PD Technology BigBot User manual

BIGBOT KIT ASSEMBLY INSTRUCTIONS
www.BigBot-3D.com
1/22/2017
V0.6

THANKS FOR PURCHASING A PDTECH BIGBOT KIT! WE SINCERELY HOPE YOU ENJOY YOUR
PRINTER AND THE EVER-GROWING WORLD OF 3D PRINTING!
PART ORGANIZATION:
YOUR KIT INCLUDES SEVERAL BOXES AND/OR BAGS OF PARTS. THESE BOXES AND BAGS ARE
LABELED AND SORTED IN A MANNER WHICH HOPEFULLY MAKES ASSEMBLY EASY. DURING
ASSEMBLY, PLEASE LEAVE THESE PARTS IN A SAFE PLACE WHERE THEY HOPEFULLY WILL NOT
BE MISPLACED OR MIXED WITH OTHER PARTS OF THE KIT. THIS INSTRUCTION MANUAL
REFERENCES THE PART BY BOX OR BAG, AND WITH SO MANY IT CAN BECOME A VERY TIME
CONSUMING TASK WHEN THINGS GET MIXED UP!
SUPERHUMAN STRENGTH?
CAN YOU TIGHTEN SCREWS SO HARD THEY BREAK THINGS? I BET YOU CAN! FEEL FREE TO
USE THAT STRENGTH WHEN YOU TIGHTEN A METAL SCREW TO A METAL PART, BUT NOT A
PLASTIC PART. THIS PRINTER UNDERGOES ONLY SLIGHT STRESSES DURING OPERATION, OF
WHICH A TIGHT SCREW WILL BE NO BETTER THAN A SLIGHTLY SNUG SCREW. IF IN DOUBT
PLEASE JUST ENSURE A SNUG FIT. IF SCREW TIGHTNESS IS IMPORTANT, IT WILL BE
ESPECIALLY NOTED IN THIS INSTRUCTION MANUAL.
CAUTION:
THIS ASSEMBLY CONTAINS SEVERAL POTENTIALLY DANGEROUS ELEMENTS. THE HOT END
TYPICALLY OPERATES AT 180-240 DEGREES CELSIUS, AND THE HEATED BED IS RATED UP TO
100 CELCIUS. THESE SURFACES CAN BURN YOU IF TOUCHED, OR CATCH FLAMMABLE OBJECTS
ON FIRE. IT IS THE USER'S RESPONSIBILITY TO ENSURE THE WORK AREA IS FREE OF
FLAMMABLE ITEMS AND TO ENSURE PROPER, NON-HAZARDOUS OPERATION. WHEN WORKING
WITH AC VOLTAGES, PROPER CARE MUST BE TAKEN TO PREVENT ELECTROCUTION AND SHORT
CIRCUIT WIRING. PDTECH ASSUMES NO LIABILITY FOR ANY DAMAGES INCURRED, AS IT IS THE
RESPONSIBILITY OF THE USER TO CHECK AND MAINTAIN THIS DEVICE FOR PROPER OPERATION.
COORDINATE SYSTEM DESCRIPTIONS:
THIS ASSEMBLY DESCRIBES MANY PARTS IN REFERENCE TO THE PRINTER AXIS: X, Y, AND Z.
WHEN FACING THE PRINTER, THE X AXIS EXTENDS LEFT TO RIGHT. THE Y AXIS
EXTENDS FRONT TO BACK, AND THE Z AXIS EXTENDS UP AND DOWN.

INDEX
PAGE 1: TITLE
PAGE 2: PREFACE
PAGE 3: INDEX
PAGE 4: INDEX (CONTINUED)
PAGE 5: 1.1 ASSEMBLE BED ADJUSTING THUMB NUT: 4 TIMES
PAGE 6: 1.2 ASSEMBLE HEIGHT LOCKING THUMB NUT: 4 TIMES
PAGE 7: 1.3 ASSEMBLE 90 CORNERS TO Y BEARING MOUNTS: 4 TIMES
PAGE 8: 1.4 ASSEMBLE SCREWS, WASHERS, AND TSLOT NUTS TO BED
PAGE 9: 1.5 ASSEMBLE HEATERS TO BUILD PLATFORM 1.6 SLIDE FRAME INTO BUILD PLATFORM
PAGE 10: 1.7 ASM Y BEARING MOUNT TO FRAME
PAGE 11: 1.8 ASM SIDE FRAME INTO BUILD PLATFORM
PAGE 12: 1.9 ASSEMBLE FRAME CROSS-MEMBERS: 600x600 ONLY
PAGE 13: 1.10 MOUNT THERMISTOR TO BUILD PLATFORM
PAGE 14: 1.11 ASM Y BELT, CORNER PROTECTORS, AND Y CHAIN MOUNT
PAGE 15: 2.1 ASM Y ROD MOUNT HARDWARE: 4 TIMES
PAGE 16: 2.2 BUILD Y BELT IDLER/TENSIONER
PAGE 17: 2.3 ASSEMBLE FRONT AND REAR FRAME MEMBERS
PAGE 18: 2.4 ASM LOWER Z BEARING ROD MOUNT: 2 TIMES
PAGE 19: 2.5 ASM SIDE FRAME MEMBERS
PAGE 20: 2.6a (600x600 ONLY): ASM Y MOTOR MOUNT TO FRAME
PAGE 21: 2.6b (600x300 AND 300x300): ASM Y MOTOR MOUNT TO FRAME
PAGE 22: 2.7a (600x600 ONLY) ASM Y MOTOR FRAME TO MAIN FRAME
PAGE 23: 2.8 ASSEMBLE BED TO MAIN FRAME
PAGE 24: 2.9 TIGHTEN Y BELT AND Y ROD MOUNTS. ALIGN BED ASM
PAGE 25: 3.1 ASM FRAME SUPPORTS
PAGE 26: 3.2 ASM Z MOTOR MOUNTS: LEFT AND RIGHT
PAGE 27: 3.3 ASM GANTRY CORNERS
PAGE 28: 3.4 ASM GANTRY SIDE FRAME TO TOP OF GANTRY
PAGE 29: 3.5 ASSEMBLE X IDLER MOUNT (LOOSE BEARING MOUNT SCREW)
PAGE 30: 3.6 ASSEMBLE X MOTOR MOUNT (LOOSE BEARING MOUNT SCREW)
PAGE 31: 3.7 FLIP BED ASM UP AND INSERT Z BEARING RODS
PAGE 32: 3.8 ASSEMBLE GANTRY TO LOWER ASSEMBLY
PAGE 33: 3.9 REEL HOLDER AND FILAMENT GUIDE

INDEX (CONTINUED)
PAGE 34: 4.1 CLAMP X RAILS AND ASM IDLER
PAGE 35: 4.2 ASSEMBLE X RAILS TO MOTOR SIDE
PAGE 36: 4.3 ASM X LIMIT SWITCH
PAGE 37: 4.4 INSERT Z THREADED ROD AND NUT
PAGE 38: 4.5 ASSEMBLE CARRIAGE BACK AND CLIP X AXIS BELT
PAGE 39: 4.6 DUAL EXTRUDER LIFT (OPTIONAL, WITH DUAL EXTRUDER)
PAGE 40: 4.7 ASSEMBLE CARRIAGE FRONT TO CARRIAGE BACK
PAGE 41: 4.8 ASSEMBLE 30mm FAN: 1 OR 2 (DUAL EXTRUDER)
PAGE 42: 4.9 CARRIAGE FAN AND SWITCH MOUNT
PAGE 43: 4.10 EXTRUDER ASSEMBLY (1 OR 2)
PAGE 44: 4.11 MOUNT FAN AND SWITCH MOUNT TO CARRIAGE
PAGE 45: 4.12 ASSEMBLE EXTRUDER(S) TO CARRIAGE
PAGE 46: 4.13 OPTIONAL R EXTRUDER LIFT (DUAL EXTRUDER ONLY)
PAGE 47: 4.14 ADJUST BED LEFT OR RIGHT AND GANTRY FORWARD OR BACK
PAGE 48: 5.1 AC CIRCUIT COMPONENTS
PAGE 49: 5.2 AC CIRCUIT WIRING
PAGE 50: 5.3 24VDC CIRCUIT
PAGE 51: 5.4 INSTALL RAMPS 1.4, MEGA 2560, AND ENCLOSURE FAN
PAGE 52: 5.5 6.25VDC CIRCUIT
PAGE 53: 5.6 MOUNT ENCLOSURE TO TOP GANTRY FRAME
PAGE 54: 5.7 WIRE EXTENSIONS AND ROUTING
PAGE 55: 5.7 WIRE EXTENSIONS AND ROUTING (CONTINUED)
PAGE 56: 5.8 ROUTE CARRIAGE WIRES AND ASM X CABLE CHAIN MOUNT
PAGE 57: 5.9 CONNECT THERMISTORS, LIMIT SWITCHES, FILAMENT SENSORS,
AND MOTORS TO RAMPS 1.4
PAGE 58: 5.10 MOUNT AND CONNECT LCD AND SD READER
PAGE 59: 5.11 TEST ELECTRONIC SYSTEMS
PAGE 60: 5.12 COMPLETE WIRE MANAGEMENT, CLEAN UP
PAGE 61: 5.13 ALL DONE!

1.1 ASSEMBLE BED ADJUSTING THUMB NUT: 4 TIMES
PART LOCATION QTY
[1] LONG THUMB WHEEL PLASTIC PARTS BAG 4
[2] SHORT THUMB WHEEL PLASTIC PARTS BAG 4
[3] SCREW BAG 33 4
[4] LOCK WASHER BAG 10 4
[5] NUT BAG 4 8
USE SHORTER M5 SCREW TO SHOULDER WHEEL
AGAINST AND TIGHTEN NUT INTO SHORT THUMB WHEEL
[2]
[5]
[4]
[1]
[3]

1.2 ASSEMBLE HEIGHT LOCKING THUMB NUT: 4 TIMES
PART LOCATION QTY
[1] LONG THUMB WHEEL PLASTIC PARTS BAG 4
[2] SCREW BAG 32 4
[3] LOCK WASHER BAG 10 4
[4] NUT BAG 4 4
[2]
[1]
[3]
[4]

1.3 ASSEMBLE 90 CORNERS TO Y BEARING MOUNTS: 4 TIMES
PART LOCATION QTY
[1] ADJUSTING THUMB NUT ASM ASM 1.1 4
[2] LOCKING THUMB NUT ASM ASM 1.2 4
[3] Y BEARING MOUNT, L PLASTIC PARTS BAG 2
[4] Y BEARING MOUNT, R PLASTIC PARTS BAG 2
[5] CORNER BRACKET HARDWARE BOX 4
[6] WASHER, 10MM OD BAG 9 4
[7] WASHER, 15MM OD BAG 8 4
[8] WING NUT BAG 6 4
[9] NUT BAG 5 4
[10] WING NUT INSERT TOOL PLASTIC PARTS BAG 1
[1]
[6]
[3]
[4] MIRROR PART
[8]
[9]
[5]
[7]
[2]
USE WING NUT INSERT TOOL
TO HOLD WING NUT WHILE
INSERTING SCREW
[10]

1.4 ASSEMBLE SCREWS, WASHERS, AND TSLOT NUTS TO BED
PART LOCATION QTY
[1] ALUMINUM BED ASM PACKED IN BOX 1
600x600
[2] SCREWS: 600x300
300x300
BAG 52
22
12
8
600x600
[3] WASHERS: 600x300
300x300
BAG 53
44
24
16
600x600
[4] T SLOT NUTS: 600x300
300x300
BAG 3
22
12
8
UNPACK ALUMINUM BED:
KEEP PROTECTIVE FILM ON
THIS STEP IS EASIEST WITH BED ASM HEATERS UP AND SETTING ON
A BOX OR SOMETHING TO GIVE THE BUILDER ACCESS UNDERNEATH
[4]
[3]
[2]
[1] LOOSLY ASSEMBLE NUT

1.6 SLIDE FRAME INTO BUILD PLATFORM
PART LOCATION QTY
[1] ALUMINUM BED ASM 1.5 1
600x600: 555mm [21.85"] 2020 FRAME
[2] 600x300: 555mm [21.85"] 2020 FRAME
300x300: 250mm [9.85"] 2020 FRAME
WRAPPED IN BOX
4
2
2
1.5 ASSEMBLE HEATERS TO BUILD
PLATFORM (MAY BE SUPPLIED PRE-
ASSEMBLED). IF HEATERS ARE
APPLIED TO ALUMINUM BED, THIS
STEP IS COMPLETE
ALIGN NUT INTO FRAME SLOT AND SLIDE LEFT
[1]
[2]
DO NOT TIGHTEN SCREWS YET
KEEP FRAMING LOOSE

1.7 ASM Y BEARING MOUNT TO FRAME
PART LOCATION QTY
[1] Y BEARING MOUNT ASM 1.3 1
[2] TSLOT NUT BAG 3 4
[3] SCREW BAG 24 4
LOOSEN HEIGHT LOCK THUMB
NUT TO TIGHTEN SCREW
ORIENTATION OF THIS WALL (4 PLACES) IN
RELATION TO FRONT OF BED IS IMPORTANT
BED FRONT
[1]
[3]
[2] IN RAIL

1.8 ASM SIDE FRAME INTO BUILD PLATFORM
PART LOCATION QTY
590mm [23.23"] 2020 FRAME
[1] 285mm [11.23"] 2020 FRAME
285mm [11.23"] 2020 FRAME
WRAPPED IN BOX 2
[1]

1.9 ASSEMBLE FRAME CROSS-MEMBERS: 600x600 ONLY
PART LOCATION QTY
[1] 600x600: 330mm [13"] 2020 FRAME, DRILLED
600x300: N/A
300x300: N/A
WRAPPED IN BOX 2
0
0
[2] T SLOT NUT BAG 3 8
[3] SCREW BAG 29 8
[2] IN RAIL
[3]
[1]

1.10 MOUNT THERMISTOR TO BUILD PLATFORM
PART LOCATION QTY
[1] THERMISTOR HEATED BED BAG 1
[2] KAPTON TAPE HEATED BED BAG 1
[1]
[2] TAPE THERMISTOR BEAD END TO CENTER OF
BUILD PLATE BOTTOM WITH KAPTON TAPE
TAPE IN 3 PLACES MIN.
NOTE: FOR 300x300 PRINTER, PLACE THERMISTOR
IN CENTER HOLE OF RED HEATER PCB.
RUN THERMISTER WIRE UNDER
ALUMINUM FRAME

1.11 ASM Y BELT, CORNER PROTECTORS, AND Y CHAIN MOUNT
PART LOCATION QTY
[1] Y BELT MOUNT PLASTIC PARTS BAG 1
[2] Y BELT: 1.95M [76.75"] LONG HARDWARE BOX 1
[3] TSLOT NUT BAG 3 10
[4] WASHER FOR BELT MOUNT BAG 8 8
[5] SCREW BAG 31 4
[6] Y CABLE CHAIN BOTTOM MOUNT PLASTIC PARTS BAG 1
[7] Y CABLE CHAIN BOTTOM WASHER BAG 9 2
[8] Y CABLE CHAIN BOTTOM SCREW BAG 24 2
[9] END PROTECTORS PLASTIC PARTS BAG 4
[10] END PROTECTOR SCREW BAG 57 4
ASSEMBLE SCREWS LOOSLY
CLAMP Y BELT EVENLY AND FIRMLY
WITH BELT TEETH FACING UPWARD
[1] SOME PART WARPAGE MAY EXIST.
ORIENT SO FLAT SIDE IS TOUCHING FRAME.
USE 2 WASHERS TO CLAMP BELT
IF NESSESARY
[6]
[9]
[10]
[2]
[5] CLAMP TIGHT
AND EVENLY
[4]
[7]
[8]
[3] IN FRAME

2.1 ASM Y ROD MOUNT HARDWARE: 4 TIMES
PART LOCATION QTY
[1] Y ROD MOUNT PLASTIC PARTS BAG 4
[2] NUT BAG 1 4
[3] T SLOT NUT BAG 3 8
[4] WASHER BAG 9 12
[5] SCREW BAG 26 8
[6] SCREW BAG 17 4
LOOSLY ASSEMBLE ALL HARDWARE
[5]
[4]
[6]
[2]
[4]
[3]
[1]

2.2 BUILD Y BELT IDLER/TENSIONER
PART LOCATION QTY
[1] Y IDLER MOUNT PLASTIC PARTS BAG 1
[2] WASHER BAG 9 4
[3] SCREW BAG 29 1
[4] SCREW BAG 25 2
[5] NUT BAG 4 1
[6] T SLOT NUT BAG 3 2
[7] M5 FLANGED BEARING HARDWARE BOX 2
LOOSLY ASSEMBLE SCREWS TO NUTS
[5]
[2]
[4]
[3]
[1]
[6]
[7]

2.3 ASSEMBLE FRONT AND REAR FRAME MEMBERS
PART LOCATION QTY
600x600: 828mm [32.6"] 2020 FRAME
[1] 600x300: 828mm [32.6"] 2020 FRAME
300x300: 523mm [20.6"] 2020 FRAME WRAPPED IN BOX 2
[2] Y ROD MOUNT ASM 2.1 4
[3] Y IDLER ASM 2.2 1
[4] 90 CORNER HARDWARE BOX 4
[5] Y LIMIT SWITCH MOUNT PLASTIC PARTS BAG 1
[6] Y LIMIT SWITCH ELECTRONICS BOX 1
[7] Y LIMIT SWITCH MOUNT SCREW BAG 27 1
[8] T SLOT NUTS BAG 3 5
[9] SCREW BAG 20 2
[10] WASHER BAG 9 1
[11] SCREW BAG 24 4
Y LIMIT SWITCH
LOOSLY ASSEMBLE ALL PARTS.
PARTS WILL BE TIGHTENED AND
POSITIONED PROPERLY IN
FUTURE STEPS
[2] ORIENT SO SCREW HEAD IS
ACCESSIBLE FROM THE SIDES, NOT
THE MIDDLE: 4 PLACES
[1]
[4]
[3]
[11]
[8] IN FRAME
[10]
[7]
[9]
[6]
[5]

2.4 ASM LOWER Z BEARING ROD MOUNT: 2 TIMES
PART LOCATION QTY
[1] Z BEARING ROD MOUNT PLASTIC PARTS BAG 2
[2] SCREW BAG 26 4
[3] SCREW BAG 16 2
[4] WASHER BAG 7 2
[5] T SLOT NUT BAG 3 4
[6] NUT BAG 1 2
ASSEMBLE ALL PARTS LOOSLY
[3] [4]
[2]
[1]
[5]
[6]

600x600: 16.85 [428]
OTHER: 6.80 [173]
2 PLACES
2.5 ASM SIDE FRAME MEMBERS
PART LOCATION QTY
600x600: 968mm [38.11"] 2020 FRAME
[1] 600x300: 460mm [18.11"] 2020 FRAME
300x300: 460mm [18.11"] 2020 FRAME
WRAPPED IN
BOX 2
[2] 600x600 ONLY: Y ROD MOUNT
(WITHOUT SCREWS)
PLASTIC PARTS
BAG 2
[3] Z ROD MOUNT ASM 2.4 2
[4] T SLOT NUTS BAG 3 4
[5] SCREW BAG 24 4
NOTE SIDE FRAME IS INSIDE
FRONT AND BACK FRAME
ASSEMBLE LOOSE
[1]
[3]
[2]
[4]
[5]

2.6a (600x600 ONLY): ASM Y MOTOR MOUNT TO FRAME
SEE 2.6b FOR 600X300 AND 300X300 Y MOTOR MOUNT
PART LOCATION QTY
[1] 968mm [38.11"] 2020 FRAME WRAPPED IN BOX 1
[2] Y MOTOR: NEMA 23 HARDWARE BOX 1
[3] Y MOTOR MOUNT PLASTIC PARTS BAG 1
[4] 90 METAL CORNER HARDWARE BOX 2
[5] SPACERS BAG 13 4
[6] NUT BAG 5 4
[7] T SLOT NUTS BAG 3 4
[8] WASHER BAG 8 2
[9] 90 CORNER SCREW BAG 24 2
[10] MOTOR MOUNT SCREW BAG 28 4
[11] FRAME MOUNT SCREW BAG 30 2
SEE DETAIL A
[9]
[4]
[1]
[7] IN FRAME
LOOSE
[3]
[6]
[8]
[11]
[2]
[5]
[10]
