PARRY 1832 User manual

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 1 of 12
www.parry.co.uk
INSTALLATION INSTRUCTIONS
SAFETY INSTRUCTIONS
USER INSTRUCTIONS
CABINETS & PLATE WARMERS
MODEL: 1832/1863/1869/1868/1888/9214

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 2 of 12
www.parry.co.uk
IMPORTANT
Please read these instructions before you attempt to use the equipment. Keep these
instructions for future reference.
WARNING
To avoid scratching the highly polished exterior surface of this equipment whilst in
transit, the protective film on the exterior surfaces has NOT been removed.
It is IMPORTANT that this protective film is peeled off before the equipment is used.
WARNING
1. All electrical appliances/parts must be earthed.
2. No user-serviceable parts.
3. Isolate power supply before carrying out any installation work.
INSTALLATION
1. Choose a suitable site for your machine taking into consideration its, use, and any
heat that may be generated whilst in service.
2. Remove all protect film and packing material, and inspect for any damage which may
effect the machine’s electrical safety.
3. All appliances with an electrical loading above 3 kilowatts must be connected to a
suitable supply by qualified electrician, who should ensure that
a) Precaution is taken during installation regarding leakage current,
b) The means of isolation has a contact separation of at least 3mm on all poles, and
c) It is installed in accordance with Health and Safety at Work Act, BS Codes of
Practice, IEE Wiring Regulations and Building and Local Authority Standards.

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 3 of 12
www.parry.co.uk
ENSURE THAT ALL THE SHELVES ARE FIRMLY IN PLACE
OPERATING
1. Switch on power supply, the red lamp will indicate the power is ON
2. Turn the temperature dial to the required heat setting, the green lamp will show indicated
power to the element and will extinguish when the desired temperature is reached.
This procedure will be repeated automatically as the thermostat maintains a constant
temperature.
For the best results from your new plate warmer, pre-heat the machine by turning the
thermostat to maximum (80°C) for approximately 20minutes. We recommend that you load
each shelf with a maximum of 20 or 40 plates, depending on the width of the machine, giving
a total machine load of 80 or 160 plates. Anything above our advised limits may reduce the
efficiency of this machine
Fitting a Different Plug
Should you need to replace the plug connect the wires as follows:
Green/Yellow wire To EARTH terminal (╧)
Brown Wire To LIVE (L) terminal of new plug
Blue Wire To NEUTRAL (N) terminal of the new plug
Always fit the same value fuses as that originally supplied with your appliance. Only use
BS1362 approved fuses. As a guide only, appliances under 700w can have a 3 amp fuse (red)
and all others should have a 13 amp fuse (brown).
When disposing of an old plug (particularly the moulded type which has been cut from the
mains cord) always remove the fuse as the plug could be dangerous if ever inserted into a live
socket.

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 4 of 12
www.parry.co.uk
Cables
Appliances exceeding 3kw which are connected to a single phase supply should be wired
using 6mm² twin-and-earth flat cable, code designation 6242Y.
To connect a 3 phase and neutral supply, 5 wire 1.5mm² cable should be used with the code
designation HO5RRF. All flexible cables must comply to BS6500.
Access to the supply terminals at appliances exceeding 3kw is gained by the removal of the
panel at the rear of the appliance by four self-tapping screws. Pass the mains cable through
the hole in the panel and connect to the terminal block: see diagram on the reverse of panel
for the method which applies to your supply. After connection, ensure the back panel is firmly
secured back into position and the nylon cable is fitted.
Details of the machine current requirements are given on the rating label on the rear, and it
must be ensured that the correct type and rating or circuit breaker is used as protection for
your appliance.
Do Not Plug In Or Switch On Yet
Read the operating instructions for your appliance to make yourself familiar with its use. Also,
make sure whoever is operating the appliance is fully conversant with its working and aware of
the dangers of incorrect operation, or cleaning, especially the risk of burns and scalds from the
cooking medium, hot water or cooking plates.
We advise that these appliances should not be left unattended when switched on.

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 5 of 12
www.parry.co.uk
MAINTENANCE INSTRUCTIONS
Servicing
This appliance should be routinely serviced to prolong its lifetime. Parry recommends
that the appliance is serviced every 12 months by a Parry authorised engineer. Failure
to service your product within the initial 12 month warranty period will cause the 24
month warranty to become void.
MAINTENANCE AND SERVICE MUST ONLY BE UNDERTAKEN BY A QUALIFIED
ELECTRICIAN.
Wiring Diagrams
For units 1832, 1863, 1869, 1868 and 9214 use this wiring diagram

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 6 of 12
www.parry.co.uk
For units 1888 use this wiring
diagram

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 7 of 12
www.parry.co.uk
SPARES LIST
PART DESCRIPTION
PART CODE
1832
1863
1869
1868
1888
9214
Element Clamp
AS2640ELC
1
5
5
5
3
5
Single Bezel
BEZELCBOX
1
1
1
1
1
Black Nylon bush SB500-6
BUPL50006
1
Black nylon bush SR6P30CEE
BUSR06003
1
1
1
1
1
CABLE CLIP 50073092
CABLECLIP
1
125MM RUBBER TYRED 13MM
BOLT HOLE
CASTR0125
2
125MM RUBBER TYRED 13MM
BOLT HOLE CASTOR
CASTRB125
2
Kilp 15 Magnet catch
DRCT00015
1
2
2
1
2
2
New platewarmer element
ELPW02000/1
1
1
1
1
1
1
1.5MM SQ CURLEY CABLE
BLACK 400MM
FLEXBK13A
1
Cabinet Loom Live 1525MM &
180MM
HACABL001
1
1
1
1
Cabinet Loom Live 710MM &
180MM
HACABL003
1
1
1
1
1
CABINET LOOM LIVE 1880MM
HACABL005
2
CABINET LOOM LIVE 635MM
HACABL006
1
Cabinet Loom Neutral 1525MM &
100MM
HACABN001
1
1
1
1
Cabinet Loom Neutral 710MM
HACABN002
1
1
1
1
1
CABINET LOOM NEUTRAL
1270MM
HACABN005
2
Two Piece Handle
HANDLECAB
1
2
2
1
2
2
ALUMINIUM HANDLE SUPPORT
HANDLESUP
1
Adjustable foot
INBK025SG
4
4
4
4
4
Knob 30 –80C
KNOBTYPEB
1
1
1
1
1
1
S/LAMP Black/Green 30x11
LNGN06378
2
1
S/LAMP Black/Red 30x11
LNRE06178
1
1
1
S/LAMP RED 6.3 TABS TBF010S
LNRE2211P
1
S/LAMP Green
LNGN2211P
1
1
Mains Cable H05RR-F black 2M 3
core
MAINSLEAD
1
1
1
1
1
Parry Nameplate
NAMEPLATE
1
1
1
1
1
1
M5 Full Nut BZP
NUST21000
8
8
LEG MOUNTING PLATE –STEEL
WITH 3MM
OVENLGPLT
4
2mm laser cut plate warmer hinge
PLATEWHINGE
1
2
2
1
2
BLIND RIVET NUT STEEL SML
HD M5 7X12.5
RIVNUTSM5
2
4
BLIND RIVET NUT STEEL M8 11X
17
RIVNUTSM8
4

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 8 of 12
www.parry.co.uk
AVEX1/8STL L/PROF Z/P ASSY
POP RIVET
RVCP00424
21
35
87
M5 X 30MM SLOTTED PAN HD
BZP SCREW
SCST04006
2
M5 X 12 SLTD POZI PAN HD
SCREW BZP
SCST23012
3
24
6
M5 40MM PAN HD SCREW ZINC
BZP
SCST21038
3
“1/4 WHIT HEXHD ½ “” M/S SET
SCREW
SCST60012
2
*NO.6 X ½””POZI PAN SELF
TAPPER BZP”
SEMS74B30
4
8
4
Mains cable termination bracket 3KW
TERMBKT1
1
1
1
1
1
1
EGO Thermostat
TMST13012
1
1
1
1
1
1
Plate Warmer 525mm x 360mm
TRPW00525
2
3
Plate Warmer rack 600mm x 500mm
TRWC00600
4
3
WARMER CABINET TRAY
1000MM X 500MM
TRWC01000
2
WARMER CABINET TRAY 745MM
X 500MM
TRWC00750
3
2BA FLAT WASHER NICKEL
PLATED
WAFL20003
3
2BA SINGLE COIL SPRING
WASHER
WASC20000
7
4
6
M12 X 36MM X 2M WASHER
ZINC/YELLOW
WASH03818
4
Warranty Policy
The manufacturer’s warranty is only valid in the UK mainland. Northern Ireland,
Western Isles, Inner Hebrides and Islands are parts only warranty.
All service calls will be carried out between the hours of 8.00am –5.00pm Monday to
Friday only.
We accept no responsibility for delays in replacing or repairing the equipment due to
circumstances beyond our control.
Your warranty can be immediately invalid if the installation of the equipment has not
been carried out in accordance with the manufacturer’s instructions. (See installation
details). Also the misuse, alteration or unauthorised repairs of the equipment will
invalidate the warranty.
During the warranty period it is at Parry’s discretion to repair or replace the equipment.

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 9 of 12
www.parry.co.uk
Warranty only applies if the equipment has been used in a professional manner
following the manufacturer’s instructions and maintenance guide lines.
The warranty covers defects in the material and component failure only. We are not
liable for trading loss, loss of perishable items, water damage, loss due to injury or fire
damage.
Please be aware that the warranty starts from the date of purchase from Parry and not
the sale or installation date of the equipment.
Warranty Request
Please ensure you have referred to the manufacturers’ instructions before placing a
warranty call. Or contact our warranty department on 01757 213909 for technical
assistance, ensure you obtain the model number before calling.
Please ensure you have read the section not covered under warranty to avoid any
unnecessary warranty charges.
It is vital that all warranty requests be submitted to Parry via email to
[email protected]
It is at the discretion of PARRY whether to honour a service call which is out of the
warranty period.
Not Covered Under Warranty
• Fault due to poor maintenance.
• Resetting of equipment or circuit breakers.
• Abuse of the equipment
• Foil should never be used on racks
• Blockages e.g., drains, condensers, pumps etc.
• Lime scale related issues
• Installed incorrectly
• Access arranged for service call and engineer refused access or customer not there.

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 10 of 12
www.parry.co.uk
• No faults with the machine.
• Setting up of equipment e.g., dishwasher detergents, levelling and setting up of doors on a 6
burner cooker.
• Excessive carbon build up on griddle plates.
• Over use of lava rock on the chargrills. Parry recommends maximum of 2kg.
• Faulty electrics – e.g., customers plug socket, plug, wiring, junction box fault, wrong fuse.
• Any damages caused by the customer.
• Lamps, glass, door gaskets, Perspex, baskets, knobs all perishable items are not covered.
This appliance should be routinely serviced to prolong its lifetime. Parry recommends that the
appliance is serviced every 12 months by a Parry authorised engineer. Failure to service your
product within the initial 12 month warranty period will cause the 24 month warranty to become
void.

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 11 of 12
www.parry.co.uk
Disposal Information
This appliance is marked according to the European Directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health which could otherwise be caused by
inappropriate waste handling of this product.
A symbol on the product, or on the documents accompanying the product, indicates that this
appliance may not be treated as household waste. Instead it should be handed over to the
applicable collection point for the recycling of electrical and electronic equipment.
Disposal must be carried out in accordance with local environmental regulations for waste
disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local city office, your household waste disposal service or the shop where you
purchased the product.
Parry Catering recognises our obligations to the EU DIRECTIVE covering the waste disposal
of electrical and electronic equipment (WEEE) Parry Catering are committed to this policy in
order to help conserve the environment.
At the end of this units life you MUST dispose of it in an approved manner. You MUST not
discard the unit or place it in the refuse bin.

INSTRUCTIONS REF :IN111
ISSUE NUMBER : 3
DATE 10.08.15
PAGE 12 of 12
www.parry.co.uk
You have several options:
a) Take the unit to an approved WEEE scheme company, there will be one in your area.
b) Take the unit to an approved waste disposal site; many sites are managed by your local
authority.
Contact the units manufacturer, importer or their agent; the contact details will be on the unit.
There will probably be a charge for this service which will depend on the physical size and
location of the unit. You will be given a collection price for a curb side collection based on
commercial rates prevailing at the time.
It should be noted that the unit to be collected should be suitably packed and sealed to prevent
dangerous gases and fluids from escaping. The condition of the unit must also be clean to
comply with health and safety regulations.
Parry Group Ltd,
Town End Road,
Draycott,
Derby,
England,
DE72 3PT
