Parkside PNKP 105 B1 User manual

HOT GLUE GUN PNKP 105 B1
HOT GLUE GUN
Translation of the original instructions ΠΙΣΤΌΛΙ ΘΕΡΜΌΚΌΛΛΗΣHΣ
Μετάφραση των αυθεντικών οδηγιών
λειτουργίας
HEISSKLEBEPISTOLE
Originalbetriebsanleitung
IAN 327104_1904

GB/IE/NI/CY Translation of the original instructions Page 1
GR / CY Μετάφραση των αυθεντικών οδηγιών λειτουργίας Σελίδα 15
DE/AT/CH Originalbetriebsanleitung Seite 29
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και
εξοικειωθείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

PNKP 105 B1 GB│IE│NI│CY │ 1 ■
Contents
Introduction .................................. 2
Intended use..........................................2
Features .............................................3
Package contents ......................................3
Technical details .......................................3
General safety warnings for power tools in
household use ................................ 4
Additional safety instructions for glue guns ..................5
Original accessories/auxiliary equipment ...................6
Operation ................................... 6
Maintenance and cleaning ...................... 7
Disposal ..................................... 8
Disposal of the appliance................................8
Kompernass Handels GmbH warranty............ 9
Service ..................................... 12
Importer.................................... 12
Translation of the original Conformity Declaration . 13

PNKP 105 B1
■ 2 │ GB│IE│NI│CY
HOT GLUE GUN PNKP 105 B1
Introduction
Congratulations on the purchase of your new appliance. You have
selected a high-quality product. The operating instructions are part of
this product. They contain important information about safety, usage
and disposal. Before using the product, please familiarise yourself
with all operating and safety instructions. Use the product only as
described and for the range of applications specified. Please also
pass these operating instructions on to any future owner.
Intended use
This appliance is specifically intended for a variety of creative hobby
applications involving the gluing of heat-sensitive materials such as
paper, flowers, cardboard, packaging, plastics, leather, ceramics,
glass and fabric. The material to be glued must be clean, dry and
free of grease. Any other usage of or modification to the appliance
is deemed to be improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for damage(s) attribut-
able to misuse. The appliance is not intended for commercial use.

PNKP 105 B1 GB│IE│NI│CY │ 3 ■
Features
Feeder shaft
Power cable
Trigger
Stand
Nozzle
Thermal protection for nozzle
Glue sticks
Package contents
1 hot glue gun PNKP 105 B1
1 stand
6 glue sticks
1 set of operating instructions
Technical details
Rated voltage: 230V ~50Hz (AC)
Rated power consumption: 5 W (20 W in operation)
Operating temperature: 105–140°C
Heating-up time: approx. 5 min.
Protection class: II/ (double insulation)
For glue sticks: ø 7 mm e.g. PARKSIDE PNKPZ 3 B2

PNKP 105 B1
■ 4 │ GB│IE│NI│CY
General safety warnings for power
tools in household use
CAUTION!
► Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
■ This appliance may be used by children aged
8 years and above and by persons with limited
physical, sensory or mental capabilities or lack
of experience and knowledge, provided that
they are under supervision or have been told
how to use the appliance safely and are aware
of the potential risks. Do not allow children to use
the appliance as a plaything. Cleaning and user
maintenance tasks may not be carried out by
children unless they are supervised.
■ To avoid potential risks, damaged mains cables
should be replaced by the manufacturer, their
customer service department or a similarly quali-
fied person.

PNKP 105 B1 GB│IE│NI│CY │ 5 ■
Additional safety instructions for glue guns
■ Children should be supervised to ensure that they do not play
with the appliance.
■ ATTENTION! This appliance must be placed on its stand
when not in use.
■ Always protect the appliance from rain and moisture. Water
entering a power tool will increase the risk of electric shock.
■ Do not misuse the power cord, e.g. to carry or hang up the appli-
ance, or to pull the plug from the socket. Keep cord away from
heat, oil, sharp edges or moving parts.
If the power cord is damaged or severed during work, do not touch
the cord but rather pull out the plug. Damaged or entangled
cords increase the risk of electric shock.
■ Only for indoor use.
■ If you take a break of longer than 30 minutes, pull out the power
plug.
■ Allow the appliance to cool completely after use and before
storage.
■ Do not work on any material containing asbestos.
■ Avoid the risk of injury or fire as well as health risks: RISK OF
BURNS! The adhesive and the nozzle reach a temperature of
around 105°C. Do not touch the nozzle or the glue. Do not
allow hot glue to come into contact with people or animals. In
case of contact with skin, rinse the affected part in cold running
water for a few minutes. Do not attempt to remove the adhesive
from the skin.
■ Always route the power cable towards the rear, away from the
appliance.

PNKP 105 B1
■ 6 │ GB│IE│NI│CY
Original accessories/auxiliary equipment
♦ Only use the accessories and additional equipment that are
specified in the operating instructions and compatible with the
appliance.
Operation
Preparing the surfaces to be glued:
■ Do not use flammable solvents to clean the surfaces to be glued.
■ The ambient temperature and the materials to be bonded may
not be colder than 5°C and not warmer than 50°C.
■ The area to be glued must be clean, dry and free of grease.
♦ Smooth surfaces should be roughened before gluing.
♦ Quick-cooling materials such as steel should be warmed a little
to facilitate adhesion.
1. Fold out the stand . Put down the appliance.
2. Push a glue stick into the feeder shaft .
3. Allow the appliance heat up for about 5 minutes.
The appliance is now ready for use.

PNKP 105 B1 GB│IE│NI│CY │ 7 ■
Preparing the surfaces to be glued:
♦ Pull the trigger to regulate the flow of glue in accordance
with your requirements.
1. Apply the glue in spots. For flexible materials, such as textiles,
apply the glue in zigzag lines.
2. Press the two workpieces to be bonded together immediately
after applying the glue and hold for about 30 seconds. The
glued bond is ready after about 5 minutes.
3. During breaks in work, put the glue gun down on the stand .
Switching the appliance off:
♦ Unplug the appliance from the mains socket.
The nozzle reaches a temperature of over 140°C.
Maintenance and cleaning
WARNING! ALWAYS REMOVE THE POWER PLUG
FROM THE POWER SOCKET BEFORE CLEANING
THE APPLIANCE.
■ The low-temperature glue gun is maintenance-free.
■ Keep the appliance clean and dry at all times.
■ Never permit liquids to enter inside the appliance. Use a cloth to
clean the housing. Never use petrol, solvents or cleansers which
can damage plastic.
140

PNKP 105 B1
■ 8 │ GB│IE│NI│CY
Disposal
Disposal of the appliance
The packaging is made from environmentally friendly mate-
rial and can be disposed of at your local recycling plant.
Do not dispose of power tools in your normal
household waste!
European Directive 2012/19/EU requires that worn-out power tools
be collected separately and recycled in an environmentally compatible
manner.
Your local community or municipal authorities can provide informa-
tion on how to dispose of the worn-out appliance.
Dispose of the packaging in an environmentally friendly
manner.
Note the labelling on the packaging and separate the
packaging material components for disposal if
necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following
meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites
Your local community or municipal authorities can
provide information on how to dispose of the worn-out
product.

PNKP 105 B1 GB│IE│NI│CY │ 9 ■
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of pur-
chase. If this product has any faults, you, the buyer, have certain
statutory rights. Your statutory rights are not restricted in any way by
the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your
receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the
date of purchase of the product, we will either repair or replace the
product for you or refund the purchase price (at our discretion). This
warranty service requires that you present the defective appliance
and the proof of purchase (receipt) within the three-year warranty
period, along with a brief written description of the fault and of
when it occurred.
If the defect is covered by the warranty, your product will either be
repaired or replaced by us. The repair or replacement of a product
does not signify the beginning of a new warranty period.

PNKP 105 B1
■ 10 │ GB│IE│NI│CY
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the
warranty. This also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be re-
ported immediately after unpacking. Repairs carried out after expiry
of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict
quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The war-
ranty does not extend to product parts subject to normal wear and
tear or to fragile parts which could be considered as consumable
parts such as switches, batteries or parts made of glass.
The warranty does not apply if the product has been damaged,
improperly used or improperly maintained. The directions in the
operating instructions for the product regarding proper use of the
product are to be strictly followed. Uses and actions that are discour-
aged in the operating instructions or which are warned against must
be avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or
improper handling, use of force and modifications/repairs which
have not been carried out by one of our authorised Service centres.

PNKP 105 B1 GB│IE│NI│CY │ 11 ■
Warranty claim procedure
To ensure quick processing of your case, please observe the follow-
ing instructions:
■ Please have the till receipt and the item number (e.g.
IAN12345) available as proof of purchase.
■ You will find the item number on the type plate on the product,
an engraving on the product, on the front page of the operating
instructions (below left) or on the sticker on the rear or bottom of
the product.
■ If functional or other defects occur, please contact the service
department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the ser-
vice address that will be provided to you. Ensure that you enclose
the proof of purchase (till receipt) and information about what the
defect is and when it occurred.
You can download these instructions along with many
other manuals, product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to the Lidl service
page (www.lidl-service.com) where you can open your
operating instructions by entering the item number (IAN) 123456.

PNKP 105 B1
■ 12 │ GB│IE│NI│CY
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kom[email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: kom[email protected]
IAN 327104_1904
Importer
Please note that the following address is not the service address.
Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PNKP 105 B1 GB│IE│NI│CY │ 13 ■
Translation of the original Conformity
Declaration
We, KOMPERNASS HANDELS GMBH, documents officer:
Mr. Semi Uguzlu, BURGSTR. 21, 44867 BOCHUM, GERMANY,
hereby declare that this product complies with the following
standards, normative documents and EC directives:
EC Low Voltage Directive
(2014/35/EU)
EMC (Electromagnetic Compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)*
* The manufacturer bears the full responsibility for compliance with
this conformity declaration. The object of the declaration described
above complies with the requirements of the Directive 2011/65/EU
of the European Parliament and Council of 8 June 2011 on the
limitations of use of certain dangerous substances in electrical and
electronic appliances.
Applied harmonised standards:
EN 60335-2-45:2002/A2:2012
EN 60335-1:2012/A13:2017
EN 62233:2008
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 50581:2012

PNKP 105 B1
■ 14 │ GB│IE│NI│CY
Type designation of machine: Hot glue gun PNKP 105 B1
Year of manufacture: 09-2019
Serial number: IAN 327104_1904
Bochum, 04/09/2019
Semi Uguzlu
- Quality Manager -
The right to effect technical changes in the context of further
development is reserved.

PNKP 105 B1 GR│CY │ 15 ■
Περιεχόμενα
Εισαγωγή ................................... 16
Προβλεπόμενη χρήση .................................16
Εξοπλισμός .........................................17
Παραδοτέος εξοπλισμός...............................17
Τεχνικά χαρακτηριστικά ................................17
Γενικές υποδείξεις ασφαλείας για ηλεκτρικές
συσκευές οικιακής χρήσης .................... 18
Συμπληρωματικές υποδείξεις ασφαλείας για θερμοκολλητικά
πιστόλια ............................................19
Γνήσια εξαρτήματα/πρόσθετες συσκευές ..................20
Θέση σε λειτουργία ........................... 20
Συντήρηση και καθαρισμός .................... 21
Απόρριψη .................................. 22
Απόρριψη συσκευής ..................................22
Εγγύηση της Kompernass Handels GmbH ........ 23
Σέρβις ...................................... 26
Εισαγωγέας ................................. 26
Μετάφραση της Πρωτότυπης Δήλωση συμμόρφωση 27

PNKP 105 B1
■ 16 │ GR│CY
ΠΙΣΤΟΛΙ ΘΕΡΜΟΚΟΛΛΗΣΗΣ
PNKP 105 B1
Εισαγωγή
Σας συγχαίρουμε για την αγορά της νέας σας συσκευής. Αποφασί-
σατε έτσι για την απόκτηση ενός προϊόντος υψηλής ποιότητας. Οι οδη-
γίες χρήσης είναι τμήμα αυτού του προϊόντος. Περιέχουν σημαντικές
υποδείξεις για την ασφάλεια, τη χρήση και την απόρριψη. Πριν από τη
χρήση του προϊόντος, εξοικειωθείτε με όλες τις υποδείξεις χειρισμού
και ασφάλειας. Χρησιμοποιείτε το προϊόν μόνο όπως περιγράφεται και
για τους αναφερόμενους τομείς χρήσης. Παραδώστε όλα τα έγγραφα
σε περίπτωση παράδοσης του προϊόντος σε τρίτους.
Προβλεπόμενη χρήση
Η συσκευή ενδείκνυται ειδικά για ένα πλήθος δημιουργικών εφαρμο-
γών χόμπι για την κόλληση ευαίσθητων στις υψηλές θερμοκρασίες
υλικών, όπως χαρτί, λουλούδια, ξύλο, χαρτοκιβώτια, συσκευασίες,
πλαστικό, δέρμα, κεραμικό, γυαλί και υφάσματα. Το προς κόλληση
υλικό πρέπει να είναι καθαρό, στεγνό και χωρίς ίχνη λίπους. Κάθε
άλλη χρήση ή μετατροπή της συσκευής ισχύει ως μη σύμφωνη με
τους κανονισμούς και ενέχει σημαντικούς κινδύνους ατυχημάτων.
Για βλάβες από χρήση μη σύμφωνη με τους κανονισμούς, ο κατα-
σκευαστής δεν αναλαμβάνει καμία ευθύνη. Η συσκευή δεν προορί-
ζεται για επαγγελματική χρήση.

PNKP 105 B1 GR│CY │ 17 ■
Εξοπλισμός
Κανάλι τροφοδοσίας
Καλώδιο δικτύου
Τόξο τροφοδοσίας
Τόξο τοποθέτησης
Ακροφύσιο
Θερμοπροστατευτικό κάλυμμα του ακροφυσίου
Στικ κόλλας
Παραδοτέος εξοπλισμός
1 Πιστολι θερμοκολλησης PNKP 105 B1
1 Τόξο τοποθέτησης
6 Στικ κόλλας
1 Οδηγίες χρήσης
Τεχνικά χαρακτηριστικά
Τάση μέτρησης: 230 V ∼ 50 Hz (εναλλασσόμενο ρεύμα)
Κατανάλωση μέτρησης: 5 W (για θέση σε λειτουργία 20 W)
Θερμοκρασία λειτουργίας: 105–140 °C
Χρόνος προθέρμανσης: περ. 5 λεπτά
Κατηγορία προστασίας: II / (διπλή μόνωση)
Για στικ κόλλας: ø 7 χιλ. π.χ. PARKSIDE PNKPZ 3 B2
