Parkside 89587 User manual

POWER ENGRAVING TOOL PGG 15 A1
POWER ENGRAVING TOOL
Operation and Safety Notes
Translation of original operation manual
URZĄDZENIE DO GRAWEROWANIA
Wskazówki dotyczące obsługi i bezpieczeństwa
Tłumaczenie oryginalnej instrukcji obsługi
GRAVÍROZÓ KÉSZÜLÉK
Kezelési és biztonsági utalások
Az originál használati utasítás fordítása
GRAVIERGERÄT
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
APARAT ZA GRAVIRANJE
Navodila za upravljanje in varnostna opozorila
Prevod originalnega navodila za uporabo
GRAVÍROVAČKA
Pokyny pre obsluhu a bezpečnostné pokyny
Preklad originálneho návodu na obsluhu
IAN 89587

GB Operation and Safety Notes Page 5
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 19
HU Kezelési és biztonsági utalások Oldal 35
SI Navodila za upravljanje in varnostna opozorila Stran 51
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 67
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 81
Before reading, unfold the page containing the illustrations and familiarise yourself with all
functions of the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z
wszystkimi funkcjami urządzenia.
Olvasás előtt kattintson az ábrát tartalmazó oldalra és végezetül ismerje meg a készülék
mindegyik funkcióját.
Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

B
1 2 3
45
6
A
7

5GB
Table of contents
Introduction
Proper use................................................................................ Page 6
Features and equipment......................................................... Page 6
Included items ......................................................................... Page 7
Technical details...................................................................... Page 7
General safety advice for electrical
power tools....................................................................... Page 8
1. Workplace safety............................................................... Page 9
2. Electrical safety................................................................... Page 9
3. Personal safety.................................................................... Page 10
4. Careful handling and use of electrical power tools......... Page 11
5. Service................................................................................. Page 12
Operation
Switching on/ off .................................................................... Page 13
Setting the cutting depth......................................................... Page 13
Changing the engraving point ............................................... Page 14
Advice on use.......................................................................... Page 14
Cleaning ............................................................................... Page 15
Service................................................................................... Page 15
Warranty............................................................................. Page 15
Disposal................................................................................ Page 17
Manufacturer’s Declaration of
Conformity/Manufacturer................................... Page 17

6 GB
Introduction Introduction
Power engraving tool PGG 15 A1
Introduction
We congratulate you on the purchase of your new device. You have
chosen a high quality product. The instructions for use are part of the
product. They contain important information concerning safety, use
and disposal. Before using the product, please familiarise yourself with
all of the safety information and instructions for use. Only use the unit
as described and for the specified applications. If you pass the product
on to anyone else, please ensure that you also pass on all the docu-
mentation with it.
Proper use
This product is intended for engraving or decorating materials such
as metal, plastic, glass, ceramic, wood, leather and stone. Any other
use or modification to the drill/grinder shall be considered as improper
use and could give rise to considerable dangers. The manufacturer will
not accept liability for loss or damage arising from improper use. Not
intended for commercial use.
Features and equipment
1ON/ OFF switch
2Stroke rate rotary controller
3Hanging eye
4Mains lead

7GB
Introduction Introduction
5Engraving point
6Engraving point holder
7Engraving stencils
Included items
1 Power engraving tool PGG 15 A1
2 Engraving stencils
1 Operating instructions
Technical details
Rated voltage: 230V∼ 50Hz
Mode of operation: intermittent operation: S3 20%
Note: A duty cycle (in %) defines explicitly the maximum continuous
duration of use and the subsequent rest period. In this case the tool
requires a cooling phase of eight minutes after an operating period of
two minutes, for example.
Rated current: 0.15A
Stroke rate: 6000min-1
Noise and vibration data:
Measured values for noise are determined in accordance with
EN 60745. The A-weighted noise level of the electrical power tool
are typically:
Sound pressure level: 74.4dB(A)
Sound power level: 85.4dB(A)
Uncertainty K: 3dB

8 GB
General safety advice for electrical power toolsIntroduction/General safety advice for electrical power tools
Wear ear protection!
Evaluated acceleration, typical:
Hand/ arm vibration: 1.582m/s2
Uncertainty K = 1.5m/ s2
The vibration level specified in these instructions was
measured in accordance with an EN 60745 standardised measurement
process and can be used to compare equipment. The vibration emission
value specified can also serve as a preliminary assessment of the ex-
posure.
The vibration level will change according to the application of the elec-
trical tool an in some cases may exceed the value specified in these in-
structions. Regularly using the electric tool in such a way may make it
easy to underestimate the vibration.
Note: If you wish to make an accurate assessment of the vibration
loads experienced during a particular period of working, you should
also take into account the intervening periods of time when the device
is switched off or is running but is not actually in use. This can result in
a much lower vibration load over the whole of the period of working.
General safety advice for
electrical power tools
Read all the safety advice and
instructions! Failure to observe the safety advice and in-
structions may result in electric shock, fire and/or serious
injury.

9GB
General safety advice for electrical power toolsIntroduction/General safety advice for electrical power tools
Keep all the safety advice and instructions in a safe place
for future reference!
The term “electrical tool” used in the safety advice refers to electrical
tools powered by mains electricity (by means of a mains lead) and elec-
trical tools powered by rechargeable batteries (without a mains lead).
1. Workplace safety
a) Keep your working area clean and well lit. Untidy or
poorly lit working areas can lead to accidents.
b) Do not work with the device in potentially explosive
environments in which there are inflammable liquids,
gases or dusts. Electrical power tools create sparks, which can
ignite dusts or fumes.
c) Keep children and other people away while you are
operating the electrical tool. Distractions can cause you to
lose control of the device.
2. Electrical safety
a) T he mains plug on the device must match the mains
socket. The plug must not be modified in any way.
Do not use an adapter plug with devices fitted with
a protective earth. Unmodified plugs and matching sockets
reduce the risk of electric shock.
b) Avoid touching earthed surfaces such as pipes, radia-
tors, ovens and refrigerators with any part of your
body. There is an increased risk of electric shock if your body is
earthed
.

10 GB
General safety advice for electrical power toolsGeneral safety advice for electrical power tools
c) Keep the device away from rain or moisture. Water en-
tering an electrical device increases the risk of electric shock.
d) Do not use the mains lead for any purpose for which
it was not intended, e.g. to carry the device, to hang
up the device or to pull the mains plug out of the mains
socket. Keep the mains lead away from heat, oil, sharp
edges or moving parts of the device. Damaged or tangled
mains leads increase the risk of electric shock.
e) When working outdoors with an electrical power tool
always use extension cables that are also approved
for use outdoors. The use of an extension cable suitable for
outdoor use reduces the risk of electric shock.
f) Use a residual current device (RCD) for protection if
operating the electrical power tool in a moist environ-
ment is unavoidable. The use of an RCD reduces the risk of
electric shock.
3. Personal safety
a) Remain alert at all times, watch what you are doing
and always proceed with caution. Do not use the de-
vice if you are tired or under the influence of
drugs,
alcohol or medication. One mo
ment of carelessness when using
the device can lead to serious injury.
b) Wear personal protective equipment and always wear
safety glasses. The wearing of personal protective equipment
such as dust masks, non-slip safety shoes, safety helmets or ear
protectors, appropriate to the type of electrical power tool used
and work undertaken, reduces the risk of injury.
c) Avoid unintentional operation of the device. Check
that the electrical power tool is switched off before y ou

11GB
General safety advice for electrical power toolsGeneral safety advice for electrical power tools
connect it to the mains, pick it up or carry it. Accidents
can happen if you carry the device with your finger on the ON/
OFF switch or with the device switched on.
d) Remove any setting tools or spanners before you
switch the device on. A tool or spanner left attached to a
rotating part of a device can lead to injury.
e) Avoid placing your body in an unnatural position.
Keep proper footing and balance at all times. By doing
this you will be in a better position to control the device in unfore-
seen circumstances.
f) Wear suitable clothing. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves clear of
moving parts. Loose clothing, jewellery or long hair can become
trapped in moving parts.
g) If vacuum dust extraction and collection devices are fit ted
do not forget to check that they are properly con nected
and correctly used. The use of these devices reduces the haz-
ard presented by dust.
4. Careful handling and use of
electrical power tools
a) Do not overload the device. Always use an electrical
power tool that is intended for the task you are un-
dertaking. By using the right electrical power tool for the job
you will work more safely and achieve a better result.
b) Do not use an electrical power tool if its switch is de-
fective. An electrical power tool that can no longer be switched
on and off is dangerous and must be repaired.
c) Pull the mains plug from the socket before you make
any adjustments to the device, change accessories or

12 GB
OperationGeneral safety advice for electrical power tools
when the device is put away. This precaution is intended to
prevent you from unintentionally starting the device.
d) When not in use always ensure that electrical power
tools are kept out of reach of children. Do not let anyone
use the device if he or she is not familiar with it or has
not read the instructions and advice. Electrical power tools
are dangerous when they are used by inexperienced people.
e) Look after the device carefully. Check that moving
parts are working properly and move freely. Check
for any parts that are broken or damaged enough to
detrimentally affect the functioning of the device.
Have damaged parts repaired before you use the
device. Many accidents have their origins in poorly maintained
electrical power tools.
f) Keep cutting tools clean and sharp. Carefully maintained
cutting tools with sharp cutting edges are less likely to jam and
are easier to control.
g) Use the electrical power tool, accessories, inserted
tools etc. in accordance with these instructions and ad-
vice, and the stipulations drawn up for this particular
type of device. In doing this, take into account the
working conditions and the task in hand. The use of
electrical power tools for purposes other than those intended can
lead to dangerous situations.
5. Service
a) Have your device repaired at the service centre or by
qualified specialist personnel using original manufac-
turer parts only. This will ensure that your device remains safe
to use.

13GB
OperationGeneral safety advice for electrical power tools
Operation
Never use the device for a purpose for which it was not intended or
with non-original parts/accessories. The use of tools or accessories
other than those recommended in the operating instructions could lead
to you suffering an injury.
Switching on/off
Insert the mains plug into a mains socket.
Switching on:
Press the ON/ OFF switch 1.
Switching off:
Release the ON/ OFF switch 1.
Setting the cutting depth
The cutting depth of the engraver is set using the stroke rate rotary control-
ler 2. A low setting is usually sufficient for most common applications.
Turn the stroke rate rotary controller 2towards the +sign to in-
crease the cutting depth.
Turn the stroke rate rotary controller 2towards the -depth.
Note: Take care when increasing the cutting depth not to turn the stroke
rate rotary controller 2too far towards the +sign. Otherwise the switch
could screw off the device.

14 GB
Operation/Cleaning/ Service/WarrantyOperation
Changing the engraving point
RISK OF INJURY! Switch the device off before
performing any tasks on the device and pull the mains plug out of the
mains socket.
Replace the engraving point 5as soon as it becomes too worn
and no longer provides the desired engraving performance. Turn
the engraving point holder 6anticlockwise until the engraving
point 5is released.
Remove the spring and the plain washer.
Push the plain washer and spring on to a new engraving point 5.
Then insert this and turn the engraving point holder 6clockwise
to lock the engraving point in position.
Ensure that the engraving point 5is properly fixed in position.
Advice on use
You can use the mini-engraver to produce creative, individual engravings.
For example, you can use it to place identifying marks on your valuables.
You can engrave numbers and letters into metal, glass, wood, plastic,
ceramic, stone and leather. This is done with the help of the supplied
engraving stencils 7, see Figs. A and B.
Hold the device at an angle, as you would a pencil.
Your arm should rest on the table.
Using very light pressure, guide the engraving point 5over the
workpiece. Find the ideal speed of movement by trial and error on
a piece of waste material.

15GB
Operation/Cleaning/ Service/WarrantyOperation
Note: The engraving point 5supplied with the product is made
from tungsten steel. Therefore it is not suitable for engraving electronic
media such as CDs, DVDs etc. It could damage these materials and
render them illegible.
Cleaning
Before performing any cleaning or maintenance
work, always remove the mains plug from the socket.
Clean all the dirt off the device. Use a dry cloth for cleaning.
Service
Have your device repaired at the ser-
vice centre or by qualified specialist personnel using
original manufacturer parts only. This will ensure that your
device remains safe to use.
If the plug or lead needs to be replaced,
always have the replacement carried out by the man-
ufacturer or its service centre. This will ensure that your device
remains safe to use.
Warranty
The warranty for this appliance is for 3 years from the
date of purchase. The appliance has been manufactured
with care and meticulously examined before delivery.
Please retain your receipt as proof of purchase. In the

16 GB
…/ Manufacturer’s Declaration of Conformity/ManufacturerWarranty
event of a warranty claim, please make contact by tele-
phone with our Service Department. Only in this way can
a post-free despatch for your goods be assured.
The warranty covers only claims for material and maufacturing defects,
but not for transport damage, for wearing parts or for damage to frag-
ile components, e.g. buttons or batteries. This product is for private use
only and is not intended for commercial use.
The warranty is void in the case of abusive and improper handling, use
of force and internal tampering not carried out by our authorized service
branch. Your statutory rights are not restricted in any way by this war-
ranty.
T
he warranty period will not be extended by repairs made unter warran ty.
This applies also to replaced and repaired parts. Any damage and de-
fects extant on purchase must be reported immediately after unpacking
th
e appliance, at the latest, two days after the purchase date. Repairs mad e
after the expiration of the warranty period are subject to payment.
GB
Service Great Britain
Tel.: [phone]
(0,10 GBP/Min.)
e-mail: k[email protected]
IAN 89587

17GB
…/ Manufacturer’s Declaration of Conformity/ManufacturerWarranty
Disposal
The packaging is wholly composed of environmentally-
friendly materials that can be disposed of at a local
recycling centre.
Do not dispose of electric tools in
the household waste!
In accordance with European Directive 2002/96 /EC about waste
electrical and electronic equipment and its transposition into national
legislation, worn out electric tools must be collected separately and
taken for environmentally compatible recycling.
Contact your local refuse disposal authority for more details of how to
dispose of your worn out electrical devices.
Manufacturer’s Declaration of
Conformity/Manufacturer
We, KOMPERNASS GMBH, the person responsible for documents:
Mr Semi Uguzlu, BURGSTR. 21, 44867 BOCHUM, GERMANY, hereby
declare that this product complies with the following standards, norma-
tive documents and EU directives:
Machinery Directive
(2006/ 42/EC)
EU Low Voltage Directive
(2006/ 95/EC)

18 GB
Manufacturer’s Declaration of Conformity/Manufacturer
Electromagnetic compatibility
(2004/ 108/EC)
RoHS Directive
(2011/ 65/EU)
Applicable harmonized standards
EN 60745-1:2009
EN ISO 12100-2/A1:2009
EN 55014-1/A1:2009
EN 55014-2/A2:2008
EN 61000-3-2/A2:2009
EN 61000-3-3:2008
Type /Device description:
Power engraving tool PGG 15 A1
Date of manufacture (DOM): 04–2013
Serial number: IAN 89587
Bochum, 30.04.2013
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical modifications in the course of
further development.
Spis zawartości

19PL
Manufacturer’s Declaration of Conformity/Manufacturer
Wstęp
Zastosowanie zgodne z przeznaczeniem ......................... Strona 20
Wyposażenie....................................................................... Strona 20
Zakres dostawy.................................................................... Strona 21
Dane techniczne .................................................................. Strona 21
Ogólne wskazówki bezpieczeństwa
dla elektronarzędzi................................................. Strona 22
1. Bezpieczeństwo miejsca pracy ...................................... Strona 23
2. Bezpieczeństwo elektryczne........................................... Strona 23
3. Bezpieczeństwo osób ..................................................... Strona 24
4. Staranne obchodzenie się i użytkowanie
narzędzi elektrycznych........................................................ Strona 26
5. Serwis............................................................................... Strona 27
Obsługa
Załączenie/ wyłączenie...................................................... Strona 27
Ustawienie głębokości skoku .............................................. Strona 28
Wymiana szpica grawerskiego.......................................... Strona 28
Instrukcje robocze................................................................ Strona 29
Czyszczenie.................................................................... Strona 29
Serwis ................................................................................. Strona 30
Gwarancja...................................................................... Strona 30
Usuwanie......................................................................... Strona 31
Deklaracja zgodności /Producent .............. Strona 32
Spis zawartości

20 PL
Wstęp Wstęp
Urządzenie do grawerowania PGG 15 A1
Wstęp
Gratulujemy zakupu nowego urządzenia. Tym samym zdecydowali
się Państwo na zakup produktu wysokiej jakości. Instrukcja obsługi jest
częścią tego produktu. Zawiera ona ważne wskazówki dotyczące
bezpieczeństwa, użytkowania iutylizacji. Przed pierwszym użyciem
produktu należy zapoznać się ze wszystkimi wskazówkami dotyczącymi
obsługi ibezpieczeństwa. Używać produktu wyłącznie zgodnie zjego
poniżej opisanym przeznaczeniem. Wprzypadku przekazania pro-
duktu innej osobie należy dołączyć do niego całą jego dokumentację.
Zastosowanie zgodne z przeznaczeniem
Niniejsze urządzenie przeznaczone jest do grawerowania lub dekoro-
wania materiałów takich jak metal, tworzywo sztuczne, szkło, ceramika,
drewno, skóra i kamień. Każde inne zastosowanie lub dokonywanie
zmian na urządzeniu uważane jest za sprzeczne z przeznaczeniem i
niesie ze sobą znaczne zagrożenie wypadkiem. Za szkody powstałe
na wskutek zastosowania sprzecznego z przeznaczeniem, producent
nie przejmuje żadnej odpowiedzialności. Nie jest przeznaczone do
celów komercyjnych.
Wyposażenie
1Przycisk ZAŁ./ WYŁ.
2Pokrętło liczba skoków
3Pętla
