PCE Instruments PCE-CMM 10 User manual

© PCE Instruments
PCE-CMM 10 CO2analyser
User Manual
User manuals in various languages (français,
italiano, español, português, nederlands, türk, polski,
русский, 中文) can be found by using our
product search on: www.pce-instruments.com
Last change: 27 November 2020
v1.0
English

© PCE Instruments
Contents
1Safety notes........................................................................................... 1
2System description............................................................................... 2
2.1 Device.............................................................................................................................. 2
2.2 Display............................................................................................................................. 3
2.3 Function keys................................................................................................................... 3
2.4 Terms / icons ................................................................................................................... 3
3Technical specifications ...................................................................... 4
4Operation ............................................................................................... 5
4.1 On / off............................................................................................................................. 5
4.2 Temperature .................................................................................................................... 5
4.3 Alarm ............................................................................................................................... 5
4.4 Measurement mode......................................................................................................... 5
4.5 Backlight.......................................................................................................................... 5
4.6 Automatic power-off ......................................................................................................... 5
4.7 Charging the battery......................................................................................................... 5
4.8 Date / time........................................................................................................................ 6
5Calibration ............................................................................................. 6
5.1 Automatic calibration........................................................................................................ 6
5.2 Manual calibration............................................................................................................ 6
6Warranty.................................................................................................7
7Disposal ................................................................................................. 7

© PCE Instruments
1
1 Safety notes
Please read this manual carefully and completely before you use the device for the first time. The
device may only be used by qualified personnel and repaired by PCE Instruments personnel.
Damage or injuries caused by non-observance of the manual are excluded from our liability and
not covered by our warranty.
•The device must only be used as described inthis instructionmanual. If used otherwise,
this can cause dangerous situations for the user and damage to the meter.
•The instrument may only be used if the environmental conditions (temperature, relative
humidity, …) are within the ranges stated in the technical specifications. Do not expose
the device to extreme temperatures, direct sunlight, extreme humidity or moisture.
•Do not expose the device to shocks or strong vibrations.
•The case should only be opened by qualified PCE Instruments personnel.
•Never use the instrument when your hands are wet.
•You must not make any technical changes to the device.
•The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,
no abrasives or solvents.
•The device must only be used with accessories from PCE Instruments or equivalent.
•Before each use, inspect the case for visible damage. If any damage is visible, do not
use the device.
•Do not use the instrument in explosive atmospheres.
•The measurement range as stated in the specifications must not be exceeded under
any circumstances.
•Non-observance of the safety notes can cause damage to the device and injuries to
the user.
We do not assume liability for printing errors or any other mistakes in this manual.
We expressly point to our general guarantee terms which can be found in our general terms of
business.
If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.

© PCE Instruments
2
2 System description
2.1 Device
①
Case
③
USB socket
②
Display
③
Function keys

© PCE Instruments
3
2.2 Display
①
Audio alarm indicator
②
Mode indicator
③
Calibration indicator
④
Automatic power-off
⑤
Battery status
⑥
Cancel calibration
⑦
Measured CO2value
⑧
Emoticon CO2value
⑨
Air humidity
⑩
Date / time
⑪
Temperature
⑫
Freeze displayed measured value
2.3 Function keys
2.4 Terms / icons
Symbol
Measurement modality
HOLD
Freeze measured values
MAX
Maximum measured value
MIN
Minimum measured value
AVG
Average measured value
TWA
Time weighted average (8 hours)
STEL
Short-term exposure limit (15 minutes weighted average)

© PCE Instruments
4
Emoticons
Emoticon
CO2reading range
400ppm ~ 450ppm
450ppm ~ 700ppm
700ppm ~ 1000ppm
1000ppm ~ 2000ppm
2000ppm ~ 5000ppm
>5000ppm
3 Technical specifications
Specification
Description
Measurement range CO2
400 ... 5000 ppm
Resolution
1 ppm
Accuracy
±(5 % + 50 ppm) between 400 ... 2000 ppm
and at an atmospheric pressure of 1013 mbar
Measurement range temperature
-10.0 ... 50.0 °C
Resolution
0.1 °C
Accuracy
±1 °C
(may be influenced by meter’s waste heat)
Measurement range air humidity
0 ... 99 % RH
Resolution
1 % RH
Accuracy
±(5 % at 25 °C) between 10 ... 90 % RH
Sensor
NDIR principle
ABC
Automatic baseline correction
Audio alarm
Buzzer
Visual alarm
Red backlight
Display
3-inch LC display
Battery status
Four-level display
Display frequency
3 seconds
Automatic power-off
switches itself off after 2 hours
Backlight
white backlight
Operating conditions
0 ... 50 °C, 0 ... 85 % RH
Storage conditions
-20 ... 60 °C, 0 ... 95 % RH
Power supply
integrated rechargeable 3.7 VDC battery
Weight
195 g
Dimensions
75 x 55 x 130 mm

© PCE Instruments
5
4 Operation
4.1 On / off
On
To switch on the meter when it is switched off, press and hold the centre key for about 3
seconds. The meter starts with a 120-second warm-up phase.
Off
To switch off the meter when it is switched on, press and hold the centre key for approx. 3
seconds.
4.2 Temperature
Press and release the key to switch between the temperature units °C and °F.
4.3 Alarm
When 1000 ppm of CO2is reached, the unit switches to alarm mode.
This is indicated by means of an acoustic and a visual alarm.
Visual alarm:
The display background flashes red every second.
Audible alarm:
The beep sounds every second. To switch the acoustic warning off or on, press and hold the
key for about 3 seconds.
4.4 Measurement mode
Press the MODE key to switch between the different measurement modes. (see 2.4)
Press and hold the MODE key to delete the minimum, maximum and average values.
4.5 Backlight
When the meter is switched on, press the central key to switch the backlight on or off.
4.6 Automatic power-off
The unit switches off after 2 hours of inactivity (no operation by pressing a key) in battery mode.
This function is not active during mains operation. The unit then remains permanently switched
on.
4.7 Charging the battery
Fully charge the device using the USB cable supplied before using it for the first time.
Recharge the device when the battery status indicator shows the flat battery icon .
For example, use a USB plug-in mains adaptor (not included) with at least 1 A output power or
use a USB port on a PC that provides this power.

© PCE Instruments
6
4.8 Date / time
To set the dateand time, press and hold the + keys simultaneously when the meter is turned
off until the display switches on.
Press the key twice. The year flashes.
Use the keys and MODE to set the current year.
Press the key.
Use the keys and MODE to set the current month.
Press the key.
Use the and MODE keys to set the current day.
Press the key to switch to the hour setting.
Use the and MODE keys to set the current hour.
Press the key.
Use the and MODE keys to set the current minute.
Press the key.
Use the and MODE keys to set the current second.
Press the key to go to 12-hour or 24-hour setting mode.
Use the and MODE keys to select the mode.
To save your entries, press and hold the key until the icon appears on the display as a
confirmation.
Press and hold the + keys to exit setting mode.
5 Calibration
The unit was calibrated at the factory. If there are noticeable deviations in the measured values,
you can recalibrate the unit.
Two options are available for calibration.
5.1 Automatic calibration
The PCE-CMM 10 has an integrated self-correcting ABC (Automatic Baseline Correction)
algorithm for automatic adjustment of the base value.
To calibrate the meter, place it in an environment with fresh air for 3 days when it is switched
on. (The best result is achieved outside buildings)
Connect the instrument to an external power source for calibration.
The measured value is automatically adjusted.
The ABC function is permanently switched on and adjusts the base value at regular intervals in
case of low CO2pollution.
Do not use this meter in a closed environment where the CO2concentration remains relatively
high. This would negatively affect the self-correction of the device.
5.2 Manual calibration
Place the switched-on unit in an environment with fresh air for 20 minutes.
(The best results are achieved outside buildings)
When the meter is switched on, press and hold the and MODE keys and until the icon
appears on the display. The calibration takes about 10 minutes. Afterwards, the instrument
returns to measurement mode.

© PCE Instruments
7
6 Warranty
You can read our warranty terms in our General Business Terms which you can find here:
https://www.pce-instruments.com/english/terms.
7 Disposal
For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.
If you have any questions, please contact PCE Instruments.
