Parkside PAPK 12 C1 User manual

RECHARGEABLE BATTERY 12V 5Ah
AKKU 12 V 5 Ah / BATTERIE 12 V 5 Ah
PAPK 12 C1
BATTERIE 12 V 5 Ah
Traduction des instructions d’origine
AKKU 12 V 5 Ah
Originalbetriebsanleitung
RECHARGEABLE BATTERY
12V 5Ah
Translation of the original instructions
AKUMULÁTOR 12 V 5 Ah
Překlad originálního provozního návodu
ACCU 12 V 5 Ah
Vertaling van de originele gebruiks-
aanwijzing
BATÉRIA 12 V 5 Ah
Preklad originálneho návodu na obsluhu
AKUMULATOR 12 V 5 Ah
Tłumaczenie oryginalnej instrukcji obsługi
BATERÍA 12 V 5 Ah
Traducción del manual de instrucciones
original
GENOPLADELIGT
BATTERI 12 V 5 Ah
Oversættelse af den originale driftsvej-
ledning
BATTERIA 12 V 5 Ah
Traduzione delle istruzioni d’uso originali
AKKUMULÁTOR 12 V
5 Ah
Az originál használati utasítás fordítása
POLNILNA BATERIJA
12V 5 Ah
Prevod originalnega navodila za uporabo
IAN 391277_2201

GB/IE Translation of the original
instructions Page 1
DE/AT/CH Originalbetriebsanleitung Seite 21
FR/BE Traduction des instructions
d’origine Page 43
NL/BE Vertaling van de originele
gebruiksaanwijzing Pagina 71
CZ Překlad originálního
provozního návodu Strana 93
PL Tłumaczenie oryginalnej
instrukcji obsługi Strona 113
SK Preklad originálneho návodu
na obsluhu Strana 133
ES Traducción del manual
de instrucciones original Página 153
DK Oversættelse af den originale
driftsvejledning Side 175
IT Traduzione delle istruzioni
d’uso originali Pagina 195
HU Az originál használati
utasítás fordítása Oldal 215
SI Prevod originalnega
navodila za uporabo Stran 235

A

All Parkside tools and the chargers PLGK12A1/A2/A3/B2/
PDSLG 12 A1 of the X12V Team series are compatible with
the PAPK12A1/A2/A3/A3/B1 /B3 /C1/D1 battery pack.
Alle Parkside Geräte und die Ladegeräte PLGK12A1/2/B2/
PDSLG12A1 der X12V Team Serie sind mit dem Akku-Pack
PAPK12A1/A2/A3/A3/B1/B3/C1/D1 kompatibel.
Tous les outils Parkside et les chargeurs PLGK12A1/A2/A3/
B2/PDSLG 12 A1 de la série X12V Team sont compatibles
avec la batterie PAPK12A1/A2/A3/B1
/B3 /C1/D1.
Charging times
Ladezeiten
Temps de charge
Charging currents
Ladeströme
Courants de charge
2 Ah
Battery pack
Batterie
Batterie
PAPK 12 A1
2
A
Batter
y
Batt
e
Batt
e
PAPK 12
max. 2,4 A · PLGK 12 A1/A2/A3
Charger · Ladegerät · Chargeur
60 min
2,4 A
60
m
2,4
max. 4,5 A
· PLGK 12 B2
Charger · Ladegerät · Chargeur
60 min
2,4 A
45
m
3,5
max. 4,5 A
· PDSLG 12 A1
Charger · Ladegerät · Chargeur
60 min
2,4 A
45
m
3,5

12 V max.
10,8 V
High-performance Li-Ion battery
Cell Balancing – longer battery life, increased
battery lifespan · Higher battery resources due to evenly
used cells · Maximises the charge potential.
A
h
y
pack
e
rie
e
rie
A2/A3
2,5 Ah
Battery pack
Batterie
Batterie
PAPK 12 C1
4 Ah
Battery pack
Batterie
Batterie
PAPK 12 B1 /B3
5 Ah
Battery pack
Batterie
Batterie
PAPK 12 D1
m
in
A
80 min
2,4 A
120 min
2,4 A
150 min
2,4 A
m
in
A
55 min
3,8 A
60 min
4,5 A
80 min
4,5 A
m
in
A
55 min
3,8 A
60 min
4,5 A
80 min
4,5 A

PAPK 12 D1 GB│IE │ 1 ■
Contents
Introduction........................2
Intended use............................. 2
Features ................................ 3
Package contents ......................... 3
Technical specifications .................... 3
General Power Tool Safety Warnings . . 5
Extended safety guidelines.................. 7
Charging the battery pack (seefig. A) . .8
Maintenance and storage ............9
Kompernass Handels GmbH warranty 10
Service...........................14
Importer .........................14
Disposal..........................15
Original declaration ofconformity ....18
Ordering a replacement battery......20
Telephone ordering ......................20

PAPK 12 D1■ 2 │ GB│IE
Introduction
Congratulations on the purchase of your new appli-
ance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage and
disposal. Before using the product, please familiarise
yourself with all of the operating and safety instruc-
tions. Use the product only as described and for the
range of applications specified. Please also pass these
operating instructions on to any future owner.
Intended use
This rechargeable battery is suitable for:
This rechargeable battery is not intended for commer-
cial use. Any other usage of or modification to the
appliance is deemed to be improper and carries a
significant risk of accidents. The manufacturer accepts
no responsibility for damage attributable to misuse.

PAPK 12 D1 GB│IE │ 3 ■
Features
Battery pack
Release buttons
Red charge control LED
Green charge control LED
High-speed charger (not supplied)
Package contents
1 rechargeable battery 12V 5Ah
1 set of operating instructions
Technical specifications
PAPK 12 D1
Type LITHIUM ION
Rated voltage 12 V (DC)
Capacity 5000 mAh
Cells 6

PAPK 12 D1■ 4 │ GB│IE
Use only X12V Team Series high-speed battery
chargers to charge the battery pack:
(not supplied).
High-speed battery charger PLGK 12 B2
INPUT
Rated current 220–240 V ∼,
50–60 Hz (AC)
Rated power consumption 50 W
Fuse (internal) 2 A T2A
OUTPUT
Rated voltage 12 V (DC)
Rated current 4.5 A
Charging time approx. 80 min
Protection class II/ (double insulation)
ATTENTION!
► This charger can only charge the following
batteries: PAPK12A1/PAPK12A2/
PAPK12A3/PAPK12B1/PAPK12B3/
PAPK12C1/PAPK12D1.

PAPK 12 D1 GB│IE │ 5 ■
ATTENTION!
► A current list of battery compatibility can be
found at www.lidl.de/akku.
General Power Tool
Safety Warnings
WARNING!
■Read all safety warnings and all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for
future reference.
a) Charge a rechargeable battery unit using only
the charger recommended by the manufacturer.
Chargers are often designed for a particular type
of rechargeable battery unit. There is the danger
of fire if other types of rechargeable battery units
are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.

PAPK 12 D1■ 6 │ GB│IE
c) When they are not being used, store recharge-
able battery units away from paperclips, coins,
keys, nails, screws or other small metal objects
that could cause the contacts to be bridged.
Short-circuiting the contacts of a rechargeable
battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens, avoid
contact with the fluid. If contact occurs, flush
the affected area with water. Seek additional
medical help if any of the fluid gets into your
eyes. Escaping battery fluid may cause skin
irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries!
Protect the rechargeable
battery from heat, for example from continuous
exposure to sunlight, fire, water and moisture.
There is a risk of explosion.

PAPK 12 D1 GB│IE │ 7 ■
Extended safety guidelines
■Do not use a damaged or modified battery.
Damaged or modified batteries may behave
unexpectedly and cause fires, explosions or pose
a risk of injury.
■Do not expose a battery to fire or excessively
high temperatures. Fire or temperatures in excess
of 130°C (265°F) can cause an explosion.
■Follow all instructions regarding charging and
never charge the battery or the cordless tool
outside the temperature range given in the
operating instructions.
Incorrect charging or charging outside of the
permissible temperature range can destroy the
battery and increase the risk of fire.

PAPK 12 D1■ 8 │ GB│IE
Charging the battery pack
(seefig. A)
CAUTION!
► Always unplug the appliance before you
remove the battery pack from or connect the
battery pack to the charger.
NOTE
► Never charge the battery pack if the ambient
temperature is below 10°C or above 40°C.
If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The storage climate
should be cool and dry and the ambient tem-
perature should be between 0°C and 50°C.
♦ Insert the battery pack into the high-speed
charger .
♦ Insert the power plug into the socket. The charge
control LED lights up red.
♦ The green charge control LED indicates that
charging is complete and the battery pack is
ready for use.

PAPK 12 D1 GB│IE │ 9 ■
♦ Push the battery pack into the appliance.
♦ You should always switch the high-speed
charger off for at least 15 minutes between
successive charging processes. Also disconnect
the power plug from the mains power socket.
Maintenance and storage
■ If you do not intend to use the battery for an
extended period, remove it from the appliance
and store it in a clean, dry place out of direct
sunlight.
■ If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
■Never try to repair damaged batteries.
Maintenance of batteries should only be carried
out by the manufacturer or an approved customer
service centre.
■ Clean the charger and the battery with a dry
cloth or a brush. Do not use water or metallic
objects.

PAPK 12 D1■ 10 │ GB│IE
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from the
date of purchase. If this product has any faults, you,
the buyer, have certain statutory rights. Your statutory
rights are not restricted in any way by the warranty
described below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will be
required as proof of purchase.
If any material or manufacturing fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you
or refund the purchase price (at our discretion). This
warranty service requires that you present the defective
appliance and the proof of purchase (receipt) within
the three-year warranty period, along with a brief
written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product
will either be repaired or replaced by us. The repair
or replacement of a product does not signify the
beginning of a new warranty period.

PAPK 12 D1 GB│IE │ 11 ■
X 12 V and X 20 V Team Series battery packs come
with a 3-year warranty valid from the date of purchase.
Warranty period and statutory claims for
defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accord-
ance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product parts
subject to normal wear and tear or to fragile parts
which could be considered as consumable parts
such as switches or parts made of glass.
The warranty does not apply if the product has been
damaged, improperly used or improperly main-
tained. The directions in the operating instructions
for the product regarding proper use of the product

PAPK 12 D1■ 12 │ GB│IE
are to be strictly followed. Uses and actions that are
discouraged in the operating instructions or which
are warned against must be avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications/repairs
which have not been carried out by one of our
authorised Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity
over time
■ Commercial use of the product
■ Damage to or alteration of the product by the
customer
■ Non-compliance with safety and maintenance
instructions, operating errors
■ Damage caused by natural hazards

PAPK 12 D1 GB│IE │ 13 ■
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(IAN)391277_2201 available as proof of
purchase.
■ You will find the item number on the type plate on
the product, an engraving on the product, on the
front page of the operating instructions (below
left) or on the sticker on the rear or bottom of the
product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free
of charge to the service address that will be
provided to you. Ensure that you enclose the
proof of purchase (till receipt) and information
about what the defect is and when it occurred.
You can download these instructions
along with many other manuals,
product videos and installation soft-
ware at www.lidl-service.com.

PAPK 12 D1■ 14 │ GB│IE
This QR code will take you directly to the Lidl service
page (www.lidl-service.com) where you can open
your operating instructions by entering the item
number (IAN) 391277_2201.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
Service Ireland
Tel.: [phone]
E-Mail: [email protected]
IAN 391277_2201
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PAPK 12 D1 GB│IE │ 15 ■
Disposal
The product and its packaging are recyclable.
They are subject to an extended manufacturer
responsibility and will be collected separately.
Do not dispose of power tools
in your normal domestic waste!
The adjacent symbol of a crossed-out
dustbin means that this appliance is
subject to Directive 2012/19/EU. This directive
states that this appliance may not be disposed of in
the normal household waste at the end of its useful
life, but must be taken to specially set-up collection
locations, recycling depots or disposal companies.
The disposal is free of charge for the user.
Protect the environment and dispose of this
appliance properly.
