Parkside PLS 48 C1 User manual

SOLDERING STATION PLS 48 C1
SOLDERING STATION
Translation of the original instructions
IAN 270214
REGULOWANA STACJA
LUTOWNICZA Z LUTOWNICĄ
Tłumaczenie oryginalnej instrukcji obsługi
FORRASZTÓPÁKA
Az originál használati utasítás fordítása NASTAVLJIVA SPAJKALNA
Prevod originalnega navodila za uporabo
REGULOVATELNÁ PÁJECÍ
STANICE
Překlad originálního provozního návodu REGULOVATEĽNÁ SPÁJKOVA-
CIA STANICA
Preklad originálneho návodu na obsluhu
REGELBARE LÖTSTATION
Originalbetriebsanleitung

GB Translation of the original instructions Page 1
PL Tłumaczenie oryginalnej instrukcji obsługi Strona 17
HU Az originál használati utasítás fordítása Oldal 35
SI Prevod originalnega navodila za uporabo Stran 53
CZ Překlad originálního provozního návodu Strana 71
SK Preklad originálneho návodu na obsluhu Strana 89
DE/AT/CH Originalbetriebsanleitung Seite 107
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie
proszę zapoznać się z wszystkimi funkcjami urządzenia.
Olvasás előtt kattintson az ábrát tartalmazó oldalra és végezetül ismerje meg
a készülék mindegyik funkcióját.
Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami
naprave.
Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi
funkcemi přístroje.
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všet-
kými funkciami prístroja.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

1
PLS 48 C1
GB
Contents
Introduction .................................. 2
Intended use..........................................2
Features .............................................3
Package contents ......................................3
Technical data ........................................3
General power tool safety warnings ............. 4
1. Work area safety....................................4
2. Electrical safety .....................................4
3. Personal safety......................................5
4. Power tool use and care ..............................7
5. Service ............................................7
Original accessories/auxiliary equipment ...................7
Beforefirstuse ............................... 8
Fitting the coil spring....................................8
Inserting/replacing the soldering tip .......................8
Operation ................................... 9
Switching on/off and setting the temperature ................9
Soldering sponge.....................................10
Soldering ...........................................10
Maintenance and cleaning .....................11
Disposal .................................... 12
Disposal of the appliance...............................12
Warranty................................... 12
Service .....................................13
Importer....................................13
Translation of the original Conformity Declaration . 14

GB
2PLS 48 C1
SOLDERING STATION PLS 48 C1
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high quality product. The operating
instructions are part of this product. They contain important
information on safety, usage and disposal. Before using the product,
familiarise yourself with all handling and safety guidelines. Use the
product only as described and for the range of applications speci-
fied. Please also pass these operating instructions on to any future
owner.
Intended use
This appliance is intended for electronic soldering for leisure and DIY
purposes. It is designed for applications such as soldering, welding of
plastics and the application of ornamentation. Use this product only as
described and for the areas of applications specified. The appliance
is not meant for commercial use. Any other usage of or modification to
the appliance is deemed to be improper and carries a significant risk
of accidents. The manufacturer accepts no responsibility for damage(s)
attributable to misuse.

3
PLS 48 C1
GB
Features
Soldering iron
Solder
Storage compartment for soldering tips
Temperature control
ON/OFF switch
Soldering sponge
Soldering tip
Coil spring
Package contents
1 soldering station incl. PLS 48 C1 soldering iron with 2 standard
soldering tips (1 pre-fitted)
1 solder, ø 1.0 mm, 10 g
1 solder, ø 1.5 mm, 10 g
1 soldering sponge
1 operating instructions
Technical data
Rated voltage: 230 V ~
Nominal frequency: 50 Hz
Nominal power: 48 W
Temperature range: 100–500°C
Power cord: 1.85 m from the power plug to the station;
1.00 m from the soldering iron to the station

GB
4PLS 48 C1
General power tool safety war-
nings
WARNING!
► Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded/mains adapter) power tools or battery-operated (cordless)
power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.

5
PLS 48 C1
GB
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
g) Always hold the power cord away from the working area of the appliance
and run it to the rear away from the appliance.
h) Always pull out the plug if you leave the appliance unattended or carry out
work on the appliance.
3. Personal safety
■ This appliance may be used by children aged
8 years and above and by persons with limited
physical, sensory or mental capabilities or lack of
experience and knowledge, provided that they
are under supervision or have been told how to
use the appliance safely and are aware of the
potential risks. Children must not use the appli-
ance as a plaything. Cleaning and user mainte-
nance tasks may not be carried out by children
unless they are supervised.
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of inat-
tention while operating power tools may result in serious personal injury.
■ RISK OF BURNS! Do not touch the heated soldering tip or the
molten solder. There is a risk of being burnt. Always allow the ap-
pliance to cool down completely before changing components,
cleaning or checking it.

GB
6PLS 48 C1
■ After work, allow the soldering iron to cool down in the air only.
Do not attempt to quench it with water.
■ CAUTION! RISK OF FIRE! Use only the special multi-functional
holder or another fireproof surface when putting down the
soldering iron.
■ During breaks in work, the soldering iron must be placed in the
multi-functional holder.
■ Keep the appliance away from flammable material.
■ Never leave a switched-on appliance unsupervised.
■ CAUTION! RISK OF INJURY! Keep your hands away from the
heated workpiece. The heat can be emitted through the work-
piece.
■ Avoid contact between the hot soldering tip and the plastic parts
of the multi-functional holder. Otherwise, the appliance might be
damaged.
■ In case of danger, remove the plug from the socket immediately.
■ CAUTION! RISK OF POISONING! Avoid inhaling vapours!
■ During work over an extended period in which hazardous
vapours can be created, always ensure sufficient ventilation of the
workplace. In addition, protective gloves, a face mask and work
apron are recommended.
■ Avoid eating, drinking and smoking in rooms where soldering
work is taking place.
Otherwise, lead residues on your hands might contaminate the
food or cigarettes and be absorbed into your body.
■ Always wash your hands thoroughly after soldering.
■ Do not dispose of solder waste in normal domestic waste! Solder
waste should be disposed of with hazardous waste.

7
PLS 48 C1
GB
4. Power tool use and care
a) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained
users.
b) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired be-
fore use. Many accidents are caused by poorly maintained power tools.
c) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
5. Service
■Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that the
safety of the power tool is maintained.
■Always ensure that the power plug or the pow-
er cord is replaced only by the manufacturer
of the appliance or by an approved customer
service provider. This will ensure that the safety of
the appliance is maintained.
Original accessories/auxiliary equipment
■Use only the additional equipment and accessories specified
in the operating instructions. Using attachments or accessory
tools other than those recommended in the operating instructions
can lead to a risk of injury.

GB
8PLS 48 C1
Before first use
Fitting the coil spring
♦ Push the bracket of the coil spring up to the stop into the slot
provided on the soldering station (see fold out page).
Inserting/replacing the soldering tip
CAUTION! RISK OF BURNS!
► Never heat the soldering iron without a soldering tip .
■ The soldering tip may only be removed when the appliance is
switched off and the soldering tip is cooled down.
■ The soldering tip has a screw thread and can thus be removed
quickly from the soldering iron.
♦ Unscrew the soldering tip anticlockwise.
♦ Screw the soldering tip in clockwise.
NOTE
► Before use remove the protective cap from the soldering tip .
► Before using the soldering station for the first time and also
before using a new soldering tip, the soldering tip must be
tinned.
Procedure:
♦ Plug the mains plug into a wall socket and press the ON/OFF
switch to position “I”.
♦ Set the temperature control to level 3 and wait until the
appliance has heated up. Allow a little bit of solder to melt
into a thin film on the soldering tip.

9
PLS 48 C1
GB
Operation
Switching on/off and setting the temperature
Switching on and setting the temperature:
♦ Plug the mains plug into an appropriate wall socket and press
the ON/OFF switch to position “I”.
♦ Turn the temperature control to set the desired temperature.
NOTE
► The prerequisite for perfect soldering is to use appropriate
solder. Furthermore, it is not possible to make perfect soldered
joints unless the correct soldering temperature is used. If the sol-
dering temperature is too low, the solder is not sufficiently fluid
and causes dirty solder joints (so-called cold solder joints). If
the soldering temperature is too high, the soldering agent can
burn and the solder does not flow. In addition, the materials to
be processed can be destroyed.
Use the temperature settings below for the most common applica-
tions. These may vary depending on the solder/manufacturer.
Level “min” = room temperature
Level 1 = approx. 100°C – warm-up level and for solders with
correspondingly low melting point
Level 2 = 200°C melting point of the most frequently used soft
solders
Level 3 = 300°C normal operation, e.g. when using lead-free solder
Level 4 = 400°C high soldering temperature, e.g. for de-soldering
small solder joints
Level 5 = 500°C maximum soldering temperature, e.g. for de-solder-
ing larger solder joints

GB
10 PLS 48 C1
Switching off:
NOTE
► After use, always replace the soldering iron in the coil
spring .
♦ Move the ON/OFF switch into the “0” position.
Always remove the plug from the socket when not in use.
Soldering sponge
NOTICE!
► The hot soldering tip must never come into contact with a
dry soldering sponge . Otherwise, the soldering sponge can
be damaged.
NOTE
► The soldering sponge is used to clean the soldering tip.
► Dampen the soldering sponge before use.
Soldering
Vapours can lead to headaches and fatigue if inhaled.
■ The soldering iron has a rated power output of 48 watts and is
ideal for electronic solders.
■ Its design makes it especially suitable for difficult-to-access and
fine soldering work.
♦ Clean the soldering tip on the moist soldering sponge .
♦ After cleaning, the soldering tip must be tinned. Tin the hot
soldering iron tip by melting the solder .
♦ Guide the soldering tip to the solder joint and heat it.

11
PLS 48 C1
GB
♦ Place the solder (with flux) between the solder joint and solder-
ing tip to melt it.
♦ Keep feeding in solder until the entire solder joint is covered.
♦ Then withdraw the soldering tip immediately to prevent over-
heating the molten solder.
♦ Allow the solder to harden and avoid vibrations.
NOTE
► The flux is either included in the solder or it is applied separately.
When buying the solder ask about its use and the appropriate flux.
Maintenance and cleaning
WARNING! RISK OF INJURY! Always pull the
plug out of the socket and let the appliance cool
down before you carry out any work on the
appliance.
■ Always clean the appliance after completion of work.
■ To clean the housing, use a cloth and a mild detergent if neces-
sary.
■ Never use sharp objects, petrol, solvents or cleaning agents that
can damage plastic.
■ Do not allow any liquids to get into the interior of the appliance.
NOTE
► You can order spare parts (such as solder tips) via our service
hotline.

GB
12 PLS 48 C1
Disposal
Disposal of the appliance
The packaging is made of environmentally friendly material
and can be disposed of at your local recycling centre.
Do not dispose of power tools in the normal
domestic waste!
European Directive 2012/19/EU requires that worn-out power
tools be collected separately and recycled in an environmentally
compatible manner.
Your local community or municipal authorities can provide informa-
tion on how to dispose of the worn-out appliance.
Warranty
This appliance is provided with a 3-year warranty valid from the
date of purchase. This appliance has been manufactured with care
and inspected meticulously prior to delivery.
Please retain your receipt as proof of purchase. In the event of a war-
ranty claim, please contact your Customer Service unit by telephone.
This is the only way to guarantee free return of your goods.
NOTE
► This warranty is valid only for material or manufacturing faults,
not for damage sustained during carriage, parts subject to wear
and tear or damage to fragile parts, e.g. switches.
This product is intended solely for private use and not for commercial
purposes. The warranty shall be deemed void in the case of misuse
or improper handling, use of force or modifications which have not
carried out by one of our authorised Service centres.
Your statutory rights are not restricted by this warranty. The warranty
period is not prolonged by repairs effected under the warranty. This

13
PLS 48 C1
GB
also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be
reported immediately after unpacking, but no later than two days
after the date of purchase.
Repairs carried out after expiry of the warranty period shall be
subject to charge.
Service
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
IAN 270214
Hotline availability: Monday to Friday from 8:00 a.m. to 8:00
p.m. (CET)
Importer
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

GB
14 PLS 48 C1
Translation of the original
Conformity Declaration
We, KOMPERNASS HANDELS GMBH, documents officer: Mr. Semi
Uguzlu, BURGSTR. 21, 44867 BOCHUM, GERMANY, hereby
declare that this product complies with the following standards,
normative documents and EC directives:
EC Low Voltage Directive
(2006/95/EC)
EMC (Electromagnetic Compatibility)
(2004/108/EC)
RoHS Directive
(2011/65/EU)
Applied harmonised standards:
EN 60335-2-45: 2002 / A2: 2012
EN 60335-1: 2012 / A11: 2014
EN 62233: 2008
EN 55014-1: 2006 / A2: 2011
EN 55014-2: 1997 / A2: 2008
EN 61000-3-2: 2014
EN 61000-3-3: 2013

15
PLS 48 C1
GB
Type designation of machine:
Soldering station PLS 48 C1
Year of manufacture: 06-2015
Serial number: IAN 270214
Bochum, 09/04/2015
Semi Uguzlu
- Quality Manager -
The right to effect technical changes in the context of further develop-
ment is reserved.

16 PLS 48 C1 16

17
PLS 48 C1
PL
Spis treści
Wstęp......................................18
Użytkowanie zgodne z przeznaczeniem...................18
Wyposażenie........................................19
Zakres dostawy ......................................19
Dane techniczne......................................19
Ogólne wskazówki bezpieczeństwa dla elektronarzędzi20
1. Bezpieczeństwo na stanowisku pracy ...................20
2. Bezpieczeństwo elektryczne ..........................20
3. Bezpieczeństwo osób ...............................21
4. Zastosowanie i obsługa elektronarzędzia ................23
5.Serwis ...........................................24
Oryginalne akcesoria i elementy dodatkowe ...............24
Przed uruchomieniem.........................24
Montaż sprężyny spiralnej ..............................24
Wkładanie / wymiana grotu lutownicy ....................25
Uruchomienie ...............................26
Włączanie/wyłączanie i ustawianie temperatury ............26
Gąbka lutownicza ....................................27
Lutowanie ...........................................28
Konserwacja i czyszczenie ..................... 29
Utylizacja................................... 29
Utylizacja urządzenia .................................29
Gwarancja..................................30
Serwis ..................................... 31
Importer....................................31
Tłumaczenie oryginalnej deklaracji zgodności .... 32
