Parkside PGG 15 B1 Owner's manual

POWER ENGRAVING TOOL PGG 15 B1
POWER ENGRAVING TOOL
Operation and Safety Notes
Translation of original operation manual
KAIVERRUSLAITE
Käyttö- ja turvaohjeet
Alkuperäisen käyttöohjeen käännös
GRAVYRMASKIN
Bruksanvisning och säkerhetsanvisningar
Översättning av bruksanvisning i original
GRAVIERGERÄT
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
GRAVERINGSMASKINE
Brugs- og sikkerhedsanvisninger
Oversættelse af den originale driftsvejledning
IAN 96760

GB/IE Operation and Safety Notes Page 5
FI Käyttö- ja turvaohjeet Sivu 19
SE Bruksanvisning och säkerhetsanvisningar Sidan 33
DK Brugs- og sikkerhedsanvisninger Side 47
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 61
Before reading, unfold the page containing the illustrations and familiarise yourself with all
functions of the device.
Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.
Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant
med apparatens/maskinens funktioner.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

B
1 2
45
6
A
7
3

5GB/IE
Introduction
Proper use................................................................................ Page 6
Features and equipment......................................................... Page 6
Included items ......................................................................... Page 7
Technical details...................................................................... Page 7
General power tool safety warnings......... Page 8
1. Work area safety................................................................ Page 9
2. Electrical safety................................................................... Page 9
3. Personal safety.................................................................... Page 10
4. Power tool use and care.................................................... Page 11
5. Service................................................................................. Page 12
Operation
Switching on/ off .................................................................... Page 12
Setting the cutting depth......................................................... Page 13
Changing the engraving point ............................................... Page 13
Advice on use.......................................................................... Page 14
Cleaning ............................................................................... Page 14
Service................................................................................... Page 15
Warranty............................................................................. Page 15
Disposal................................................................................ Page 16
Translation of the original declaration
of conformity/Manufacturer............................. Page 17
Table of contents

6 GB/IE
Introduction Introduction
Power engraving tool PGG 15 B1
Introduction
We congratulate you on the purchase of your new device. You have
chosen a high quality product. The instructions for use are part of the
product. They contain important information concerning safety, use
and disposal. Before using the product, please familiarise yourself with
all of the safety information and instructions for use. Only use the unit
as described and for the specified applications. If you pass the product
on to anyone else, please ensure that you also pass on all the docu-
mentation with it.
Proper use
This product is intended for engraving or decorating materials such
as metal, plastic, glass, ceramic, wood, leather and stone. Any other
use or modification to the drill/grinder shall be considered as improper
use and could give rise to considerable dangers. The manufacturer will
not accept liability for loss or damage arising from improper use. Not
intended for commercial use.
Features and equipment
1ON/ OFF switch
2Stroke rate rotary controller
3Hanging eye
4Mains lead

7GB/IE
Introduction Introduction
5Engraving point
6Engraving point holder
7Engraving stencils
Included items
1 Power engraving tool PGG 15 B1
2 Engraving stencils
1 Operating instructions
Technical details
Rated voltage: 230V∼ 50 Hz
Mode of operation: intermittent operation: S3 20%
Note: A duty cycle (in %) defines explicitly the maximum continuous
duration of use and the subsequent rest period. In this case the tool
requires a cooling phase of eight minutes after an operating period of
two minutes, for example.
Rated current: 0.15A
Stroke rate: 6000min-1
Noise and vibration data:
Measured values for noise are determined in accordance with
EN 60745. The A-weighted noise level of the electrical power tool
are typically:
Sound pressure level: 74.4dB(A)
Sound power level: 85.4dB(A)
Uncertainty K: 3dB

8 GB/IE
General power tool safety warningsIntroduction/General power tool safety warnings
Wear ear protection!
Evaluated acceleration, typical:
Hand/ arm vibration: 1.582m/s2
Uncertainty K = 1.5 m/s2
The vibration level specified in these instructions was
measured in accordance with an EN 60745 standardised measurement
process and can be used to compare equipment. The vibration emission
value specified can also serve as a preliminary assessment of the ex-
posure.
The vibration level will change according to the application of the elec-
trical tool an in some cases may exceed the value specified in these in-
structions. Regularly using the electric tool in such a way may make it
easy to underestimate the vibration.
Note: If you wish to make an accurate assessment of the vibration
loads experienced during a particular period of working, you should
also take into account the intervening periods of time when the device
is switched off or is running but is not actually in use. This can result in
a much lower vibration load over the whole of the period of working.
General power tool safety warnings
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.

9GB/IE
General power tool safety warningsIntroduction/General power tool safety warnings
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carry-
ing, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.

10 GB/IE
General power tool safety warningsGeneral power tool safety warnings
e) When operating a power tool outdoors, use an exten-
sion cord suitable for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoid-
able, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for appropri-
ate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/ or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a rotat-
ing part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool in un-
expected situations.
f) Dress properly. Do not wear loose clothing or jewel-
lery. Keep your hair, clothing and gloves away from

11GB/IE
General power tool safety warningsGeneral power tool safety warnings
moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your applica tion. The correct power tool will do the
job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools
are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s oper-
ation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.

12 GB/IE
OperationGeneral power tool safety warnings/Operation
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
g) Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those intended
could result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified repair
person using only
identical replacement parts. This will
ensure that the safety of the power tool is maintained.
Operation
Never use the device for a purpose for which it was not intended or
with non-original parts/accessories. The use of tools or accessories
other than those recommended in the operating instructions could lead
to you suffering an injury.
Switching on/off
Insert the mains plug into a mains socket.
Switching on:
Press the ON/ OFF switch 1.

13GB/IE
OperationGeneral power tool safety warnings/Operation
Switching off:
Release the ON/OFF switch 1.
Setting the cutting depth
The cutting depth of the engraver is set using the stroke rate rotary control-
ler 2. A low setting is usually sufficient for most common applications.
Turn the stroke rate rotary controller 2towards the +sign to in-
crease the cutting depth.
Turn the stroke rate rotary controller 2towards the -sign to de-
crease the cutting depth.
Note: Take care when increasing the cutting depth not to turn the stroke
rate rotary controller 2too far towards the +sign. Otherwise the switch
could screw off the device.
Changing the engraving point
RISK OF INJURY! Switch the device off before
performing any tasks on the device and pull the mains plug out of the
mains socket.
Replace the engraving point 5as soon as it becomes too worn
and no longer provides the desired engraving performance. Turn
the engraving point holder 6anticlockwise until the engraving
point 5is released.
Remove the spring and the plain washer.

14 GB/IE
Service/WarrantyOperation/ Cleaning
Push the plain washer and spring on to a new engraving point 5.
Then insert this and turn the engraving point holder 6clockwise
to lock the engraving point in position.
Ensure that the engraving point 5is properly fixed in position.
Advice on use
You can use the mini-engraver to produce creative, individual engravings.
For example, you can use it to place identifying marks on your valuables.
You can engrave numbers and letters into metal, glass, wood, plastic,
ceramic, stone and leather. This is done with the help of the supplied
engraving stencils 7, see Figs. A and B.
Hold the device at an angle, as you would a pencil.
Your arm should rest on the table.
Using very light pressure, guide the engraving point 5over the
workpiece. Find the ideal speed of movement by trial and error on
a piece of waste material.
Note: The engraving point 5supplied with the product is made
from tungsten steel. Therefore it is not suitable for engraving electronic
media such as CDs, DVDs etc. It could damage these materials and
render them illegible.
Cleaning
Before performing any cleaning or maintenance
work, always remove the mains plug from the socket.
Clean all the dirt off the device. Use a dry cloth for cleaning.

15GB/IE
Service/WarrantyOperation/ Cleaning
Service
Have your device repaired at the ser-
vice centre or by qualified specialist personnel using
original manufacturer parts only. This will ensure that your
device remains safe to use.
If the plug or lead needs to be replaced,
always have the replacement carried out by the man-
ufacturer or its service centre. This will ensure that your device
remains safe to use.
Note: Spare parts not listed (e.g. carbon brushes, switches) can be
ordered through our call centre.
Warranty
The warranty for this appliance is for 3 years from the
date of purchase. The appliance has been manufactured
with care and meticulously examined before delivery.
Please retain your receipt as proof of purchase. In the
event of a warranty claim, please make contact by tele-
phone with our Service Department. Only in this way can
a post-free despatch for your goods be assured.
The warranty covers only claims for material and maufacturing defects,
but not for transport damage, for wearing parts or for damage to frag-
ile components, e.g. buttons or batteries. This product is for private use
only and is not intended for commercial use.
The warranty is void in the case of abusive and improper handling, use
of force and internal tampering not carried out by our authorized service

16 GB/IE
…/Translation of the original declaration of conformity/ …Warranty/Disposal
branch. Your statutory rights are not restricted in any way by this war-
ranty.
T
he warranty period will not be extended by repairs made unter warran ty.
This applies also to replaced and repaired parts. Any damage and de-
fects extant on purchase must be reported immediately after unpacking
th
e appliance, at the latest, two days after the purchase date. Repairs mad e
after the expiration of the warranty period are subject to payment.
GB
Service Great Britain
Tel.: [phone]
(0.10 GBP/Min.)
e-mail: k[email protected]
IAN 96760
IE
Service Ireland
Tel: [phone]
(0.08 EUR/Min. (peak)
0.06 EUR/Min. (off peak))
e-mail: k[email protected]
IAN 96760
Disposal
The packaging is wholly composed of environmentally-
friendly materials that can be disposed of at a local
recycling centre.

17GB/IE
…/Translation of the original declaration of conformity/ …Warranty/Disposal
Do not dispose of electric tools in
the household waste!
In accordance with European Directive 2012/19 / EU about waste
electrical and electronic equipment and its transposition into national
legislation, worn out electric tools must be collected separately and
taken for environmentally compatible recycling.
Contact your local refuse disposal authority for more details of how to
dispose of your worn out electrical devices.
Translation of the original declaration of
conformity/Manufacturer
We, KOMPERNASS HANDELS GMBH, the person responsible for
documents: Mr Semi Uguzlu, BURGSTRASSE 21, 44867 BOCHUM,
GERMANY, hereby declare that this product complies with the following
standards, normative documents and EU directives:
Machinery Directive
(2006/ 42 /EC)
EU Low Voltage Directive
(2006/ 95 /EC)
Electromagnetic compatibility
(2004/ 108 /EC)
RoHS Directive
(2011/ 65 /EU)

18 GB/IE
Translation of the original declaration …/Manufacturer
Applicable harmonized standards
EN 60745-1/A11:2010
EN ISO 12100:2010
EN 55014-1/A2:2011
EN 55014-2/A2:2008
EN 61000-3-2/A2:2009
EN 61000-3-3:2008
Type /Device description:
Power engraving tool PGG 15 B1
Date of manufacture (DOM): 04–2014
Serial number: IAN 96760
Bochum, 30.04.2014
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical modifications in the course of
further development.
Sisällysluettelo

19FI
Translation of the original declaration …/Manufacturer Sisällysluettelo
Aluksi
Määräystenmukainen käyttö....................................................Sivu 20
Varustus .....................................................................................Sivu 20
Toimitukseen kuuluu ..................................................................Sivu 21
Tekniset tiedot............................................................................Sivu 21
Sähkötyökaluja koskevat yleiset turvaohjeet
1. Työpaikkaturvallisuus............................................................Sivu 22
2. Sähköturvallisuus ..................................................................Sivu 23
3. Henkilöiden turvallisuus........................................................Sivu 24
4. Sähkötyökalujen huolellinen käsittely ja käyttö..................Sivu 25
5. Huolto....................................................................................Sivu 26
Käyttö
Päälle-/ poiskytkentä ................................................................Sivu 26
Iskusyvyyden säätäminen.........................................................Sivu 27
Kaiverruskärjen vaihto ..............................................................Sivu 27
Työohjeet...................................................................................Sivu 28
Puhdistus ...............................................................................Sivu 28
Huolto.......................................................................................Sivu 28
Takuu........................................................................................Sivu 29
Hävittäminen.....................................................................Sivu 30
Käännös alkuperäisestä EY-vaatimusten-
mukaisuusvakuutuksesta/Valmistajan.....Sivu 30

20 FI
Aluksi
Kaiverruslaite PGG 15 B1
Aluksi
Onnittelemme sinua hyvästä valinnastasi! Valitsit erittäin korkealaatuisen
tuotteen. Käyttöohje on osa tätä tuotetta. Se sisältää tärkeitä turvallisuu-
sohjeita sekä käyttöä ja hävitystä koskevia ohjeita. Tutustu ennen tuot-
teen käyttöä huolellisesti kaikkiin käyttöja turvallisuusohjeisiin. Käytä
tuotetta ainoastaan ohjeen mukaan ja siinä mainittuihin tarkoituksiin. Anna
kaikki ohjeet mukaan, jos luovutat tuotteen edelleen.
Määräystenmukainen käyttö
Tämä laite on tarkoitettu eri materiaalien kuten metallin, muovin, lasin,
keramiikan, puun, nahkan ja kiven kaiverrukseen ja koristeluun. Jokaista
muuta käyttöä tai laitteen muutamista pidetään ei-määräystenmukaisena
ja sisältää huomattavia onnettomuusvaaroja. Määräystenvastaisesta
käytöstä syntyneistä vahingoista valmistaja ei ota mitään vastuuta.
Varustus
1PÄÄLLE- /POIS -kytkin
2Iskuluvun kääntösäädin
3Silmukka
4Verkkojohto
5Kaiverruskärki
6Kaiverruskärjen lukitus
7Kaiverrussablonit
Aluksi
