Parkside PALP 16 A1 User manual

IAN 280447
CORDLESS COMPRESSOR PAK 16 A1
CORDLESS AIR PUMP PALP 16 A1
CORDLESS COMPRESSOR
CORDLESS AIR PUMP
Translation of the original instructions
АКУМУЛАТОРЕН КОМПРЕСОР
АКУМУЛАТОРНА ВЪЗДУШНА
ПОМПА
Превод на оригиналното ръководство за експлоатация
COMPRESOR CU ACUMULATOR
POMPA DE AER CU ACUMULATOR
Traducerea instrucţiunilor de utilizare original
EΠΑΝΑΦΟΡΤΙΖΟΜΕΝΟ
ΚΟΜΠΡΕΣΕΡ AEPOΣ
EΠΑΝΑΦΟΡΤΙΖΟΜΕΝH ANTΛIA
AEPOΣ
Μετάφραση των αυθεντικών οδηγιών λειτουργίας
AKKU-KOMPRESSOR
AKKU-LUFTPUMPE
Originalbetriebsanleitung

GB/CY Translation of the original instructions Page 1
RO Traducerea instrucţiunilor de utilizare original Pagina 15
BG Превод на оригиналното ръководство за експлоатация Cтраница 29
GR/CY Μετάφραση των αυθεντικών οδηγιών λειτουργίας Σελίδα 43
DE/AT / CH Originalbetriebsanleitung Seite 57
Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the
device.
Înainte de a citi instrucţiunile, priviţi ambele pagini cu imagini şi familiarizaţi-vă cu toate funcţiile aparatului.
Преди да прочетете отворете двете страници с фигурите и след това се запознайте с всички
функции на уреда.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και εξοικειωθείτε με όλες τις
λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

A
22a

PAK 16 A1 / PALP 16 A1 GB│CY │ 1 ■
Contents
Introduction......................................................2
Intended use................................................................ 2
Features ................................................................... 2
Technical data .............................................................. 3
General Power Tool Safety Warnings ................................4
1. Work area safety .......................................................... 4
2. Electrical safety ........................................................... 4
3. Personal safety............................................................ 5
4. Power tool use and care .................................................... 5
5. Use and handling of the cordless electrical power tool............................. 6
6. Service .................................................................. 6
Extended safety guidelines..................................................... 6
Safety instructions for battery chargers & blowers ................................... 7
Before use: ......................................................7
Charging the battery pack (see fig. A)............................................ 7
Attaching/disconnecting the battery pack to/from the appliance....................... 8
Operating the cordless air pump PALP 16 A1 ..........................8
Inflation ................................................................... 8
Deflation................................................................... 8
Adapters................................................................... 8
Operating the cordless compressor PAK 16 A1.........................9
Display indicator ............................................................ 9
Setting the pressure .......................................................... 9
Initial operation ..................................................9
Adapters..................................................................10
Maintenance, storage and cleaning .................................10
Disposal........................................................11
Kompernass Handels GmbH warranty ..............................11
Service .........................................................12
Importer .......................................................12
Translation of the original Conformity Declaration ......................1

PAK 16 A1 / PALP 16 A1
■ 2 │ GB│CY
CORDLESS COMPRESSOR
PAK 16 A1
CORDLESS AIR PUMP
PALP 16 A1
Introduction
Congratulations on the purchase of your new appli-
ance. You have chosen a high-quality product. The
operating instructions are part of this product. They
contain important information about safety, usage
and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Intended use
Cordless compressor PAK 16 A1:
The appliance is designed for pumping up bicycle
tyres and inflatable game, sport and beach
articles; however, not for large-volume inflatables
such as rubber dinghies and large inflatable mat-
tresses. It is also suitable for measuring the current
pressure. The pressure display is not calibrated.
The compressor is not suitable for inflating car
tyres.
Cordless air pump PALP 16 A1:
The appliance is designed for inflating and deflat-
ing inflatable mattresses, rubber dinghies, paddling
pools and other large-volume inflatables for home
use. It is not suitable for pumping up bicycle or
car tyres.
The appliances are not suitable for commercial
use. Any other usage of or modification to the
appliances is deemed to be improper and carries
the risk of serious personal injury. The manufacturer
accepts no responsibility for damage(s) attribut-
able to misuse.
NOTE
► Store these operating instructions in the im-
mediate vicinity of the compressor and make
them available to all operators.
Features
Air inlet
Battery pack
Battery charge level button
Battery display LED
Release button for battery pack
ON/OFF switch
LED work light
Air outlet
Adapter nozzle
Adapter nozzle
Adapter nozzle
Display indicator
"+" button
ON/OFF button on the display
"−" button
Battery pack
Battery charge level button
Battery display LED
Release button for battery pack
ON/OFF switch
LED work light
Compressed air hose adapter
22a Compressed air hose threaded connection
Union nut
Compressed air hose
Ball needle
Valve adapter
Valve adapter
Universal adapter
Universal adapter
Universal adapter
High-speed charger
Red charge control LED
Green charge control LED

PAK 16 A1 / PALP 16 A1 GB│CY │ 3 ■
Package contents
1 battery charger PLG 16 A1
1 rechargeable battery PAP 16 A1
1 cordless compressor PAK 16 A1
incl. 1 x hose with valve adapter
incl. 2 x inner-tube valves (1 x Dunlop/express
valve, 1 Presta valve)
incl. 1 x ball needle
incl. 3 x plastic adapters
1 cordless air pump PALP 16 A1
incl. 3 x plastic adapters (universal adapter for
valves with an internal diameter of approx.
8 mm, adapter screw valve, e.g. for bathing
boats, adapter for deflation valves)
1 carrying case
1 set of operating instructions
Technical data
Cordless compressor: PAK 16 A1
Rated voltage: 16 V (DC)
Max. pressure: 7 bar (100 psi)
Cordless air pump: PALP 16 A1
Rated voltage: 16 V (DC)
Air flow rate: 45 m³/h
Use only the following battery to operate
the cordless tools:
PAP 16 A1:
Type: LITHIUM ION
Cells: 4
Rated voltage: 16 V (DC)
Capacity: 1.5 Ah
Use only the following charger to charge the
battery pack:
PLG 16 A1
INPUT:
Rated voltage: 230–240 V ∼, 50 Hz
(AC)
Rated power consumption:33 W
OUTPUT:
Rated voltage: 16.5 V (DC)
Charging current: 1.8 A
Charging time: approx. 60 min
Fuse (internal): 3.15 A T3.15A
Protection class: II/ (double insulation)
Noise emission value:
The measured values have been determined in
accordance with EN60745. The A-rated noise
level of the tool is typically:
Cordless compressor:
Sound pressure level: LPA = 84 dB(A)
Uncertainty: KPA = 3 dB
Sound power level: LWA = 95 dB(A)
Uncertainty: KWA= 3 dB
Cordless air pump:
Sound pressure level: LPA = 80 dB(A)
Uncertainty: KPA = 3 dB
Sound power level: LWA = 91 dB(A)
Uncertainty: KWA= 3 dB
Total vibration value:
Total vibration values (vector total of three direc-
tions) determined in accordance with EN 60745:
Cordless compressor:
Vibration emission value: ah = 2.6 m/s²
Uncertainty: K = 1.5m/s²
Cordless air pump:
Vibration emission value: ah = 2.5 m/s²
Uncertainty: K = 1.5m/s²
NOTE
► The vibration level specified in these instruc-
tions has been measured in accordance with
a standardised measuring procedure and
can be used for equipment comparisons. The
specified vibration emission value can also
be used to make an initial exposure estimate.

PAK 16 A1 / PALP 16 A1
■ 4 │ GB│CY
WARNING!
► The vibration level will vary according to the
use of the power tool and may sometimes
be higher than the value specified in these
instructions. Regular use of the power tool in
this way may cause the user to underestimate
the vibration. To estimate the vibration load
during a specific working period accurately,
also take into account periods during which
the appliance is switched off (or running, but
not being used). This can significantly reduce
the vibration load over the total working
period.
General Power Tool
Safety Warnings
WARNING!
►Read all the safety information, instruc-
tions, illustrations and technical data
provided with this electric tool. Failure
to follow the warnings and instructions may
result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to
mains-operated (corded) power tools or battery-
operated (cordless) power tools.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the mains cable. Never use the
cable for carrying, pulling or unplugging the
power tool. Keep mains cable away from heat,
oil, sharp edges or moving parts. Damaged
or entangled cables increase the risk of electric
shock.
e) When working outdoors with an electrical
power tool always use extension cords which
are also suitable for use outdoors. The use
of an extension cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD
reduces the risk of electric shock.

PAK 16 A1 / PALP 16 A1 GB│CY │ 5 ■
3. Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying the power
tool with your finger on the ON/OFF switch or
connecting the power tool to the mains supply
whilst it is switched on can lead to serious ac-
cidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A tool or wrench
attached to a rotating component on the power
tool can cause serious injuries.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. The
use of an extraction system can reduce hazards
caused by dust.
h) Do not allow yourself to get lulled into a false
sense of security and do not ignore the safety
regulations for power tools, even if you are
familiar with the power tool after repeated
use. Careless handling can lead to serious
injuries within a fraction of a second.
4. Power tool use and care
a) Do not overload the power tool. Use the
correct power tool for your application. The
correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that can-
not be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source
and/or remove any removable battery packs
before making any adjustments, changing
accessories, or storing the power tool.
This precaution is intended to prevent you from
unintentionally starting the appliance.
d) Store idle power tools out of the reach of
children. Do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Look after power tools and accessories with
care. Check for misalignment or binding of
moving parts, breakage of parts and any
other condition that may affect the power
tool's operation. Arrange for damaged
components to be repaired before using the
power tool. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.

PAK 16 A1 / PALP 16 A1
■ 6 │ GB│CY
g) Use the power tool, accessories and ac-
cessory tools etc. in accordance with these
instructions, taking into account the working
conditions and the work to be performed.
Use of the power tool for operations different
from those intended could result in a hazardous
situation.
h) Keep the handles and handle surfaces dry,
clean and free from oil and grease. Slippery
handles and handle surfaces do not allow safe
use and operation of the power tool in unfore-
seen situations.
5. Use and handling of the cordless
electrical power tool
a) Charge the rechargeable battery unit using
only the charger recommended by the manu-
facturer. Chargers are often designed for a par-
ticular type of rechargeable battery unit. There is
a risk of fire if the battery charger specified for
a particular type of battery is used with other
batteries.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store recharge-
able battery units away from paperclips, coins,
keys, nails, screws or other small metal objects
that could cause the contacts to be bridged.
Short-circuiting the contacts of a rechargeable
battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens,
avoid contact with the fluid. If contact occurs,
flush the affected area with water. Seek addi-
tional medical help if any of the fluid gets into
your eyes. Escaping battery fluid may cause
skin irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries!
Protect the rechargeable battery from
heat, for example from continuous
exposure to sunlight, fire, water and
moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replace-
ment parts. This will ensure that the safety of
the power tool is maintained.
Extended safety guidelines
■Do not use a damaged or modified battery.
Damaged or modified batteries may behave
unexpectedly and cause fires, explosions or
pose a risk of injury.
■Do not expose a battery to fire or excessively
high temperatures. Fire or temperatures in
excess of 130°C (265°F) can cause an explo-
sion.
■Follow all instructions regarding charging
and never charge the battery or the cordless
tool outside the temperature range given in
the operating instructions. Incorrect charging or
charging outside of the permissible temperature
range can destroy the battery and increase the
risk of fire.

PAK 16 A1 / PALP 16 A1 GB│CY │ 7 ■
Safety instructions for battery
chargers & blowers
■ This appliance may be used by
children aged 8 and above and
by persons with limited physical,
sensory, or mental capabilities or
lack of experience and knowledge,
provided that they are under super-
vision or have been told how to use
the appliance safely and are aware
of the potential risks. Do not allow
children to use the appliance as a
toy. Cleaning and user maintenance
tasks may not be carried out by
children unless they are supervised.
The charger is suitable for
indoor use only.
WARNING!
■ If the power cord requires replacement, this
should be carried out by the manufacturer or
an approved representative to avoid safety
hazards.
Before use:
Charging the battery pack (see fig. A)
CAUTION!
► Always unplug the appliance before you re-
move the battery pack from or connect
the battery pack to the charger.
NOTE
► The battery is supplied partially charged.
Before first use, charge the battery in the
charger for at least 1 hours. This guarantees
full battery power. Li-ion batteries can be
charged at any time without adversely affect-
ing their service life. Interruption of the charg-
ing process will not damage the battery.
► Never charge the battery pack when
the ambient temperature is below 10°C or
above 40°C. If a lithium-ion battery is to be
stored for an extended period, the charge level
should be checked regularly. The optimum
charge level is between 50% and 80%. The
storage climate should be cool and dry and
the ambient temperature should be between
0°C and 50°C.
♦ Insert the battery pack into the high-speed
charger .
♦ Insert the power plug into the socket. The
control LED lights up red to indicate that the
appliance is charging.
♦ The green control LED indicates that the
charging process is complete and the battery
pack is ready for use.
♦ Push the battery pack back onto the
appliance.
♦ Switch off the charger for at least 15 minutes
between successive charging sessions. Also
disconnect the power plug from the mains
power socket.

PAK 16 A1 / PALP 16 A1
■ 8 │ GB│CY
Attaching/disconnecting the battery
pack to/from the appliance
Inserting the battery pack:
♦ Allow the battery pack to click into the
handle.
Removing the battery pack:
♦ Press the release button and remove the
battery pack .
Checking the battery charge level:
♦ Press the battery charge level button to
check the battery charge level.
The status/remaining charge will be shown on
the battery display LED as follows:
♦ RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Operating the cordless air
pump PALP 16 A1
This appliance is not designed for continuous
operation. The appliance may be used for a maxi-
mum of 20 minutes of continuous operation. If the
appliance overheats, remove the battery pack .
Allow the appliance to cool down completely and
then try using it again.
Inflation
♦ Remove the valve cap of the item you want to
inflate.
♦ Fit the appropriate adapter , or onto
the pump air outlet .
♦ Push the adapter , or into the valve of
the item to be inflated.
♦ Switch the appliance on by pressing the ON/
OFF switch .
♦ Once the desired level of inflation has been
reached, switch off the appliance by releasing
the ON/OFF switch .
♦ Now remove the adapter , or .
♦ Replace the valve cap on the item that you have
inflated.
Deflation
♦ Fit the appropriate adapter , or onto
the pump air inlet .
♦ Remove the valve cap of the item you want to
deflate and push the adapter , or into
the valve of the item to be deflated.
♦ Switch the appliance on by pressing and holding
the ON/OFF switch .
♦ Once the item is fully deflated, switch off the ap-
pliance by releasing the ON/OFF switch .
♦ Now remove the adapter , or .
Adapters
Adapter :
For standard valves with an internal diameter of
8 mm.
Adapter :
For inflatable items with a screw valve. Deflation
is only possible with an unscrewed valve and with
this adapter.
Adapter :
For inflatable items with a deflation valve.
NOTE
► The LED working light is lit when the ON/
OFF switch is lightly or fully depressed.
This allows illumination of the working area
while inflating in low light conditions.

PAK 16 A1 / PALP 16 A1 GB│CY │ 9 ■
Operating the cordless
compressor PAK 16 A1
This appliance is not designed for continuous
operation. The appliance may be used for a maxi-
mum of 10 minutes continuous operation. If the
appliance overheats, remove the battery pack .
Allow the appliance to cool down completely and
then try using it again.
Display indicator
♦ Press the ON/OFF switch on the display
or press the ON/OFF switch to switch on
the display indicator .
♦ The last set pressure is displayed for 2 seconds.
♦ After two seconds, the current pressure of the
connected item is shown.
NOTE
► If the compressed air hose is not connected
to a suitable item, the display indicator
shows "0".
♦ If the display indicator is switched on, you
can switch between "bar" and "psi" by pressing
the ON/OFF button .
♦ To switch off the display indicator , press the
ON/OFF button for 3 seconds.
NOTE
► The compressor will not work if the display
indicator is switched off.
Setting the pressure
♦ Hold down the "+" or "–" button until the
display flashes.
♦ Press the "+" or "–" button to set the
desired pressure.
♦ Once you see the desired pressure on the
display indicator , do not press any button
for about 3 seconds.
The desired pressure is now set.
NOTE
► The display indicator (and thus the com-
pressor) switches off after around three
minutes of inactivity.
TIP
► If you press and hold the "+" or "–"
button, the pressure changes quickly.
Initial operation
♦ Loosen the cap nut (do not unscrew it com-
pletely!), twist in the compressed air hose
threaded connection 22a and retighten the
cap nut .
♦ Select the desired pressure.
♦ Screw one of the supplied adapters ( , , ,
, , ) tightly onto the compressed air hose
adapter .
♦ Connect the adapter , , , , or
to the object to be inflated.
♦ Press the ON/OFF switch .
♦ The compressor switches off automatically when
you reach the preset pressure.
♦ Pull the adapter , , , , or out of
the now inflated item.

PAK 16 A1 / PALP 16 A1
■ 10 │ GB│CY
Adapters
Adapter
The ball needle can be used to inflate various balls.
Adapter
The Presta valve can be used for inflating bicycle
tyres.
Adapter
The Dunlop valve can be used for inflating bicycle
tyres.
Adapter
The universal adapter can be used to inflate air
mattresses or similar.
Adapter
For inflating pool toys, etc.
Adapter
The universal adapter can be used to inflate air
mattresses or similar.
Maintenance, storage and
cleaning
WARNING!
RISK OF ELECTRIC SHOCK! Before
cleaning, disconnect the charger
from the mains socket.
NOTE
► Before carrying out any work on the appli-
ance, ensure that the battery pack has
been removed. This prevents unintentional
switching on.
■ The cordless appliances are maintenance-free.
■ The appliances must always be clean, dry and
free from oil or grease.
■ Never allow liquids to get into the appliances.
■ Use a soft cloth to clean the housing. Never use
petrol, solvents or cleansers which can damage
plastic.
■ Always ensure the appliances and attachments
are clean, free of dust and dry before storing.
■ If you do not intend to use the appliances for an
extended period, remove the batteries and store
them in a clean, dry place away from direct
sunlight.
■ If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
■ Never try to repair damaged batteries. Main-
tenance of batteries should only be carried out
by the manufacturer or an approved customer
service centre.
NOTE
► Replacement parts not listed (such as batteries,
battery charger) can be ordered via our
service hotline.

PAK 16 A1 / PALP 16 A1 GB│CY │ 11 ■
Disposal
The packaging consists of environmentally
friendly material. It can be disposed of in
the local recycling containers.
Do not dispose of power tools in
your normal domestic waste!
European Directive 2012/19/EU requires that
worn-out power tools be collected separately and
recycled in an environmentally compatible manner.
Do not dispose of batteries in your
normal household waste!
Defective or worn-out rechargeable batteries must
be recycled according to Directive 2006/66/EC.
Take the battery pack and/or appliance to a
nearby collection facility.
Please consult your local authorities regarding
suitable disposal of worn out power tools/battery
packs.
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from
the date of purchase. If this product has any faults,
you, the buyer, have certain statutory rights. Your
statutory rights are not restricted in any way by the
warranty described below.
Warranty conditions
The validity period of the warranty starts from the
date of purchase. Please keep your original receipt
in a safe place. This document will be required as
proof of purchase.
If any material or production fault occurs within three
years of the date of purchase of the product, we
will either repair or replace the product for you at
our discretion. This warranty service is dependent
on you presenting the defective appliance and
the proof of purchase (receipt) and a short written
description of the fault and its time of occurrence.
If the defect is covered by the warranty, your prod-
uct will either be repaired or replaced by us. The
repair or replacement of a product does not signify
the beginning of a new warranty period.
Warranty period and statutory claims for
defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accord-
ance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product
parts subject to normal wear and tear or fragile
parts such as switches, batteries, baking moulds or
parts made of glass.

PAK 16 A1 / PALP 16 A1
■ 12 │ GB│CY
The warranty does not apply if the product has
been damaged, improperly used or improperly
maintained. The directions in the operating instruc-
tions for the product regarding proper use of the
product are to be strictly followed. Uses and
actions that are discouraged in the operating
instructions or which are warned against must be
avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications/ repairs
which have not been carried out by one of our
authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(e.g. IAN 12345) available as proof of pur-
chase.
■ You will find the item number on the type plate,
an engraving on the front page of the instruc-
tions (bottom left), or as a sticker on the rear or
bottom of the appliance.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be pro-
vided to you. Ensure that you enclose the proof
of purchase (till receipt) and information about
what the defect is and when it occurred.
NOTE
► For Parkside and Florabest tools, please send
us only the defective item without the acces-
sories (e.g. battery, storage case, assembly
tools, etc.).
You can download these instructions
along with many other manuals, product
videos and software on
www.lidl-service.com.
Service
WARNING!
■Have the power tool repaired by the
service centre or a qualified electrician and
only using genuine replacement parts.This
will ensure that the safety of the appliance is
maintained.
WARNING!
■Always ensure that the power plug or
the mains cable is replaced only by the
manufacturer of the appliance or by an
approved customer service provider.This
will ensure that the safety of the appliance is
maintained.
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: [email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: [email protected]
IAN 280447
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PAK 16 A1 / PALP 16 A1 GB│CY │ 13 ■
Translation of the original
Conformity Declaration
We, KOMPERNASS HANDELS GMBH, docu-
ment officer: Mr. Semi Uguzlu, BURGSTR. 21,
44867 BOCHUM, GERMANY, hereby declare
that this product complies with the following
standards, normative documents and EC directives:
Machinery Directive
(2006/42/EC)
EC Low Voltage Directive
(2014/35/EU)
EMC (Electromagnetic Compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)*
*The manufacturer bears the full responsibility for compli-
ance with this conformity declaration. The object of the
declaration described above complies with the require-
ments of the Directive 2011/65/EU of the European
Parliament and Council of 8 June 2011 on the limitations
of use of certain dangerous substances in electrical and
electronic appliances.
Applied harmonised standards:
EN 60745-1:2009/A11:2010
EN ISO 12100:2010
EN 60335-1:2012/A11:2014
EN 60335-2-29:2004/A2:2010
EN 62233:2008
EN 55014-1:2006/A2:2011
EN 55014-2:1997/A2:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
Type designation of machine:
Cordless compressor PAK 16 A1
Cordless air pump PALP 16 A1
Year of manufacture: 10 - 2016
Serial number: IAN 280447
Bochum, 18/10/2016
Semi Uguzlu
- Quality Manager -
We reserve the right to technical changes in the
context of further product development.

PAK 16 A1 / PALP 16 A1
■ 14 │ GB│CY

PAK 16 A1 / PALP 16 A1 RO │ 15 ■
Cuprins
Introducere .....................................................16
Utilizarea conform destinaţiei..................................................16
Dotare ...................................................................16
Date tehnice ...............................................................17
Indicaţii generale privind siguranţa .................................18
1. Siguranţa zonei de lucru ...................................................18
2. Siguranţa electrică ........................................................ 18
3. Siguranţa persoanelor .....................................................19
4. Utilizarea şi manevrarea sculei electrice ....................................... 19
5. Utilizarea şi manevrarea sculei cu acumulator................................... 20
6. Service .................................................................20
Indicaţii extinse privind siguranţa ............................................... 20
Indicaţii de siguranţă pentru încărcătoare şi suflante ................................21
Înainte de punerea în funcţiune: ....................................21
Încărcarea setului de acumulatori (a se vedea fig. A) ...............................21
Introducerea/scoaterea setului de acumulatori ....................................22
Operarea pompă de aer cu acumulator PALP 16 A1 ...................22
Pomparea/umflarea......................................................... 22
Evacuarea prin pompare/aspirarea ............................................ 22
Adaptor..................................................................22
Operarea compresor cu acumulator PAK 16 A1 .......................23
Afişaj ....................................................................23
Reglarea presiunii...........................................................23
Punerea în funcţiune..............................................23
Adaptor..................................................................24
Întreţinerea, depozitarea şi curăţarea ...............................24
Eliminarea ......................................................25
Garanţia Kompernass Handels GmbH ...............................25
Service .........................................................27
Importator......................................................27
Traducerea declaraţiei de conformitate originale ......................27

PAK 16 A1 / PALP 16 A1
■ 16 │ RO
COMPRESOR CU ACUMULATOR
PAK 16 A1
POMPĂ DE AER CU ACUMULA-
TOR PALP 16 A1
Introducere
Vă felicităm pentru cumpărarea noului dvs. aparat.
Aţi decis să alegeţi un produs de calitate superioară.
Instrucţiunile de utilizare fac parte integrantă din
acest produs. Acestea cuprind informaţii importante
privind siguranţa, utilizarea şi eliminarea. Înainte
de utilizarea produsului familiarizaţi-vă cu toate
indicaţiile privind utilizarea şi siguranţa. Utilizaţi
produsul numai în modul descris şi numai în scopu-
rile menţionate. În cazul transmiterii produsului unei
alte persoane, predaţi-i toate documentele aferente
acestuia.
Utilizarea conform destinaţiei
Compresor cu acumulator PAK 16 A1:
Aparatul este destinat umflării anvelopelor de
bicicletă şi a articolelor gonflabile de joacă, sport
şi de plajă, însă nu este conceput pentru umflarea
articolelor gonflabile voluminoase precum bărci
pneumatice şi saltele mari. Compresorul este adec-
vat şi pentru măsurarea presiunii la un moment dat.
Indicatorul de presiune nu este calibrat.
Compresorul nu este adecvat pentru umflarea
anvelopelor de automobil.
Pompă de aer cu acumulator PALP 16 A1:
Aparatul este destinat umflării şi dezaerării saltele-
lor şi bărcilor pneumatice, bazinelor de scăldat şi
altor articole gonflabile voluminoase pentru uzul
privat. Aparatul nu este adecvat pentru umflarea
anvelopelor de bicicletă sau de automobil.
Aparatele nu sunt destinate utilizării în scopuri
comerciale. Orice altă utilizare sau modificare
a aparatelor este considerată a fi neconformă şi
atrage după sine pericole serioase de accidentare.
Producătorul nu îşi asumă răspunderea pentru
prejudiciile rezultate în urma unei utilizări care
contravine destinaţiei.
INDICAŢIE
► Instrucţiunile de utilizare trebuie păstrate
permanent în imediata apropiere a compre-
sorului şi trebuie să fie disponibile pentru
personalul de deservire.
Dotare
Admisia aerului
Set de acumulatori
Tastă pentru nivelul acumulatorului
Led indicator acumulator
Tastă de deblocare a setului de acumulatori
Comutator PORNIT/OPRIT
Lampă de lucru cu led
Evacuarea aerului
Adaptor
Adaptor
Adaptor
Afişaj
Tastă „+”
Tastă PORNIT/OPRIT pe afişaj
Tastă „‒”
Set de acumulatori
Tastă pentru nivelul acumulatorului
Led indicator acumulator
Tastă de deblocare a setului de acumulatori
Comutator PORNIT/OPRIT
Lampă de lucru cu led
Adaptor pentru ventil al furtunului de
aer comprimat
22a Racord filetat al furtunului de aer comprimat
Piuliţă olandeză
Furtun de aer comprimat
Ac pentru umflat mingi
Adaptor pentru ventil
Adaptor pentru ventil
Adaptor universal
Adaptor universal
Adaptor universal
Încărcător rapid
Led roşu de control al încărcării
Led verde de control al încărcării
