Parkside PGG 15 A1 User manual

POWER ENGRAVING TOOL PGG 15 A1
IAN 73867
POWER ENGRAVING TOOL
Operation and Safety Notes
Translation of original operation manual
KAIVERRUSLAITE
Käyttö- ja turvaohjeet
Alkuperäisen käyttöohjeen käännös
GRAVYRMASKIN
Bruksanvisning och säkerhetsanvisningar
Översättning av bruksanvisning i original
GRAVIERGERÄT
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
GRAVERINGSMASKINE
Brugs- og sikkerhedsanvisninger
Oversættelse af den originale driftsvejledning

GB/IE Operation and Safety Notes Page 5
FI Käyttö- ja turvaohjeet Sivu 21
SE Bruksanvisning och säkerhetsanvisningar Sidan 35
DK Brugs- og sikkerhedsanvisninger Side 51
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 67
Before reading, unfold the page containing the illustrations and familiarise yourself with all
functions of the device.
Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.
Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant
med apparatens/maskinens funktioner.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

B
1 2 3
45
6
A
7

5GB/IE
Introduction
Proper use................................................................................ Page 7
Features and equipment......................................................... Page 7
Included items ......................................................................... Page 8
Technical details...................................................................... Page 8
General safety advice for electrical
power tools....................................................................... Page 9
1. Workplace safety............................................................... Page 10
2. Electrical safety................................................................... Page 10
3. Personal safety.................................................................... Page 11
4. Careful handling and use of electrical power tools......... Page 12
5. Service................................................................................. Page 13
Operation
Switching on/off .................................................................... Page 14
Setting the stroke rate ............................................................. Page 14
Changing the engraving point ............................................... Page 15
Advice on use.......................................................................... Page 15
Cleaning ............................................................................... Page 16
Service................................................................................... Page 16
Warranty............................................................................. Page 17
Disposal................................................................................ Page 18
Manufacturer’s Declaration of
Conformity/Manufacturer................................... Page 19
Table of contents

6 GB/IE
Introduction
The following pictograms are used in these operating
instructions/on the device:
Read instruction manual!
V~Volt (AC)
AAmps
Observe caution and safety notes!
Risk of explosion!!
Keep children away from electrical power tools!
Caution–electric shock! Danger to life!
Risk of loss of life by electric shock from damaged mains
lead or mains plug!
Wear hearing protection, dust protection mask, protective
glasses and protective gloves.
Dispose packaging and appliance in an environmen-
tally-friendly way!

7GB/IE
Introduction
Power engraving tool PGG 15 A1
Introduction
We congratulate you on the purchase of your new device.
You have chosen a high quality product. The instructions for
use are part of the product. They contain important information
concerning safety, use and disposal. Before using the product, please
familiarise yourself with all of the safety information and instructions for
use. Only use the unit as described and for the specified applications.
If you pass the product on to anyone else, please ensure that you also
pass on all the documentation with it.
Proper use
This product is intended for engraving or decorating materials such
as metal, plastic, glass, ceramic, wood, leather and stone. Any other
use or modification to the drill/grinder shall be considered as improper
use and could give rise to considerable dangers. The manufacturer will
not accept liability for loss or damage arising from improper use. Not
intended for commercial use.
Features and equipment
1ON/OFF switch
2Stroke switch
3Hanging eye
4Mains lead
5Engraving point

8 GB/IE
6Engraving point holder
7Engraving stencils
Included items
1 Power engraving tool PGG 15 A1
2 Engraving stencils
1 Operating instructions
Technical details
Rated voltage: 230V∼ 50Hz
Mode of operation: intermittent operation: S3 20%
Note: A duty cycle (in %) defines explicitly the maximum continuous
duration of use and the subsequent rest period. In this case the tool
requires a cooling phase of eight minutes after an operating period of
two minutes, for example.
Rated current: 0.15A
Stroke rate: 6000min-1
Noise and vibration data:
Measured values for noise are determined in accordance with
EN 60745. The A-weighted noise level of the electrical power tool
are typically:
Sound pressure level: 74.4dB(A)
Sound power level: 85.4dB(A)
Uncertainty K: 3dB
Introduction/General safety advice for electrical power tools
Introduction

9GB/IE
Wear ear protection!
Evaluated acceleration, typical:
Hand/arm vibration: 1.582m/s2
Uncertainty K = 1.5m/s2
The vibration level given in these instructions has
been measured in accordance with a standardised measurement pro-
cedure specified in EN 60745 and can be used to compare devices.
Different uses of the device give rise to different vibration levels and in
many cases they may exceed the values given in these instructions. It is
easy to underestimate the vibration load if the electrical power tool is
used regularly in particular circumstances.
Note: If you wish to make an accurate assessment of the vibration
loads experienced during a particular period of working, you should
also take into account the intervening periods of time when the device
is switched off or is running but is not actually in use. This can result in
a much lower vibration load over the whole of the period of working.
General safety advice for
electrical power tools
Read all the safety advice and instruction s!
Failure to observe the safety advice and instructions may result in electric
shock, fire and/or serious injury.
Keep all the safety advice and instructions in a safe place
for future reference!
Introduction/General safety advice for electrical power tools
Introduction

10 GB/IE
The term “electrical tool” used in the safety advice refers to electrical
tools powered by mains electricity (by means of a mains lead) and elec-
trical tools powered by rechargeable batteries (without a mains lead).
1. Workplace safety
a) Keep your working area clean and well lit. Untidy or
poorly lit working areas can lead to accidents.
b) Do not work with the device in potentially
explosive environments in which there are
inflammable liquids, gases or dusts. Electrical
power tools create sparks, which can ignite dusts or fumes.
c) Keep children and other people away while
you are operating the electrical tool. Distrac-
tions can cause you to lose control of the device.
2. Electrical safety
a) T he mains plug on the device must match the mains
socket. The plug must not be modified in any way.
Do not use an adapter plug with devices fitted with
a protective earth. Unmodified plugs and matching sockets
reduce the risk of electric shock.
b) Avoid touching earthed surfaces such as pipes, radia-
tors, ovens and refrigerators with any part of your
body. There is an increased risk of electric shock if your body is
earthed
.
c) Keep the device away from rain or moisture. Water en-
tering an electrical device increases the risk of electric shock.
General safety advice for electrical power tools
General safety advice for electrical power tools
