Parkside PKLL 7 D3 User manual

CROSS LINE LASER PKLL 7 D3
CROSS LINE LASER
Operation and safety notes
KREUZLINIENLASER
Bedienungs- und Sicherheitshinweise
IAN 353255_2007
K ŘÍŽOVÝ LINIOVÝ LASER
Pokyny pro obsluhu a bezpečnostní
pokyny
KRÍŽOVÝ LÍNIOVÝ LASER
Pokyny pre obsluhu a bezpečnostné pokyny
KERESZTVONALAS LÉZER
Kezelési és biztonsági utalások
KRIŽNO LINIJSKI LASER
Navodila za upravljanje in varnostna
opozorila

CROSS LINE LASER PKLL 7 D3
GB Operation and safety notes Page 5
HU Kezelési és biztonsági utalások Oldal 22
SI Navodila za upravljanje in varnostna
opozorila Stran 39
CZ Pokyny pro obsluhu a bezpečnostní
pokyny Strana 57
SK Pokyny pre obsluhu a bezpečnostné
pokyny Strana 73
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 90

5 4
6
10
8
9
7
3
1
2

1
2
AA1
A2
5
3a
3a

5GB
List of pictograms used..................................... Page 6
Introduction................................................................ Page 7
Intended use..................................................................... Page 7
Description of parts.......................................................... Page 8
Scope of delivery............................................................. Page 8
Technical data.................................................................. Page 8
Safety notes............................................................... Page 9
Safety instructions for batteries/rechargeable
batteries............................................................................ Page 12
Initial use...................................................................... Page 14
Inserting /Changing batteries ......................................... Page 14
Switching on /off ............................................................. Page 14
Use automatic levelling system........................................ Page 15
Working without the automatic levelling system............ Page 16
Practical guidance ........................................................... Page 16
Working with the clamp .................................................. Page 16
Working with the tripod................................................... Page 17
Maintenance and cleaning............................ Page 17
Storage .......................................................................... Page 18
Disposal......................................................................... Page 18
Warranty...................................................................... Page 19
Warranty claim procedure.............................................. Page 20
Service .............................................................................. Page 21

6 GB
List of pictograms used
Please read the instructions for use.
Danger of explosion!
Wear safety gloves!
Attention! - The manual must be consulted in all
cases where this symbol is marked.
Protect yourself from laser radiation!
Do not stare into the laser beam!
Direct current/voltage
Alkaline batteries included

7GB
Cross line laser PKLL 7 D3
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product. The
instructions for use are part of the product. They contain
important information concerning safety, use and disposal. Before
using the product, please familiarise yourself with all of the safety
information and instructions for use. Only use the product as de-
scribed and for the specified applications. If you pass the product
on to anyone else, please ensure that you also pass on all the
documentation with it.
Intended use
The product is suitable for the the determination and verification of
horizontal and vertical lines. The product is exclusively suitable for
use in enclosed operating sites. Any other use or modification of the
product shall be considered improper use and may result in serious
accidents. The manufacturer assumes no liability for damages due
to improper use. Not intended for commercial purposes.

8 GB
Description of parts
1Ring-button
2LED indicator (red: levelling off, green levelling on)
3Battery compartment
3a Battery compartment cover
4LOCK Switch
5-thread (underneath)
6Laser beam opening
7-screw (to align with -thread of cross line laser)
8Retaining screw
9Clamp Jaw
10 Clamping Nut
Scope of delivery
1 Cross line laser
1 Clamp
2 1.5V-Batteries, Type AAA
1 Set of instructions for use
Technical data
Operating voltage: 3V
Working area1): 7m
Levelling accuracy: +/- 0.8mm/m
Typical self-levelling range: ± 4°

9GB
Typical levelling time: approx. 6 seconds
Operating temperature: +5°C–35°C
Max. relative humidity: ≤ 90%
Laser class: 2
Wave length (λ): 635nm
Maximum performance P max: 1mW
Clamp mount:
Batteries: 2 x 1.5V-Batteries, Type AAA
Product weight: 240g (with batteries)
Clamp weight: 160g
Product dimensions: approx. 67 x 66 x 84mm
Max. Clamp jaw opening: 60mm
Degree of protection: IP20
Max. operation altitude: 2000m
1) The operating range can be reduced by unfavourable environ-
mental conditions (e.g. direct sunlight).
Safety notes
DANGER OF SUFFOCATION! Packaging materials (e.g.
films or polystyrene) can not be used as toys. Always keep
children away from the packaging material. The packaging
material is not a toy.
Do not work with the measuring tool in an environment where
there is a danger of explosion, where there are flammable liq-
uids, gasses or dusts. Sparks can be created in the product,
which could ignite dust or fumes.

10 GB
Test on known sources before use, to make sure that equipment
is functioning correctly.
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may
be impaired.
The manual must be consulted in all cases where symbol
is marked.
This product may be used by children from the age of 8, by
persons of reduced physical, sensory or mental abilities or a
lack of experience and/or knowledge if they are supervised or
instructed with regard to the safe use of the product and have
understood the risks resulting from use. Do not allow children
to play with the product. Cleaning and user maintenance may
not be carried out by children unless they are supervised.
Do not leave the switched-on product unattended and switch
the product off after use. Others could be blinded by the laser
beam. Risk of eye injury.
Do not expose the product to moisture or direct sunlight.
Do not expose the product to extremely high temperatures or
temperature fluctuations. For example, do not leave it in your
car for a long time. In the case of large temperature fluctuations,
let the product acclimatise before using it. In extreme tempera-
tures or temperature fluctuations, the precision of the product
can be impaired.
Avoid strong impacts against the measuring tool. Damage to
the measuring tool can impair its accuracy. After a strong impact
compare the laser line with a known vertical or horizontal ref-
erence line to check it.

11GB
Turn the measuring tool off when you transport it. When it is
switched off the pendulum unit is locked, which otherwise can
be damaged in strong movements.
Do not bring the measuring tool near to heart pacemakers.
The magnet inside the measuring tool creates a field that can
impair the function of pacemakers.
Keep the measuring tool away from magnetic data carriers and
devices that are sensitive to magnetic influences. The effects of
the magnet can lead to irreversible data losses.
Protect yourself from laser
radiation!
LASER
2
Pmax < 1 mW
λ = 635 nm
EN 60825-1:2014
Do not look directly into the laser beam or the laser beam
opening 6.
Viewing the laser beam with optical instruments
(e.g. loupe, magnifying glass etc.) is associated with risk injury
to the eyes.
CAUTION! If operating or adjusting devices than other than
those described here are used or other procedures are carried
out, this can lead to dangerous radiation effects.

12 GB
Never direct the laser beam at people, animals or reflective
surfaces. Even looking briefly into the laser beam can cause
damage to the eyes.
The laser assembly inside the equipment can be examined,
repaired or replaced by the manufacturer only. If functional or
other defects occur, please contact the service department
listed either by telephone or by e-mail.
The radiation pattern emitted from this equipment during the
performance of operation and maintenance procedure:
• Wavelength: 635nm
• Maximum power or energy output: <1mW
Safety instructions for batteries/
rechargeable batteries
DANGER TO LIFE! Keep batteries /rechargeable batteries
out of reach of children. If accidentally swallowed seek imme-
diate medical attention.
Swallowing may lead to burns, perforation of soft tissue, and
death. Severe burns can occur within 2 hours of ingestion.
DANGER OF EXPLOSION! Never recharge
non-rechargeable batteries. Do not short-circuit bat-
teries/rechargeable batteries and/or open them.
Overheating, fire or bursting can be the result.
Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable bat-
teries.

13GB
Risk of leakage of batteries/rechargeable batteries
Avoid extreme environmental conditions and temperatures,
which could affect batteries/ rechargeable batteries, e.g. radi-
ators/direct sunlight.
If batteries/rechargeable batteries have leaked, avoid contact
with skin, eyes and mucous membranes with the chemicals!
Flush immediately the affected areas with fresh water and
seek medical attention!
WEAR PROTECTIVE GLOVES! Leaked or dam-
aged batteries/rechargeable batteries can cause
burns on contact with the skin. Wear suitable pro-
tective gloves at all times if such an event occurs.
In the event of a leakage of batteries/rechargeable batteries,
immediately remove them from the product to prevent damage.
Only use the same type of batteries/ rechargeable batteries.
Do not mix used and new batteries/rechargeable batteries.
Remove batteries/rechargeable batteries if the product will
not be used for a longer period.
Risk of damage of the product
Only use the specified type of battery/rechargeable battery!
Insert batteries/rechargeable batteries according to polarity
marks (+) and (-) on the battery/rechargeable battery and
the product.
Use a dry lint-free cloth or cotton swab to clean the contacts
on the battery/ rechargeable battery and in the battery com-
partment before inserting!
Remove exhausted batteries/ rechargeable batteries from the
product immediately.

14 GB
Initial use
Check that the delivery is complete and that there is no visible
damage.
Remove the packaging material from the product.
Inserting/Changing batteries
Open the battery compartment cover 3a as shown in the
fig A1.
Insert batteries into the battery compartment 3as shown in
the fig A2.
Make sure that the batteries are inserted in a correct polarity
as shown in the fig A2 before closing back the battery com-
partment cover 3a .
Note: when the battery is low, the LED indicator 2blinks.
Always replace all batteries at the same time. Only use batteries
from the same manufacturer and with the same capacity.
Remove the batteries from the product if it will not be in use
for a prolonged period of time. In long periods of storage the
batteries can corrode and can run themselves down.
Switching on/off
To switch the product on, push the LOCK switch 4to the
position while the product is on a flat and horizontal surface
(< 4°). Immediately after being switched on, the product
releases two laser lines from the laser beam opening 6.

15GB
To switch the product off, push the LOCK switch 4to the
position . When switched off, the pendulum unit is locked.
Use automatic levelling system
To work with automatic levelling, place the product on a level,
firm surface, or fasten it with the -thread 5to -screw 7
of supplied clamp.
When it is switched on, the automatic levelling system automat-
ically corrects irregularities of ±4° within the self levelling area.
The levelling is concluded when the laser lines stop moving and
the LED indicator 2goes green.
If automatic levelling is not possible, e.g. because the base of
the measuring tool deviates by more than 4° from the horizon-
tal or because the product is being freely hand-held, the LED
indicator 2will go red and the horizontal and vertical laser
lines will be switched off.
Note 1: operation without automatic levelling will always be
indicated via the red LED indicator 2.
Note 2: if the product is agitated or its position is changed
during operation, the product will automatically re-level. After
re-levelling check the positions of the horizontal and vertical
laser lines against reference points to avoid errors.
Note 3: The top Ring-button 1has no function at this mode.

16 GB
Working without the automatic
levelling system
Put the LOCK switch 4into the position .
Press and hold the ring-button 1on the top of the product until
the product release two laser lines from the laser beam opening
6that are not levelled. Operation without automatic levelling
will always be indicated via the red LED indicator 2.
Press and hold the ring-button 1on top again until the product
switch off two laser lines from the laser beam opening at this mode.
Practical guidance
Always use only the middle of the laser line for markings. The
width of the line depends on the distance.
Working with the clamp
The clamp provided can be used to attach the device to various
objects.
1. Release the clamping nut 10 by rotating the clamping nut
anti-clockwise.
2. Position the clamping jaws 9to the desired location.
3. Rotate the clamping nut 10 clockwise until fastened.
4. Place -thread 5of cross line laser with the -screw 7of
the clamp and tighten with hand. Do not use excessive force as
this may damage the device.

17GB
5. Align the cross line laser. To do so, release the retaining screw
8by rotating anti-clockwise and move the cross line laser into
the desired position.
6. Fix the position by fastening the retaining screw 8.
Working with the tripod
You can place the cross line laser in a stable position and adjust
the height using a tripod (not provided in scope of delivery).
Place the cross line laser with -thread 5onto the -screw of
your tripod and tighten by hand. Do not use excessive force as this
may damage the device.
Maintenance and cleaning
The product requires no maintenance.
ATTENTION! Never submerge the product in water or other
liquids. Do not allow water to enter into the product during
cleaning.
Keep the product clean to ensure good, secure work.
Use a dry cloth to clean the outside.
Clean the laser beam opening 6with a soft air jet. In cases
of heavy contamination, remove the dirt with a slightly damp
Q-tip. Do not exert any strong pressure!
For repair purposes the product may only be
opened by a professional.

18 GB
Have the measuring tool repaired by qualified professionals
and only with original replacement parts. This ensures that the
safety of the measuring tool is maintained.
Storage
If you will not be using the product for a prolonged period of
time, remove the batteries and store it in a clean, dry place that
is not exposed to direct sunlight.
Disposal
The packaging is made entirely of recyclable materials, which you
may dispose of at local recycling facilities.
b
a
Observe the marking of the packaging materials for waste
separation, which are marked with abbreviations (a)
and numbers (b) with following meaning: 1–7: plastics/
20–22: paper and fibreboard/80–98: composite
materials.
The product and packaging materials are recyclable,
dispose of it separately for better waste treatment. The
Triman logo is valid in France only.
Contact your local refuse disposal authority for more
details of how to dispose of your worn-out product.

19GB
To help protect the environment, please dispose of the
product properly when it has reached the end of its use-
ful life and not in the household waste. Information on
collection points and their opening hours can be obtained
from your local authority.
Faulty or used batteries/rechargeable batteries must be recycled
in accordance with Directive 2006/66/EC and its amendments.
Please return the batteries/rechargeable batteries and/ or the
product to the available collection points.
Environmental damage through incorrect
disposal of the batteries/ rechargeable
batteries!
Batteries/rechargeable batteries may not be disposed of with the
usual domestic waste. They may contain toxic heavy metals and
are subject to hazardous waste treatment rules and regulations.
The chemical symbols for heavy metals are as follows: Cd = cad-
mium, Hg = mercury, Pb = lead. That is why you should dispose of
used batteries/rechargeable batteries at a local collection point.
Warranty
The product has been manufactured to strict quality guidelines and
meticulously examined before delivery. In the event of product de-
fects you have legal rights against the retailer of this product. Your
legal rights are not limited in any way by our warranty detailed
below.

20 GB
The warranty for this product is 3 years from the date of purchase.
The warranty period begins on the date of purchase. Please keep
the original sales receipt in a safe location. This document is required
as your proof of purchase.
Should this product show any fault in materials or manufacture
within 3 years from the date of purchase, we will repair or replace
it – at our choice – free of charge to you. This warranty becomes
void if the product has been damaged, or used or maintained im-
properly.
The warranty applies to defects in material or manufacture. This
warranty does not cover product parts subject to normal wear, thus
possibly considered consumables (e.g. batteries) or for damage to
fragile parts, e.g. switches, rechargeable batteries or glass parts.
Warranty claim procedure
To ensure quick processing of your case, please observe the fol-
lowing instructions:
Please have the till receipt and the item number (e.g. IAN
123456_7890) available as proof of purchase. You will find the
item number on the rating plate, an engraving on the front page of
the instructions for use (bottom left), or as a sticker on the rear or
bottom of the product. If functional or other defects occur, please
contact the service department listed either by telephone or by
e-mail.
