Parkside PLS 48 C1 Operation instructions

SOLDERING STATION PLS 48 C1
SOLDERING STATION
Translation of the original instructions
PEГУЛИPУEMA CTAHЦИЯ ЗA
ЗAПOЯBAHE
Превод на оригиналното ръководство
за експлоатация
STAŢIE REGLABILĂ DE LIPIT
Traducerea instrucţiunilor de utilizare original
PODESIVA STANICA ZA
LEMLJENJE
Prijevod originalnih uputa za uporabu
IAN 279871
REGELBARE LÖTSTATION
Originalbetriebsanleitung
KOΛΛНТНPΙ ΜΕ PYΘΜΙ-
ΖOMENH ΘΕPΜOKPΑΣΙΑ
Οδηүίες χρήσης

GB/CY Translation of the original instructions Page 1
HR Prijevod originalnih uputa za uporabu Stranica 15
RO Traducerea instrucţiunilor de utilizare original Pagina 31
BG Превод на оригиналното ръководство
за експлоатация Cтраница47
GR/CY Μετάφραση των αυθεντικών οδηγιών
λειτουργίας Σελίδα 65
DE/AT/CH Originalbetriebsanleitung Seite 81
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na
osnovu toga sa svim funkcijama uređaja.
Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate funcţii-
le aparatului.
Преди да прочетете отворете страницата с фигурите и след това се
запознайте с всички функции на уреда.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειω-
θείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

PLS 48 C1 GB│CY │ 1 ■
Contents
Introduction .................................. 2
Intended use..........................................2
Features .............................................3
Package contents ......................................3
Technical details .......................................3
Safety....................................... 4
Safety information .....................................4
Beforeuse................................... 6
Fitting the coil spring....................................6
Inserting/replacing the soldering tip .......................6
Operation ................................... 7
Switching on/off and setting the temperature ................7
Soldering sponge......................................8
Soldering ............................................9
Maintenance and cleaning .....................10
Disposal .................................... 10
Disposal of the appliance...............................10
Kompernass Handels GmbH warranty...........11
Service .............................................13
Importer............................................13
Translation of the original Conformity Declaration . 14

PLS 48 C1
■ 2 │ GB│CY
SOLDERING STATION
PLS 48 C1
Introduction
Congratulations on the purchase of your new appliance. You have
selected a high-quality product. The operating instructions are part of
this product. They contain important information about safety, usage
and disposal. Before using the product, please familiarise yourself
with all operating and safety instructions. Use the product only as
described and for the range of applications specified. Please also
pass these operating instructions on to any future owner.
Intended use
This appliance is intended for electronic soldering for leisure and DIY
purposes. It is designed for applications such as soldering, welding
of plastics and the application of ornamentation. Use this product
only as described and for the areas of applications specified. The
appliance is not intended for commercial use. Any other usage of or
modification to the appliance is deemed to be improper and carries
a significant risk of accidents. The manufacturer accepts no responsi-
bility for damage(s) attributable to misuse.

PLS 48 C1 GB│CY │ 3 ■
Features
Soldering iron
Solder
Storage compartment for soldering tips
Temperature control
ON/OFF switch
Soldering sponge
Soldering tip
Coil spring
Package contents
1 soldering station PLS 48 C1 incl. soldering iron
with 2 standard soldering tips (1 pre-fitted)
1 solder, ø 1.0 mm, 10 g
1 solder, ø 1.5 mm, 10 g
1 soldering sponge
1 set of operating instructions
Technical details
Rated voltage: 230 V ~(alternating current)
Rated frequency: 50 Hz
Rated power
consumption: 48 W
Temperature range: 100–500 °C
Mains cable: 1.85 m from the power plug to the station;
1.00 m from the soldering iron to the station

PLS 48 C1
■ 4 │ GB│CY
Safety
Safety information
WARNING!
► Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire
and/or serious injury.
The soldering station is suitable for indoor use only.
■ This appliance may be used by children aged
8 years and above and by persons with limited
physical, sensory or mental capabilities or lack
of experience and knowledge, provided that they
are under supervision or have been told how to
use the appliance safely and are aware of the
potential risks. Do not allow children to use the
appliance as a plaything. Cleaning and user
maintenance tasks may not be carried out by
children unless they are supervised.

PLS 48 C1 GB│CY │ 5 ■
■ To avoid potential risks, damaged mains cables
should be replaced by the manufacturer, their
customer service department or a similarly
qualified person.
CAUTION - ELECTRIC SHOCK HAZARD!
Do not use the soldering station if the handle,
the mains cable or the plug are damaged.
Never open the appliance!
Remaining risks
■ RISK OF BURNS! Do not touch the heated soldering tip or the
molten solder. There is a risk of being burnt. Always allow the
appliance to cool down completely before changing components,
cleaning or checking it.
■ After work, allow the soldering iron to cool down in the air only.
Do not attempt to quench it with water.
■ CAUTION! RISK OF FIRE! Use only the special multi-functional
holder or another fireproof surface when putting down the solder-
ing iron.
■ During breaks in work, the soldering iron must be placed in the
multi-functional holder.
■ Keep the appliance away from flammable material.
■ Never leave a switched-on appliance unsupervised.
■ CAUTION! RISK OF INJURY! Keep your hands away from the
heated workpiece. The heat can be emitted through the workpiece.
■ Avoid contact between the hot soldering tip and the plastic parts
of the multi-functional holder. Otherwise, the appliance might be
damaged.

PLS 48 C1
■ 6 │ GB│CY
■ In case of danger, remove the plug from the socket immediately.
■ CAUTION! RISK OF POISONING! Avoid inhaling vapours!
■ During work over an extended period in which hazardous vapours
can be created, always ensure sufficient ventilation of the work-
place. In addition, protective gloves, a face mask and work apron
are recommended.
■ Avoid eating, drinking and smoking in rooms where soldering work
is taking place.
Otherwise, lead residues on your hands might contaminate the
food or cigarettes and be absorbed into your body.
■ Always wash your hands thoroughly after soldering.
■ Do not dispose of solder waste in normal domestic waste! Solder
■ waste should be disposed of with hazardous waste.
Before use
Fitting the coil spring
♦ Push the bracket of the coil spring up to the stop into the
slot provided on the soldering station (see fold out page).
Inserting/replacing the soldering tip
CAUTION! RISK OF BURNS!
► Never heat the soldering iron without a soldering tip .
■ The soldering tip may only be removed when the appliance is
switched off and the soldering tip is cooled down.
■ The soldering tip has a screw thread and can thus be removed
quickly from the soldering iron.
♦ Unscrew the soldering tip anticlockwise.
♦ Screw the soldering tip in clockwise.

PLS 48 C1 GB│CY │ 7 ■
Operation
Switching on/off and setting the temperature
Switching on and setting the temperature:
♦ Plug the mains plug into an appropriate wall socket and press
the ON/OFF switch to position "I".
♦ Turn the temperature control to set the desired temperature.
NOTE
► Remove the protective cap from the soldering tip .
► Before using the soldering station for the first time and also before
using a new soldering tip, the soldering tip must be tinned.
NOTE
► The prerequisite for perfect soldering is to use appropriate
solder. Furthermore, it is not possible to make perfect soldered
joints unless the correct soldering temperature is used. If the
soldering temperature is too low, the solder is not sufficiently
fluid and causes dirty solder joints (so-called cold solder joints).
If the soldering temperature is too high, the soldering agent can
burn and the solder does not flow. In addition, the materials to
be processed can be destroyed.
Use the temperature settings below for the most common applications.
These may vary depending on the solder/manufacturer.
Level "Min" = room temperature
Level 1 = approx. 100°C – warm-up level and for solders with
correspondingly low melting point
Level 2 = 200°C melting point of the most frequently used soft
solders

PLS 48 C1
■ 8 │ GB│CY
Level 3 = 300°C normal operation, e.g. when using lead-free solder
Level 4 = 400°C high soldering temperature, e.g. for de-soldering
small solder joints
Level 5 = 500°C maximum soldering temperature, e.g. for
de-soldering larger solder joints
Switching off:
NOTE
► After use, always replace the soldering iron in the coil
spring .
♦ Move the ON/OFF switch to position "0". Always remove
the plug from the socket when not in use.
Soldering sponge
CAUTION!
► The hot soldering tip must never come into contact with a
dry soldering sponge . Otherwise, the soldering sponge
can be damaged.
NOTE
► The soldering sponge is used to clean the soldering tip.
► Dampen the soldering sponge before use.

PLS 48 C1 GB│CY │ 9 ■
Soldering
Vapours can lead to headaches and fatigue if inhaled.
■ The soldering iron has a rated power output of 48 watts and is
ideal for electronic solders.
■ Its design makes it especially suitable for difficult-to-access and
fine soldering work.
♦ Clean the soldering tip on the moist soldering sponge .
♦ After cleaning, the soldering tip must be tinned. Tin the hot
soldering iron tip by melting the solder .
♦ Guide the soldering tip to the solder joint and heat it.
♦ Place the solder (with flux) between the solder joint and soldering
tip to melt it.
♦ Keep feeding in solder until the entire solder joint is covered.
♦ Then withdraw the soldering tip immediately to prevent over-
heating the molten solder.
♦ Allow the solder to harden and avoid vibrations.
NOTE
► The flux is either included in the solder or applied separately.
When buying the solder, ask about its use and the appropriate
flux.

PLS 48 C1
■ 10 │ GB│CY
Maintenance and cleaning
WARNING! RISK OF INJURY! Always pull the
plug out of the socket and let the appliance
cool down before you carry out any work
on the appliance.
■ Always clean the appliance after completion of work.
■ To clean the housing, use a cloth and a mild detergent if necessary.
■ Never use sharp objects, petrol, solvents or cleaning agents that
can damage plastic.
■ Do not allow any liquids to get into the interior of the appliance.
NOTE
► You can order spare parts (such as solder tips) via our service
hotline.
Disposal
Disposal of the appliance
The packaging is made from environmentally friendly
material and can be disposed of at your local recycling
plant.
Do not dispose of power tools in your normal
household waste!
European Directive 2012/19/EU requires that worn-out power
tools be collected separately and recycled in an environmentally
compatible manner.
Your local community or municipal authorities can provide informa-
tion on how to dispose of the worn-out appliance.

PLS 48 C1 GB│CY │ 11 ■
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase.
If this product has any faults, you, the buyer, have certain statutory
rights. Your statutory rights are not restricted in any way by the war-
ranty described below.
Warranty conditions
The validity period of the warranty starts from the date of purchase.
Please keep your original receipt in a safe place. This document will
be required as proof of purchase.
If any material or production fault occurs within three years of the
date of purchase of the product, we will either repair or replace the
product for you at our discretion. This warranty service is dependent
on you presenting the defective appliance and the proof of purchase
(receipt) and a short written description of the fault and its time of
occurrence.
If the defect is covered by the warranty, your product will either be
repaired or replaced by us. The repair or replacement of a product
does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the
warranty. This also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be
reported immediately after unpacking. Repairs carried out after ex-
piry of the warranty period shall be subject to a fee.

PLS 48 C1
■ 12 │ GB│CY
Scope of the warranty
This appliance has been manufactured in accordance with strict qual-
ity guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty
does not extend to product parts subject to normal wear and tear
or fragile parts such as switches, batteries, baking moulds or parts
made of glass.
The warranty does not apply if the product has been damaged, im-
properly used or improperly maintained. The directions in the operat-
ing instructions for the product regarding proper use of the product are
to be strictly followed. Uses and actions that are discouraged in the
operating instructions or which are warned against must be avoided.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in cases of misuse or
improper handling, use of force and modifications/repairs which
have not been carried out by one of our authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please observe the follow-
ing instructions:
■ Please have the till receipt and the item number (e.g. IAN
12345) available as proof of purchase.
■ You will find the item number on the type plate, an engraving on
the front page of the instructions (bottom left), or as a sticker on
the rear or bottom of the appliance.
■ If functional or other defects occur, please contact the service
department listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the ser-
vice address that will be provided to you. Ensure that you enclose
the proof of purchase (till receipt) and information about what the
defect is and when it occurred.

PLS 48 C1 GB│CY │ 13 ■
You can download these instructions along with
many other manuals, product videos and software
on www.lidl-service.com.
Service
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: k[email protected]
IAN 279871
Importer
Please note that the following address is not the service address.
Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PLS 48 C1
■ 14 │ GB│CY
Translation of the original Conformity
Declaration
We, KOMPERNASS HANDELS GMBH, documents officer: Mr. Semi
Uguzlu, BURGSTR. 21, 44867 BOCHUM, GERMANY, hereby
declare that this product complies with the following standards,
normative documents and EC directives:
EC Low Voltage Directive
(2014/35/EU)
EMC (Electromagnetic Compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)
Applied harmonised standards:
EN 60335-1: 2012 / A11: 2014
EN 60335-2-45: 2002 / A2: 2012
EN 62233: 2008
EN 55014-1: 2006 / A2: 2011
EN 55014-2: 1997 / A2: 2008
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Type designation of machine:
Soldering station PLS 48 C1
Year of manufacture: 07-2016
Serial number: IAN 279871
Bochum, 07.06.2016
Semi Uguzlu
- Quality Manager -
The right to effect technical changes in the context of further develop-
ment is reserved.

PLS 48 C1 HR │ 15 ■
Sadržaj
Uvod.......................................16
Namjenska uporaba ..................................16
Oprema............................................17
Opseg isporuke ......................................17
Tehnički podaci ......................................17
Sigurnost ...................................18
Sigurnosne napomene .................................18
Prije uključivanja uređaja .....................21
Montiranje spiralne opruge .............................21
Umetanje/promjena vrha lemilice ........................21
Puštanje u pogon ............................22
Uključivanje / isključivanje i podešavanje temperature ........22
Spužvica za čišćenje lemilice ............................24
Lemljenje............................................25
Održavanje i čišćenje .........................26
Zbrinjavanje ................................26
Zbrinjavanje uređaja ..................................26
Jamstvo tvrtke Kompernass Handels GmbH ......27
Servis ..............................................29
Uvoznik ............................................29
Prijevod originalne izjave o sukladnosti..........30

PLS 48 C1
■ 16 │ HR
PODESIVA STANICA ZA LEMLJENJE
PLS 48 C1
Uvod
Čestitamo na kupnji Vašeg novog uređaja. Time ste se odlučili za
vrlo kvalitetan proizvod. Upute za uporabu sastavni su dio ovog
proizvoda. One sadrže važne napomene za sigurnost, rukovanje
i zbrinjavanje. Prije uporabe proizvoda upoznajte se sa svim napo-
menama za rukovanje i sa svim sigurnosnim napomenama. Proizvod
koristite isključivo na opisani način i u navedenim područjima upora-
be. U slučaju predaje proizvoda trećim osobama, priložite i također
predajte i svu dokumentaciju.
Namjenska uporaba
Uređaj je predviđen za lemljenje elektronike u slobodno vrijeme
i uradi-sam okruženjima. Uređaj je pritom namijenjen za primjene
kao što su lemljenje, lijepljenje plastike zavarivanjem i ukrašavanje.
Uređaj koristite samo na opisani način i u opisanim područjima
uporabe. Uređaj nije namijenjen za komercijalnu uporabu. Svaki
drugi način uporabe i svaka izmjena uređaja smatra se nenamjen-
skom i krije znatnu opasnost od nezgode. Proizvođač ne preuzima
odgovornost za štete nastale uslijed nenamjenskog korištenja
uređaja.

PLS 48 C1 HR │ 17 ■
Oprema
Fina lemilica
Lem
Kutijica za čuvanje vrha lemilice
Regulator temperature
Prekidač UKLJ / ISKLJ
Spužvica za čišćenje lemilice
Vrh lemilice
Spiralna opruga
Opseg isporuke
1 podesiva stanica za lemljenje PLS 48 C1
uklj. 2 standardna vrha (1 x unaprijed montiran)
1 lem, ø 1,0 mm, 10 g
1 lem, ø 1,5 mm, 10 g
1 spužvica za čišćenje lemilice
1 Upute za uporabu
Tehnički podaci
Nazivni napon: 230 V ~(izmjenična struja)
Nazivna frekvencija: 50 Hz
Nazivna snaga: 48 W
Temperaturno područje: 100–500 °C
Mrežni kabel: 1,85 m od utikača do stanice;
1,00 m od fine lemilice do stanice
