Parkside PHP 500 A1 - 3 User manual

LIMPISTOL
Brugs- og sikkerhedsanvisninger
HOT GLUE GUN
Operation and Safety Notes
3
LIMPISTOL
Bruksanvisning och säkerhetsanvisningar
KUUMALIIMAPISTOOLI
Käyttö- ja turvaohjeet
HEISSKLEBEPISTOLE
Bedienungs- und Sicherheitshinweise
HOT GLUE GUN PHP 500 A1

GB/IE Operation and Safety Notes Page 5
FI Käyttö- ja turvaohjeet Sivu 11
SE Bruksanvisning och säkerhetsanvisningar Sidan 17
DK Brugs- og sikkerhedsanvisninger Side 23
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 29
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.
Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.
Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant med
apparatens/maskinens funktioner.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

B C
D E F
10
A9
8
11
2
8
1
3
567 4

5GB/IE
Table of contents
Introduction
Proper use......................................................................................................................Page 6
Features .........................................................................................................................Page 6
Included items ...............................................................................................................Page 6
Technical details............................................................................................................Page 7
Safety notes
1. Workplace safety.....................................................................................................Page 7
2. Electrical safety.........................................................................................................Page 7
3. Personal safety..........................................................................................................Page 7
4. Careful handling and use of electrical power tools ...............................................Page 8
Operation
Before first use...............................................................................................................Page 8
Preparing the tool for use .............................................................................................Page 8
Maintenance and Cleaning........................................................................Page 9
Service.........................................................................................................................Page 9
Warranty...................................................................................................................Page 9
Disposal......................................................................................................................Page 10
Declaration of Conformity/Manufacturer....................................Page 10

6 GB/IE
Introduction
Hot glue gun PHP 500 A1
Introduction
You must familiarise yourself with all
safety instructions and functions of the
machine before starting it up. Further
details can be found in the operating instructions.
Keep these instructions in a safe place. If you pass
the tool on to anyone else, please ensure that you
also pass on all the documentation.
Proper use
The device is intended for gluing wood, cardboard,
packaging, PVC, carpet, seals, plastic, leather,
ceramic, glass and textiles with hot-melt adhesive.
The material to be glued must be clean, dry and
free of grease. Any other use or modification to the
tool shall be considered as improper use and could
give rise to considerable dangers. The manufacturer
will not accept liability for loss or damage arising
from improper use. The tool is not intended for com-
mercial use.
Features
1Feed channel
2Check indicator
3Charger connection
4Charger with stand
5Feed clamp
6Wire stand
7Drip tray
8Nozzle
9Nozzle heat shield
10 Glue gun connection
11 Mains lead
 Included items
1 Hot glue gun PHKP500 SE
1 Charger with stand
1 Mains lead
1 Wire stand
1 Replacement nozzle (short)
1 Interchangeable nozzle (long)
6 Glue sticks
1 Carry case
1 Operating instructions
The following pictograms are used in these operating instructions/on the device:
Read instruction manual! For indoor use only!
V~Volt (AC) Risk of loss of life by electric shock from
damaged mains lead or mains plug!
WWatts (Effective power) Danger of burns from nozzle or glue
(up to 200°C)!
Safety class II Cordless working
Observe caution and safety notes! Wear protective gloves!
Keep children away from electrical
devices!
Dispose packaging and appliance in
an environmentally-friendly way!

7GB/IE
Introduction/ Safety notes
Technical details
Nominal voltage: 230V~50Hz
Nominal power: approx. 40W (500W)
Heating up time: approx. 4min.
Protection class: II/
Safety notes
 ATTENTION! Please read all the instructions
and advice. Failure to observe the instructions
and advice given below may result in electric
shock, fire and/or serious injury.
Keep all the safety advice and instructions
in a safe place for future reference!
1. Workplace safety
a) Keep your working area clean and
clutter-free. Untidy or poorly lit working
areas can lead to accidents.
b) Do not allow the device to become wet.
Do not operate it in a moist environment.
c) Keep children and other
people away while you are
operating the electrical tool.
Distractions can cause you to lose control of
the device.
 Children or persons who lack the
knowledge or experience to use the
device or whose physical, sensory or
intellectual capacities are limited must
never be allowed to use the device
without supervision or instruction by
a person responsible for their safety.
Children must never be allowed to play with
the device.
 ATTENTION! This tool must be placed down
on its wire stand 6when it is not being used.
2. Electrical safety
a) The mains plug on the device must
match the mains socket. The plug must
not be modified in any way. Do not
use an adapter plug with devices fitted
with a protective earth. Unmodified
plugs and matching sockets reduce the risk of
electric shock.
b) Avoid touching earthed surfaces such
as pipes, radiators, ovens and refrig-
erators with any part of your body.
There is an increased risk of electric shock if
your body is earthed.
c) Keep the device away from rain or
moisture. Water entering an electrical device
in creases the risk of electric shock.
d) Do not use the mains lead for
any purpose for which it
was
not intended, e.g. to carry
the device, to hang up the device or to
pull the mains plug out of the mains
socket. Keep the lead away from heat,
oil and sharp edges. Do not touch the
mains lead if it becomes damaged or severed
while you are working, instead pull the mains
plug out of the mains socket immediately.
Damaged or tangled mains leads increase the
risk of electric shock.
e) When working outdoors with an elec-
trical power tool always use extension
cables that are also approved for use
outdoors. The use of an extension cable suit-
able for outdoor use reduces the risk of electric
shock.
3. Personal safety
a) Remain alert at all times, watch what
you are doing and always proceed
with caution. Do not use the device if
you are tired or under the influence of
drugs, alcohol or medication. One mo ment
of carelessness when using the device can lead
to serious injury.

8 GB/IE
Safety notes/ Operation
b) To avoid the danger of injury,
burning and damage to
health:
DANGER OF BURNS! The glue
and the nozzle can reach tempera-
tures of 200°C. Do not touch the
nozzle or the glue. Keep other people and an-
imals away from the hot glue. On contact with
the skin, hold the affected part under running
cold water for several minutes. Do not try to
remove the glue from the skin.
4. Careful handling and use
of electrical power tools
a) Pull the mains plug from the socket
before you make any adjustments to
the device, change accessories or when
the device is put away. This precaution is
intended to prevent you from unintentionally
starting the device.
b) When not in use always ensure that
electrical power tools are kept out of
reach of children. Do not let anyone
use the device if he or she is not
familiar with it or has not read the
instructions and advice. Electrical power
tools are dangerous when they are used by
inexperienced people. Let the device cool
down completely before putting it away. The
hot nozzle can cause damage.
c) Look after the device carefully. Check
that moving parts are working prop-
erly and move freely. Check for any
parts that are broken or damaged
enough to detrimentally affect the
functioning of the device. Have dam-
aged parts repaired before you use
the device. Many accidents have their origins
in poorly maintained electrical power tools.
d) Always work with the mains lead leading
away from the rear of the device.
Operation
Before first use
Preparing the glue site:
 Do not use inflammable solvents to clean the
glue site.
 The ambient temperature and temperature of
the materials to be glued must be not less than
+ 5°C and not warmer than + 50°C.
 The glue sites must be clean, dry and free of
grease.
 Smooth surfaces should be roughened before
gluing.
 Warm any materials that are prone to cool
down quickly (e.g. steel) to improve the bond
with the glue.
 Screw on the appropriate nozzle 8and fit
the wire stand 6.
Preparing the tool for use
Working with the mains lead connected:
1. Connect the mains lead 11 to the glue gun
connection 10 (see Fig. F).
Insert the mains plug into the mains socket.
2. Fold forward the wire stand 6.
Stand the device up.
3. Push a glue stick into the feed channel 1.
4. Let the device heat up for about 4minutes.
The device is now ready for use.
Cordless working:
1. Connect the mains lead 11 to the charger
connection 3.
Insert the mains plug into the mains socket.
2. Place the glue gun into the charger 4.
3. Push a glue stick into the feed channel 1.
4. Let the device heat up for about 4 minutes.
The device is now ready for use.
5. Repeat the heating-up procedure if the feed
switch becomes stiff or the outcoming glue
becomes viscous.

9GB/IE
Operation/ Maintenance and Cleaning/ Service/ Warranty
Gluing:
 Press the feed clamp 5to regulate the flow of
glue as required for your work.
1. Apply the glue in individual dots. Apply in zig-
zags on flexible materials such as fabrics.
2. Immediately after applying the glue, press the
two materials together for about 30 seconds. The
glued joint can be loaded after about 5minutes.
3. When you take a break from work, set the
glue gun down on the wire stand 6or in the
charger 4.
4. Remove any glue residue with a sharp knife
after cooling. Glued joints can be loosened
again by applying heat.
Switching off the device:
 Pull the mains lead out of the mains socket.
Changing the nozzle:
 Wear protective gloves.
 Heat up the device for about 4 minutes.
Change the nozzle 8when it is hot.
 DANGER OF BURNS! Touch the
nozzle 8only by the heat shield 9.
The nozzle tip is hot!
Maintenance and Cleaning
The glue gun is maintenance-free.
 WARNING! Pull the mains lead out of the
mains socket before you clean the tool.
 Always keep the device clean and dry.
 Do not allow any liquids to enter the tool. Use
a soft cloth to clean the housing. Never use
petrol, solvents or cleaning agents that might
attack plastic.
Service
 WARNING! Have your device
repaired only by qualified specialist
personnel using original manufacturer
parts only. This will ensure that your device
remains safe to use.
 WARNING! If the plug or mains
lead needs to be replaced, always
have the replacement carried out by
the manufacturer or its service centre.
This will ensure that your device remains safe
to use.
Warranty
The warranty for this appliance is for 3
years from the date of purchase. The ap-
pliance has been manufactured with care
and meticulously examined before deliv-
ery. Please retain your receipt as proof
of purchase. In the event of a warranty
claim, please make contact by telephone
with our Service Department. Only in this
way can a post-free despatch for your
goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile compo-
nents, e.g. buttons or batteries. This product is for
private use only and is not intended for commercial
use.
The warranty is void in the case of abusive and im-
proper handling, use of force and internal tamper-
ing not carried out by our authorized service branch.
Your statutory rights are not restricted in any way
by this warranty.
The warranty period will not be extended by repairs
made unter warranty. This applies also to replaced
and repaired parts. Any damage and defects extant
on purchase must be reported immediately after
unpacking the appliance, at the latest, two days after
the purchase date. Repairs made after the expiration
of the warranty period are subject to payment.
GB
DES UK LTD
Tel.: [phone] (£ 0.10 / minute)
e-mail: [email protected]

10 GB/IE
Warranty/ Disposal/ Declaration of Conformity/ Manufacturer
IE
Kompernass Service Ireland
Tel: [phone] (0,082 EUR/Min.)
Standard call rates apply.
Mobile operators may vary.
e-mail: [email protected]
Disposal
The packaging is made entirely of recy-
clable materials, which you may dispose
of at local recycling facilities.
Do not dispose of electrical
appliances in household waste.
In accordance with European Directive
2002/96/EC on used electrical and electronic
appliances and its implementation in national law,
used power tools must be collected separately and
recycled in an ecologically compatible manner.
Information on options for disposing of electrical
appliances after their useful life can be obtained
from your local or city council.
Declaration of Conformity/
Manufacturer
We, Kompernaß GmbH, the person responsible for
documents: Mr Felix Becker, Burgstr. 21, D-44867
Bochum, Germany, hereby declare that this product
complies with the following standards, normative
documents and EU directives:
EU Low Voltage Directive
(2006/95/EC):
EN60335-1,
EN60335-2-45
Electromagnetic compatibility
(2004/108/EC):
EN55014,
EN55014-2,
EN61000-3-2,
EN61000-3-3
Description of the device:
Hot glue gun PHP 500 A1
Date of manufacture (DOM): 06-2010
Serial number: IAN 54325
Bochum, 30.06.2010
Hans Kompernaß
- Managing Director -
We reserve the right to make technical modifica-
tions in the course of further development.

11FI
Sisällysluettelo
Johdanto
Määräystenmukainen käyttö.........................................................................................Sivu 12
Varusteet.........................................................................................................................Sivu 12
Toimituslaajuus ...............................................................................................................Sivu 12
Tekniset tiedot.................................................................................................................Sivu 13
Turvallisuusohjeita
1. Työpaikkaturvallisuus.................................................................................................Sivu 13
2. Sähköturvallisuus .......................................................................................................Sivu 13
3. Henkilöiden turvallisuus.............................................................................................Sivu 13
4. Tarkkaavainen käsittely ja käyttö sähkölaitteilla .....................................................Sivu 14
Käyttö
Ennen käyttöönottoa......................................................................................................Sivu 14
Käyttöönotto...................................................................................................................Sivu 14
Huolto ja hoito.......................................................................................................Sivu 15
Huolto............................................................................................................................Sivu 15
Takuu.............................................................................................................................Sivu 15
Hävittäminen..........................................................................................................Sivu 15
Yhdenmukaisuus/Valmistaja..................................................................Sivu 16
