Patron PATRON E9 User manual

1Patron E9 -12/00
USER’S MANUAL FOR
PATRON E9
ELECTRIC FAN HEATER
(12/00)
IMPORTANT
READ AND UNDERSTAND THIS MANUAL
BEFORE ASSEMBLING, STARTING OR
SERVICING THE HEATER.
IMPROPER USE OF HEATER CAN CAUSE
SERIOUS INJURY.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
FOR PROFESSIONAL USE ONLY

2Patron E9 -12/00
READ ALL INSTRUCTIONS BEFORE USING THIS HEATER
1. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Use handle when moving this heater. Keep combustible materials at least 6 feet (2 me-
ter) from the front of the heater and keep them away from sides and rear
2. Extreme caution is necessary when the heater is used near children or invalids and
whenever the heater is left unattended
3. Always unplug the heater when not in use
4. Do not operate any heater with a damaged cord or plug or after the heater malfunc-
tions, has been dropped or damaged in any manner. Return heater to authorized serv-
ice facility for examination, electrical or mechanical adjustment or repair
5. Do not expose to rain, water spray or dripping water
6. This heater is not intended for use in bathrooms, laundry areas and similar indoor loca-
tions. Never locate the heater where it may fall into a bathtub or other liquid container
7. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or the like.
Arrange cord away from traffic area and where it will not be tripped over
8. To disconnect heater, turn controls to off, then remove plug from outlet
9. Connect to properly grounded outlets only
10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater
11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not
use on soft surfaces, where openings may become blocked
12. A heater has hot and arcing or sparking parts inside. Do not use in areas where gaso-
line, paint or flammable liquids are used or stored
13. Do not point to flammable materials
14. Use heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock or injury to persons
15. Avoid use of an extension cord because it may overheat and cause a risk of fire. How-
ever, if you have to use an extension cord, the cord shall be a three (3) wire grounded
cord (check minimum size from specifications)

3Patron E9 -12/00
1. GENERAL INFORMATION FOR USER
Patron electric heaters are designed for professional use.
The heat is generated in sealed heating elements inside the inner mantle of the
heater. Heated air is then distributed by an electric motor driven fan blowing air
through the heater.
Although effectively cooled by the fan, the heating elements have high surface tem-
peratures. That is why combustible materials must be kept at a safe distance from
the heater and care must be taken that no combustible particles enter the heater
with the air sucked in by the fan.
Keep the heater clean of dust at any time. Dust may cause fire when heated.
Make sure that the fan blades may rotate unobstructed at all times.
Do not block air intakes or exhaust in any manner.
2. LIMITED WARRANTY
PATRON heater products are professional construction heaters. They are warranted for
twenty-four (24) months from original date of purchase. The warranty does not cover
products modified outside our factory, damage or failure caused by acts of God, abuse,
misuse, use on other than rated voltage, abnormal usage, faulty or improper installation,
failure to provide recommended maintenance or any repairs other than those provided by
an authorized PATRON service.
THERE ARE NO OBLIGATIONS OR LIABILITIES ON THE PART OF PATRON PROD-
UCTS INC. FOR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN CONNECTION
WITH THE USE OR PERFORMANCE OF THE PRODUCT OR OTHER INDIRECT
DAMAGES WITH RESPECT TO LOSS OF PROPERTY, REVENUES, OR PROFIT, OR
COST OF REMOVAL, INSTALLATION OR REINSTALLATION.
THIS WARRANTY CONSTITUTES THE EXCLUSIVE REMEDY OF ANY PURCHASER
OF EQUIPMENT SOLD BYTHE MANUFACTURER AND ITS DEALERS AND DISTRIBU-
TORS AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
During the warranty period, Patron Products will, at its sole option, repair or replace any
defective parts or products returned, freight prepaid, to Patron Products or such other lo-
cation as Patron Products may designate.
Returned products must be packaged carefully, and Patron Products shall not be respon-
sible for damage in transit. When returning parts, the owner must provide the model num-
ber of the product and the nature of difficulty being experienced. This warranty does not
oblige Patron Products to bear the cost of labour in replacing any assembly, unit or com-
ponent or part thereof, nor does the company assume any liability for secondary charges,
expenses of removal or installing, freight or damages. There will be charges rendered for
product repair after our warranty period has expired. Proof of purchase, including date,
must accompany request for in-warranty service.

4Patron E9 -12/00
3. OPERATION
REVIEW AND UNDERSTAND ALL WARNINGS IN THIS MANUAL.
THEY ARE ESSENTIAL FOR SAFE USE OF THE HEATER.
FOLLOW ALL LOCAL CODES.
This heater is for use on 240 volts.
The cord has a plug as shown in the figure.
The type of outlet is a 240-volt grounding outlet. When properly installed, it provides
a ground connection through the cord to the heater to protect the operator from elec-
tric shock.
TO START HEATING:
1. Place the heater on a stable and level surface. Make sure that no explosive or
combustible fumes or dust are present
2. Connect power cord of heater into 240 V / 60 Hz power source. See paragraph
“Technical specifications” in this manual for correct amperage rating
3. Turn the toggle switch into position “on” and the fan starts
4. Set the room thermostat to a temperature above the ambient room temperature
by turning the knob. Note! The heater will heat up only if the thermostat “calls for
heat” meaning that it is set to higher than prevailing ambient temperature
5. The heater will now operate automatically, controlled by the thermostats
TO STOP HEATING:
2. Turn the room thermostat into “0” position
3. Let the fan rotate for 1-2 minutes to cooldown the heater
4. Turn the toggle switch into position “off”
5. Disconnect the power supply plug
NOTE!
THE HEATER IS EQUIPPED WITH AN OVERHEAT LIMIT SWITCH WHICH
MAY CAUSE THE HEATER TO STOP.
CHECK AND REMOVE THE CAUSE FOR OVERHEATING BEFORE RE-
STARTING.
MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS:
OUTLET = 6 feet SIDES = 1 foot
TOP = 2 feet REAR = 2 feet
FLOOR = COMBUSTIBLE
Grounding pin
G

5Patron E9 -12/00
4. MAINTENANCE
WARNING!
NEVER SERVICE THE HEATER WHILE IT IS PLUGGED IN, RUNNING OR
HOT. SEVERE BODILY INJURE OR ELECTRIC SHOCK MAY OCCUR.
ONLY QUALIFIED PERSONS ARE ALLOWED TO OPEN HEATER FOR
SERVICE. NO USER-SERVICEABLE PARTS INSIDE.
•Keep heater clean. Use pressurized air to blow fan blades clean. Note! Use
moderate pressure to avoid damage to fan blades
•Inspect heater before and after each use
•The fan motor is sealed and has permanently lubricated bearings
5. STORAGE
When not in use, the heater must be disconnected from power source, cleaned of
dust and stored in a dry place.
The power supply cord should be loosely wound around the handle of the heater.
6. TECHNICAL SPECIFICATIONS
MODEL PATRON E9
Heat output BTU/hr 30,700 (9,000 W)
Air flow CFM 350 (600 m³/h)
Electric connection V ac / Hz 240 / 60, single phase
Amperage draw A37.5
Power cord 3×8 AWG
Plug NEMA 6-50P
Extension cord min. 3×8 AWG
Ambient thermostat Temp. range 32 ... 100 °F (0 ... 40 °C)
Length inches 23.0 (585 mm)
Width inches 11.8 (300 mm)
Height inches 18.3 (465 mm)
Weight lbs 39.9 (18.1 kg)

6Patron E9 -12/00
7. EXPLODED VIEW
Pos. Patron E9 -Code #
1bottom plate plaque de fond 4008001
2front panel panneau avant 4008002
3rear panel panneau arriere 4008003
4outer mantle carcasse 4008004
5inner mantle cheminee interieure 4008005
6handle poignee 80100
7heating element (3 pcs) element (3 pcs) 42800
8fan motor motor du ventilateur 14201
9fan blade pales du ventilateur 16110
10 contactor contacteurs 22570
11 room thermostat + knob thermostat ambiant 20210+20575
12 toggle switch interrupteur 26900
13 strain reliever retenue de fil 36930
14 overheat limit switch disjoncteur de surchauffe 21200
—hub for fan moyeu 17909

7Patron E9 -12/00
Pos. Patron E9 -Code #
Ccontactor contacteurs 22570
Mfan motor motor du ventilateur 14201
R1...3 heating element element 42800
S1 toggle switch interrupteur 26900
S2 room thermostat thermostat ambiant 20210
S3 overheat limit switch disjoncteur de surchauffe 21200
X1 terminal block bloc terminal 36703
X2 grounding lug bloc terre —
X3 power cord & plug fil electrique & fiche —
t
8. WIRING DIAGRAM

8Patron E9 -12/00
