PCE Instruments PCE-IR 56 Manual

6-Channel Modbus
Infrared Thermometer PCE-IR 56
Operator’s Guide
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: [phone]
Fax: [phone]
[email protected]
www.pce-instruments.com/english
www.pce-instruments.com
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: [phone]
Fax: [phone]
[email protected]

2
The P CE-IR 56
PCE Instruments infrared temperature sensors.
The P CE-IR5 6 functions as the Modbus Master on an RS485 network of up to 6 temperature sensors,
and can itself be connected as a slave device to another RS485 network via a second, isolated
Modbus interface. This allows multiple P CE-IR5 6 units to be multi-dropped to create a large network
of sensors and displays.
Optional alarm relay modules allow the P CE-IR5 6 to be connected to alarm equipment such as
sounders and beacons, and optional analogue output modules allow it to be connected to non-
Modbus instrumentation.
modules are adjustable via the PCE-IR5 6 built-in resistive touch screen interface, which can be
operated even with gloves on.
With an optional MicroSD Card inserted, the P CE-IR5 6
SPECIFICATIONS
Display 2.83” (72 mm) resistive touch TFT,
320 x 240 pixels, backlit
Supply Voltage 10 to 30 V DC
Maximum Current Draw 100 mA
Ambient Temperature Range 0°C to 60°C
Relative Humidity Maximum 95%, non-condensing
Congurable Parameters (global) Temperature units, date and time, data logging,
graph channels, alarm logging
Congurable Parameters (per channel) Signal processing, emissivity setting, reected energy
compensation, alarms, Modbus address
Alarm Conguration 12 alarms (2 per sensor) with adjustable level,
individually congurable as HI or LO.
Temperature Units °C or °F selectable
Temperature Resolution 0.1° below 1000°; 1° above 1000°
Signal Processing Average, peak hold, valley hold, minimum, maximum
Display Sample Period 120 ms per device (720 ms in total for 6 devices)
MECHANICAL
Dimensions 98(w) x 64(h) x 36(d) mm excluding cable glands
Weight 280 g

3
DATA LOGGING
ebyamgniggolatad6,PCE-IR 5ehtedisnitolsehtnidellatsnidraCDSorciMlanoitponahtiW
manually started and stopped via a button on the temperature display screen, or scheduled to
begin at a pre-determined time via the Settings menu.
If the PCE-IR 56 is connected via the slave interface to another Modbus network, logging may also be
started remotely by the Modbus Master on that network.
DATA LOGGING SPECIFICATIONS
Logging Interval1 to 86,400 seconds (1 day)
MicroSD Card Max. capacity: 32 GB (not included)
Internal Clock Battery 1 x BR 1225 3V (not included)
Variables Logged Target temperature, sensing head temperature, alarm events
File Format .csv (can be imported to Excel)
Configurable Parameters Sample period, number of samples, scheduled start date
and time
DIMENSIONS (MM)
Touch screen
72 mm (2.83")
48
18
Cable glands:
17 mm AF
64
36
20
36
Mounting
holes: use
M4 CSK
screws
98
86

4
Modbus
Slave
Modbus
Master
0V* RS+ RS- RS+ RS-PWR+ PWR-
Removable
screw
terminals
0 V
+10 to 28 V DC
RS485 +
RS485 -
Signal Ground*
RS485 +
RS485 -
* If using the Modbus
Slave interface, the 0V
terminal should be
connected to the signal
ground of this network's
Modbus Master (e.g. a
PLC or SCADA system)
Ensure PWR- of all sensors and GND of all output
modules on this network is connected to PWR- of
the PCE-IR 56 Modbus Master interface
PCE-IR56
The PCE-IR 56 has removable screw terminal blocks for the Modbus Slave and Modbus Master
interfaces.
− Connect the Master interface to the sensors and output modules. Be sure to check the power
supply requirements of each device before applying power.
− Optionally, connect the Slave interface to another Modbus network with its own Modbus
Master such as a PLC or SCADA system.
Isolation is provided between the Slave and Master interfaces.
MICROSD CARD AND BATTERY
The MicroSD Card and battery slots are located on the touch screen circuit board. Unscrew the lid
of the PCE-IR 56 to access them.
The battery is optional. With a battery tted, the internal clock will continue to run when the power
is o. Without a battery, the unit will request the date and time each time the power is cycled.
All other settings are stored in the unit’s permanent memory and will be preserved when it is
switched o, regardless of whether a battery is tted.

5
Modbus
Slave
Modbus
Master
0V* RS+ RS- RS+ RS-PWR+ PWR-
Removable
screw
terminals
0 V
+10 to 28 V DC +12 V DC+24 V DC
PyroBus
sensor
PyroMini or FibreMini
sensor
RS485 +
RS485 -
Signal Ground*
RS485 +
RS485 -
* If using the Modbus
Slave interface, the 0V
terminal should be
connected to the signal
ground of this network's
Modbus Master (e.g. a
PLC or SCADA system)
Ensure PWR- of all sensors and GND of all output
modules on this network is connected to PWR- of
the PM180 Modbus Master interface
PM180
PyroMiniBus
sensor
PASSWORD
The default password is 1234. The password may be changed via the touch screen interface.

6
Address Leng t h
(words)
Description R/W
0x0000 1 MODBUS slave address R/W
0x0001 7 Sensor identication string in ASCII R
"PCE-IR 56 vx.xx" where x.xx is the rmware version
0x0008 2 Serial number R
0x000A 2 Sample Period (1 to 86400) R/W
0x000C 2 Number of Samples (0 to 86400) R/W
0x000E 1 Data acquisition enabled (0 for disabled, 1 for enabled) R/W
0x000F 1 Data acquisition start time: Hours (0 to 23) R/W
0x0010 1 Data acquisition start time: Minutes (0 to 59) R/W
0x0011 1 Data acquisition start time: Seconds (0 to 59) R/W
0x0012 1 Data acquisition start time: Day (1 to 31) R/W
0x0013 1 Data acquisition start time: Month (1 to 12) R/W
0x0014 1 Data acquisition start time: Year (2012 to 2105) R/W
0x0015 1 Alarm log settings R/W
Bit 0 - Log trigger time
Bit 1 - Log while triggered
Bit 2 - Log acknowledge time
Bit 3 - Log reset time
0x0020 1 Remote request - Start logging R/W
Write 1 - request start of data logging
Read 1 - request pending, Read 0 - no request pending
0x0021 1 Remote request - Stop logging R/W
Write 1 - request termination of data logging
Read 1 - request pending, Read 0 - no request pending
0x0022 1 Remote request - Acknowledge alarms R/W
Write 1 - request acknowledgement of alarms
Read 1 - request pending, Read 0 - no request pending
0x0023 1 Remote request - Reset alarms R/W
Write 1 - request reset of alarms
Read 1 - request pending, Read 0 - no request pending
MODBUS OVER SERIAL LINE (RS485)
INTERFACE
Baud rate9600
Format 8 data, No parity, 1 stop bit
Reply delay (ms) 20
SUPPORTED FUNCTIONS
Read register 0x03, 0x04
Write single register 0x06
Write multiple register 0x10
The list below includes all available addresses:
R = Read, W = Write

7
SENSOR SETTINGS ADDRESS SPACE
The settings of attached sensors can be read by adding the following offsets to the addresses speci-
fied by the sensor manufacturer:
Sensor index Address offset
0 0x1000
1 0x1100
2 0x1200
3 0x1300
4 0x1400
5 0x1500
6 0x1600
See sensor manual for further details.
Notes:
1. For further information please refer to http://www .modbus.org/specs.php
2. Use address 255 to communicate with any connected unit (only one sensor connected)
3. Use address 0 to broadcast to all connected units (no response expected)
