Manual
Digital Thermometer
PCE-T 390

[email protected]
2

Table of contents
1.  Features ............................................................................................................................................ 3
2.  Specifications .................................................................................................................................. 3
2-1 General Specifications ..................................................................................................................... 3
2-2 Electrical Specifications (23± 5 Ԩ ) .................................................................................................. 6
3.  Front Panel Description ...................................................................................................................... 7
4.  Measuring Procedure ........................................................................................................................ 8
4-1 Type K measurement ....................................................................................................................... 8
4-2 Type J/T/E/R/S measurement ........................................................................................................... 8
4-3 Pt 100 ohm measurement ................................................................................................................. 8
4-4 T1-T2 measurement ......................................................................................................................... 8
4-5 Data Hold ........................................................................................................................................ 9
4-6 Data Record ( Max., Min. reading ) .................................................................................................. 9
4-7 LCD Backlight ON/OFF .................................................................................................................. 9
5.  Datalogger ........................................................................................................................................ 9
5-1 Preparation before execute datalogger function ................................................................................ 9
5-2  Auto Datalogger ( Set sampling time
ؤ
1 second ) ................................................................... 10
5-3
 Manual Datalogger (Set sampling time = 0 second) ................................................................... 10
5-4 Check time information ................................................................................................................. 11
5-5 Check sampling time information .................................................................................................. 11
5-6 SD Card Data structure .................................................................................................................. 11
6.  Saving data from the SD card to the computer (EXCEL software) ............................................. 11
EXCEL data screen ( for example ) ....................................................................................................... 12
7. Advanced Setting........................................................................................................................... 12
7-1 Set clock time (Year/Month/Date, Hour/Minute/ Second) ............................................................... 13
7-2 Decimal point of SD card setting ................................................................................................... 13
7-3 Auto power OFF management ....................................................................................................... 13
7-4 Set beeper sound ON/OFF ............................................................................................................. 13
7-5 Select the Temp. unit to Cº or Fº .................................................................................................... 14
7-6 Set sampling time (Seconds) .......................................................................................................... 14
7-7 SD memory card Format ................................................................................................................ 14
8. Power Supply from DC Adapter ....................................................................................................... 14
9. Battery Replacement ......................................................................................................................... 14
10. RS232 PC Serial Interface ............................................................................................................... 15
11. Offeset Adjustment .......................................................................................................................... 16
11-1 Type K/J/T/E/R/S offset adjustment ............................................................................................. 16
11-2 Pt 100 ohm offset adjustment ....................................................................................................... 16
12. Optional Type K Temp. probe ........................................................................................................ 17
13. Patent ............................................................................................................................................... 18

[email protected]
3
1. Features
* Type K/J/T/E/R/S, Pt 100 ohm, measurement with 4 display.
* Show 4 channels display on the LCD at the same time.
* Type K: -100 to 1300 ℃ .
*
Type J: -100 to 1200 ℃ .
*
Pt 100 ohm: -199.9 to 850.0 ℃ .
*
℃ / ℉ , 0.1 degree/1 degree.
* 4 channels (T1, T2, T3, T4 ), T1-T2.
* Microcomputer circuit provides intelligent function and high accuracy.
* Offset adjustment for the Type K/J/T/E/R/S measurement.
* Offset adjustment for the Pt 100 measurement.
* Measuring unit can select to ℃ or ℉ .
* Real time SD memory card Datalogger, it Built-in Clock and Calendar, real time data recorder,
sampling time set from 1 second to 3600 seconds.
* Manual datalogger is available (set the sampling time to 0 second), during execute the manual
datalogger function, it can set the different position (location) No. (position 1 to position 99).
* Innovation and easy operation, computer is not need to setup extra software, after execute
datalogger, just take away the SD card from the meter and plug in the SD card into the computer, it
can down load the all the measured value with the time information ( year/month/date/
hour/minute/second ) to the Excel directly, then user can make the further data or graphic analysis
by themselves.
* SD card capacity: 1 GB to 16 GB.
* LCD with green light backlight, easy reading.
* Can default auto power off or manual power off.
* Data hold, record max. and min. reading.
* Microcomputer circuit, high accuracy.
* Power by UM3/AA (1.5 V) x 6 batteries or DC 9V adapter.
* RS232/USB PC COMPUTER interface.
* Heavy duty & compact housing case.
2. Specifications
2-1 General Specifications

[email protected]
4
Circuit Custom one-chip of microprocessor LSI
circuit.
Display L CD size : 52 mm x 38 mm
LCD with green backlight ( ON/OFF ).
Channels
T1, T2, T3, T4,
T1-T2.
Sensor type Type K thermocouple probe.
Type J/T/E/R/S thermocouple probe. PT
100
ohm probe
* Cooperate with an 0.00385 alpha
coefficient,
meet DIN IEC 751.
Res ol ut io n
0.1
Ԩ / 1 Ԩ , 0.1 Ԭ / 1 Ԭ .
Datalogger
Sampling Time
Setting range
Auto 1 second to 3600 seconds
@ Sampling time can set to 1 second,
but memory data may loss.
Manual
Push the data logger button
once
will save data one time.
@ Set the sampling time to
0 second.
@ Manual mode, can also select the
1 to 99 position ( Location ) no.
Memory Card SD memory card. 1 GB to 16 GB.
Advanced
setting
* Set clock time ( Year/Month/Date,
Hour/Minute/ Second )
* Decimal point of SD card setting
* Auto power OFF management
* Set beep Sound ON/OFF
* Set temperature unit to Cº or Fº
* Set sampling time
* SD memory card Format

[email protected]
5
Temperature
Compensation
Automatic temp. compensation for the
type K/J/T/E/R/S thermometer.
Linear
Compensation
Linear Compensation for the full range.
Offset
Adjustment
Available for Type K/J/T/E/R/S and
Pt 100 ohm.
Probe Input
Socket
Type K/J/T/E/R/S
2 pin
thermocouple socket.
Pt 100 ohm : Ea
r
p
hone socket.
Over Indication Show " - - - - ".
Data Hold Freeze the displa
y
readin
g
.
Memor
y
Recall Maximum &Minimum value.
Sampling Time
of Display
Approx. 1 second.
Data Output RS 232/USB PC computer interface.
* Connect the optional RS232 cable
UPCB-02 will get the RS232 plug.
* Connect the optional USB cable
USB-01 will get the USB plug.
Power off
Auto shut off saves battery life or
manual off b
y
push button.
Operating
Temperature
0
to 50 Cº.
Operating
Humidity
Less than 85% R.H.
Power Supply * Alkaline or heavy duty DC 1.5 V battery
(
UM3, AA ) x 6 PCs, or equivalent.
* DC 9V adapter input. ( AC/DC power
adapte
r
is optional
)
.
Power Current
Normal operation ( w/o SD card save
data
and LCD Backlight is OFF) :
A
pprox. DC 8.5 mA.
When SD card save the data but and
LCD Backlight is OFF) :
Approx. DC 30 mA.
* If LCD backlight on, the power
consumption
will increase approx.
14 mA.
Wei
g
ht
489
g
/1.08 LB.
Dimension
177
x 68 x 45 mm
(7.0
x 2.7x 1.9 inch)
Accessories
Included
*
Instruction manual......................1 PC

[email protected]
6
Optional
Accessories
*
Type K thermocouple probe.
TP-01, TP-02A. TP-03, TP-04
*
Pt 100 ohm probe, TP-101.
*
SD Card ( 1 GB )
*
SD Card ( 2 GB )
*
USB cable, USB-01.
*
RS232 cable, UPCB-02.
*
Data Acquisition software,
SW-U801-WIN.
*
AC to DC 9V adapter.
*
Hard carrying case, CA-06.
*
Soft carrying case, CA-05A.
2-2 Electrical Specifications (23± 5 ℃ )
PT 100 ohm:
Resolution Ran
g
e
A
ccurac
y
0.1 Cº -199.9 to 850.0 Cº ±
(
0.4 % + 1 Cº
)
0.1 Fº -327.0 to 999.9 Fº ±
(
0.4 % + 1.8 Fº
)
1 Fº 1000 to 1562 Fº ±
(
0.4 % + 2 Fº
)
* Pt 100 ohm
p
robe TP-101 is the o
p
tional accessor
y
.
Type K/J/T/E/R/S:
Senso
r
T
yp
eResolutio
n
Range
A
ccuracy
Type
K
0.1 Cº -50.1 to -100.0 Cº ±
(
0.4 % + 1
Cº
)
-50.0 to 999.9
Cº
±
(
0.4 % + 0.5 Cº
)
1 Cº 1000 to 1300
Cº
±
(
0.4 % + 1
Cº
)
0.1 Fº -58.1 to -148.0Fº ±
(
0.4 % + 1.8 Fº
)
-58.0 to 999.9
Fº
±
(
0.4 % + 1
Fº
)
1 Fº 1000 to 2372
Fº
±
(
0.4 % + 2
Fº
)
Type J
0.1 Cº -50.1 to -100.0 Ԩ ±
(
0.4 % + 1 Ԩ
)
-50.0 to 999.9 Ԩ ±
(
0.4 % + 0.5 Ԩ
)
1 Cº 1000 to 1150 Ԩ ±
(
0.4 % + 1 Ԩ
)
0.1 Ԭ -58.1 to -148.0 Ԭ ±
(
0.4 % + 1.8 Ԭ
)
-58.0 to 999.9 Ԭ ±
(
0.4 % + 1 Ԭ
)
1 Ԭ 1000 to 2102 Fº ±
(
0.4 % + 2 Ԭ
)
Type T
0.1 Ԩ -50.1 to -100.0 Ԩ ±
(
0.4 % + 1 Ԩ
)
-50.0 to 400.0 Ԩ ±
(
0.4 % + 0.5 Ԩ
)
0.1 Ԭ -58.1 to -148.0 Ԭ ±
(
0.4 % + 1.8 Ԭ
)
-58.0 to 752.0 Ԭ ±
(
0.4 % + 1 Ԭ
)
Type E
0.1 Ԩ -50.1 to -100.0 Ԩ ±
(
0.4 % + 1 Ԩ
)
-50.0 to 900.0 Ԩ ±
(
0.4 % + 0.5 Ԩ
)
0.1 Ԭ -58.1 to -148.0 Ԭ ±
(
0.4 % + 1.8 Ԭ
)
-58.0 to 999.9 Ԭ ±
(
0.4 % + 1 Ԭ
)
1 Ԭ 1000 to 1652 Ԭ ±
(
0.4 % + 2 Ԭ
)
Type R
1 Ԩ 0to 600 Ԩ ±
(
0.5 % + 1 Ԩ
)
601 to 1700 Ԩ ±
(
0.5 % + 1 Ԩ
)
1 Ԭ 32 to 1112 Ԭ ±
(
0.5 % + 2 Ԭ
)
1113 to 3092 ±
(
0.5 % + 2 Ԭ
)

@Abo
v
less th
a
3-1
Di
s
3-2 Po
w
3-3 H
o
3-4 R
E
3-5 Ty
p
3-6 T1
-
3-7 S
E
3-8 Lo
g
3-9 T1
3-10
P
3-11
P
3-12
R
3-13 D
3-14
T
r
3-15 B
T
R
v
e specifica
t
a
n 30 MHz
o
s
play.
w
e
r
Button
o
ld Button (
E
C Button (
p
e Button (
-
T2 Button
(
E
T Button (
g
ge
r
Butto
n
,T2,T3,T4 i
n
T1 input so
T2
input so
R
S-232 outp
C
9V adap
t
r
ipod Fix N
u
attery Cov
e
T
ype S
1
Ԩ
1
Ԭ
R
ema
r
k :
a.
A
ccura
c
b. Accura
c
temper
a
c. Lineari
t
Memori
CPU
t
ion tests u
n
o
nly.
( ESC, Ba
c
Next Butto
n
Enter Butt
o
▲ Button,
(
▼ Button
,
Time chec
k
n
( OFFSET
n
put socket
cket ( Pt 1
0
cket ( Pt 1
0
ut terminal
t
e
r
socket
u
t
er
Screws
Ԩ
Ԭ
c
y value is
s
c
y is tested
a
ture within
t
y Correctio
n
ze the ther
m
n
de
r
the en
v
3. Fron
t
c
klight Butt
o
n
)
o
n )
L Button )
,
R Button )
k
Button )
Button, Sa
(
Type K,
T
0
0 ohm )
0
0 ohm )
0to 600 Ԩ
601 to 150
0
32 to 1112
1113 to 27
3
s
pecified for
unde
r
the
m
23 ± 5 Cº.
n
:
m
ocouple's
c
v
ironment R
t
Panel
o
n )
mpling tim
e
T
ype J )
±
(
0.
5
0
Ԩ ±
(
0.
5
Ԭ ±
(
0.
5
3
2 Ԭ ±
(
0.
5
the meter o
m
eter's envir
o
c
urve into th
e
F Field Str
e
Descrip
e
check But
t
i
5
% + 1 Ԩ
5
% + 1 Ԩ
5
% + 2 Ԭ
)
5
% + 2 Ԭ
)
nly.
o
nment
e
intelligent
e
ngth less t
h
tion
t
on)
i
nfo@tursdalete
c
)
)
)
)
h
an 3 V/M
&
c
hnicalservices.c
o
&
frequency
o
.u
k
7

[email protected]
8
3-16
Battery compartment/Cover
3-17 Stand
3-18 SD card socket
4. Measuring Procedure
4-1 Type K measurement
1) Power on the meter by pressing the "Power button" ( 3-2, Fig. 1) once.
* After already power on the meter, pressing the "Power button" once (> 2 sec) will turn off the
meter.
2) Meter default Temp. sensor type is Type K, the display will show " K " indicator. The
default
temperature unit is Cº (Fº), the method to
change the Temp. unit from Cº to Fº or Fº
please
refer to Chapter 7-5, page 18.
3)
Insert the Type K probes into the " T1, T2, T3, T4 input socket " ( 3-9, Fig. 1 ). The LCD will
show the 4 channels ( T1, T2, T3, T4 ) temperature value at the same time.
* If the certain channels do not insert the temperature probes, the relative channel display will
show over range " - - - - - ".
4-2 Type J/T/E/R/S measurement
All the measuring procedures are same as the Type K ( section 4-1 ) except to select the Temp.
Sensor
type to "Type J/K/T/E/R/S" by pressing the "Type Button" ( 3-5, Fig. 1) once in sequence
until
the up LCD display show "J/T/E/R/S" indicator.
4-3 Pt 100 ohm measurement
1) All the measuring procedures are same as the Type K ( section 4-1 ) except to select the
Temp. Sensor type to "Pt" by pressing the "Type Button" ( 3-5, Fig. 1) once in sequence
until the right down LCD display show " Pt " text as :
PT
2)
Insert the Pt 100 ohm probe ( optional, PT-101 ) to
PT1 input socket ( 3-10, Fig. 1 ) PT2 input socket ( 3-11, Fig. 1 )
* The Pt 100 ohm measurement only allow max. two channels ( two probes ) input.
4-4 T1-T2 measurement
If the meter already insert two probes: Type K/J/T/E/R/S : T1, T2 input socket Pt 100 ohm :
PT1, PT2 input socket
Pressing the " T1-T2 button " ( 3-6, Fig. 1 ), display will show the difference temperature
value between T1, T2 (PT1,
PT2) as :

[email protected]
9
4-5 Data Hold
During the measurement, press the " Hold Button " ( 3-3, Fig. 1 ) once will hold the measured
value & the LCD will display a " HOLD " symbol.
Press the " Hold Button " once again will release the data hold function.
4-6 Data Record ( Max., Min. reading )
1) The data record function records the maximum and minimum readings. Press the " REC
Button " ( 3-4, Fig. once to start the Data Record function and there will be a " REC "
symbol on the display.
2) With the " REC " symbol on the display :
a) Press the " REC Button " ( 3-4, Fig. 1 ) once, the " REC MAX " symbol along with the
maximum value will appear on the display. If intend to delete the maximum value, just
press the " Hold Button " ( 3-3, Fig. 1 ) once, the display will show the " REC " symbol
only & execute the memory function continuously.
b) Press the " REC Button " ( 3-4, Fig. 1 ) again, the " REC MIN " symbol along with the
minimum value will appear on the display. If intend to delete the minimum value, just
press the " Hold Button " ( 3-3, Fig. 1 ) once, the display will show the " REC " symbol
only & execute the memory function continuously.
c) To exit the memory record function, just press the " REC " button > 2 seconds at least.
The display will revert to the current reading.
4-7 LCD Backlight ON/OFF
After power ON, the "LCD Backlight" will light automatically. During the measurement, press
the "Backlight Button" ( 3-2, Fig. 1) once will turn OFF the "LCD Backlight". Press the "Backlight
Button" once again will turn ON the"
LCD Backlight" again.
5. Datalogger
5-1 Preparation before execute datalogger function
a. Insert the SD card Prepare a "SD memory card" (1 GB to 16 GB, optional), insert the SD
card into the "SD card socket" ( 3-18, Fig. 1). The front panel of the SD card should face
against the down case.
b. SD card Format If SD card just the first time use into the meter, it recommend to make the
"SD card Format" at first. , please refer chapter 7-7 ( page 19 ).

[email protected]
10
c. Time setting
If the meter is used at first time, it should to adjust the clock time exactly, please refer
chapter 7-1 ( page 16 ).
d. Decimal format setting
The
numerical data structure of SD card is default used the as the decimal, f or
example
"20.6" "1000.53" . But in certain countries ( Europe ...) is used the " , " as
the decimal point, for example " 20, 6 " "1000,53". Under such situation, it should
change
the Decimal character at first, details of
setting the Decimal point, refer to
Chapter 7-2, page 17.
5-2 Auto Datalogger ( Set sampling time
≧
1 second )
a. Start
the datalogger
Press the " REC Button ( 3-4, Fig. 1 ) once , the LCD will show the text " REC ", then press
the " Logger Button " ( 3-8, Fig. 1 ), the " REC " will flashing and beeper will sound, at the
same time the measuring data along the time information will be saved into the memory
circuit. Remark:
* How to set the sampling time, refer to Chapter 7-6, page 19.
* How to set the beeper sound is enable, refer to Chapter 7-4, page 18.
b.
Pause the datalogger
During execute the Datalogger function , if press the " Logger Button " ( 3-8, Fig. 1 ) once
will
pause the Datalogger function ( stop to save the measuring data into the memory circuit
temporally ). In the same time the text of " REC " will stop flashing.
Remark :If
press the " Logger Button " ( 3-8, Fig. 1 ) once again will
execute the Datalogger
again, the text of " REC " will flashing.
c.. Finish the datalogger
During pause the Datalogger, press the " REC Button " ( 3-4, Fig. 1) continuously at least
two seconds, the " REC " indicator will be disappeared and finish the Datalogger.
5-3 Manual
Datalogger (Set sampling time = 0 second)
a.
Set sampling time is to 0 second
Press the " REC Button ( 3-4, Fig. 1 ) once , the LCD will show the text " REC ", then press
the " Logger Button " ( 3-8, Fig. 1 ) once, the " REC " will flashing once and Beeper will
sound once, at the same time the measuring data along the time information and the
Position no. will be saved into the memory circuit.
Remark:
* For the 4 channels measurement, the right lower Display will show the Position/Location
no. (P1, P2... P99) and the T4 measurement value alternately.
* During execute the Manual Datalogger, use the " ▲Button " ( 3-5, Fig. 1) or " ▼Button
" (3-6, Fig. 1 ) to set the measuring position (1 to 99, for example room 1 to room 99 ) to
identify the measurement location.
b. Finish the Datalogger
Press
the "REC Button " ( 3-4, Fig. 1) continuously at least two seconds, the " REC "
indication will
be disappeared and finish the Datalogger.

[email protected]
11
5-4
Check time information
During the normal measurement ( not execute the Datalogger ), If press "Time check Button" ( 3-
7,
Fig.1) once , the lower LCD display will present the time information of Year/Month,
Date/Hour, Minute/Second.
5-5 Check sampling time information
During the normal measurement ( not execute the Datalogger ), If press " Sampling Button " (
3-8, Fig. 1 ) once , the lower LCD display will present the Sampling time information in second
unit.
5-6 SD Card Data structure
1) When the first time, the SD card is used into the meter, the SD card will generate a folder :
TMA01
2) If the first time to execute the Datalogger, under the route TMA01\, will generate a new file
name TMA01001.XLS. After exist the Datalogger, then execute again, the data will save to
the TMA01001.XLS until Data column reach to 30,000 columns, then
will generate a new
file, for example TMA01002.XLS
3)
Under the folder TMA01\, if the total files more than 99 files, will generate a new route, such
as TMA02\ ........
4)
The file's route structure : TMA01\
TMA01001.XLS TMA01002.XLS
TMA01099.XLS TMA02\ TMA02001.XLS
TMA02002.XLS
TMA02099.XLS TMAXX\
Remark : XX : Max. value is 10.
6. Saving data from the SD card to the
computer (EXCEL software)
1) After execute the Data Logger function, take away the SD card out from the "SD card
socket" ( 3-18, Fig. 1 ).
2)
Plug in the SD card into the Computer's SD card slot ( if your computer build in this
installation )
or insert the SD card into the " SD card adapter ". then connect the " SD card
adapter " into the computer.
3)
Power ON the computer and run the "EXCEL software". Down
load the saving data file ( for
example the file name : TMA01001.XLS, TMA01002.XLS ) from the SD card to the computer.
The saving data will present into the EXCEL software screen ( for example as following
EXCEL
data screens ), then user can use those EXCEL data to make the further Data or
Graphic analysis usefully.

[email protected]
12
EXCEL data screen ( for example )
EXCEL graphic screen ( for example )
7. Advanced Setting
Under do not execute the Datalogger function, press the "SET Button " ( 3-7, Fig. 1)
continuously at least two seconds will enter the " Advanced Setting " mode. then press the"
Next
Button " (3-3, Fig. 1 ) once a while in sequence to select the seven main function, the
lower display will show :
dAtE..... Set clock time ( Year/Month/Date, Hour/Minute/ Second )
dEC...... . Set SD card Decimal character PoFF..... Auto power OFF management bEEP.... . Set
beeper sound ON/OFF
t-CF...... Select the Temp. unit to Cº or Fº
SP-t...... Set sampling time ( Hour/Minute/Second )
Sd F..... SD memory card Format
Remark:
During execute the " Advanced Setting " function, if
press " ESC Button " ( 3-2, Fig. 1 ) once will
exit the " Advanced Setting " function, the LCD will return
to normal screen.

[email protected]
13
7-1 Set clock time (Year/Month/Date, Hour/Minute/ Second)
When the lower display show "dAtE"
1) Press the " Enter Button " ( 3-4, Fig. 1 ) once, Use the " ▲ Button " ( 3-5, Fig. 1 ) or " ▼
Button" ( 3-6, Fig. 1 ) to adjust the value ( Setting start from Year value ). After the desired
value is set, press the " Enter Button " ( 3-4, Fig. 1 ) once will going to next value
adjustment ( for example, first setting value is Year then next to adjust Month, Date, Hour,
Minute,
Second value ).
2)
After set all the time value ( Year, Month, Date, Hour, Minute, Second ), the screen will jump
to " SD card Decimal character" setting screen ( Chapter 7-2 ).
Remark:
After the time value is setting, the internal clock will run
precisely even Power is off (The battery
is under normal condition, no low battery condition).
7-2 Decimal point of SD card setting
The numerical data structure of SD card is default used the " . " as the decimal, for example
"20.6" "1000.53" . But in certain countries ( Europe ...) is used the " , " as the decimal
point,
for example " 20,6 " "1000,53". Under such situation, it should change the Decimal
character
at first.
When
the lower display show "dEC"
1) Use the " ▲ Button " ( 3-5, Fig. 1 ) or " ▼ Button " ( 3-6, Fig. 1 ) to select the upper value to
" bASI " or " Euro ".
bASI - Use " . " as the Decimal point with default. Euro - Use " , " as the Decimal point with
default.
2)
After select the upper text to " bASI " or " Euro ", press the " Enter Button " ( 3-4, Fig. 1 ) will
save the setting function with default.
7-3 Auto power OFF management
When the lower display show " PoFF "
1) Use the " ▲ Button " ( 3-5, Fig. 1 ) or " ▼ Button " ( 3-6, Fig. 1 ) to select the upper value to
"yES " or " no ".
yES - Auto Power Off management will enable. no - Auto Power Off management will
disable.
3) After select the upper text to " yES " or " no ", press the " Enter Button " ( 3-4, Fig. 1 ) will
save the setting function with default.
7-4 Set beeper sound ON/OFF
When the lower display show " bEEP "
1) Use the " ▲ Button " ( 3-5, Fig. 1 ) or "▼ Button" ( 3-6, Fig. 1 ) to select the upper value to
"yES " or " no ".
yES - Meter's beep sound will be ON with default. no - Meter's beep sound will be OFF with
default.
is
power ON.
3) After select the upper text to " yES " or " no ", press the " Enter Button " ( 3-4, Fig. 1 ) will
save the setting function with default.

[email protected]
14
7-5 Select the Temp. unit to Cº or Fº
When the lower display show " t-CF "
1) Use the " ▲ Button " ( 3-5, Fig. 1 ) or " ▼ Button " ( 3-6, Fig. 1 ) to select the upper Display
text to " C " or " F ".
C - Temperature unit is Cº
F - Temperature unit is Fº
2)
After Display unit is selected to " C " or " F ", press the " Enter Button " ( 3-4, Fig. 1 ) will
save the setting function with default.
7-6 Set sampling time (Seconds)
When the lower display show " SP-t "
1)
Use the " ▲ Button " ( 3-5, Fig. 1 ) or " ▼ Button " ( 3-6, Fig. 1 ) to adjust the value ( 0, 1, 2,
5, 10, 30,60, 120, 300, 600, 1800,3600
seconds ).
Remark :
If select the sampling time to " 0 second ", it is ready for manual Datalogger.
2)
After the Sampling value is selected, press the "Enter Button" ( 3-4, Fig. 1 ) will save the
setting function with default.
7-7 SD memory card Format
When the lower display show " Sd F "
1) Use the " ▲ Button " ( 3-5, Fig. 1 ) or " ▼ Button " ( 3-6, Fig. 1 ) to select the upper value to
" yES " or " no ".
yES - Intend to format the SD memory card
no - Not execute the SD memory card format
2) If select the upper to " yES ", press the " Enter Button " ( 3-4, Fig. 1 ) once again, the
Display will show text " yES Ent " to confirm again, if make sure to do the SD memory card
format, then press " Enter Button " once will format the SD memory clear all the existing
data
that already saving into the SD card.
8. Power Supply from DC
Adapter
The meter also can supply the power supply from the DC 9V Power Adapter ( optional ). Insert
the plug of Power Adapter into "DC 9V Power Adapter Input Socket" ( 3-13, Fig. 1 ). The meter
will
permanent power ON when use the DC ADAPTER power supply ( The power Button
function
is disable ).
9. Battery Replacement
1) When the left corner of LCD display show " ", it is necessary to replace the battery.
However, in-spec. measurement may still be made for several hours after low battery
indicator appears before the instrument become inaccurate.
2) Loose the "Battery Cover Screws " ( 3-15, Fig. 1 ) and take away the " Battery Cover " (3-
16, Fig. 1 ) from the instrument and remove the battery.

[email protected]
15
Baud rate
9600
Parit
y
No
p
arit
y
Data bit no. 8 Data bits
Stop bit
1
Stop bit
3) Replace with DC 1.5 V battery ( UM3, AA, Alkaline/heavy duty ) x 6 PCs, and reinstate the
cover.
4) Make sure the battery cover is secured after changing the battery.
10. RS232 PC Serial Interface
The instrument has RS232 PC serial interface via a 3.5 mm terminal ( 3-12, Fig. 1 ).
The data output is a 16 digit stream which can be utilized for user's specific application.
A RS232 lead with the following connection will be required to link the instrument with the PC
serial port.
The 16 digits data stream will be displayed in the following
format :
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Each digit indicates the following status:
D15 Start Word
D14 4
D13 When send the upper display data = 1
When send the lower display data = 2
D12, D11 Annunciator for Display
℃ = 01 ℉ = 02
D10 Polarity
0 = Positive 1 = Negative
D9
Decimal Point(DP), position from right to the
left
0
= No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D8 to D1
Display reading, D1 =LSD, D8 =MSD
For
example :
If the display reading is 1234, then D8 to
D1 is : 00001234
D0 End Word
RS232 FORMAT: 9600, N, 8, 1

[email protected]
16
11. Offeset Adjustment
11-1 Type K/J/T/E/R/S offset adjustment
1) Set the function to Type K ( or other type J/E/R/T/S ).
2) Insert the probe to the T1 input socket ( 3-9, Fig. 1 )
3) Pressing " Offset button " ( 3-8, Fig. 1 ) continuously at least two seconds then release, the
display will show :
* Use the " ▲ button "( 3-5, Fig. 1 ) " ▼ button " ( 3-6 Fig. 1 ) to adjust the desiring value on
right bottom display.
*
Pressing " Enter button " ( 3-4, Fig. 1 ) once, the adjustment value will save into memory then
return to normal measuring screen and finish the offset adjustment procedures.
* The above offset adjustment for Type K/J/T/E/R/S is valid for T1, T2, T3, T4 at the same time.
11-2 Pt 100 ohm offset adjustment
1) Set the function to Pt 100 ohm.
2)
Insert the Pt 100 ohm probe to the PT1 ( PT2 ) input socket.
3) Pressing " Offset button " ( 3-8, Fig. 1 ) continuously at least two seconds then release, the
display
will show :
4) If intend to make the offset adjustment for Pt 1, it should insert the probe to PT1 input
socket. Pressing " L button " ( 3-5, Fig. 1 ) once, the display will show example as following.
If intend to make the offset adjustment for Pt 2, it should insert the probe to PT2 input
socket. Pressing " R button " ( 3-6, Fig. 1 ) once, the display will show example as
following.

[email protected]
17
*
Use the " ▲ button "( 3-5, Fig. 1 ) " ▼ button " ( 3-6, Fig. 1 ) to adjust the desiring value on
right bottom display.
*
Pressing " Enter button " ( 3-4, Fig. 1 ) once, the adjustment value will save into memory
then return to normal measuring screen and finish the offset adjustment procedures.
* The above offset adjustment for Pt 100 ohm is valid for PT1, PT2 individually.
12. Optional Type K Temp. probe
(Type K)
T
P-01 * Max. short-tern operating
Temperature:
300 ℃ (572 ℉ ).
*
It is an ultra fast response
naked-bead
thermocouple
suitable for many general purpose
application.
T
hermocouple
Probe
(Type K), TP-02A
* Measure Range: -50 ℃ to 900 ℃ ,
-50 ℉ to 1650 ℉ .
*
Dimension:10cm tube, 3.2mm Dia.
T
hermocouple
Probe
(Type K), TP-03
* Measure Range: -50 ℃ to 1200 ℃ ,
-50 ℉ to 2200 ℉ .
*
Dimension: 10cm tube, 8mm Dia.
Surface Probe
(Type K), TP-04 *
Measure Range: -50 ℃ to 400 ℃ ,
-50 ℉ to 752 ℉ .
*
Size :
Temp. sensing head - 15 mm Dia.
Probe
length - 120 mm.

[email protected]
18
13. Patent
The meter ( SD card structure ) already get patent
or patent pending in following
countries :
Germany N r. 20 2008 016 337.4
JAPAN 3151214
TAIWAN M 358970
M 359043
CHINA ZL 2008 2 0189918.5
ZL 2008 2 0189917.0
USA Patent pending
In this direction will find a vision of the measurement technique:
http://www.industrial-needs.com/measuring-instruments.htm
NOTE: "This instrument doesn’t have ATEX protection, so it should not be used in potentially explosive
atmospheres (powder, flammable gases)."
