

6.1 "QUICK CHANGE" DEFAULT SETTINGS ............................5

6.2 MENU CHANGE INSTRUCTIONS .......................................5

6.3 CHANGE THE DEFAULT MIRROR IMAGE TO REAL IMAGE

(TO USE CAMERA AS FORWARD FACING OR USE WITH

DVR)......................................................................................6

6.4 HYBRID CAMERA ...............................................................7

6.5 SETTING UP THE MENU.....................................................9

6.6 LENS................................................................................... 10

6.7 EXPOSURE ........................................................................ 10

6.8 BACKLIGHT........................................................................ 13

6.9 WHITE BALANCE...............................................................15

6.10 BLACK AND WHITE IMAGE ...............................................16

6.11 NR (NOISE REDUCTION) ..................................................17

6.12 ADJUST ..............................................................................22

6.13 EXIT ....................................................................................24

7.0 CARE AND MAINTENANCE ........................................................24

8.0 WARRANTY TERMS & CONDITIONS .........................................25

9.0 NOTES ..........................................................................................30

32

1.0 INTRODUCTION

Thank you for purchasing Parkmate’s PM-81HYR camera. We

are certain that our product will give you trouble-free operation

while providing you with safety features that enhance your driving

experience.

DISCLAIMER

Our products are to assist and aid the driver, not to replace the

manual function of the person operating the vehicle.

Although the PM-81HYR is a visual aid and will allow you to view

what is behind the vehicle, it does not remove the responsibility

of driving the vehicle from the driver. Legal responsibility and

safe driving practise remains with the driver at all times.You have

purchased this product with the understanding that its use is as

an aid only. We highly recommend that you have this product

professionally installed to ensure that it will provide the functions it

is set out to perform.

CAUTION

• Ensure you are using your rear camera within your countries’

road laws. Please make sure you are familiar with your local

road legislation before use.

1.1 COMPONENT LIST

IMPORTANT NOTICE

• Please read this manual carefully before using the product.

• Wire connection points should always be insulated.

• Wiring should always be installed away from heat sources and

electrical components.

10 Metre

Extension Cable

RCA

Adaptor

PM-81HYR

Rear Camera

Screws

+ Allen Key

Camera

Progamming

Module

• Please perform tests after nishing installation to ensure

camera is working correctly.

• This camera is intended for use as an aid when reversing

your vehicle. Drivers must always use extreme caution when

operating a vehicle.

• Specications are subject to change without notice.

WARNING

• Do not disassemble the camera or cut the camera cable

as this voids the warranty. Disassembling the camera will

compromise the waterproof seal.

1.2 TECHNICAL SPECIFICATIONS:

Signal System: NTSC / PAL

Horizontal Resolution: 900 TVL / 960 AHD

Minimum Illumination: 0.0 Lux

Diagonal Angle: 150°

Waterproof Rating: IP69K

Nominal Voltage: 12V/24V

Working Temperature: -30°C to 85°C

2.0 WIRING DIAGRAM

Front view option: PM-81HYR functions as a rear view camera

as standard.

12V +

54

3.0 TESTING

3.1 HOW TO TEST

1. Apply the parking brakes. (Safety Precaution)

2. Turn ignition on. (DO NOT TURN ON VEHICLE)

3. Shift into reverse gear.

4. Image should appear on the monitor.

4.0 TROUBLESHOOTING

PROBLEM SOLUTION

“No Signal” appears while

reversing

1. Check video input

connections

2. Check camera power

connections

Video image is not sharp Check camera lens for debris

5.0 CARE AND MAINTENANCE

Always keep camera clear from dirt and mud. Clean camera with a

soft moist cloth.

6.0 USING CONTROLLER TO CHANGE OUTPUT RESOLUTION

The PM-81HYR camera has PAL and AHD settings by default.

Default settings can be quickly changed by using the camera

programming module (supplied).

The camera programming module has to be connected with the

camera connector as shown in above gure.

NOTE : Please note AHD output will only work with AHD

compatible monitors. CVBS output can work with both

AHD and CVBS compatible monitors.

6.1 "QUICK CHANGE" DEFAULT SETTINGS

5. After the camera is connected with the programming module

and the monitor please follow below steps.

6. Press the Down button for 5 seconds, Camera output will

switch to PAL from NTSC. Repeat the same step to revert to

PAL .

7. Press the LEFT key for 5 seconds, the output of camera will

change from AHD to CVBS. Repeat the same step to revert

to AHD.

6.2 MENU CHANGE INSTRUCTIONS

1. After the camera is connected with the programming module

and the monitor please follow the below steps.

TO CHANGE LANGUAGE (IF REQUIRED) : DEFAULT

LANGUAGE IS ENGLISH.

1. Press the OK key and the screen will change to the MAIN

MENU.

2. Using UP or DOWN key navigate to the item no 7, SPECIAL

and press the OK key which will open up a new sub Menu

page.

3. Using UP and DOWN key go to menu option 5 and press the

LEFT or RIGHT key to change to desired Language.

UP

RIGHT

DOWN

LEFT

RIGHT

BUTTON

MENU

BUTTON

TOP

BUTTON

LEFT

BUTTON

Programming Module Image

DOWN

BUTTON CAM(Handheld Programmer)PM-81HYR cable harness and programmer12V +

To Monitor

76

4. Press DOWN key to reach menu option RETURN, Press OK

key to return to MAIN MENU. Using UP and DOWN key reach

to menu option SAVE & EXIT, press the OK key which will

save the settings and will navigate out of the programming

menu.

6.3 CHANGE THE DEFAULT MIRROR IMAGE TO REAL IMAGE

(TO USE CAMERA AS FORWARD FACING OR USE WITH DVR).

1. Press the OK key to enter into MAIN MENU.

2. Press UP and DOWN key to reach menu option 7, SPECIAL

and press the OK key which will open sub menu page.

3. Using UP and DOWN key select option 2, D-EFFECT. Press

OK button to enter the sub menu.

4. Pressing UP and DOWN key, select option 2and press OK key

which will open V- FLIP, using LEFT and RIGHT key, change

the orientation of the image to REAL image.

Test the image by pressing "Test" in camera view and you

should be able to read text conrming REAL Image

5. To change back to MIRROR image, follow the same above

mentioned steps.

6.4 HYBRID CAMERA

OSD MENU TREE

㻌



☞

-



-



-



-



AREA

►

WHITE BAL ATW

AWB

MANUAL BLUE 0 ~ 100

RED 0 ~ 100

OUTDOOR

INDOOR

AWC SET

DAY&NIGHT AUTO D N (CDS)

D N (DELAY)

N D (CDS)

N D (DELAY)

0 ~ 255

0 ~ 60

0 ~ 255

0 ~ 60

EXT D N (DELAY) 0 ~ 60

N D (DELAY) 0 ~ 60

BW BURST ON / OFF

IR SMART ON / OFF LEVEL

AREA 0 ~ 15

COLOR

EXPOSURE SHUTTER AUTO, 1/30(25) ~ 1/50000, x2 ~ x30

AGC 0 ~ 15

SENS-UP AUTO / OFF

BRIGHTNESS 1 ~ 100 x2 ~ x30

D-WDR ON 0 ~ 8

OFF

AUTO

DEFOG AUTO / OFF POS / SIZE

GRADATION

DEFAULT 0 ~ 2

BACKLIGHT BLC LEVEL HIGH, MIDDLE, LOW

DEFAULT

HSBLC SELECT AREA1 ~ AREA4

DISPLAY

BLACK MASK ON / OFF

ON / OFF

LEVEL 0 ~ 100

MODE ALL DAY

NIGHT 0 ~ 255

AREA

DEFAULT

OFF

MAIN MENU LENS DC INDOOR / OUTDOOR MAX SHU 1/60(50) ~ 1/50000

IRIS SPEED 0 ~ 15

MANUAL

►

98

6.5 SETTING UP THE MENU

Settings can be changed using the OSD Programming Controller.

1. Press the menu button to access the SETUP mode. The

SETUP menu is displayed on the monitor.

2. Please select any function you wish to activate by using the

UP / DOWN buttons on the programming controller.

The cursor can be moved up or down by using the UP / DOWN

selections. Position the cursor to point to the function you wish

to operate.

MAIN MENU: Use UP / DOWN button.

SUB MENU: Use LEFT / RIGHT button.

3. Change the status of the selected feature using the LEFT /

RIGHT buttons. When the LEFT or RIGHT selection is done,

available values and modes are displayed in order.

4. When completed, move the cursor indicator to EXIT position

and press the menu button to nish the setting.

NOTE: If Appears at the mode you wish to operate, it means

that there is a sub-menu which can be selected by OSD

programming controller.

㻌



☞

-



-



-



-



►

MAIN MENU SUB MENU

►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►



►

*Please see Programming

Module Image on Page 4

for which buttons to press.

㻌



☞

-



-



-



-



►



SPECIAL CAM TITLE ON / OFF

D-EFFECT FREEZE ON / OFF

MIRROR ROTATE / V-FLIP / MIRROR / OFF

NEG. IMAGE ON / OFF

MOTION ON / OFF SELECT

DISPLAY AREA1 ~ AREA4

GREEN / RED /

WHITE / BLUE

SENSITIVITY ON / OFF

0 ~ 100

COLOR

0.25 / 0.50 / 0.75

/ 1.00

TRANS

ALARM VIEW T YPE ALL / OUTLINE /

BLOCK / OFF

OSD VIEW ON / OFF

ALARM OUT. ON / OFF

ALARM SIG. HIGH / LOW

TIME 0 ~ 15

DEFAULT

PRIVACY ON / OFF SELECT AREA1 ~ AREA4

COLOR / INV. / MOSAIC / OFFDISPLAY

CYAN / GREEN / YELLOW / BLUE

/ RED / BLACK / WHITE / USER

COLOR

TRANS 0.25 / 0. 50 / 0.75 / 1.00

DEFAULT

NR

2DNR

HIGH, MIDDLE, LOW, OFF

3DNR HIGH, MIDDLE, LOW, OFF

DEFECT LIVE DPC ON / OFF AGC LEVEL 0 ~ 255

LEVEL 0 ~ 100

WHITE DPC ON / OFF POS / SIZE

START

DPC VIEW ON / OFF

LEVEL 0 ~ 60

AGC 0 ~ 14

SENS-UP X2 ~ X30

BLACK DPC ON / OFF POS / SIZE

START

DPC VIEW ON / OFF

LEVEL 0 ~ 255

ADJUST SHARPNESS AUTO / OFF LEVEL 0 ~ 10

START AGC 0 ~ 255

END AGC 0 ~ 255

MONITOR LCD GAMMA 0.45 ~ 1.00, USER

BLUE GAIN 0 ~ 100

RED GAIN 0 ~ 100

CRT BLUE GAIN 0 ~ 100

RED GAIN 0 ~ 100

LSC ON / OFF

VIDEO. OUT NTSC / PAL

OUT. MODE AHD / CVBS

SAVE&ENDEXIT

NOT SAVE

RESET

LANGUAGE ENG / ARB / HEB / JPN / KOR / TUR / NED / POR / RUS / POL / SPA

/ ITA / FRA / GER / CHN2 / CHN1

►

1110

6.6 LENS

1. MANUAL - When manual lens is used.

2. DC - When DC IRIS lens is used

- MODE: INDOOR - Adjusts the MAX SHUTTER

OUTDOOR - Adjusts the MAX SHUTTER

You can select the MAX SHUTTER from 1/60 to 1/50,000 sec

(NTSC), and 1/50 to 1/50,000 sec (PAL).

- IRIS SPEED: Adjusts the IRIS SPEED 0 ~ 15.

- RETURN: Return to the MAIN MENU or SAVE & EXIT.

6.7 EXPOSURE

1. SHUTTER:

- DC: When lens mode is on DC, shutter will be deactivated.

MANUAL

- A. AUTO: The shutter speed is controlled automatically.

㻌



☞

-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►



►

㻌



☞

-



-



-



-



►1. MODE

2. IRIS SPEED

3. RETURN

INDOOR

8

RET

DC LENS MODE

||||||||||||||||||||

►



►

㻌



☞

-



-



-



-



►

1. MIN SHU

2. MAX SHU

3. RETURN

1/30

FLK

RET

INDOOR MODE

►



►

㻌



☞

-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►



►

㻌



☞

-



-



-



-



►

►1. SHUTTER

2. AGC

3. SENS-UP

4. BRIGHTNESS

5. D-WDR

6. DEFOG

7. RETURN

AUTO

15

AUTO

40

OFF

RET

EXPOSURE

||||||||||||||||||||

►



►

- B. FLK: Please select FLK mode when ickering occurs on

the screen, due to an imbalance between illumination and

frequency.

- C. FIXED: The shutter speed is controlled manually.

-You can select the speed from 1/30 to 1/50,000’sec.

(NTSC), 1/25 to 1/50,000 sec. (PAL)

2. AGC (Auto Gain Control) - Adjusts the AGC 1 ~ 15.

3. INCREASE SENSITIVITY

- Low light sensitivity is greatly improved with the use of this

function.

- Low light sensitivity level is adjustable from 2 to 30 times.

- When SENS-UP level is higher, the picture becomes brighter

while noise is increased at the same rate of SENS-UP.

AUTO : Adjustable SENS-UP level between x2 ~ x30.

OFF : SENS-UP is disabled.

Default setting is <x4>

4. BRIGHTNESS - Adjusts the brightness in 1 ~ 100. (Default 40).

㻌



☞

-



-



-



-



►

1. SHUTTER

2. AGC

3. SENS-UP

4. BRIGHTNESS

5. D-WDR

6. DEFOG

7. RETURN

AUTO

15

AUTO

40

OFF

RET

EXPOSURE

||||||||||||||||||||

|||||| ||||||||||||||

►



►

㻌



☞

-



-



-



-



►

1. SHUTTER

2. AGC

3. SENS-UP

4. BRIGHTNESS

5. D-WDR

6. DEFOG

7. RETURN

AUTO

15

AUTO

40

OFF

RET

EXPOSURE

||||||||||||||||||||

|||||| ||||||||||||||

►



►

㻌



☞

-



-



-



-



►

1. SHUTTER

2. AGC

3. SENS-UP

4. BRIGHTNESS

5. D-WDR

6. DEFOG

7. RETURN

AUTO

15

AUTO

40

OFF

RET

EXPOSURE

||||||||||||||||||||

|||||| ||||||||||||||

►



►

1312

5. D-WDR (Digital Wide Dynamic Range) - D-WDR Function

scans both dark and bright clearly. This model achieves its best

set up for different levels of backlit or contrast lighting

situations.

- Adjusts the level in 0 ~ 8. (Default 2)

6. DEFOG - Images in low visibility environments such as fog or

rain or in a very strong luminous intensity have DR (dynamic

range), lower than ordinary images. Contrast-based defog

function is used to overcome such shortcoming.

- POS / SIZE: Determines the coordinate of the vertical /

Horizontal position and size.

- GRADATION: Adjusts the gradation 0 ~ 2.

㻌



☞

-



-



-



-



►

1. SHUTTER

2. AGC

3. SENS-UP

4. BRIGHTNESS

5. D-WDR

6. DEFOG

7. RETURN

AUTO

15

AUTO

40

OFF

RET

EXPOSURE

||||||||||||||||||||

|||||| ||||||||||||||

►



►

㻌



☞

-



-



-



-



►

1. SHUTTER

2. AGC

3. SENS-UP

4. BRIGHTNESS

5. D-WDR

6. DEFOG

7. RETURN

AUTO

15

AUTO

40

OFF

RET

EXPOSURE

||||||||||||||||||||

|||||| ||||||||||||||

►



►

㻌



☞

-



-



-



-



►

1. POS / SIZE

2. GRADATION

3. DEFAULT

4. RETURN

0

RET

DEFOG

||||||||||||||||||||

►



►

㻌



☞

-



-



-



-



►



►

(A) Original Image (B) D-WDR ON

- DEFAULT: Initialize all settings of the defog.

- RETURN: Return to EXPOSURE or SAVE & EXIT.

7. RETURN: Return to the MAIN MENU or SAVE & EXIT.

6.8 BACKLIGHT

1. BLC - Used for backlight environment.

(HIGH / MIDDLE / LOW)

㻌



☞

-



-



-



-



►



►

(A) Original Image (B) DEFOG ON

㻌



☞

-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►



►

㻌



☞

-



-



-



-



►

1. LEVEL

2. AREA

3. DEFAULT

4. RETURN

MIDDLE

RET

BLC

►



►

㻌



☞

-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

BLC

ATW

AUTO

SAVE&END

MAIN MENU

►



►

㻌



☞

-



-



-

( )

-



-



►

HIGH

MIDDLE

LOW

►



►

1514

2. HSBLC - Can mask the head lights to view car license number

plates more clearly.

- SELECT:You can select up to 4 areas.

- DISPLAY: Determines whether to use the HSBLC selected in

AREA SELECT.

- ON: Determines the coordinate of the vertical / horizontal

position and size.

- BLACK MASK: BLACK MASK ON / OFF

- LEVEL: Adjusts the level 0 ~ 100.

- MODE: ALL DAY / NIGHT Adjusts the AGC level 0 ~ 255

when selecting NIGHT.

- DEFAULT: Initialize all settings of the HSBLC.

- RETURN: Return to the MAIN MENU or SAVE & EXIT.

3. OFF

㻌



☞

-



-



-



-



►

ECLIPSE MASKING AREA

►



►

ECLIPSE ON

ECLIPSE OFF

㻌



☞

-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

HSBLC

ATW

AUTO

SAVE&END

MAIN MENU

►



►

㻌



☞

-



-



-



-



►



►

►1. SELECT

2. DISPLAY

3. BLACK MASK

4. LEVEL

5. MODE

6. DEFAULT

7. RETURN

AREA1

ON

20

ALL DAY

RET

HSBLC

||||||||||||||||||||

6.9 WHITE BALANCE

This is useful when the camera is installed in different articial

lighting conditions where a standard ‘White Balance’ condition is

not suitable for alll.

1. ATW (Auto Tracking White Balance): This mode can be used

within the colour temperature range 2,000K - 20,000K.

2. AWB (Auto White Balance): Shows the AWB encompassing all

the colour temperature spaces without separately specifying a

white area in-line with the colour temperature.

3. MANUAL: In the Manual mode, the user can choose the

colour and temperature. The user can adjust the colour and

temperature by changing the red and blue gain.

4. OUTDOOR: A colour temperature is xed for use in the

outdoor environment.

5. INDOOR: A colour temperature is xed for use in the

indoor environment.

6. AWC SET: This mode is used to x the colour

temperature value once it is set under a certain colour

temperature environment. When AWC SET of the OSD

MENU is on, the colour temperature is xed in 1-2 seconds.

㻌



☞

-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►



►

㻌



☞

-



-



-



-



►



►

1. BLUE

2. RED

3. RETURN

50

RET

MANUAL

||||||||||||||||||||

►

1716

If one or more values of each OPD Block are included

in the ATW area, the colour temperature is xed by the

corresponding OPD data. Otherwise, it becomes xed by all

the OPD data.

6.10 BLACK AND WHITE IMAGE

You can display pictures in colour or black / white.

1. AUTO: Automatically turns between Day and Night mode

according the CDS operation.

You can select the duration time of the Day / Night mode by

changing 0 ~ 60.

- D N: To adjust LUX level for switching Day to Night

- N D: To adjust LUX level for switching Night to Day

2. EXIT: Colour or black / white is controlled by the signal coming

from an external GPIO port.

3. BW: The picture is always in black and white.

- BURST: ON / OFF

- IR AMART: ON / OFF

Adjusts the level 0 ~ 15. (Default 3)

4. COLOUR: The picture is always in colour.

㻌



☞

-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU



►

6.11 NR (NOISE REDUCTION)

Noise Reduction (NR) is used in order to obtain a high quality

output image and enhance compression efficiency. Offers Edge

Preserving 2D NR and Motion Adaptive 3D NR.

1. 2D NR: Cuts off the noise in low light conditions.

2. 3D NR: Cuts off the noise in low light conditions.

3. RETURN: Return to the MAIN MENU or SAVE & EXIT.

9. SPECIAL

1. CAM TITLE: If you enter a title, the title will appear on the

monitor.

1. Position the arrow to point to SPECIAL using the UP and

DOWN selection.

2. Select ON by using the LEFT and RIGHT selection. When

you press the button to complete ON, it will display CAM TITLE.

NOTE: If OFF is selected, CAM TITLE will not appear on the

monitor, even if it has been input.





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►

▶



 

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

►ON

ON

RET

1. 2DNR

2. 3DNR

3. RETURN

NR





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

0 1 2 3 4 5 6 7 8 9

A B C D E F G H I J K

L M N O P Q R S T U V

W X Y Z ▶ ( )

/ = & : ~ , .

CAM TITLE

CLR POS END

----------------------------------------

►1. CAM TITLE

2. D-EFFECT

3. MOTION

4. PRIVACY

5. LANGUAGE

6. DEFECT

7. RETURN

ON

OFF

ENG

RET

SPECIAL

►

1918

3. Up to 15 letters are available for the CAM TITLE.

- Move the cursor to the letters by using the UP and DOWN

selections.

- Set an ID from 0-9, A-Z by using the UP, DOWN, LEFT and

RIGHT selections.

- Lock in the letters by using the button. When the letter is

locked in, the cursor will move to the next space.

- Repeat the above to input CAM TITLE.

4. When a name has been chosen, please select a position for

the name to display.

- Move the cursor onto POS and then press the button.

- The name will appear at the top right corner.

- Find the position you wish to display the name by using the 4

directional selections, and then press the button to nish.

5. Select END, press button to complete CAM TITLE input.

2. D-EFFECT:

- FREEZE: You can view still or moving pictures.

- MIRROR: ROTATE / V-FLIP / MIRROR / OFF.

- NEG. IMAGE: Negative ON / OFF

- RETURN: Return to SPECIAL MENU or SAVE & EXIT.





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. CAM TITLE

2. D-EFFECT

3. MOTION

4. PRIVACY

5. LANGUAGE

6. DEFECT

7. RETURN

ON

OFF

ENG

RET

SPECIAL

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. FREEZE

2. MIRROR

3. NEG . IMAGE

4. RETURN

OFF

RET

D-EFFECT

►

3. MOTION

- SELECT:You can select up to 4MD areas.

- DISPLAY: Determines whether to use the MD area selected

in AREA SELECT.

ON: Determines the coordinate of the vertical / horizontal

position and size.

- SENSITIVITY: Determines the coordinate of sensitivity.

- COLOUR: GREEN, RED, WHITE and BLUE.

- TRANS: Set the colour transparency for displaying a

detected area.

- ALARM: Set the alarm output (VIEW TYPE, OSD VIEW, etc)

- DEFAULT: Initialize all setting of the MOTION.

- RETURN: Return to SPECIAL MENU or SAVE & EXIT.

4. PRIVACY





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. CAM TITLE

2. D-EFFECT

3. MOTION

4. PRIVACY

5. LANGUAGE

6. DEFECT

7. RETURN

OFF

ENG

RET

SPECIAL

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

AREA1

OFF

30

BLUE

1.00

TIME

RET

►

1. SELECT

2. DISPLAY

3. SENSITIVITY

4. COLOR

5. TRANS

6. ALARM

7. DEFAULT

8. RETURN

MOTION

||||||||||||||||||||

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. CAM TITLE

2. D-EFFECT

3. MOTION

4. PRIVACY

5. LANGUAGE

6. DEFECT

7. RETURN

OFF

ENG

RET

SPECIAL

►

2120

SELECT:You can select up to 4 PRIVACY areas.

DISPLAY: Determines whether to use the MD area selected in

AREA SELECT.

COLOUR: CYAN, GREEN, YELLOW, BLUE, RED, WHITE,

WHITE and USER.

TRANS: Set the colour transparency for displaying a detected

area.

DEFAULT: Initialize all setting of the PRIVACY.

RETURN: Return to the SPECIAL MENU or SAVE & EXIT.

5. LANGUAGE

ENG / ARB / HEB / JPN / KOR / TUR / NED / POR / RUS / POL /

SPA / ITA / FRA / GER / CHN2 / CHN1.

(Supports up to 16 Languages)

6. DEFECT

- LIVE DPC (Live Dead Pixel Correction)

- AGC Level: Adjust the AGC level 0 ~ 255.





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. SELECT

2. DISPLAY

3. COLOR

4. TRANS

5. DEFAULT

6. RETURN

AREA1

OFF

0

3

RET

PRIVACY

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. CAM TITLE

2. D-EFFECT

3. MOTION

4. PRIVACY

5. LANGUAGE

6. DEFECT

7. RETURN

OFF

ENG

RET

SPECIAL

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. CAM TITLE

2. D-EFFECT

3. MOTION

4. PRIVACY

5. LANGUAGE

6. DEFECT

7. RETURN

OFF

ENG

RET

SPECIAL

►

- LEVEL: Adjust the LEVEL 0 ~ 100.

- RETURN: Return to DEFECT MENU or SAVE & EXIT.

- WHITE DPC (White Dead Pixel Correction)

- POS / SIZE: Adjusts the position and size.

- START

- DPC VIEW: ON / OFF

- LEVEL: Adjust the LEVEL 0 ~ 60.

- AGC: Adjust the LEVEL 0 ~ 14.

- SENS-UP: Adjust the LEVEL x2 ~x30.

- RETURN: Return to DEFECT MENU or SAVE & EXIT.

- BLACK DPC (Black Dead Pixel Correction)

- POS / SIZE: Adjust the position and size.

- START

- DPC VIEW: ON / OFF

- LEVEL: Adjust the LEVEL 0 ~ 255.

- RETURN: Return to DEFECT MENU or SAVE & EXIT.





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. LIVE DPC

2. WHITE DPC

3. BLACK DPC

4. RETURN

ON

OFF

RET

DEFECT

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

►64

80

RET

1. AGC LEVEL

2. LEVEL

3. RETURN

LIVE DPC

||||||||||||||||||||

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. POS / SIZE

2. START

3. DPC VIEW

4. LEVEL

5. AGC

6. SENS-UP

7. RETURN

OFF

10

x4

RET

WHITE DPC

||||||||||||||||||||

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. POS / SIZE

2. START

3. DPC VIEW

4. LEVEL

5. RETURN

OFF

255

RET

BLACK DPC

||||||||||||||||||||

►

2322

- RETURN: Return to SPECIAL MENU or SAVE & EXIT.

7. RETURN: Return to MAIN MENU or SAVE & EXIT.

6.12 ADJUST

1. SHARPNESS:

- LEVEL: Adjusts the LEVEL 0 ~ 255.

- START AGC: When the level is high, the sharpness of picture

at night is improved while noise is increased.

- END AGC: Set to 255 level for optimised denition at night.

- RETURN: Return to ADJUST MENU or SAVE & EXIT.





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. SHARPNESS

2. MONITOR

3. LSC

4. VIDEO.OUT

5. OUT. MODE

6. RETURN

AUTO

LCD

OFF

NTSC

AHD

RET

ADJUST

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

►6

128

255

RET

1. LEVEL

2. START AGC

3. END AGC

4. RETURN

SHARPNESS

||||||||||||||||||||

►

2. MONITOR

A. LCD

- GAMMA: Adjust LEVEL 0.45 ~ 1.00, USER.

- BLUE GAIN: Adjust LEVEL 0 ~ 100.

- RED GAIN : Adjust LEVEL 0 ~ 100.

- RETURN: Return to ADJUST MENU or SAVE & EXIT.

B. CRT

- BLUE GAIN: Adjust LEVEL 0 ~ 100.

- RED GAIN : Adjust LEVEL 0 ~ 100.

- RETURN: Return to ADJUST MENU or SAVE & EXIT.

3. LSC

Lens Shading Correction (LSC) corrects the instance where

the image gets darkened or blurred on the periphery.

4. VIDEO OUT

NTSC / PAL: Video output can be set to NTSC or PAL

according to local TV standard.





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

►USER

70

RET

1. GAMMA

2. BLUE GAIN

3. RED GAIN

4. RETURN

LCD

||||||||||||||||||||

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. SHARPNESS

2. MONITOR

3. LSC

4. VIDEO.OUT

5. OUT. MODE

6. RETURN

AUTO

LCD

OFF

NTSC

AHD

RET

ADJUST

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. SHARPNESS

2. MONITOR

3. LSC

4. VIDEO.OUT

5. OUT. MODE

6. RETURN

AUTO

LCD

OFF

NTSC

AHD

RET

ADJUST

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. SHARPNESS

2. MONITOR

3. LSC

4. VIDEO.OUT

5. OUT. MODE

6. RETURN

AUTO

LCD

OFF

NTSC

AHD

RET

ADJUST

►

2524

5. OUT. MODE

6. RETURN: Return to MAIN MENU or SAVE & EXIT.

If the version of DVR is 1.0, DISTANCE menu is added.

DISTANCE menu enables to choose NORMAL or LONG

depending on length of cable.

6.13 EXIT

1. SAVE & EXIT: Save the current settings and exit the menu.

2. NOT SAVED: Do not save the current settings and exit the

menu.

3. RESET: Reset the camera settings to factory default.

7.0 CARE AND MAINTENANCE

Always keep camera clear from dirt and mud. Clean camera with a

soft moist cloth.





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. SHARPNESS

2. MONITOR

3. LSC

4. VIDEO.OUT

5. OUT. MODE

6. RETURN

AUTO

LCD

OFF

NTSC

AHD

RET

ADJUST

►





☞



①

②

③

④

①

②

③

-



-



-



-



-



►

▶



 

►

1. LENS

2. EXPOSURE

3. BACKLIGHT

4. WHITE BAL

5. DAY&NIGHT

6. NR

7. SPECIAL

8. ADJUST

9. EXIT

DC

OFF

ATW

AUTO

SAVE&END

MAIN MENU

►

8.0 WARRANTY TERMS & CONDITIONS

Our goods come with guarantees that cannot be excluded under

the Australian & New Zealand Consumer Law. You are entitled to

a replacement or refund for a major failure and for compensation

for any other reasonably foreseeable loss or damage.You are also

entitled to have the goods repaired or replaced if the goods fail to

be of acceptable quality and the failure does not amount to a major

failure.

This warranty is provided in addition to your rights under the

Australian & New Zealand Consumer Law.

Directed Electronics Australia Pty Ltd (Directed Electronics)

warrants that this product is free from defects in material and

workmanship for a period of 12 months from the date of purchase

or for the period stated on the packaging. This warranty is only

valid where you have used the product in accordance with any

recommendations or instructions provided by Directed Electronics.

This warranty excludes defects resulting from alterations of the

product, accident, misuse, abuse or neglect.

In order to claim the warranty, you must return the product to the

retailer from which it was purchased or if that retailer is part of a

National network, a store within that chain, along with satisfactory

proof of purchase. The retailer will then return the goods to Directed

Electronics. Directed Electronics will repair, replace or refurbish

the product at its discretion. The retailer will contact you when the

product is ready for collection. All costs involved in claiming this

warranty, including the cost of the retailer sending the product to

Directed Electronics, will be borne by you.

Directed Electronics Address: 115-119 Link Road Melbourne

Airport, 3045 Victoria. Australia

Ph: +61 03 8331 4800 Email: service@parkmate.com.au

2726

INDEMNITY

YOU AGREE TO DEFEND, INDEMNIFY AND HOLD HARMLESS

PARKMATE AND ITS SUBSIDIARIES AND AFFILIATES FROM

AND AGAINST ANY AND ALL CLAIMS, PROCEEDINGS,

INJURIES, LIABILITIES, LOSSES, COSTS AND EXPENSES

(INCLUDING REASONABLE LEGAL FEES), INCLUDING

BUT NOT LIMITED TO, CLAIMS ALLEGING NEGLIGENCE,

INVASION OF PRIVACY, COPYRIGHT INFRINGEMENT AND/

OR TRADEMARK INFRINGEMENT AGAINST PARKMATE AND

ITS SUBSIDIARIES AND AFFILIATES OR THE PARKMATE

SERVICES, RELATING TO OR ARISING OUT OF YOUR

BREACH OF ANY PROVISION OF THESE TERMS, YOUR

MISUSE OF THE PARKMATE OR PARKMATE SERVICES, OR

YOUR UNAUTHORIZED MODIFICATION OR ALTERATION OF

PRODUCTS OR SOFTWARE.

WARRANTY AND WARRANTY DISCLAIMER

PARKMATE HAS A LIMITED WARRANTY ON WHEREBY

PARKMATE WARRANTS TO AND ONLY TO YOU THAT THE

ON PARKMATE VEHICLE DASH CAMERAS, MIRROR DASH

CAMERAS, FRONT, REAR AND REVERSING CAMERAS AND

MIRROR MONITOR DEVICES WILL BE FREE FROM DEFECTS

IN MATERIALS AND WORKMANSHIP FOR ONE (1) YEAR FROM

THE DATE OF YOUR PURCHASE OF THE ON PARKMATE

VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS, FRONT,

REAR AND REVERSING CAMERAS AND MIRROR MONITOR

DEVICES (UNLESS A LONGER WARRANTY PERIOD IS

REQUIRED BY LAW).

THE SPECIFICS OF THIS PARKMATE LIMITED WARRANTY ARE

AT HTTPS://WWW.PARKMATE.COM.AU/WARRANTY

TO THE EXTENT POSSIBLE UNDER GOVERNING LAW, OTHER

THAN THE ABOVE PRODUCT WARRANTY FOR THE PARKMATE

VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS, FRONT,

REAR AND REVERSING CAMERAS AND MIRROR MONITOR

DEVICES, YOU UNDERSTAND AND AGREE THAT THE

PARKMATE SERVICES ARE PROVIDED ON AN "AS IS" AND

"AS AVAILABLE" BASIS. PARKMATE MAKES NO WARRANTY

THAT THE PARKMATE SERVICES WILL MEET YOUR

REQUIREMENTS OR THAT USE OF THE PARKMATE SERVICES

WILL BE UNINTERRUPTED, TIMELY, SECURE OR ERROR-

FREE NOR DOES PARKMATE MAKE ANY WARRANTY AS TO

THE ACCURACY OR RELIABILITY OF ANY INFORMATION

OBTAINED THROUGH THE PARKMATE SERVICES (INCLUDING

THIRD PARTY CONTENT), THAT ANY DEFECTS IN THE

PARKMATE SERVICES WILL BE CORRECTED OR THAT THE

PARKMATE PRODUCTS OR PARKMATE SERVICES WILL BE

COMPATIBLE WITH ANY OTHER SPECIFIC HARDWARE OR

SERVICE. FURTHER, PARKMATE DOES NOT WARRANT THAT

THE PARKMATE SERVICES OR THE PARKMATE SERVERS

THAT PROVIDE YOU WITH DATA AND CONTENT ARE FREE OF

VIRUSES OR OTHER HARMFUL COMPONENTS. PARKMATE

ALSO ASSUMES NO RESPONSIBILITY FOR AND SHALL NOT

BE LIABLE FOR ANY DAMAGES CAUSED BY VIRUSES THAT

MAY INFECT YOUR PARKMATE VEHICLE DASH CAMERAS,

MIRROR DASH CAMERAS, FRONT, REAR AND REVERSING

CAMERAS AND MIRROR MONITOR DEVICES, COMPUTER

SOFTWARE, OR OTHER HARDWARE.

YOU AGREE THAT PARKMATE IS NOT AN INSURER AND THAT

PARKMATE IS NOT PROVIDING ME WITH INSURANCE OF ANY

TYPE. ANY AMOUNTS THAT YOU PAY PARKMATE FOR THE

PARKMATE SERVICE ARE NOT INSURANCE PREMIUMS AND

ARE NOT RELATED TO THE VALUE OF YOUR VEHICLE OR

PROPERTY, ANYONE ELSE’S PROPERTY LOCATED IN YOUR

VEHICLE OR PREMISES, OR ANY RISK OF LOSS IN YOUR

VEHICLE OR AT YOUR PREMISES. IF YOU WANT INSURANCE

TO PROTECT AGAINST ANY RISK OF LOSS AT YOUR VEHICLE

OR PREMISES, YOU WILL PURCHASE IT. IN THE EVENT OF

ANY LOSS, DAMAGE OR INJURY, YOU WILL NOT LOOK TO

PARKMATE TO COMPENSATE YOU OR ANYONE ELSE. YOU

RELEASE AND WAIVE FOR YOURSELF AND YOUR INSURER

ALL SUBROGATION AND OTHER RIGHTS TO RECOVER

AGAINST PARKMATE ARISING AS A RESULT OF THE PAYMENT

OF ANY CLAIM FOR LOSS, DAMAGE OR INJURY.

PARKMATE’S EQUIPMENT AND SERVICES DO NOT CAUSE

AND CANNOT ELIMINATE OCCURRENCES OF CERTAIN

EVENTS, INCLUDING, BUT NOT LIMITED TO, VEHICLE

ACCIDENTS, PROPERTY DAMAGE, LOST PROPERTY, THEFT

OF VEHCLE , THEFT OF PROPERTY. PARKMATE MAKES

2928

NO GUARANTEE OR WARRANTY, INCLUDING ANY IMPLIED

WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE, THAT THE PARKMATE EQUIPMENT

AND SERVICES PROVIDED WILL DETECT OR AVERT SUCH

INCIDENTS OR THEIR CONSEQUENCES. PARKMATE DOES

NOT UNDERTAKE ANY RISK THAT YOU OR YOUR VEHICLE OR

PROPERTY, OR THE PERSON OR PROPERTY OF OTHERS,

MAY BE SUBJECT TO INJURY OR LOSS IF SUCH AN EVENT

OCCURS. THE ALLOCATION OF SUCH RISK REMAINS WITH

YOU, NOT PARKMATE.

OTHER THAN THE ABOVE PRODUCT WARRANTY FOR

THE PARKMATE VEHICLE DASH CAMERAS, MIRROR DASH

CAMERAS, FRONT, REAR AND REVERSING CAMERAS

AND MIRROR MONITOR DEVICES, PARKMATE AND ITS

SUPPLIERS DISCLAIM ALL WARRANTIES OF ANY KIND,

WHETHER EXPRESS, IMPLIED, OR STATUTORY, REGARDING

THE PARKMATE EQUIPMENT AND ANY ASSOCIATED APP/

SERVICE. INCLUDING ANY IMPLIED WARRANTY OF TITLE,

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,

OR NON INFRINGEMENT OF THIRD PARTY RIGHTS. BECAUSE

SOME JURISDICTIONS DO NOT PERMIT THE EXCLUSION

OF IMPLIED WARRANTIES, THE LAST SENTENCE OF THIS

SECTION MAY NOT APPLY TO YOU. PARKMATE HEREBY

FURTHER EXPRESSLY DISCLAIMS ALL LIABILITY FOR ANY

CLAIMS FOR SERVICE FAILURES THAT ARE DUE TO NORMAL

PRODUCT WEAR, PRODUCT MISUSE, ABUSE, PRODUCT

MODIFICATION, IMPROPER PRODUCT SELECTION OR

YOUR NON-COMPLIANCE WITH ANY AND ALL APPLICABLE

FEDERAL, STATE OR LOCAL LAWS. THIS WARRANTY AND

WARRANTY DISCLAIMER GIVE YOU SPECIFIC LEGAL RIGHTS,

AND YOU MAY HAVE OTHER RIGHTS THAT VARY BY STATE,

PROVINCE, OR COUNTRY. OTHER THAN AS PERMITTED BY

LAW, PARKMATE DOES NOT EXCLUDE, LIMIT OR SUSPEND

OTHER RIGHTS YOU HAVE, INCLUDING THOSE THAT MAY

ARISE FROM THE NONCONFORMITY OF A SALES CONTRACT.

FOR A FULL UNDERSTANDING OF YOUR RIGHTS YOU

SHOULD CONSULT THE LAWS OF YOUR STATE, PROVINCE,

OR COUNTRY. FOR OUR AUSTRALIAN CUSTOMERS: PLEASE

NOTE THAT THIS WARRANTY IS IN ADDITION TO ANY

STATUTORY RIGHTS IN AUSTRALIA IN RELATION TO YOUR

GOODS WHICH, PURSUANT TO THE AUSTRALIAN CONSUMER

LAW, CANNOT BE EXCLUDED.

LIMITATIONS OF PARKMATE LIABILITY

UNDER NO CIRCUMSTANCES WILL PARKMATE BE LIABLE IN

ANY WAY FOR ANY CONTENT, INCLUDING, BUT NOT LIMITED

TO, THE LOSS OF CONTENT, ANY ERRORS OR OMISSIONS

IN ANY CONTENT, OR ANY LOSS OR DAMAGE OF ANY KIND

INCURRED IN CONNECTION WITH USE OF OR EXPOSURE

TO ANY CONTENT POSTED, EMAILED, ACCESSED,

TRANSMITTED, OR OTHERWISE MADE AVAILABLE VIA THE

PARKMATE APP.

PARKMATE LIABILITY FOR DAMAGES, ESPECIALLY

FOR BREACH OF DUTY OR OBLIGATION, DELAY

IN PERFORMANCE, NON-PERFORMANCE, OR

MALPERFORMANCE SHALL BE PRECLUDED, EXCEPT

WHEN THESE ARE DUE TO NEGLIGENT BREACHES OF ANY

SIGNIFICANT CONTRACTUAL DUTY OR OBLIGATION ON

THE PART OF PARKMATE. ANY LIABILITY FOR NEGLIGENCE

IS LIMITED TO DIRECT LOSSES USUALLY AND TYPICALLY

FORESEEABLE IN SUCH CASE. SHOULD THE CLAIM FOR

DAMAGES BE BASED ON WILFUL OR GROSSLY NEGLIGENT

BREACH OF CONTRACTUAL DUTY OR OBLIGATION ON THE

PART OF PARKMATE, THE PRECLUSION AND LIMITATION OF

LIABILITY MENTIONED IN THE PRECEDING SENTENCES WILL

NOT APPLY. THE PRECEDING PRECLUSION AND LIMITATION

OF LIABILITY WILL ALSO NOT APPLY TO CLAIMS FOR

DAMAGES ARISING OUT OF LOSS OF LIFE, BODILY INJURY

OR HEALTH IMPACTS FOR WHICH PARKMATE MAY BE LIABLE,

OR FOR NON-CONTRACTUAL LIABILITY.

SOME STATES AND COUNTRIES DO NOT ALLOW

THE EXCLUSION OR LIMITATION OF INCIDENTAL OR

CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION

OR EXCLUSION MAY NOT APPLY TO YOU. ADDITIONALLY,

THIS PROVISION IS NOT INTENDED TO LIMIT PARKMATE'S

LIABILITY IN THE EVENT OF PARKMATE'S WILLFUL OR

INTENTIONAL MISCONDUCT.

3130

9.0 NOTES

3332

www.directed.com.au

www.directed.co.nz

V1.0

www.parkmate.com.au | www.parkmatehd.co.nz

Parkmate PM-81HYR User manual

Popular Automobile Accessories manuals by other brands
