Pearl Abrasive VX141MSPROR Owner's manual

serial number -
Caution! Read Safety and General Instructions carefully before using saw for the first time.
You should record the Serial Number of your Tile Saw on this
Owner’s/Operator’s Manual and on the Warranty Card. The Warranty
Card must be sent back with all the required pertinent information
for the warranty to take effect.
REV. 2
MODEL VX141MSPROR™ RENTAL
MASONRY/BRICK SAW
OWNER’S/OPERATOR’S MANUAL
Pearl Abrasive Co. 2.1 MASONRY SAW
™
™
R
R
RENTAL

TABLE OF CONTENTS
I. GENERAL SAFE Y RULES FOR ALL POWER OOLS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
II. SYMBOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
III. FEA URES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
IV. SPECIFICA IONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
V. UNPACKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
VI. INS ALLA ION AND OPERA ION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
VII. PROPER BLADE USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
VIII. CARE AND MAIN ENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
IX. CHANGING MO OR VOL AGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
X. ELEC RICAL MO OR SPECIFICA IONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
XI. REPLACEMEN PAR S LIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
XII. ROUBLESHOO ING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
XIII. ACCESSORIES AND PAR S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
XIV. HE RIGH BLADES DOES HE RIGH JOB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
XV. HOW O ORDER PAR S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
XVI. WA ER HOSE KI INS ALLA ION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
PAGE

– 3–
i. GENERAL SAFETY RULES FOR ALL POWER TOOLS
1. Know your power tool - read owner’s/operator’s manual carefully. Learn its applications and limitations
as well as the specific potential hazards unique to this tool.
2. Keep guards in place - and in working order.
3. Ground all tools - if tools are equipped with three prong plug, it should be plugged into a three-hole
electrical receptacle. f an adapter is used to accommodate a two-prong receptacle, the adapter lug must be
attached to a known ground. Never remove the third prong.
4. Remove wrenches - Form a habit of checking to see that adjusting wrenches are removed from tool before
turning it “on”.
5. Keep work area clean. Cluttered areas and benches invite accidents.
6. Do not use in dangerous environment. Do not use power tools in damp or wet locations, or expose them
to rain. Keep work area well lighted. Do not use tool in the presence of flammable liquids or gasses.
7. Keep children and visitors away. All children and visitors should be kept at a safe distance from work area.
8. Make workshop childproof with padlocks, master switches or by removing starter keys.
9. Do not force tool. t will do the job better and be safer at the rate for which it was designed.
10. Use right tool. Do not force tool or attachment to do a job for which it was not designed.
11. Wear proper apparel. Do not wear loose clothing, gloves, neckties, rings, bracelets or other jewelry that
may get caught in moving parts. Non-slip footwear is recommended. Wear protective hair covering to
contain long hair.
12. Always use safety glasses. Wear safety glasses (must comply with ANS Z87.1) at all times. Everyday
eyeglasses only have impact resistant lenses; they are not safety glasses. Use face or dust mask if cutting
operation is dusty, and ear protectors (plugs or muffs) during extended periods of operation.
13. Do not overreach. Keep proper footing and balance at all times.
14. Maintain tools in top condition. Keep tools sharp and clean for best and safest performance. Follow
instructions for lubricating and changing accessories. nspect tool cords periodically and if damaged, have
repaired by authorized service facility.
15. Disconnect tools. When not in use, before servicing, and when changing accessories, such as blades,
bits, cutters.
16. Avoid accidental starting. Make sure switch is in “off” position before plugging in power cord.
17. Use recommended accessories only. Consult the owner’s manual for recommended accessories. The
use of improper accessories may cause risk of injury to persons.
18. Never stand on tool. Serious injury could occur if the tool is tipped or if the cutting tool is accidentally
contacted.
19. Check Damaged Parts. Before further use of the tool, a guard or other part that is damaged should be
carefully checked to ensure that it will operate properly and perform it’s intended function. Check for
alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other conditions
that may affect it’s operation. A guard or part that is damaged should be properly repaired or replaced.
20. Never leave tool running unattended. Turn power “off”. Do not leave tool until it comes to a complete
stop.
Read all instru tions. As with all ma hinery there are ertain hazards involved with
operation and use of the ma hine. The following basi safety pre autions should be followed at all times to
redu e the risk of fire, ele tri sho k and serious personal injury to you or others. Keep these important
operating instru tions with this produ t.
WARNING!

– 4–
KEEP GUARD N PLACE
D AMOND BLADE
BLADE CUTT NG DEPTH
ELECTR C SW TCH OFF
ELECTR C SW TCH ON
ELECTR CAL HAZARD
REMOVE TOOLS
PAY EXTREME
ATTENT ON
REPA RS TO BE DONE
MACH NE HAZARD
FLAMMABLE
READ NSTRUCT ONS
CAREFULLY
WARN NG
FRAG LE
KEEP DRY
DO NOT STEP ON
WEAR HEAR NG
PROTECT ON
WEAR EYE PROTECT ON
WEAR BREATH NG
PROTECT ON
WEAR HARD HAT
WEAR PROTECT VE
CLOTH NG
WEAR SAFETY SHOES
WELL VENT LATED
NO NON-WORK NG
PERSONNEL
21. Extension cords. Make sure your extension cord is in good condition. When using an extension cord,
be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause
a drop in line voltage resulting in loss of power and overheating. Extension cord tables ( efe to page 21)
show the correct size to use depending on cord length and nameplate ampere rating. f in doubt, use the
next heavier gage. The smaller the gage numbers the heavier the cord.
22. Do not abuse cord. Never carry tool by cord or pull it to disconnect from receptacle, Keep cord from
heat, oil, and sharp edges.
23. Guard against electric shock. Prevent body contact with grounded surfaces. For example, pipes,
radiators, ranges and refrigerator enclosures.
24.Outdoor use extension cords. When tool is used outdoors, use only extension cords intended for use
outdoors and so marked.
25. Stay alert. Watch what you are doing. Use common sense. Do not operate tool when you are tired.
26. Drugs, alcohol, medication. Do not operate tool while under the influence of drugs, alcohol or any
medication.
27. Store idle tool. When not in use, tool should be stored in a dry and locked place, out of reach of children.
ii. SYMBOLS

CALIFORNIA PROPOSITION 65: Sawing and drilling generates dust. Ex essive airborne
parti les may ause irritation to eyes, skin and respiratory tra t. To avoid breathing impairment always employ
dust ontrols and prote tion suitable to the material being saw or drilled in a ordan e with OSHA (29 CFR Part
1910.1). Diamond blades improperly used are dangerous. Comply with ANSI Safety Code B7.1 and OSHA
overing speed, safety guards, flanges, mounting pro edures, general operating rules, handling, storage and
general ma hine ondition.
WARNING!

– 5––
iii. FEATURES
HEAVY DUTY ALUMINUM SWITCH
box with an integrated circuit breaker
further increasing saw reliability
RAISED PLATFORM FRAME
Design making edges easy to
lift from
TABLE LOCKING MECHANISM
facilitates the saw’s chopping
operation
OPTIONAL OUTER TRAY
for wet application
POWERFUL DUAL VOLTAGE 2HP
induction motor designed to be
powerful yet convenient the user
REINFORCED
RIGID FRAME
contruction
provides steady
precision cutting
VX141MSPROR MASONRY/BRICK SAW
MOTOR MAX. BLADE
CAPACITY
CUTTING
LENGTH
CUTTING
DEPTH WEIGHT SIZE
(LxWxH)
i . SPECIFICATIONS
14" blade with
1" (25.4mm)
arbor
16"
Max material
size 8 x 8 x16"
5" 110 lbs. 31.5 x 18.5
x 21"
2 HP nduction
115 v, 60 Hz,
2,600 rpm

– 6–
i. INSTALLATION AND OPERATION
1. Rotate the blade bolt access door down.
See Figu e 1.
2. Remove the blade shaft bolt, washer and
outer flange.
3. Place the blade onto the blade shaft. The
bore of the blade should sit fully on a
shoulder located on the inner flange. Make
sure that the directional arrow on the blade
is aligned with the rotation of the shaft.
4. Reinstall the outer flange, washer and
blade shaft bolt in this order. Tighten the
bolt using the provided wrenches
The cutting table comes preinstalled on the
machine. To remove the cutting table perform the
following steps:
1. Make sure the table lock is not engaged.
See Figu e 2.
2. Loosen the bolts as shown on right so the
brackets they secure can slide down.
3. With both brackets down, lift the table
from the rails starting from the left side.
4. Perform the steps in reverse to remount
the table.
Figure 2
Figure 1
. UNPACKING
Open the container. Carefully lift the saw out evenly by the frame. Be certain you have the following
items before you discard the container:
• Saw • Size 19 Open Wrench
• 14" saw blade • 45º/90º rip guide
• Universal wrench • Owner’s manual
BLADE INSTALLATION CUTTING TABLE ASSEMBLY

– 7––
THE CUTTING TABLE
The heavy-duty cutting table provides the durability to
handle large materials. Figu e 3.
STEPS TO USE THE 45˚ / 0˚ RIP
GUIDE
1. Set the rip guide by positioning it on the
desired dimension and tighten the threaded
knob. Make sure that the rip guide is firmly
tightened to avoid slippage. The rip guide can
be used 90˚ rip cugts and 45˚ angle cuts from
both the left and right side. (Note: The
straight and 45˚ angled slits on the bottom of
the rip guide.)
2. After the rip guide is positioned for the
desired cut, place material flat against the rip
guide and the measurement rail. For the 45˚
rip cuts, place the corner of material in the
open slot of the measurement rail.
3. Simply line up the material being cut with the
appropriate pre-marked lines on the cutting
table.
4. Now you are ready to make your cut.
CUTTING DEPTH
The recommended cutting depth is 1/4" below the
cutting table surface. When setting the cutting depth,
do a practice pass with the table to make sure the
blade does not cut into it.
The VX141MSPROR Masonry Saw is designed to cut
at any cutting. t can perform plunge cutting (table is
fixed and the cutting head is in motion), jam cutting
(cutting head is fixed and the table is in motion) or
step cutting (a combination of the both).
1. Before adjusting the cutting depth always
disconnect the electrical power supply.
2. To adjust the VX141MSPROR's cutting depth,
rotate the depth control knob counter-
clockwise while holding the plunge handle
See Figu e 4. Only loosen the knob enough so
the cutting head freely moves.
3. Reposition the cutting head as necessary and
then lock it in place by rotating the knob in the
reverse direction. Tighten the knob firmly.
CHOP / PLUNGE SAW
OPERATION
To operate the VX141MSPROR as a chop or plunge
saw: pull up on the Angle Lock Pin, rotate 90 degrees,
and release. Now the cutting head can be rotated by
pulling up or pushing down on the cutting head
handle. When not in use, always lock the head into
one of the three cutting height positions.
WAR I G: Only use the 14” diameter blade
for this saw. Setting smaller size of diamond blade
may grab the material being cut, causing damage
and possibly injury.
WAR I G: It is recommended to cut all the
way through the material being cut. Failure to do
so can result in the diamond blade grabbing the
material causing damage and possibly injury.
Figure 3
Blade Diameter Cutting Depth
14" 5 inch
HEAD POSITIO APPLICATIO
Fixed head Jam cutting brick/block
Fixed head upper Diamond blade replacement
Moving head Chop or plunge cutting
Moving head with Step cutting
moving table
Figure 4

– 8–
ii. PROPER BLADE USE
iii. CARE AND MAINTENANCE
DO’S
• Inspect blades daily for cracks or uneven wear.
• Always use appropriate blade for material being cut.
• Inspect arbor shaft for uneven wear before mounting blade.
• Always use blades with the correct arbor shaft size.
• Ensure that blade is mounted in the correct direction.
• Use proper safety equipment when operating the saw.
• Secure the blade to the arbor with a wrench.
• Periodically check the blade for cracks or bond fatigue.
• In addition to the following, always follow wet
recommendations.
• Use appropriate blade for material being cut.
• Inspect segment blades for segment cracking or loss.
• Do not use damaged blades.
• Use proper safety equipment when operating the saw.
DON’TS
• Do not operate the saw without safety guards in position.
• Do not operate the saw with blades larger than 14".
• Do not cut dry with blades marked “Use Wet”.
• Do not exceed manufacturer’s recommended maximum
RPM.
• Do not force blade into material. Let blade cut at its own
speed.
• In addition to the following, always follow wet
recommendations.
• Do not make long cuts with dry blades. Allow them
to air cool.
• Do not use the edge or side of blade to cut or grind.
• Do not attempt to cut a radius or curve.
• Do not cut too deep or too fast into the material.
• Do not cut any material not recommended by blade
manufacturer.
CLEANING
AFTER EVERY USE OF THE MACH NE:
• Remove dirty water from container.
• Remove dirt and mud from the bottom of the
container
AFTER WET CLEAN NG AND BEFORE US NG THE
MACH NE AGA N:
• Connect the machine to an electric power
outlet equipped with a GFC safety power
breaker. f the safety power breaker cuts off
the electrical power supply, do not try to
operate the machine but have it checked by an
authorized dealer first.
BEFORE AND AFTER A PROLONGED T ME:
• After not using the machine for a prolonged
period of time, clean and lubricate all movable
parts.
• Check that the saw is sitting properly on the
folding stand.
• Check that all the screw joints and nuts are
fixed.
• Check that the roller table is in its guides and
that is easily moves to and from.
• With the saw blade removed, switch on the
motor for an instant and switch it off again. f
the motor does not run, have the machine
inspected by a qualified electrician.
WAR I G: For your safety before performing
any maintenance on t e saw turn off t e power
switc and unplug t e power cord.

– 9––
ix. CHANGING MOTOR VOLTAGE
The VX141MSPROR motor has the ability to accept power from a 115V
and 230V power source. By default the motor is set to accept power
from a traditional 115V power source. For best motor performance run
the motor using 230V.
To change the voltage of the motor,
perform the following steps:
1. Disconnect the electrical supply.
2. Remove the lock hardware as shown
on right.
3. Toggle the voltage select on the dual
voltage switch box to the desired
voltage.
4. Re-lock the voltage select using the
lock hardware.
WAR I G: Turning on the
saw, while the motor is set at
115V, to a 230V electrical power
supply will cause irreparable
damage to the motor.
x. ELECTRICAL MOTOR SPECIFICATIONS
Horse Power 2 HP
Volts 115V/230V
Amps 7.5A/15A
Motor RPM 3,250 rpm
Cycle 60 Hz
115V
25'
50'
75'
NA
230V
100'
150'
250'
NA
Recommendations:
• t is recommended that a 20 amp circuit be used while operating this saw.
This will prevent possible power interruption or loss.
• Always plug saw as close as possible to the power source while operating.
This will allow you to receive optimum electricity.
Electrical Wiring Diagram
WAR I G: To avoid
permanent motor damage you
must use the correct extension
cord. ever use more than one
extension cord at a time. Follow
the chart for proper size.
WIRE
GAUGE
12 AWG
10 AWG
8 AWG
6 AWG

– 10 –
VX141MSPROR
MAIN ASSEMBLY
1 Frame assembly (no rails) PA150328
2 Depth guide weldment PA141094
3 Collar Set Cutting Head V390046
4 Long shaft sleeve (194L) PA150296
5 Short shaft sleeve (53.5L) PA150297
6 Cutting head shaft PA150298
7 Shaft anti-roll block V390060
8 Cross bar position bracket PA150299
9 Spring recoiling block PA141096
10 Right torsional spring PA141099
11 Left torsional spring PA141095
12 Pin PA150303
13 Rail (2) V390013
14 Blade guard assembly PA150305
15 Complete Cutting Table without Brackets V390023
16 Underside shield PA150305
17 M4 Spring lock washer (11) PA00039
18 M10 Spring lock washer (2) PA0307
19 M5 Spring lock washer (4) V3925053
20 M4 x 0.7 x 10L Cross screw (11) V390353
21 M5 X 0.8 X 16L Cross screw (4) V3925058
22 Dia 17mm arbor inner flange V390029
23 Dia 17mm arbor outer flange V390006
24 M10 Wide washer (3) PA0306PR
25 14" (356mm) Multi-purpose seg. blade PV1412XL
26 M10 x 1.25 x 20L Hex bolt - Left V390005
27 M10 X 1.5 X 20L Hex bolt (2) V390001
28 3/8-16 X 30L UNC Adjustable knob PA414091
29 3/8 Waved lock washer PA0310
30 M10 Wide washer PA0338
31 M5 Narrow washer (4) V3925054
32 M19 External E-clip (2) PA25018
33 M8 x 1.25 x 20L Flat point set screw PA25118
34 M6 x 1.0 x 10L Set screw (5) PA0316
35 5 x 5 x 25L Square key PA25019
36 5 X 5 X 10 Square Key PA141093
37 M8 X 1.25 Nut (4) PA00015
38 M8 Narrow washer (12) PA00016
39 M8 Spring lock washer (12) PA00020
PART NAME PART NUMBER PART NAME PART NUMBER
xi. REPLACEMENT PARTS LIST

– 11 –
VX141MSPROR
FRAME ASSEMBLY
1 Left Arm V390007
2 Metal pan frame V390017
3 Dust Collection Pan V390014
4 Cross Bar Position Bracket V390048
5 Rubber Feet (4) V370104
6 Rubber stop (2) 12142
7 Rubber Cap (4) V390008
8
M8 x 1.25 x 35L Countersunk socket head hex screw (8)PA150214
9
M6 x 1.0 x 12L Countersunk socket head hex screw (2) PA25027
10 Rail (2) V390013
11 M8 X 1.25 Nylon nut (8) PA00062
12 M5 Narrow washer (4) V3925054
13 M8 Narrow washer (12) PA00016
14 M6 Narrow washer (4) PA00082
15 M5 Spring lock washer (9) V3925053
16 M8 Spring lock washer (12) PA00020
17 M5 x 0.8 x 10L Socket head hex screw (4)PA150331
18 M8 X 1.25 X 30L Socket hex bolt (2) PA2704081
19 M6 x 1.0 x 10L Socket head hex screw (4)PA150333
20 M6 x 1.0 Nut (2) PA0610001
21 M8 X 1.25 Nut (4) PA00015
22 M6 X 1.0 X 40L Hex bolt (2) PA150016
23 M8 x 1.25 x 30L Hex bolt (2) PA081253007
24 M5 X 0.8 X 10L Cross screw (5) PA25100
25 M6 x 1.0 x 20L Cross screw (4) PA110026
26 M10 x 1.5 x 20L Flat point set screw PA25102
27 M10 x 1.5 x 16L Socket button head hex screw (4) PA150338
28 M8 x 1.25 x 40L Socket head hex bolt (8) PA00012
29 Right Arm V390020
30 Left Front Joint V390018
31 Side Frame V390010
32 Cross Tube Front V390015
33 Cross Tube Rear V390019
34 Right Front Joint V390021
PART NAME PART NUMBER PART NAME PART NUMBER

– 12 –
1 2 HP 115V/230V Dual voltage motor VX141122
1A Motor Fan Cover PA141079
1B Motor Fan PA150231
2 Motor Adjustment Clip S1000-10
3 M10 Wide washer PA338
4 M6 Wide Washer PA0600033
5 M10 x 1.5 x 75L Hex bolt PA03371
6 M6 x 1.0 x 10L Hex bolt (6) V390322
7 M8 x 1.25 x 16L Hex bolt (2) PA001161
8 Belt guard bracket PA141105
9 Ø50.8 OD Ø24 ID V-belt pulley PA141072
10 8X7X30 Square Key PA141071
11 5 x 5 x 30L Square key PSV10011
12 M6 x 1.0 x 10L Set screw (2) PA0316
13 PF3300A V-belt PA141101
14 5/16" - 18 UNC x 20L Square neck bolt (4)PA03131
15 20Amp Power switch assembly PA100002
16 Belt guard weldment PA150312
17 M6 Narrow washer (6) PA00082
18 M8 Narrow washer (6) PA00016
19 M5 Narrow washer (2) V3925054
20 M6 Spring lock washer (7) V3911090
21 M8 Spring lock washer (6) PA00020
22 M5 Spring lock washer (2) V3925053
23 5/16" - 18 UNC Nut (4) PA01191
24 30D X 120 Handle PA150313
25 M6 x 1.0 x 16L Socket head hex screw PA25063
26 d39.5 D63.5 V-belt pulley PA141104
27 M5 X 0.8 X 16L Cross screw (2) V3925058
28 Mounting head PA150314
29 D47 d20 6204LBU adial bearing PSV10029
30 D52 d25 adial bearing 6205 ZZ V390032
31 M20 External C-clip CX38048
32 Blade shaft V39150317
33 Gear housing cover V390030
34 D46 d25 Oil seal V390031
35
Voltage Switch Box with bracket (no switch) PA141146
36 Toggle Switch - Change Volts PA141121
37 unning Capacitor Gasket PA141078
38 unning Capacitor PA141077
39 unning Capacitor Cover (black) PA141076
40 Starting Capacitor Gasket PA141073
41 Starting Capacitor PSV10013
42 Starting Capacitor Cover (black) PA141075
43 Power Cable V141001
44 Water Pump Cable PA141067
PART NAME PART NUMBER PART NAME PART NUMBER
A
B
VX141MSPROR
CUTTING HEAD ASSEMBLY

– 13 –
VX141MSPROR
SWI CH ASSEMBLY
VX141MSPROR
ABLE ASSEMBLY
1 Switch box (no cover or electrical components) PSV00002R
2 Aluminum cover PA100006
3 Aluminum rotary switch (external) PA100019
4 Metal relay fork (internal) PA141117
5 Switch box cradle PSV10026R
6 Switch Mounting plate PA100025
7 Rubber Gasket PA100024
8 M20x1.5 (AWG14) Power cable gland V370045
9 FGB17 Cable gland (2) PA150325
10 25Amp Circuit breaker PA150350
11 Reset button boot S1000-03.1
12 20Amp Toggle switch V390027
13 M4 x 0.7 x 13L Countersunk cross screw (4) PA2912
14 M4 X 0.7 X 6L Countersunk Screw (4) PA141112
15 M4 x 0.7 x 10L Countersunk cross screw (4) PA25055
16 M6 X 1.0 Nylon Nut CX38088
17 M4 x 0.7 x 12L Cross screw (4) PA141113
18 M6 Narrow washer (2) PA00082
PART NAME PART NUMBER PART NAME PART NUMBER
1 M6 x 1.0 x 10L Hex bolt V390322
2 Ruler Guide V390022
3 Lock bracket V390026
4 U-Shaped Bearing Roller (complete) (2) V390024
5 Metal Bearing Rollers (complete) (2) V390025
6 M8 Narrow washer (8) PA00016
7 M6 Narrow washer (3) PA00082
8 M8 Spring lock washer (12) PA00020
9 M6 Spring lock washer V3911090
10 M8 x 1.25 x 16L Hex bolt (4) PA001161
11 Spring PA100101
12 M6 x 1.0 x 30L Socket head hex bolt PA25095
13 M8 X 1.25 X 20L Hex bolt (4) CX38052
14 M8 X 1.25 Nut (4) PA00015
15 Cutting table "L" bracket V390023.1
PART NAME PART NUMBER PART NAME PART NUMBER

– 14 –
VX141MSPROR
BLADE GUARD ASSEMBLY
1 D12.7 Circular end cap PA250731
2 Arbor Cover V390003
3 D14.5 Circular end cap (2) PA25073
4 M6 Narrow washer (3) PA00082
5 M6 X 1.0 Nylon Nut CX38088
6 M6 X 1.0 X 16L Hex bolt PA00083
7 M6 x 1.0 x 10L Hex bolt V390322
8 M4 x 0.7 x 10L Cross screw (2) V390353
9 Splash guard PSV10023
PART NAME PART NUMBER

– 15 –
xii. TROUBLESHOOTING
Problem Possible Cause Solution
Machine does not run when
switched on.
Power cord not properly
fixed/plugged in.
Check that the machine is properly
connected to the power supply.
Motor stops (power cut out). Too much pressure exerted
while cutting.
Exert less pressure when cutting.
Poor machine performance little
power.
Power cord/extension cable too
long or cable still wound up
inside cable drum.
Use a power cord/extension cable of
the rated length, use a cable drum
with a cable fully extended.
ncorrect specification for saw
blade.
Use a saw blade which corresponds
to the material being cut.
Saw has a defective electric
system.
Have the electric system of the saw
checked by a qualified technician.
Power cord defective. Have the power cord checked,
replaced if necessary.
Main power switch defective. Have the main power switch checked
and replaced if necessary by a
qualified electrician.
Loose electrical connection
inside the electric system.
Have the whole electric system of the
machine checked by a qualified
electrician.
Motor defective. Have the motor checked and replaced
if necessary by a qualified technician.
Power network is insufficient. Observe the electric ratings of the
machine and connect it only to a
power network which complies with
these ratings.
Drive motor no longer runs at
rated speed (r.p.m.).
Have the motor checked by a
qualified electrician and have it
replaced if necessary.
For your safety and the safety of others, turn the power swit h off and always remove the
plug from power sour e before troubleshooting. Repairs performed by unauthorized
personnel ould ause serious hazard. We re ommend that servi e to this tool be performed by a qualified servi e
te hni ian with original equipment repla ement parts.
WARNING!

– 16 –
Problem Possible Cause Solution
Saw blade wobbles when
running.
Saw blade is damaged or bent.
Flange of the saw blade is
damaged.
Shaft of the motor is bent.
Have the saw blade aligned/flattened.
Clean the receiving flange.
Solder the diamond segments of the
old blade onto another saw blade or
use a new blade.
Replace the saw blade flange.
Replace the electric motor.
Diamond segment becomes
loose.
Overheating of the saw blade;
cooling water not sufficient.
Have the diamond segment soldered
on the blade again; ensure optimum
flow of cooling water.
Cracks in or near the diamond
segment.
Saw blade too hard.
Fixed flange is worn out.
Motor shaft bearing. Replace the bearing of the motor shaft.
Use a softer blade.
Have the fixed flange replaced.
Saw blade is blunt. Saw blade type is unsuitable for
the material being cut.
Saw blade type is unsuitable for
the machine performance.
Saw blade too hard.
Use appropriate type of saw blade.
Appearance of cut is not optimal. Poor tension in the blade
material.
Return the saw blade to the
manufacturer.
Too much load placed on the
saw blade.
Diamond segments are blunt.
Use a suitable saw blade.
Sharpen the saw blade.
The center hole in the saw blade
has become wider due to wear.
The saw blade has slipped on
the motor shaft when running.
The arbor of the saw blade must be
fitted with an appropriate adapter ring.
Check the receiving flange and have it
replaced if necessary.
Diamond segments are blunt. Sharpen the diamond saw blade.
rregular run of the saw blade. Poor tension in the blade
material.
Return the saw blade to the
manufacturer.
Excessive wear. Wrong type of saw blade.
Shaft of motor causes wobbling.
Overheating.
Use harder saw blades.
Have bearings of the motor of the
motor replaced.
Ensure optimum flow of cooling
water.

– 17 –
Problem Possible Cause Solution
Saw blades shows blooming
colors.
Lateral friction when cutting. The material feed is too high; proceed
more slowly.
Grinding marks on the saw
blade.
Material is not being fed parallel
to the saw blade.
Poor tension in the blade material.
Ensure that the direction of feed is
absolutely parallel to the saw blade.
Adjust the roller table/have it adjusted.
Too much load on the saw blade. Have the saw blade tensioned.
The material feed is too high, proceed
more slowly.
xiii. ACCESSORIES & PARTS
ame
(Optional) Wet Cutting Kit
ncludes: Water Tub, Water Feed, Drip Tray,
Drain Plug, Water Pump
Part umber
V350MSWK T
Knob Only (1)
V35016
ame (Qty.)
Complete 45˚/90˚
Rip Guide with
Knob (1)
Part umber
V35000
ame (Qty.)
(Optional)
Water Hose Kit (1)
Part umber
V350MSGHK T
ame (Qty.)
(Optional) Brick
Saw Stand (1)
Part umber
V350MS

– 18 –
x . HOW TO ORDER PARTS
Please have the following information ready before calling:
• Serial Number of your Tile Saw
• Model Number of the Tile Saw
• When purchased and where
• Part Description
All parts listed may be ordered from your Local warehouses. f the part is not stocked locally, call our Corporate
office and ask for our Customer Service Department. For Technical Support call 1-800-969-5561. n Canada call
1-800-387-0008. There is a $25.00 minimum order.
Return Policy: Return goods for credit or exchange on the basis of the following terms: (1) They must be current
products; (2) tems returned for replacement or refund should be in original cartons and must be accompanied
by a packing slip with the following information: Returned Goods Authorization (RGA) number obtainable from
Customer Service Department • List of items returned • Reason(s) for return(s) • Copy of original invoice(s); (3)
Freight charges must be assumed by sender; (4) Returning goods are subject to a 15% handling charge to cover
our cost of repacking and restocking. All Prices are subject to change without notice.
Disclaimer: Pearl Abrasive Co. reserves the right to make changes or improvements on its products without
incurring an additional obligation including any obligation to make corresponding changes or improvements to
products previously manufactured or sold. Pearl reserves the right to discontinue products at any time without
notice.
All illustrations displayed in this manual are the property of Pearl Abrasive Co. and shall not be duplicated or
reproduced without the express written consent of Pearl Abrasive Co.
xi . THE RIGHT BLADES DOES THE RIGHT JOB
For the most effective cutting and blade life always use the recommended Pearl Abrasive Co. blade.
APPLICATION
PEARL BLADE
SERIES
P1 EXV™
Concrete/Masonry
P2 PRO-V™
Concrete/Masonry
P4™ (CP)
Concrete/Masonry
P5™ (CSP)
Concrete/Masonry
P2 PRO-V™ (SDS)
Hard Materials
P5™ ( SP)
Hard Materials
P5™ (BB)
Masonry
brick block paver hard brick refrac ory
brick

– 19 –
x i. WATER HOSE KIT INSTALLATION
1. Ori nt th wat r pip s as shown in Fig. A. Ins rt th short st pip from th "Y"
adapt r into th adjac nt sl v at th r ar of th blad guard. First, you will n d to
r mov th black cap cov ring th hol ins rt (#1). Th long st pip , which has a
control valv midway, should b point d towards th floor.
2. Ins rt th s cond pip protruding from th top of th "Y" adapt r into th slot locat d
on th sid of th blad guard towards th front of th saw. This is th hol in th
front of th blad guard (#2), do not r mov th black caps on th sid . S Fig. B.
#1
#2
Black caps
(do not r mov )
Som forc will b r quir d to
pinch th mouth of th pip
wh n ins rting it into th slot.
Fig. A
Fig. B
Th clamp includ d is only us d on VX141MS -- not VX141MSPRO (RENTAL)

Part No. VX141MSPRORMAN • 07/17
GEORGIA • USA
3950 STEVE EYNOLDS BLVD.
NO C OSS, GEO GIA 30093
ONTARIO • CANADA
375-2 PIDO OAD
PETE BO OUGH, ONTA IO K9J-6X7
CORPORATE OFFICE: SO. CALIFORNIA • USA
4900 ZAMB ANO ST., COMME CE, CA 90040-0031
562-927-5561 • FAX [phone]
Toll Free: 800-969-5561
www.pearlabras ve.com
