Peak Scientific Genius 105X Series User manual

Genius1050-1051-1052-1053 User Manual Rev 9 PN UM-0002 RSID 1484 15/11/21
Genius 105X Series
User Manual

Contents
Change History 3
How to use this Manual 3
Introduction 4
Warranties and Liabilities 5
Safety Notices 6
Symbols 6
Safety Notice to Users 6
EU Declaration of Conformity 7
UK Declaration of Conformity 8
WEEE Compliance Statement 9
CSA Compliance Statement 10
Technical Specification 11
Genius 1050 11
Technical Specification 12
Genius 1051 12
Technical Specification 13
Genius 1052 13
Technical Specification 14
Genius 1053 14
Unpacking 15
Fittings Kit Contents 16
Installation 17
Generator Environment 17
Generator Overview 18
Drain Connection 21
Electrical Connection 22
Start-Up Sequence 23
Connecting to the application 24
Tubing Lengths 24
Genius 1051 Gas Flow Combinations 25
Air Selector Switch 25
Normal Operation 26
On Demand Gas 26
Generator Cycling 26
Unusual Operation 26
Service Requirements 27
Service Schedule 27
Service Indication 28
Peak Protected 29
Cleaning 30
High Duty Indication 31
High Duty Indication Reset 31
Indication of Fault 31
Troubleshooting 32
Page 2

Page 3
Change History
Rev Comment Name Date
2 Service Kit Ordering Update Liam Couttie 23/03/2018
3 Declarations Update Liam Couttie 24/04/2018
4 Genius 1053 Update Liam Couttie 15/05/2018
5 Tech Spec Update Liam Couttie 21/08/2019
6 Updates to incorporate CSA feedback Liam Couttie 10/07/2020
7 Power Cord Update Liam Couttie 18/12/2020
8 Genius 1053 Purity Figure Update Liam Couttie 08/03/2021
9 Declarations Update Liam Couttie 15/11/2021
How to use this Manual
This manual is intended for end users and has been written as a reference document
where you can skip to the relevant information.
Users can refer to the contents page to find the relevant information.
Please review each of the following sections carefully.
Thank you for selecting Peak Scientific to meet your gas generation needs, and should
you require any further assistance or support please do not hesitate to contact Peak
Scientific or the Peak Partner from which you purchased your generator.

Page 4
Introduction
The Genius 1050, 1051, 1052 & 1053 have been developed to cater for the gas
requirements of specific LCMS, and other applications, models.
Depending on model, these generators provide a source of nitrogen gas or nitrogen
and dry air with other features including:
• Small in size – fits under a standard lab bench
• Anti- vibration – maximum reduction of vibration
• Service indication – allowing you to plan your maintenance and keep your
application uptime at a maximum
• Improved drainage – reduction of moisture carry over and thus increased
reliability
• Re- heat technology – improves membrane performance and reliability
• Robust control system – improves safety and reliability of units
With the generators based on proven technology, they selectively remove oxygen,
moisture and other gases to leave clean, dry, phthalate free nitrogen gas or nitrogen
and dry air (depending on model). Two internal air compressors make these units
independent from in- house air supplies and fitted castors allow the user to easily
position the units in the lab.
To ensure the generator models meet our high expectations with regards to reliability
and performance, we have tested them extensively at our manufacturing plant and with
end users around the world to ensure reliability and longevity of the system.

Page 5
Warranties and Liabilities
1. The Company warrants that it has title to the Goods.
2. Subject to the provisions of this clause the Company warrants that the Goods
shall comply in all material respects with any specification referred to in the Order
Confirmation (as the same may be amended) and shall, subject thereto, be free
from defects in material and workmanship for the lesser of a period of twelve
months from the date of delivery or thirteen months from the date of dispatch
from the factory.
3. Save as provided in this clause and except where the Goods are sold to a person
dealing as a consumer (within the meaning of the Unfair Contract Terms Act
1977) all warranties, conditions or other terms implied by statute or common
law are hereby expressly excluded save to the extent they may not be lawfully
excluded. When the Goods are sold to a consumer within the meaning of the Unfair
Contract Terms Act 1977 their statutory rights are not aected by the provisions of
this clause.
4. In the event of the Customer making a claim in respect of any defect in terms of
clause 2 hereof the Customer must.
1. Reasonably satisfy the Company that the Goods have been properly installed,
commissioned, stored, serviced and used and without prejudice to the generality
of the foregoing that any defect is not the direct or indirect result of lack of repair
and/or servicing, incorrect repair and/or servicing, use of wrong materials and/or
incorrect spare parts
2. Allow the company to inspect the Goods and/or any installation and any relevant
packaging as and when reasonably required by the Company.
5. Subject to the Company being notified of any defect as is referred to in sub-
clause 2 hereof within a reasonable time of it becoming apparent and subject always
to the terms of sub-clause 4 hereof, the Company shall, in its option, replace or
repair the defective Goods or refund a proportionate part of the Price. The Company
shall have no further liability to the Customer (save as mentioned in sub-clause 6
hereof).
6. The Company shall be liable to indemnify the Customer in respect of any claim
for death or personal injury to any person in so far as such is attributable to the
negligence or breach of duty of the Company or any failure by the Company to
comply with the provisions of sub-clause 2 hereof.
7. Save as provided in sub-clause 2 hereof the Company shall not be liable in respect
of any claim by the Customer for costs, damages, loss or expenses (whether direct,
indirect, consequential or otherwise) or indemnity in any respect howsoever arising
including, but not by way of limitation, liability arising in negligence (other than
pursuant to clause 6 above) that may be suered by the Customer or any third
party.

WARNING
WARNING
WARNING
WARNING
CAUTION
Page 6
Safety Notices
Peak Scientific Instruments cannot anticipate every possible circumstance which may
represent a potential hazard. The warnings detailed within this manual refer to the most
likely potential hazards, but by definition cannot be all inclusive. If the user employs
an operating procedure, item of equipment or a method of working which is not
specifically recommended by Peak Scientific, the user must ensure that the equipment
will not be damaged or become hazardous to persons or property.
Symbols
This manual uses the following symbols to highlight specific areas important to the safe
and proper use of the generator.
A WARNING notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause
personal injury or in the worst case death. Do not proceed beyond a WARNING
notice until the indicated conditions are fully understood or met.
A CAUTION notice denotes a hazard. It calls attention to an operating procedure,
process or similar, which if not correctly performed or adhered to, could cause
damage to the generator or the application. Do not proceed beyond a CAUTION
notice until the indicated conditions are fully understood or met.
Caution, risk of electric shock. Ensure power to the generator has been removed
before proceeding.
Safety Notice to Users
These instructions must be read thoroughly and understood before
installation and operation of your Peak Generator. Use of the generator
in a manner not specified by Peak Scientific MAY impair the SAFETY
provided by the equipment.
When handling, operating or carrying out any maintenance, personnel
must employ safe engineering practices and observe all relevant local
health and safety requirements and regulations. The attention of UK
users is drawn to the Health and Safety at Work Act 1974, and the
Institute of Electrical Engineers regulations.
If the equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment maybe impaired.

Page 7
EU Declaration of Conformity
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Hereby declare that, this declaration of conformity is issued under the sole
responsibility of the manufacturer.
Equipment Type: Nitrogen Gas Generator
Model Designator: Genius XE 35 & 70
To which this declaration relates, is in conformity with the following applicable EU
Directives, harmonized standards, and other normative requirements.
• Low Voltage Directive 2014/35/EU
EN 61010-1: 2010 Safety Requirements for Electrical Equipment for Measurement,
Control and Laboratory Use.
• Electromagnetic Compatibility Directive 2014/30/EU
EN 61326-1: 2013 Electrical Equipment for Measurement, Control and Laboratory Use
– EMC Requirements. (Class A)
• Restriction on the use of certain hazardous substances in electronic equipment
(RoHS) Directive 2011/65/EU as amended by EU 2015/863.
• FCC 47 CFR Part 15 class A
Unintentional radiators; Conducted and Radiated emissions limits.
Signed for and on behalf of Peak Scientific by
Signed:
Name: Fraser Dunn
Position: Design Engineering Manager
Peak Scientific Instruments ltd,
Inchinnan, Renfrew, Scotland, PA4 9RE, UK.
Date: 16th August 2021

Page 8
UK Declaration of Conformity
We Peak Scientific Instruments Ltd.
Of Fountain Crescent, Inchinnan, Renfrewshire, PA4 9RE
Hereby declare that, this declaration of conformity is issued under the sole
responsibility of the manufacturer.
Equipment Type: Nitrogen Gas Generator
Model Designator: Genius XE 35 & 70
To which this declaration relates, is in conformity with the following applicable UK
Statutory Instruments, Standards and other normative requirements.
• The Electrical Equipment (Safety) Regulations 2016 (SI 2016 / 1101) as amended.
BS61010-1:2010 Safety Requirements for Electrical Equipment for Measurement
Control and Laboratory Use.
• The Electromagnetic Compatibility Regulations 2016 (SI 2016 / 1091) as amended.
BS61326-1:2013 Electrical Equipment for Measurement , Control and Laboratory Use
– EMC Requirements.
• The Restriction of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012 (SI 2012 / 3032) as amended.
Signed for and on behalf of Peak Scientific by
Signed:
Name: Fraser Dunn
Position: Design Engineering Manager
Peak Scientific Instruments ltd,
Inchinnan, Renfrew, Scotland, PA4 9RE, UK.
Date: 16th August 2021

Page 9
WEEE Compliance Statement
The Waste Electrical and Electronic Equipment (WEEE) Regulations SI 2013 No 3113
and or the Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU
apply to all electrical and electronic equipment placed on the market in the UK and EU
covered by the scope of regulations which can be found in the Government Guidance
Notes (PDF) produced by the Department for Business Innovation and skills for the UK
and here for Europe.
All PEAK products that are subject to the WEEE directive are compliant with the
WEEE marking requirement. Such products are marked with the “crossed-out wheelie
bin” symbol (shown below) in accordance with European standard EN50419. All
old electrical equipment can be recycled. Please do not dispose of any electrical
equipment (including those marked with this symbol) in general rubbish bins. Please
contact your dealer or distributor for clarity.

Page 10
CSA Compliance Statement
CSA Group (Canadian Standards Authority) is a Nationally Recognised Testing
Laboratory (NRTL), headquartered in Toronto Canada.
They are authorised to evaluate product to both their own and Underwriters Laboratory
(UL) standards and certify the product to be in compliance to the relevant standards.
Peak products are certified to the current in force revision of the following standards
in order to cover both Canadian and United States requirements for “Safety
Requirements for Electrical Equipment for Measurement, Control and Laboratory use,
Part 1: general Requirements”.
Canada: CAN/CSA C22.2 No 61010-1-12
United States: UL 61010-1
As a result the products covered by this statement are certified and listed by CSA
accordingly and are entitled to carry the CSA mark with both Canadian and United
States subscripts , as shown below on the product rating label.

Page 11
Technical Specification
Genius 1050
Environment
Minimum Operating Ambient Temperature 5°C (41°F)
Maximum Operating Ambient Temperature 35°C (95°F)
Maximum Altitude 3000 m
Maximum Relative Humidity 80% Non-Condensing
Minimum Storage Temperature* -20°C (-4°F)
Maximum Storage Temperature* 60°C (140°F)
*NOTE – When taken out of storage the Generator should be allowed to acclimatize at room temperature
for a minimum of 3 hours before operation.
Please ensure generator is situated in a well-ventilated environment
Generator Outlets
Maximum Gas Output Pressure 6.9 bar (100 psi)
Maximum Outlet Flow Rate 32 L/min (1.13 cfm)
Maximum Dewpoint ≤-50°C (-58°F)
N2 Purity ≤5%
Particles <0.01µm
Phthalates NONE
Suspended Liquids NONE
Gas Outlets 1 x ¼” BSPP
Drain outlet 1 x ¼” BSPP
Pressure gauges 1
Electrical Requirements
Voltage 220-240 VAC +/- 10%
Frequency 50/60 Hz
Current 7 Amps
Input Connection C20 Plug
Power Cord C19 socket to local connection (10A minimum)
Pollution Degree 2
Installation / overvoltage category II
General
Dimensions cm (inches) WxDxH 60 x 75 x 71.2 (23.6 x 29.5 x 28)
Generator Weight Kg (lbs) 112 (246)
Shipping Weight Kg (lbs) 134 (295)

Page 12
Technical Specification
Genius 1051
Environment
Genius 1051
Minimum Operating Ambient Temperature 5°C (41°F)
Maximum Operating Ambient Temperature 35°C (95°F)
Maximum Altitude 3000 m
Maximum Relative Humidity 80% Non-Condensing
Minimum Storage Temperature* -20°C (-4°F)
Maximum Storage Temperature* 60°C (140°F)
*NOTE – When taken out of storage the Generator should be allowed to acclimatize at room temperature
for a minimum of 3 hours before operation.
Please ensure generator is situated in a well-ventilated environment
Generator Outlets
Maximum Gas Output Pressure 6.9 bar (100 psi)
Maximum Nitrogen Outlet Flow Rate with 25 L/min (0.88 cfm) with 0 L/min Dry Air**
Maximum Dry Air Outlet Flow Rate 25 L/min (0.88 cfm) with 0 L/min Nitrogen**
** up to 25LPM of Air & Nitrogen
Maximum Dewpoint -50°C (-58°F) N2 / -20°C (-4°F) Dry Air
N2 Purity ≥97%
Particles <0.01µm
Phthalates NONE
Suspended Liquids NONE
Gas Outlets 2 x ¼” BSPP
Drain outlet 1 x ¼” BSPP
Pressure gauges 2
Air shut-o switch Yes
Electrical Requirements
Voltage 220-240 VAC +/-10%
Frequency 50/60 Hz
Current 7 Amps
Input Connection C20 Plug
Power Cord C19 socket to local connection (10A minimum)
Pollution Degree 2
Installation / overvoltage category II
General
Dimensions cm (inches) WxDxH 60 x 75 x 71.2 (23.6 x 29.5 x 28)
Generator Weight Kg (lbs) 115 (253)
Shipping Weight Kg (lbs) 136 (299)

Page 13
Technical Specification
Genius 1052
Environment
Minimum Operating Ambient Temperature 5°C (41°F)
Maximum Operating Ambient Temperature 35°C (95°F)
Maximum Altitude 3000 m
Maximum Relative Humidity 80% Non-Condensing
Minimum Storage Temperature* -20°C (-4°F)
Maximum Storage Temperature* 60°C (140°F)
*NOTE – When taken out of storage the Generator should be allowed to acclimatize at room temperature
for a minimum of 3 hours before operation.
Please ensure generator is situated in a well-ventilated environment
Generator Outlets
Maximum Heating Outlet Flow Rate 20L/min (0.703cfm) @ 3.1 bar (45psi)
Maximum Cooling Outlet Flow Rate 12L/min (0.424cfm) @ 2.07 bar (30psi)
Maximum Dewpoint ≤-50°C (-58°F)
N2 Purity ≤5%
Particles <0.01µm
Phthalates NONE
Suspended Liquids NONE
Gas Outlets 2 x ¼” BSPP
Drain outlet 1 x ¼” BSPP
Pressure gauges 1
Electrical Requirements
Voltage 220-240 VAC +/- 10%
Frequency 50/60 Hz
Current 7 Amps
Input Connection C20 Plug
Power Cord C19 socket to local connection (10A minimum)
Pollution Degree 2
Installation / overvoltage category II
General
Dimensions cm (inches) WxDxH 60 x 75 x 71.2 (23.6 x 29.5 x 28)
Generator Weight Kg (lbs) 112 (246)
Shipping Weight Kg (lbs) 137 (301)

Page 14
Technical Specification
Genius 1053
Environment
Minimum Operating Ambient Temperature 5°C (41°F)
Maximum Operating Ambient Temperature 35°C (95°F)
Maximum Altitude 3000 m
Maximum Relative Humidity 80% Non-Condensing
Minimum Storage Temperature* -20°C (-4°F)
Maximum Storage Temperature* 60°C (140°F)
*NOTE – When taken out of storage the Generator should be allowed to acclimatize at room temperature
for a minimum of 3 hours before operation.
Please ensure generator is situated in a well-ventilated environment
Generator Outlets
Maximum Gas Output Pressure 690 kPa (100 psi)
Maximum Outlet Flow Rate up to 20 L/min (0.70 cfm)
Maximum Dewpoint ≤-50°C (-58°F)
N2 Purity
20L/min @ 99.3%
15L/min @ 99.7%
10L/min @ 99.98%
5L/min @ 99.998%
Particles <0.01µm
Phthalates NONE
Suspended Liquids NONE
Gas Outlets 1 x ¼” BSPP
Drain outlet 1 x ¼” BSPP
Pressure gauges 1
Electrical Requirements
Voltage 220-240 VAC +/-10%
Frequency 50/60 Hz
Current 7 Amps
Input Connection C20 Plug
Power Cord C19 socket to local connection (10A minimum)
Pollution Degree 2
Installation / overvoltage category II
General
Dimensions cm (inches) WxDxH 60 x 75 x 71.2 (23.6 x 29.5 x 28)
Generator Weight Kg (lbs) 111 (244)
Shipping Weight Kg (lbs) 133 (293)

Page 15
Unpacking
Although Peak Scientific takes every precaution with safe transit and packaging, it is
advisable to fully inspect the unit for any sign of transit damage.
Check ‘SHOCKWATCH’ and ‘TIP-N-TELL’ labels for signs of rough handling prior to
unpacking.
Any damage should be reported immediately to the carrier and Peak Scientific or the
Peak Partner from where the unit was purchased.
Follow the unpacking instructions posted on the side of the crate. It will require two
people to remove the unit from the shipping crate and to manoeuvre the generator to
the desired location.
Ensure castors are locked once Generator is in desired position.
Please save the product packaging for storage or future shipment of the generator.
Note: Included with the generator is a “Fittings Kit” containing mains power leads for
UK, EU & US and also all the required fittings and warranty registration card. Be careful
not to discard these with the packaging.
Page 15

Page 16
Fittings Kit Contents
Supplied in the Fittings Kit are all the fittings required to connect the generator to the
application. The contents of the Fittings Kit are as follows:
1. 6mm Teflon Tubing* x 3m
2. ¼” Teflon Tubing** x 3m
3. 6mm PE Tubing x 3m
4. ¼” Compression Fitting*** x 1
5. 6mm Push-Fit Fitting**** x 2
6. Flow Control Silencer***** x 1
7. 8mm Hex Key x 1
8. UK Mains Power Cable****** x 1
9. EU Mains Power Cable****** x 1
10. US Mains Power Cable 230v****** x 1
11. JP Mains Power Cable 100v******* x 1
All of the generators output ports are located on the output panel at the rear of the
unit.
* x6m with Genius 1051 & 52
** Genius 1050 & 53 Only, x6m with Genius 1052
*** Genius 1050 & 53 Only, x2 with Genius 1052
**** x3 with Genius 105, x4 with Genius 1052
***** x2 with Genius 1051 & 52
****** Genius 1050, 51, 52 & 53 Only

Page 17
Installation
Generator Environment
The generator is designed for indoor use only. It should be installed adjacent to
the application(s) it is supplying. If this is not convenient then the unit can be sited
elsewhere, however, consideration should be made of the lengths of pipe runs as
pressure drops can result from extended runs of pipe.
The generator should be situated in a well ventilated environment, with at least a
75mm (3”) air gap all around it and should be positioned such that it can be easily
disconnected from the mains supply if required
Performance of the generator (like all sophisticated equipment) is aected by ambient
conditions. Note should also be taken to the proximity of Air Conditioning outlets.
These can sometimes give rise to “pockets” of air with high relative humidity. Operation
of the unit within such a pocket could adversely aect its performance. Consideration
should also be given to the air flow around the unit. It is recommended that an air gap
of 75mm (3”) should be maintained down both sides and at the rear of the unit. Please
refer to the drawing on the following page for the general dimensions of the unit.
Minimum Operating Ambient Temperature: 5 °C (41 °F)
Maximum Operating Ambient Temperature: 35 °C (95 °F)

Page 18
Generator Overview
General Dimensions
The generator must always be placed on a flat, level surface. Failure to
do so will aect the performance of the generator.
WARNING
600 mm / 23.6” 750 mm / 29.5”
712 mm / 28"
Power Switch

Page 19
Genius 1050 & 1053 Rear Connections
Genius 1050, 1052 & 1053 Unit Controls
¼" Compression Fitting
6mm Push-Fit Fitting
Mains Cable
Service LED
Power Switch
Pressure Gauge
High Duty LED

Page 20
Genius 1051 & 1052 Rear Connections
Genius 1051 Unit Controls
¼" Compression Fittings
6mm Push-Fit Fitting
Mains Cable
Service LED
Power Switch
Ensure all inlets and outlets
are connected to correct
sources and applications
All Connections should only
be carried out by trained
personnel
Generator must be switched
off and unplugged prior to
any cleaning or maintenance
operations
Pressure Gauge
High Duty LED
Air Selector Switch
CAUTION
CAUTION
CAUTION
