Parkside 20 M PLEM 20 A4 User manual

LASER DISTANCE MEASURER
20 M PLEM 20 A4
LASER-ENTFERNUNGS-
MESSER 20 M PLEM 20 A4
Bedienungs- und Sicherheitshinweise
LASER DISTANCE MEASURER
20 M PLEM 20 A4
Operation and safety notes
LASERAFSTANDSMÅLER
20 M PLEM 20 A4
Brugs- og sikkerhedsanvisninger
L
ASERAFSTANDSMETER 20 M
PLEM 20 A4
Bedienings- en veiligheidsinstructies
TÉLÉMÈTRE LASER 20 M
PLEM 20 A4
I nstructions d‘utilisation et consignes de sécurité
IAN 338157_2001

GB/IE/NI Operation and safety notes Page 5
DK Brugs- og sikkerhedsanvisninger Side 20
FR/BE Instructions d‘utilisation et
consignes de sécurité Page 34
NL/BE Bedienings- en veiligheidsinstructies Pagina 50
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 65

Off: Press 5 Sec
B
12a
9
12
2
12b 8
11
A1
4
3
6b
AAA
1
2
AAA
1
2
6a
5
7
10

5GB/IE/NI
List of pictograms used................................Page 6
Introduction...........................................................Page 6
Intended use................................................................Page 7
Parts description..........................................................Page 7
Scope of delivery........................................................Page 8
Technical data.............................................................Page 8
General safety instructions......................Page 9
Safety instructions for batteries/
rechargeable batteries................................................Page 10
Before using..........................................................Page 12
Inserting/replacing the batteries...............................Page 12
Start-up .....................................................................Page 13
Switching on/off ........................................................Page 13
Selecting the unit of length .........................................Page 13
Measuring lengths ......................................................Page 14
Changing measurement mode..............Page 14
Continuous measurement mode.................................Page 14
Single measurement mode.........................................Page 14
Error, faults & troubleshooting.............Page 15
Maintenance and cleaning.......................Page 15
Storage .....................................................................Page 16
Disposal....................................................................Page 16
Warranty and service...................................Page 17
Warranty .....................................................................Page 17
Warranty claim procedure.........................................Page 18
Service .........................................................................Page 18

6 GB/IE/NI
List of pictograms used
Read the instruction manual.
Danger of explosion!
Wear protective gloves!
Attention!
Protect yourself from laser radiation!
Do not stare into the laser beam!
Direct current/ voltage
Battery included
Laser distance measurer 20m
Introduction
We congratulate you on the purchase of your new product. You
have chosen a high quality product. The instructions for use are
part of the product. They contain important information concern-
ing safety, use and disposal. Before using the product, please
familiarise yourself with all of the safety information and instruc-
tions for use. Only use the product as described and for the

7GB/IE/NI
specif ied applications. If you pass the product on to anyone else,
pl
ease ensure that you also pass on all the documentation with
it.
Intended use
This product is suitable for measuring distances, lengths and
heights in indoor spaces. Any other use or product modification
shall be considered improper use and hold considerable safety
hazards. The manufacturer assumes no liability for damages
due to improper use. Not intended for commercial use.
Parts description
1Receiver lens
2Laser beam output opening
3Display
4MEAS button (Switch on and off, single measurement,
continuous measurement)
5Reference / Unit button (changing the measurement
reference point, changing unit)
6a Battery compartment cover
6b Battery compartment
Display
7Laser on
8Battery charge level display
9First (previous) measured value
10 Length unit
11 Second (latest) measured value
12 Reference plane
12a The measurement is taken from the top side of the product

8 GB/IE/NI
12b The measurement is taken from the bottom side of the
product
Note: First (previous) measured value will move to the top row
when the second (latest) measurement is successfully started.
Scope of delivery
1 Laser distance measurer
2 1.5V-batteries LR03 (AAA)
1 Instructions for use
Technical data
Measurement range: 0.075–20m* (reference point
top side)
0.175–20m* (reference point
bottom side)
Measuring accuracy (typical): ± 2.0mm**
Smallest display unit: 1mm
Operating temperature: 0°–40°C (For indoor use)
Relative humidity max.: ≤ 75%
Laser category: 2
Wavelength of the laser (λ): 620–690nm
Maximum power P max: <1mW
Operating voltage: 3V (Direct current)
Batteries: 2 x 1.5V LR03 (AAA)
Weight: 52g (without batteries)
Dimensions: 10 x 3.8 x 2.45cm
Degree of protection: IP20

9GB/IE/NI
*) The range improves the better the laser light is returned from
the surface of the target (dispersing, not refl ecting) and the
brighter the laser is compared to the ambient light (interior
rooms, twilight).
**) In unfavourable conditions such as strong sunlight or poorly
refl ective surfaces, the maximum deviation is ± 8mm at 20m.
In favourable conditions, a deviation influence of ± 0.1mm/m
must be taken into account.
General safety instructions
CHOKING HAZARD! Packaging material (e. g. foils or
polystyrol) are not to be toyed with. Keep children away from
packaging material. The packaging material is not a toy.
Do not use the product in locations where there is a risk of
fi re or explosion, e.g. in the vicinity of inflammable liquids
or gases.
This product can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the haz-
ards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Do not leave the product unattended when switched on,
and switch off the product directly after use. Other people
could be blinded by the laser beam.
Protect the product from wetness or direct sunlight.
Do not expose the product to any extremes of temperature
or temperature fluctuations. For example, do not leave it in a
car for extended periods. After exposure to large temperatu re
fluctuations, allow the product to acclimatise before using

10 GB/IE/NI
it again. The precision of the product can be adversely aff
ected by extreme temperatures or temperature fluctuations.
Avoid hefty knocks or dropping the measuring tool.
Protect yourself from laser radiation!
EN 60825-1:2014
CAUTION LASER RADIATION! DO NOT STARE
INTO BEAM! CLASS 2 LASER PRODUCT!
Never look directly into the laser beam or into the opening
from which it emerges.
Looking at a laser beam through optical instruments (e.g.
magnifying glasses etc.) can cause eye injuries.
ATTENTION! If operating and adjustment equipment is used
or procedures other than those specified here are carried
out, this may result in hazardous radiation exposure.
Never aim the laser beam at reflective surfaces, people or
animals. Even brief visual contact with a laser beam can
result in eye injuries.
Safety instructions for batteries/
rechargeable batteries
DANGER TO LIFE! Keep batteries/rechargeable batter-
ies out of reach of children. If accidentally swallowed seek
immediate medical attention.

11GB/IE/NI
Swallowing may lead to burns, perforation of soft tissue, and
death. Severe burns can occur within 2 hours of ingestion.
DANGER OF EXPLOSION! Never recharge
non-rechargeable batteries. Do not short-circuit
batteries/rechargeable batteries and/ or open
them. Overheating, fire or bursting can be the result.
Never throw batteries/rechargeable batteries into fire or
water.
Do not exert mechanical loads to batteries/ rechargeable
batteries.
Risk of leakage of batteries/rechargeable batteries
Avoid extreme environmental conditions and temperatures,
which could affect batteries/rechargeable batteries, e.g.
radiators/ direct sunlight.
If batteries/rechargeable batteries have leaked, avoid
contact with skin, eyes and mucous membranes with the
chemicals! Flush immediately the affected areas with fresh
water and seek medical attention!
WEAR PROTECTIVE GLOVES! Leaked or
damaged batteries/rechargeable batteries can
cause burns on contact with the skin. Wear suit-
able protective gloves at all times if such an event occurs.
In the event of a leakage of batteries/rechargeable batteries,
immediately remove them from the product to prevent damage.
Only use the same type of batteries/rechargeable batteries.
Do not mix used and new batteries/rechargeable batteries.
Remove batteries/rechargeable batteries if the product
will not be used for a longer period.
Risk of damage of the product
Only use the specified type of battery/rechargeable battery!

12 GB/IE/NI
Insert batteries/rechargeable batteries according to polar-
ity marks (+) and (-) on the battery / rechargeable battery
and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts
on the battery/rechargeable battery and in the battery
compartment before inserting!
Remove exhausted batteries/ rechargeable batteries from
the product immediately.
Before using
Check the consignment for completeness and for signs of
visible damage.
Remove all packaging material from the product.
Inserting/replacing the batteries
When the low battery icon appears in the display 3, you
can still make measurements. As soon as the battery icon turns
empty , however, you must replace the batteries. Measure-
ments are no longer possible.
Open the battery compartment cover 6a by gently pushing
down the battery compartment cover latch.
Remove the used batteries from the battery compartment 6b ,
if necessary.
Insert the (new) batteries. Ensure the correct polarity as
shown on the diagram inside the battery compartment 6b .
Replace the battery compartment cover 6a as shown
(fig. A).

13GB/IE/NI
Start-up
Switching on/off
To switch the product on, press the MEAS button 4.
When the product is switched on, the laser beam is activate d.
To switch the product off, press and hold the MEAS button
4for approx. 5 seconds until the “OFF“ is shown on
display 3. If no button is pressed for about 3 minutes, the
product turns off automatically to save the batteries.
To switch measuring reference point: Press the reference /
unit button 5to change measurement base from the top
side of the product to its bottom side or vice versa.
Selecting the unit of length
1. Press and hold the REF/UNIT button 5for more than
3 seconds.
2. The unit will change on the display 3.
3. Repeat the step 1 until the desired unit appears on the
display 3.
Note: Following units of length are available:
m meter
feet/inches
in inch
ft foot / feet

14 GB/IE/NI
Measuring lengths
Briefly press the MEAS button 4again to activate the laser
beam. Once the laser is switched on, this is indicated on
the top left corner of the display 3by the icon 7.
Note: If laser beam is already activated, the above men-
tioned step can be skipped.
Now aim the laser at the target point. Briefly press the
MEAS button 4again. If the measurement is successful
the measured value will be shown on the bottom line of the
display 3and the laser beam will be turned off.
If needed to measure another distance, repeat above steps.
Newly measured value will be shown on the bottom line of
the display 3and the previous measured value will be
shown in the middle of the display 3. Now, the laser
beam will be turned off.
Changing measurement mode
Continuous measurement mode
Under single measurement mode, press and hold the
MEAS button 4for 3 seconds to enter continuous meas-
urement mode.
Laser icon flashes in continuous measurement mode
Single measurement mode
Under continuous measurement mode, press and hold the
MEAS button 4for 3 seconds to enter single measurement
mode.
Laser icon stays on in single measurement mode.

15GB/IE/NI
Error, faults & troubleshooting
Faults Cause Solution
----- Calculation error P
ay attention to the corre ct
operating measuring
range.
301 Operating temperature
too low or too high P
ay attention to the corre ct
operating temperature
range (0°–40 °C).
401 Hardware failure If the icon appears despite
repeated switching on
and off, take the product
to a specialist workshop
Maintenance and cleaning
The product is maintenance-free.
CAUTION! Never submerse the product in water or other
liquids. Do not allow any moisture to penetrate into the
product during cleaning.
Clean the laser beam output opening 2and the receiver
lens 1with a gentle air stream. In the case of more serious
contamination, remove the dirt with a damp cotton swab.
Do not exert any strong pressure!
Never use petrol, solvents or cleaning agents that attack
plastic.
The product should only be opened by
a qualified person for repairs.
To clean the casing, use a soft dry cloth.
Keep the product clean to ensure fault-free operation.

16 GB/IE/NI
Storage
If you decide not to use the product for a long period,
remove the batteries and store it in a clean, dry place
away from direct sunlight.
Disposal
The packaging is made entirely of recyclable materials, which
you may dispose of at local recycling facilities.
b
a
Observe the marking of the packaging materials for
waste separation, which are marked with abbrevia-
tions (a) and numbers (b) with following meaning:
1–7: plastics/20–22: paper and fibreboard /
80–98: composite materials.
The product and packaging materials are recyclable,
dispose of it separately for better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
product.
To help protect the environment, please dispose of
the product properly when it has reached the end of
its useful life and not in the household waste. Infor-
mation on collection points and their opening hours
can be obtained from your local authority.
Faulty or used batteries / rechargeable batteries must be
recycled in accordance with Directive 2006/66/EC and its

17GB/IE/NI
amendments. Please return the batteries/rechargeable batteries
and/or the product to the available collection points.
Environmental damage through
incorrect disposal of the batteries/
rechargeable batteries!
Batteries/rechargeable batteries may not be disposed of with
the usual domestic waste. They may contain toxic heavy metals
and are subject to hazardous waste treatment rules and regula-
tions. The chemical symbols for heavy metals are as follows:
Cd = cadmium, Hg = mercury, Pb = lead. That is why you should
dispose of used batteries/rechargeable batteries at a local col-
lection point.
Warranty and service
Warranty
The product has been manufactured to strict quality guidelines
a
nd meticulously examined before delivery. In the event of pr oduct
defects you have legal rights against the retailer of this product.
Your legal rights are not limited in any way by our warranty
detailed below.
The warranty for this product is 3 years from the d ate of purchase.
Should this product show any fault in materials or manufacture
within 3 years from the date of purchase, we will repair or re-
place it – at our choice – free of charge to you.
The warranty period begins on the date of purchase. Please
keep the original sales receipt in a safe location. This document
is required as your proof of purc
hase. This warranty becomes

18 GB/IE/NI
void if the product has been damaged, or used or maintained
improperly.
The warranty applies to defects in material or manufacture. This
warranty does not cover product parts subject to normal wear,
thus possibly considered consumables (e.g. batteries) or for
damage to fragile parts, e.g. switches, rechargeable batteries
or glass parts.
Warranty claim procedure
To ensure quick processing of your case, please observe the
following instructions:
Please have the till receipt and the item number (e.g.
IAN 123456_7890) available as proof of purchase.
You will find the item number on the rating plate, an engraving
on the front page of the instructions for use (bottom left), or as
a sticker on the rear or bottom of the product.
If functional or other defects occur, please contact the service
department listed either by telephone or by e-mail.
You can return a defective product to us free of charge to the
service address that will be provided to you. Ensure that you
enclose the proof of purchase (till receipt) and information
about what the defect is and when it occurred.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]

19GB/IE/NI
Service Ireland
Tel.: [phone]
Service Northern Ireland
Tel.: [phone]
E-Mail: [email protected]

20 DK
De anvendte piktogrammers
legende..................................................................... Side 21
Indledning .............................................................. Side 21
Formålsbestemt anvendelse ....................................... Side 22
Beskrivelse af de enkelte dele.................................... Side 22
Leverede dele.............................................................. Side 23
Tekniske data............................................................... Side 23
Generelle sikkerhedshenvisninger... Side 24
Sikkerhedshenvisninger for batterier/akkuer ........... Side 25
Inden ibrugtagningen .................................. Side 27
Isættelse/udskiftning af batterier............................... Side 27
Ibrugtagning........................................................ Side 27
Tænd-/slukning .......................................................... Side 27
Vælg længdeenhed.................................................... Side 28
Måling af længder...................................................... Side 28
Ændring af målingstilstand ..................... Side 29
Konstant målingstilstand ............................................. Side 29
Enkelt målingstilstand.................................................. Side 29
Fejl, forstyrrelser og fejlfinding............ Side 29
Vedligeholdelse og rengøring.............. Side 30
Opbevaring........................................................... Side 30
Bortskaffelse........................................................ Side 30
Garanti og service........................................... Side 32
Garanti ........................................................................ Side 32
Afvikling af garantisager ............................................ Side 32
Service ......................................................................... Side 33
