Parkside PHPA 4 B2 User manual

CORDLESS HOT GLUE GUN PHPA 4 B2
CORDLESS HOT GLUE GUN
Translation of the original instructions
IAN 297748
AKKU-HEISSKLEBEPISTOLE
Originalbetriebsanleitung

GB/IE/NI Translation of the original instructions Page 1
DE/AT/CH Originalbetriebsanleitung Seite 21
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

PHPA 4 B2

PHPA 4 B2
GB│IE│NI │ 1 ■
Contents
Introduction .................................. 2
Intended use..........................................2
Notes on trademarks ...................................2
Features .............................................3
Package contents ......................................3
Technical data ........................................4
General safety warnings for electric heating tools .. 5
Use and handling of the cordless electrical power tool .........8
Safety guidelines for battery chargers ......................9
Before use .................................. 10
Charging the appliance battery ..........................10
Battery level display ..................................11
Preparing the surfaces to be glued........................11
Use ........................................ 12
Maintenance and cleaning ..................... 14
Disposal .................................... 14
Kompernass Handels GmbH warranty........... 16
Service ..................................... 18
Importer.................................... 19
Translation of the original Conformity Declaration . 19
IB_297748_PHPA4B2_LB6.indb 1 18.07.18 13:15

PHPA 4 B2
■ 2 │ GB│IE│NI
CORDLESS HOT GLUE GUN PHPA 4 B2
Introduction
Congratulations on the purchase of your new appliance.
You have chosen a high-quality product. The operating
instructions are part of this product. They contain important
information about safety, usage and disposal. Before using the
product, please familiarise yourself with all operating and safety
instructions. Use the product only as described and for the range of
applications specified. Please also pass these operating instructions
on to any future owner.
Intended use
This appliance is intended for gluing wood, cardboard, packaging,
PVC, carpet, seals, plastics, leather, ceramics, glass and fabric with
hot-melt adhesive. The material to be glued must be clean, dry and
free of grease. Any other usage of or modification to the appliance
is deemed to be improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for damage(s) attributable
to misuse. The appliance is not intended for commercial use.
Notes on trademarks
USB®is a registered trademark of USB Implementers Forum, Inc.
All other names and products may be trademarks or registered
trademarks of their respective owner.
IB_297748_PHPA4B2_LB6.indb 2 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 3 ■
Features
Temperature indicator
ON/OFF switch
Battery capacity/charge level indicator
Glue stick
Feeder shaft
Trigger
Micro USB connection
Micro USB plug of the charger cable
USB plug of the charger cable
Mains adapter
Charging contacts
Stand
Charger with appliance cradle
Nozzle
Thermal protection for nozzle
Package contents
1 cordless hot glue gun
1 charger with appliance cradle
1 stand
1 charging cable
1 mains adapter
6 glue sticks
1 set of operating instructions
IB_297748_PHPA4B2_LB6.indb 3 18.07.18 13:15

PHPA 4 B2
■ 4 │ GB│IE│NI
Technical data
Cordless hot glue gun PHPA 4 B2:
Nominal battery voltage: 4 V (DC)
Protection class: III/ (protection through
extra-low voltage)
Cells: 1
Battery (integrated): LITHIUM ion
Battery capacity: 1500 mAh
Heat-up time: approx. 60 sec.
Temperature: approx. 170°C
Glue stick diameter: Ø 7 mm
Glue stick length: 140 mm
Working time with one
battery charge: approx. 30 min.
Charger PHPA 4 B2-2:
INPUT:
Nominal voltage: 100–240 V ∼ 50/60 Hz
(AC)
Nominal current: 300 mA
Safety transformer:
Switched-mode
power supply:
OUTPUT:
Nominal voltage: 5 V
(DC)
Nominal current: 600 mA
Charging time: approx. 3 hr
Protection class: II/ (double insulation)
IB_297748_PHPA4B2_LB6.indb 4 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 5 ■
General safety warnings for
electric heating tools
WARNING!
► Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "electric heating tool" in the warnings refers to your
mains-operated (corded) electric heating tool or battery-operated
(cordless) electric heating tool.
■Children should be supervised to ensure
that they do not play with the appliance.
■NOTE! This appliance must be placed on its
stand or the charger when not in use.
IB_297748_PHPA4B2_LB6.indb 5 18.07.18 13:15

PHPA 4 B2
■ 6 │ GB│IE│NI
■ Always protect the appliance from rain and
moisture. Water entering a power tool will
increase the risk of electric shock.
■Do not misuse the power cord, e.g. to carry
or hang up the appliance, or to pull the
plug from the socket. Keep cord away from
heat, oil, sharp edges or moving parts.
If the power cord is damaged or severed
during work, do not touch the cord but rather
pull out the plug. Damaged or entangled
cords increase the risk of electric shock.
■ To avoid potential risks, damaged mains
cables should be replaced by the manufac-
turer, their customer service department or a
similarly qualified person.
■ Only for indoor use.
■ During breaks in work, rest the appliance on
the stand .
■ Allow the appliance to cool completely after
use and before storage.
■ Do not work on any material containing
asbestos.
IB_297748_PHPA4B2_LB6.indb 6 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 7 ■
■Avoid the risk of injury or fire as well as
health risks:
Risk of burns! The nozzle reaches a tempera-
ture of over 170°C. The glue reaches a tem-
perature of over 170°C. Do not touch the
nozzle or the hot glue. Do not allow hot glue
to come into contact with people or animals.
In case of contact with skin, rinse the affected
part in cold running water for a few minutes.
Do not attempt to remove the adhesive from
the skin.
■ Do not pull out the glue stick!
IB_297748_PHPA4B2_LB6.indb 7 18.07.18 13:15

PHPA 4 B2
■ 8 │ GB│IE│NI
Use and handling of the cordless electrical
power tool
a) Charge the appliance using only the charger recommended by
the manufacturer. Chargers are often designed for a particular
type of rechargeable battery unit. There is the danger of fire if
other types of rechargeable battery units are used.
c) When not in use, store the appliance away from paper clips,
coins, keys, nails, screws or other small metal objects that could
bridge the contacts. Short-circuiting the contacts of a rechargeable
battery unit may result in heat damage or fire.
c) Fluids may leak out of rechargeable battery units if they are
misused. If this happens, avoid contact with the fluid. If contact
occurs, flush the affected area with water. Seek additional
medical help if any of the fluid gets into your eyes. Escaping
battery fluid may cause skin irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable batteries.
Protect the appliance from heat, e.g. also from
continuous sunlight, fire, water and humidity.
There is a risk of explosion.
IB_297748_PHPA4B2_LB6.indb 8 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 9 ■
Safety guidelines for battery chargers
■ This appliance may be used by children
aged 8 years and above and by persons
with limited physical, sensory or mental capa-
bilities or lack of experience and knowledge,
provided that they are under supervision or
have been told how to use the appliance
safely and are aware of the potential risks.
Do not allow children to use the appliance as
a toy. Cleaning and user maintenance tasks
may not be carried out by children unless
they are supervised.
The charger is suitable for indoor use
only.
■ If you are using a USB power supply, the
mains socket used must always be easily
accessible so that the USB power supply can
be quickly disconnected from the socket in
a hazardous situation. Please also observe
the operating instructions for the USB power
supply.
WARNING! Use only the power cable supplied with the
supplied charger .
IB_297748_PHPA4B2_LB6.indb 9 18.07.18 13:15

PHPA 4 B2
■ 10 │ GB│IE│NI
The nozzle reaches a temperature of over 170°C.
WARNING!
■ Never operate the charger with a damaged power cord
or power plug. Damaged power cords can result in
danger to life due to electric shock.
Before use
Charging the appliance battery
Only for indoor use!
NOTE
► The battery is supplied partially charged. Before first use,
charge the battery for at least 3 hours. Li-ion batteries can
be charged at any time without adversely affecting their
service life. Interrupting the charging process does not
damage the battery.
■ Never charge the appliance when the ambient temperature is
below 10°C or above 40°C.
Starting charging:
♦ Connect the micro USB plug of the charger cable to the
micro USB charging port on the charger .
♦ Connect the USB plug of the charger cable to the mains
adapter .
♦ Connect the mains adapter to a 100–240 V ∼ 50/60 Hz
power source.
♦ Place the cordless glue gun onto the charging cradle .
The battery charge level indicator lights up red.
170
IB_297748_PHPA4B2_LB6.indb 10 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 11 ■
Stopping charging:
♦ The green battery charge level indicator indicates that the
charging process is complete and the cordless glue gun is
ready for use.
♦ Remove the cordless glue gun from the charging cradle .
♦ Disconnect the mains adapter from the power supply.
Battery level display
The battery level display indicates the charge level using 2 coloured
LEDs.
Green LED:
The battery is fully charged.
Red LED:
The battery is flat. Recharge it.
Preparing the surfaces to be glued
■ Do not use flammable solvents to clean the surfaces to be glued.
■ The ambient temperature and the materials to be bonded may
not be colder than 5°C and not warmer than 50°C.
■ The area to be glued must be clean, dry and free of grease.
♦ Smooth surfaces should be roughened before gluing.
♦ Quick-cooling materials such as steel should be warmed a little
to facilitate adhesion.
IB_297748_PHPA4B2_LB6.indb 11 18.07.18 13:15

PHPA 4 B2
■ 12 │ GB│IE│NI
Use
Inserting a glue stick:
♦ Push the glue stick into the feeder shaft .
♦ Allow the appliance to heat up for about 60 seconds.
The appliance is now ready for use.
Switching on:
♦ To turn on the cordless glue gun, press the ON/OFF switch
until the temperature indicator lights up red and the battery
capacity/charge level indicator lights up green/red.
The glue is heated up.
■ The temperature indicator lights up green as soon as the
appliance has reached working temperature.
Switching off:
♦ To turn off the cordless glue gun, press the ON/OFF switch
until the temperature indicator goes off.
♦ During breaks in work, put the glue gun down on the stand .
Allow the appliance to cool down fully before storing it.
The hot nozzle can cause damage and/or burns.
IB_297748_PHPA4B2_LB6.indb 12 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 13 ■
Automatic switch off:
NOTE
► The cordless glue gun switches itself off after 10 minutes to
save energy.
–Switch the cordless glue gun back on. Check the tempera-
ture indicator and the battery capacity indicator
to see whether the appliance needs to be recharged or
heated further.
► To save energy, do not switch the cordless glue gun on
unless you plan to use it.
► During breaks in work, put the glue gun down on the stand .
Gluing:
♦ Pull the trigger to regulate the flow of glue in accordance
with your requirements.
♦ Apply the glue in spots. For flexible materials, such as textiles,
apply the glue in zigzag lines.
♦ Press the two workpieces to be bonded together immediately
after applying the glue and hold for about 30 seconds. The
glued bond is ready after about 5 minutes.
♦ During breaks in work, put the glue gun down on the stand .
♦ Remove any glue residue after it has cooled down with a sharp
knife. Bonded joints can be released by heating.
IB_297748_PHPA4B2_LB6.indb 13 18.07.18 13:15

PHPA 4 B2
■ 14 │ GB│IE│NI
Maintenance and cleaning
The cordless glue gun is maintenance free.
WARNING! Always remove the mains adapter from
the power socket before cleaning the appliance. Keep the
appliance clean and dry at all times.
■ The appliance must always be kept clean, dry and free from oil
or grease.
■ Do not allow any liquids to get into the appliance.
■ Use a cloth to clean the housing. Never use petrol, solvents or
cleansers which can damage plastic.
Disposal
The packaging is made from environmentally friendly
material and can be disposed of at your local recycling
plant.
Dispose of the packaging in an environmentally friendly
manner.
Note the labelling on the packaging and separate the
packaging material components for disposal if
necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following
meanings:
1–7: plastics,
20–22: paper and cardboard,
80–98: composites
Your local community or municipal authorities can provide
information on how to dispose of the worn-out product.
IB_297748_PHPA4B2_LB6.indb 14 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 15 ■
Do not dispose of electrical appliances in the
household waste!
As required by European Guideline 2012/19/EU, worn-out
electrical appliances must be collected separately and fed into
an environmentally compatible recycling process.
The appliance and the batteries must be disposed of separately.
NOTE!
► The battery must be removed/disposed of by a specialist
technician.
Dispose of the appliance via an approved disposal company or your
municipal waste facility. Please comply with all applicable regulations.
Please contact your waste disposal facility if you are in any doubt.
Do not dispose of batteries in your normal
household waste!
Disposal of (rechargeable) batteries
Used batteries may not be disposed of in the household waste.
Consumers are legally obliged to dispose of batteries at a collection
point in their community/city district or at a retail store. The purpose
of this obligation is to ensure that batteries are disposed of in an
environmentally friendly manner. Only dispose of batteries when
they are fully discharged.
IB_297748_PHPA4B2_LB6.indb 15 18.07.18 13:15

PHPA 4 B2
■ 16 │ GB│IE│NI
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase.
If this product has any faults, you, the buyer, have certain statutory
rights. Your statutory rights are not restricted in any way by the war-
ranty described below.
Warranty conditions
The validity period of the warranty starts from the date of purchase.
Please keep your original receipt in a safe place. This document will
be required as proof of purchase.
If any material or production fault occurs within three years of the
date of purchase of the product, we will either repair or replace the
product for you at our discretion. This warranty service is dependent
on you presenting the defective appliance and the proof of purchase
(receipt) and a short written description of the fault and its time of
occurrence.
If the defect is covered by the warranty, your product will either be
repaired or replaced by us. The repair or replacement of a product
does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the
warranty. This also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be
reported immediately after unpacking. Repairs carried out after expi-
ry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quali-
ty guidelines and inspected meticulously prior to delivery.
IB_297748_PHPA4B2_LB6.indb 16 18.07.18 13:15

PHPA 4 B2
GB│IE│NI │ 17 ■
The warranty covers material faults or production faults. The warranty
does not extend to product parts subject to normal wear and tear
or fragile parts such as switches, batteries, baking moulds or parts
made of glass.
The warranty does not apply if the product has been damaged,
improperly used or improperly maintained. The directions in the oper-
ating instructions for the product regarding proper use of the product
are to be strictly followed. Uses and actions that are discouraged
in the operating instructions or which are warned against must be
avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or
improper handling, use of force and modifications/repairs which
have not been carried out by one of our authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please observe the follow-
ing instructions:
■ Please have the till receipt and the item number (e.g. IAN
12345) available as proof of purchase.
■ You will find the item number on the type plate, an engraving on
the front page of the instructions (bottom left), or as a sticker on
the rear or bottom of the appliance.
■ If functional or other defects occur, please contact the service
department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the ser-
vice address that will be provided to you. Ensure that you enclose
the proof of purchase (till receipt) and information about what the
defect is and when it occurred.
IB_297748_PHPA4B2_LB6.indb 17 18.07.18 13:15
