Pearl River S3 User manual

USER MANUAL
S3

INDEX
Safety Guideline .................................................................................................................................................. 1
Panel Controls and Interfaces............................................................................................................................. 3
Basic operations
Power on/off \ Control panel light setting ......................................................................................................... 4
Adjust the volume \ Connect Headphone\Record \ Play/Stop \ Play Demo \ Voice setting .......................... 5
Teaching function \ Metronome\Transpose \ Function control ..................................................................... 6
USB MIDI function\Audio connection ........................................................................................................... 9
Teaching function \ Further function\APP installation .................................................................................. 10
APP connection ............................................................................................................................................... 11
Appendix
Voice list\Demo songs list ............................................................................................................................... 12
MIDI keyboard percussion music checking list .............................................................................................. 13
Specification ..................................................................................................................................................... 15
Troubleshooting .............................................................................................................................................. 16

INDEX

1
Safety Guideline
Before playing the digital piano, please read the following content.
*Please put this instruction book in a safe place, in order to read it in the future.
Warning
In case of getting seriously injured or killed because of electric shock, short circuit, damage,
fire or other dangers, please obey the following warnings.These warnings include but not
limited to the following situations:
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to
you or others, or damage to the instrument or other property. These precautions include, but
are not limited to, the following:
Power Warning about humidity
* Please don't put electric cable beside heaters or
radiators. Don't bend too much or cause damage to
electric cable. Don't put any heavy stuff on the wire.
* The rated voltage of this device is fixed. The required
voltage is printed on the nameplate of this device.
* Check the plug regularly, clean the dirt and ash piled up
on the plug.
* Do not connect the instrument to the socket by multiple
connector, or it will lower the sound quality, or it will
make socket overheat.
* When unplugging the power cord from this product or
power outlet, please be sure to grab the plug. Direct pull
power cord can be can cause damage.
* When the product is not used for a long period of time,
or during a thunderstorm, unplug the electrical plug from
the socket.
* Please read all the illustrate materials of the piano to
make sure the piano installation is correctly.
* In case of any liquid splashing into the device, please do
not get this device rained or use it nearby water, in a wet
surrounding or put a container of liquid on it. If any liquid,
like water, splashes into the instrument, please cut off
power and pull out the electric cable from the AC socket
immediately. Then ask our qualified service staffs to examine
and repair the device.
* Do not plug with wet hands.
If you notice any abnormality
* When one of the following problems occur, immediately
turn off the power and disconnect the electric plug from the
outlet. Then arrange a checking by our service staff.
- The power cord or plug becomes frayed or damaged.
- It emits unusual smells or smoke.
- Some object has been dropped into the instrument.
- There is a sudden loss of sound during use
of the instrument.
Do not open
* Please do not open this device and try to dismantle inner
components or transform it in any ways. This device does
not include any components for users to fix. If you find
any problems, please stop using and ask our qualified
service staffs to examine and repair the device.
Fire
* Do not place any burning stuff, like candle, on the
instrument. It may cause fire.
Location
use two or more people.Attempting to lift the instrument
by yourself may damage your back, result in other injury,
or cause damage to the instrument itself.
* Before moving the instrument, remove all connected
cables, to prevent damage to the cables or injury to
anyone who might trip over them.
* When you set this device, please confirm the AC
socket going to be used is reachable. The device should
be connected to the socket with protecting grounding
connection. If you find any problems and questions,
please immediately turn off the power and pull out the
plug from the socket. Even though the power is turned
off, there is still a small amount of electricity current
flowing though it. If you decide not using this device for a
long time, please pull out the plug from AC socket.
* Do not place the instrument in an unstable position
where it might accidentally fall over.
* When transporting or moving the instrument, always

2
* Only use the bracket and screws provided with this
piano, If might cause injury or damage if you use other
parts to install the piano.
* Do not use the instrument/device or headphones for a
long period of time at a high or uncomfortable volume
level, since this can cause permanent hearing loss. If you
experience any hearing loss or ringing in the ears, please
consult a physician.
Connections
* Before connecting the instrument to other electronic
components, turn off the power for all components.
Before turning the power on or off for all components, set
all volume levels to minimum.
* Be sure to set the volumes of all components at their
minimum levels and gradually raise the volume controls
while playing the instrument to set the desired listening
level.
Handling caution
* Do not rest your weight on, or place heavy objects on
the instrument, and do not use excessive force on the
buttons, switches or connectors.
* Wedisclaimsanyresponsibilitycausedbyimproperuseormodicationstotheinstrument,ordata
that is lost or destroyed.
Caution
* Do not place the bench in an unstable position where it
might accidentally fall over.
* Do not play carelessly with or stand on the bench. Using
it as a tool or stepladder or for any other purpose might
result in accident or injury.
* Keep special watch over any small children so that
they don't fall off the rear of the bench.Since the bench
does not have a backrest, unsupervised use may result in
accident or in jury.
NOTICE
To avoid the possibility of malfunction/ damage to the product, damage to data, or damage to other property, follow
the notices below.
■ Handling and Maintenance
* Do not use the instrument in the vicinity of a TV, radio, stereo equipment, mobile phone, or other electric devices.
Otherwise, the instrument, TV, or radio may generate noise. When you use the instrument along with the application
on your iPhone/iPad, we recommend that you set “Airplane Mode” to “ON” on your iPhone/iPad in order to
avoid noise caused by communication.
* Do not expose the instrument to excessive dust or vibrations, or extreme cold or heat (such as in direct sunlight, near
a heater, or in a car during the day) to prevent the possibility of panel disfiguration, damage to the internal components
or unstable operation. (Verified operating temperature range: 5°– 40°C, or 41° – 104°F.)
* Do not place ethylene, plastic or rubber objects on the instrument, since this might discolor the panel or keyboard.
* During extreme changes in temperature or humidity, condensation may occur and water may collect on the surface
of the instrument. If water is left, the wooden parts may absorb the water and be damaged. Make sure to wipe any water
off immediately with a soft cloth.
* In order to avoid damage to the lithium battery, if the product is not used for a long time, please use the specified
adapter to fully charge it to keep the battery well, and charge it about 2month per time.
■ About copyrights
* Copying of the commercially available musical data, including but not limited to MIDI data and/or audio data, are
strictly prohibited except for your personal use.
* This product incorporates and bundles computer programs and contents in which the manufacturer owns copyrights
or with respect to which it has license to use others' copyrights. Such copyrighted materials include, without limitation,
all computer software, style files, MIDI files, WAVE data, musical scores and sound recordings. Any unauthorized use
of such programs and contents outside of personal use is not permitted under relevant laws. Any violation of copyright
has legal consequences. DON'T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.
■ About functions/data bundled with the instrument
* Some of the preset songs have been edited for length or arrangement, and may not be exactly the same as the original.
■ About this manual
* The illustrations as shown in this manual are for instructional purposes only, and may appear somewhat different
from those on your instrument.
* The actual goods shall prevail.Operation and specifications are subject to change without notice.All rights reserved.
* The contents in this hand book is only for introduction purpose. It may be different from the
instrument you buy.

Panel controls and Interfaces
1 Volume display ........................................page 5
2[Power](on/o󰀨) ........................................page 4
3 [VOLUME -] Button .................................page 5
For adjusting the volume to be lower.
4 [VOLUME +] Button ................................page 5
For adjusting the volume to be louder.
5 [Record] button ........................................page 5
For Recording the music when playing.
6 [Play] button.............................................page 5
For turn on /off the record.
7 [Metronome] button..................................page 6
For Start or Stop metronome.
8 [Transpose] button...................................page 6
For turn on or off the transpose function.
9[Data▼]button..........................................page5
To adjust the data/function-(down).
10[Data▲]button.......................................page4
To adjust the data/function-(up).
11 [Demo] button ........................................page 5
For on or off the demo song.
12 [Piano]button..........................................page 5
Back to the Grand piano voice.
13 [Double color LED light display] ............page 10
Each LED light is corresponding to every single key.
14 [Pedal] jack ............................................page 3
For connecting the 3 pedal.
15 [Line out] jack ........................................ page9
Audio output.
16 [Line in] jack .......................................... page9
Audio input.
17 [USB] jack..............................................page 9
For connecting to a computer via a USB MIDI cable.
18 [Speaker] jack........................................page 3
For connecting with speaker.
19 [DC 18V] jack ........................................page 4
For connecting with adapter.
20 [Headphone] jack ..................................page 5
For connecting with headphone .
⑬
⑳
①
Control panel function：
Back function panel interface：
DC 18V
SPEAKER
USBLINE INLINE OUTPEDAL
⑭ ⑮ ⑯ ⑰ ⑱ ⑲
② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫
Headphone interface
：
Front
side Back
side
At the bottom
Back function panel interface
Headphone interface
Control panel function
3

2.Turn on:
The control panel 【POWER】light will be on in red color when your hand is close to the panel. Touch
the 【POWER】 button and the panel light will be on, the default voice is Grand piano. (Note: The control panel
light will be off when your hand leaves the panel around 5 seconds.)
3.Turn o󰀨:
The control panel 【POWER】 light will be on in red color when your hand is close to the panel. Touch the
【POWER】 button for 3seconds and release the button,the power will be turned off.
Automatically turn o󰀨 note:
In order to save the energy, place the piano without any operation for 60 minutes, the piano will be turned off
automatically.
Automaticaally turn o󰀨 setting:
Press the 【PIANO】 and 【VOLUME -】 to set the 30mins turn off time.
Press the 【PIANO】 and 【VOLUME +】 to set the 60mins turn off time.
Press the 【PIANO】 and 【RECORD】 to set the 120mins turn off time.
Press the 【PIANO】 and 【PLAY】 to turn off the auto-off function.
To save the Auto-o󰀨 time setting:
Press the 【DATA ▲】 and 【DATA ▼】 at the same time,
then press the 【PIANO】.
Basic operation
Power on/o󰀨
1.Connect the power as the picture showed below:
The default background light of the control panel is blue color. Red color means the function you need. Here is the
background light setting:
1.Setting:
Press 【PIANO】, then press 【DATA ▲】 and 【DATA ▼】 at the same time to adjust the panel light color.
2.Saving:
Press 【DATA ▲】 and 【DATA ▼】 at the same time,then press【PIANO】 to save the setting.
Adapter AC outlet
DC 18V
SPEAKER PEDAL
Warning
Only specified adapters can be used. Use other power adapters may cause irreparable damage to the adapters and the
product.
Caution
Please plug out the power cable when not play the piano for a long time or in a thunderstorm.
30mins
120mins
60mins
turn o󰀨
save
Control panel light setting
4

Record
1.Start recording: Press 【RECORD】 button, indicated light is on. The piano
is start to record.
2.Stop recording: After recording, Press 【RECORD】 button, indicated light will
be in red color, log out the record function. When the storage is not enough during the
recording, the record will be stopped automatically.
Play/Stop
1.Play record: Press 【PLAY】 button, the piano will play the music you recorded.
Press the button again, the music will be stopped.
2.Power o󰀨 saving: The piano will save the last recording music even the piano is off.
When you reboot the piano, press【PLAY】,the last music you recorded can be played.
Play Demo
(1)Press 【DEMO】to turn on the demo playing, the indicated light will be in red.
(2)Press【DATA ▲】 and 【DATA ▼】 to select the demo song.
(3)Pres【DEMO】 again to turn off the demo.
Voice setting
The piano default voice is Grand piano voice, the indicated light will be red. For other
voices, the indicated light will be blue.
(1)Press 【DATA▲】 and 【DATA ▼】 to select the voice.
(2)Press 【PIANO】 to back to the grand piano voice.
Connect headphone
The instrument is equipped with two sets of standard stereo headphones jack at the
lower left. The speaker system will be mute after connecting a headphone. You can
use the master volume knob to adjust the sound level. (Note: When no need to use
headphone, please plug the headphone from the jack, then the speaker system will
restore the sound.)
Adjust the volume
To press 【VOL -】 / 【VOL +】 to adjust the volume as you want.
Long press 【VOL -】 / 【VOL +】 to continuously increase the volume.
Note: Improper volume level might damage your hearing,especially wearing the
headphone.
5

Metronome
Touch the 【METRONOME】 on the panel to enable the metronome function. The indicated light will be in red.
The default metronome tempo is 120 BPM.
(1)Long press the 【METRONOME】 over 2seconds, the indicated light will be in red, the piano will get into the
metronome tempo setting.
(2)Press the key to set the tempo, such as 120bpm, press the corresponding key 1,2,0 three keys to set it.
Or touch the 【DATA ▲】 and 【DATA ▼】 to adjust the tempo(20-280BPM).
(3)Touch the 【METRONOME】 to exit the metronome setting, the piano will save the setting.
Note: The piano will back to the default tempo (120BPM) after reboot the piano.
Transpose
This function can transpose a note to +/-12 semitone in a range of octachord.
1.The operation of Transpose:
(1)Press 【TRANSPOSE】 button to get into the transpose setting status.
(2)Press 【DATA ▲】 and 【DATA ▼】 with your other hand to adjust it. Adjusting range: -12 to +12.
(3)Release the 【TRANSPOSE】 to exit the transpose setting status.
Note: The 【TRANSPOSE】 indicator light will be in red when you set the transpose.
2.The way to turn on/o󰀨 the Transpose:
(1)Press 【TRANSPOSE】 button to on / off the function.
(2)When the piano is set a transpose, the indicator light will be in red. Press 【TRANSPOSE】 to turn off the function,
the indicator light will be in blue. The piano will back to the default transpose.
Function control
Being an extremely user-friendly instrument, the functions of this digital piano are easily activated.
Each function is associated with one of keys on the right keyboard.
The name of each function is printed under the corresponding key for your reference.
(Note: When you press the 【PIANO】button without releasing your hand, the function selection status is activated,
at the moment the keyboard is silent.)
Teaching function
Press any keys (Such as the 4th key), and press
【DEMO】 from the panel at the same time.
Then the piano will play the 4th teaching song.
The piano will get into the PAIPAI piano
function.
Press any keys
1 2 3 4 5 6 7 8 9 0
6

1.Soundboard resonance
(1)Press 【PIANO】 with your left hand and do not release it, Press the function corresponding key Soundboard
resonance ON/OFF to start or stop the soundboard resonance function with your right hand.
(2)Release 【PIANO】 key to exit the function selection, There will be the corresponding function when playing.
1 2 3 47 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
12 3 4 7 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
2.Touch setting
This digital piano has 5 touch dynamic :default (When turn on the piano), off、soft、standard、hard 4 status,Each of
them corresponds to four keys
(1)Press【PIANO】 with your left hand and do not release it, Press the function corresponding key (off、soft、
standard、hard) to choose the touch level you want with your right hand. There will be the corresponding touch level.
1 2 3 47 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
3.Split
This function can divide the keyboard into two individual playing zones and different voices.
Left keyboard Right keyboard
Split setting:
(1)Press【PIANO】with your left hand and do not release it, Press the function corresponding key Split ON/OFF to
turn on or turn off the function with your right hand.
(Note: Before turning on the split function, you have to choose the voice of left keyboard first. After turn on the split
function, you only can press 【DATA▲】 and【DATA▼】 to choose the voice of right keyboard. )
(2)Release【PIANO】key to exit the function selection, There will be the corresponding function when playing.
1 2 3 47 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
7

4.Dual voice
The Dual voice on and off function corresponds to two keys printed in front of the keyboard.
(1)Press【PIANO】with your left hand and do not release it, Press the function corresponding key Dual voice ON/
OFF to turn on or turn off the function with your right hand.
(Note: After turn on the dual voice function, you can hear there are two voices come out together. press【DATA ▲】
and 【DATA ▼】to choose the second voice you want. )
(2)Release【PIANO】key to exit the function selection, There will be the corresponding function when playing.
1 2 3 47 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
5.Beat
There are 9 kinds of styles beat. Each of them corresponds to 6 white keys and 3 black keys. You can choose the one
you need.
(1)Press【PIANO】 with your left hand and do not release it, Press the function corresponding key Beat(1-9) to
choose the beat you want with your right hand.
(2)Release【PIANO】key to exit the function selection, There will be the corresponding function when playing.
12 3 4 7 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
6.Reverb
The Reverb on and off function corresponds to two keys printed in front of the keyboard.
(1)Press【PIANO】with your left hand and do not release it, Press the function corresponding key Reverb ON / OFF
to turn on the function with your right hand.
(2)Release【PIANO】key to exit the function selection, There will be the corresponding function when playing.
12 3 4 7 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
7.Chorus
The Chorus on and off function corresponds to two keys printed in front of the keyboard.
(1)Press【PIANO】with your left hand and do not release it, Press the function corresponding key Chorus ON / OFF
to turn on the function with your right hand.
(2)Release【PIANO】key to exit the function selection, There will be the corresponding function when playing.
1 2 3 47 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
8.Percussion
The Percussion on and off function corresponds to two keys printed in front of the keyboard.
(1)Press【PIANO】 with your left hand and do not release it, Press the function corresponding key Percussion ON /
OFF to turn on the function with your right hand.
(2)Release【PIANO】key to exit the function selection, There will be the corresponding function when playing.
8

1 2 3 47 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
9.Split point
(1)Press【PIANO】with your left hand and do not release it, Press the function corresponding key Split point to get
into the split point setting status with your right hand.
(2)Choose the split point you want, and press the key. For example: when you want to split the keyboard from key
(central C), just press the central C key , the keyboard will be split from the key.
1 2 3 47 9
REVERB
OFFON
CHORUS
OFFON
PERCUSSION
OFFON
SPLIT
OFFON
DUAL VOICE
OFFON SPLIT
POINT
BEAT
SOFT
TOUCH
HARD
STANDARD
OFF 85 6
SOUNDBOARD
RESONANCE
OFFON
Audio Connection
1.Line In: Connect the musical instrument to the built-in speaker system, regarding the digital piano as speaker.
2.Line Out: Regarding this digital piano as sound source, connect it to the external speaker system.
USB MIDI function
Connect the computer to the USB MIDI Jack in the back inserting plate to get MIDI Production Function.
USB TO HOST Connection
Digital Piano Back Interface Plate USB Jack
Audio Connection
SPEAKERUSBLINE INLINE OUT
Audio Connection
LINE INLINE OUT
9

Teaching function
This piano supports connecting Bluetooth audio and Bluetooth MIDI at the same time. It can be a phone or tablet
computer connect to both Bluetooth audio and Bluetooth MIDI at the same time. Or it can be two phones or two
tablet computer connect to Bluetooth audio and Bluetooth MIDI separately.
1 . Audio Bluetooth function
(1) Turn on the piano, the Bluetooth function will be on at the same time.
(2) Open your phone or iPad to search Bluetooth device name【S3】. The password is “6666”, input the password
if needed.
(3) After successful pairing, we can play music through the phone or iPad.
(4) You can switch song and volume with your phone. (Phone support required)
2. Bluetooth MIDI function (Software support required)
(1) The Bluetooth MIDI transfer function is available on the piano.
(2) Turn on the piano, the Bluetooth function will be on at the same time.
(3) Open your phone or iPad to search Bluetooth device name【S3 MIDI】.
(4) After successful pairing, we can transfer MIDI data through the phone or iPad.
Note: Bluetooth MIDI connection need your device support (computer/phone/iPad), different software have different
connection method. For the specific connection method, please check the instruction of your software.
Further function
The below functions require software support. Here we use【PIANO BAR】APP as an example to illustrate the
details.
1.Double color LED intelligent light
Connect the APP and play a music, the LED light will be on. Practice the music by following the LED light. Red light
for left hand, blue light for right hand.
2.Intelligent accompanied playing
You can set accompanied playing mode. For example, when you set right hand accompanied playing, the piano will
play the right hand part of the music, you only need to play the left hand part.
3.Intelligent following practice
Follow the LED light to practice the music.
4.Voice setting
You can change the digital piano voice from the APP. Such as 128 standard GM voices.
APP installation
The download link: http://.tan8.com/app.
Note:
(1)After installation, please follow the steps to finish the registration.
(2)【PIANO BAR】VIP membership needs to be purchase separately.
10

APP connection
1.Wired Connection
Connect with phone or tablet computer via a USB cable and OTG cable.
2.Bluetooth connection
Turn on the Bluetooth function from your device. The piano Bluetooth function will be on automatically when the
piano is on.
(1)Click the [PIANO BAR] APP, and find a song you want.
(2)Click the song, you can see the music stave.
(3)Click the [setting] and click the Bluetooth connection
(4)The screen will show you “Connected”.
Note:For now, the [PIANO BAR] APP is only available for the IOS system devices.
USB cable
Android/Apple OTG cable
Digital Piano Back Interface Plate USB Jack
*Instruction
(1)Please do not use the the wired / Bluetooth connection at the same time. It might cause the problem.
(2)Due to the IOS system version issue, some devices don't respond after connection. Please turn off the Bluetooth
function both from your device and the APP, and try to connect it again as the above steps.
(3)After connection with APP, the piano voice will be changed according to the instruction sent by APP. If there is
abnormal sound after connection, please reboot the piano and exit the APP and reconnect it again.
11
S3 MIDI

No. Instrument
024 SHAMISEN
Chinese Musical
Instrument
025 PiPa
026 ErHu
027 BangDi
028 GuZheng
029 HuLuSi
Percussion
001 STANDARD DRUMS
Voice List
No. Instrument
000 GRAND PIANO
001 BRITE PIANO
002 HONKY-TONK
003 E PIANO 1
004 E PIANO 2
005 HARPSCRD
006 MARIMBA
007 HAMND ORG
008 CHURCH ORG
009 GTR NYLON
010 ACOU BASS
011 STR PIZZ
12
No. Instrument
012 HARP
013 STRINGS 2
014 STR SYN 2
015 MUTE TPUMPET
016 ALTO SAX
017 CLARINET
018 PAN FLUTE
019 SHAKHACHI
020 WARM PAD
021 SWEEP
022 CRYSTAL FX
023 SITAR
No. English name
000 Chopin Fi
001 AMASON Rock
002 Fountain
003 Bach Piano
004 Minuet Bach
005 Love Romance
006 Four Cygnets
007 Puppy Wlatz
008 CpnEtude
009 Turkey March
010 Chopin No.6
011 Menuett
012 MarciaAT
013 Chopin Night
014 Piano Ballad
015 Ragetime
016 Zi Zhu Diao
017 Sad Person
018 Fn Rhythm
019 Eugenia
020 Dolly's Dream
021 4 Cygnets
No. English name
044 Minuet Piano
045 Little Starts
046 Deep Sea
047 Wa Ha Ha
048 Snail & Bird
049 In Moonshine
050 Nature Wonder Land
051 Years Ago
052 CuaiYunZhuiYue
053 Liang Zhu
054 Jingle Bells
055 Run Hours On Hall
056 Moscow Nights
057 Shear
058 North Spring
059 Youth Dance
060 Rainbow
061 On Wings Of Song
062 Arirang
063 TianXianPei
064 Sakura
Demo songs list
No. English name
022 Old France
023 Minuet Bath
024 Song of Joy
025 Busker
026 NewsPaper Sale
027 Doves
028 Mai Tang Yuan
029 Trout
030 Curvet Piano
031 Spring Waltz
032 Aledeman
033 Bach 2 Creative
034 Moonlight
035 Tea & Butterfly
036 Gavotte Dance
037 Canon Piano
038 Cowboy & Flute
039 Turkey March
040 Humoresque
041 England March
042 Little Boat
043 Happy Farmer

MIDI keyboard percussion music checking list
Note# Note Ostand set 1Room set 2Power set 3Electric set 4Synth set
27 C1 Syn Sound Syn Sound Syn Sound Syn Sound Syn Sound
28 C#1 Slap Slap Slap Slap Slap
29 D1 Scratch1 Scratch1 Scratch1 Slap Scratch1
30 D#1 Scratch2 Scratch2 Scratch2 Scratch2 Scratch2
31 E1 Sticks Sticks Sticks Sticks Sticks
32 F1 Click Click Click Click Click
33 F#1 Metronome
Click
Metronome
Click
Metronome
Click Metronome Click Metronome Click
34 G1 Metronome Bell Metronome Bell Metronome Bell Metronome Bell Metronome Bell
35 G#1 Kick2 Kick2 Kick2 Electric Kick2 Kick2
36 A1 Kick1 Kick1 Power Kick1 Electric Kick1 Synth Kick
37 A#1 Side Stick Side Stick Side Stick Side Stick Synth Side Stick
38 B1 Snare Drum2 Snare Drum2 Power Snare Electric Snare
Drum2 Synth Snare
39 C2 Hand Clap Hand Clap Hand Clap Hand Clap Hand Clap
40 C#2 Snare Drum1 Room Snare1 Snare Drum1
Snare 1
Electric Room Snare Drum1
41 D2 Low Tom2 Power Low
Tom2
Power Low
Tom2 Electry Low Tom2 Synth Low Tom2
42 D#2 Closed Hi-Hat Closed Hi-Hat Closed Hi-Hat Closed Hi-Hat Synth Closed Hi-
Hat
43 E2 Low Tom1 Power Low Tom1 Power Low Tom1 Electric Low Tom1 Synth Low Tom1
44 F2 Pedal Hi-Hat Low Tom1 Pedal Hi-Hat Pedal Hi-Hat Synth Pedal Hi-
Hat
45 F#2 Mid Tom2 Power Mid Tom2 Power Mid Tom2 Electric Mid Tom2 Synth Mid Tom2
46 G2 Open Hi-Hat Open Hi-Hat Open Hi-Hat Open Hi-Hat Synth Open Hi-
Hat
47 G#2 Mid Tom1 Power Mid Tom1 Power Mid Tom1 Electric Mid Tom1 Synth Mid Tom1
48 A2 High Tom2 Power High
Tom2
Power High
Tom2
Electric High Tom2 Synth Tom2
45 F#2 Mid Tom2 Power Mid Tom2 Power Mid Tom2 Electric Mid Tom2 Synth Mid Tom2
46 G2 Open Hi-Hat Open Hi-Hat Open Hi-Hat Open Hi-Hat Synth Open Hi-
Hat
47 G#2 Mid Tom1 Power Mid Tom1 Power Mid Tom1 Electric Mid Tom1 Synth Mid Tom1
48 A2 High Tom2 Power High
Tom2
Power High
Tom2
Electric High Tom2 Synth Tom2
49 A#2 Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal Synth Crash
Cymbal
50 B2 High Tom1 Power High
Tom1
Power High
Tom1
Power High Tom1 Synth High Tom1
51 C3 Ride Cymbal Ride Cymbal Ride Cymbal Ride Cymbal Ride Cymbal
52 C#3 Chinese Cymbal
1
Chinese Cymba1 Chinese Cymbal 1 Chinese Cymbal 1 Chinese Cymbal 1
13

Note# Note Ostand set 1Room set 2Power set 3Electric set 4Synth set
53 D3 Ride Bell Ride Bell Ride Bell Ride Bell Ride Bell
54 D#3 Tambourine Tambourine Tambourine Tambourine Tambourine
55 E3 Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal Splash Cymbal
56 F3 Cowbell Cowbell Cowbell Cowbell Cowbell
57 F#3 Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal Crash Cymbal
58 G3 Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap Vibra-Slap
59 G#3 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1 Ride Cymbal1
60 A3 High bomgo High bomgo High bomgo High bomgo High bomgo
61 A#3 Low conga Low conga Low conga Low conga Low conga
62 B3 Mute conga Mute conga Mute conga Mute conga Mute conga
63 C4 High conga High conga High conga High conga High conga
64 C#4 Low conga Low conga Low conga Low conga Low conga
65 D4 High Timbale High Timbale High Timbale High Timbale High Timbale
66 D#4 Low Timbale Low Timbale Low Timbale Low Timbale Low Timbale
67 E4 High Agogo High Agogo High Agogo High Agogo High Agogo
68 F4 Low Agogo Low Agogo Low Agogo Low Agogo Low Agogo
69 F#4 Cabasa Cabasa Cabasa Cabasa Cabasa
70 G4 Msracas Msracas Msracas Msracas Msracas
71 G#4 Short Hi Whistle Short Hi Whistle Short Hi Whistle Short Hi Whistle Short Hi Whistle
72 A4 Long low whistle Long low whistle Long low whistle Long low whistle Long low whistle
73 A#4 ShortGuiro ShortGuiro ShortGuiro ShortGuiro ShortGuiro
74 B4 logn Guiro logn Guiro logn Guiro logn Guiro logn Guiro
75 C5 Claves Claves Claves Claves Claves
76 C#5 Hi Wood Block Hi Wood Block Hi Wood Block Hi Wood Block Hi Wood Block
77 D5 Low Wood
Block
Low Wood Block Low Wood Block Low Wood Block Low Wood Block
78 D#5 Mute Cuica Mute Cuica Mute Cuica Mute Cuica Mute Cuica
79 E5 Open Cueca Open Cueca Open Cueca Open Cueca Open Cueca
80 F5 Mute Triangle Mute Triangle Mute Triangle Mute Triangle Mute Triangle
81 F#5 Open Triangle Open Triangle Open Triangle Open Triangle Open Triangle
82 G5 Shaker Shaker Shaker Shaker Shaker
83 G#5 Jingle Bell Jingle Bell Jingle Bell Jingle Bell Jingle Bell
84 A5 Bell Tree Bell Tree Bell Tree Bell Tree Bell Tree
85 #5 Castanets Castanets Castanets Castanets Castanets
86 B5 Mute Surdo Mute Surdo Mute Surdo Mute Surdo Mute Surdo
87 C6 Open Surdo Open Surdo Open Surdo Open Surdo Open Surdo
14

Specication
Exterior: Fashionable home-furniture design, solid-wood cabinet, walnut color, individual speaker, foldable keyboard
cover.
Control Panel: toughened glass surface, proximity sensing function panel, touch key module.
Sound Source: Independent developed Spectral Composite techniques DSP chip. German famous Schimmel
Grand 9 foot Piano sound sampling, 10 layers dynamic wave table, String overtones resonance simulation sound
technology .
Keyboard:Italian Imported 88 Grand-ResponseTM Key trends with hammer action & dynamic curve keyboard.
Polyphony: 512 (stereo)
Demo song: 65 songs.
Voice: 31 voices,including a set of percussion.
Touch: 5 piano touch curves, Default、off、soft、standard、hard.
Record: Record and replay, maximum notes for per composition is 22,000. MIDI Record supports 64 tracks, 16
channels. MIDI 0&1 format.
Voice Control: Grand piano tone, Dual voice, Double keyboard, Split mode, Split point.
Dual Voice: String music background, user can edit multiple sound combinations.
Split Keyboard: Double piano, Same range, Split the keyboard into two zones with same pitch, Piano Duet, String
ensemble, Wind ensemble, Piano + The violin family, Guitar+Violin performance, multi combination available.
Transpose: 25 gears (0,-/+12)
E󰀨ect: 64 reverb, 64 chorus.
Metronome: Dynamics click as per beat,1,2,3,4,5,6,7,8,9.
Tempo: 20-280per minute.
Pedal function: Soft pedal, sostenuto pedal, sustain pedal, imitation of the traditional grand piano pedal function.
Headphone: There are two 3.5mm headphone jacks.
USB interface: USB MIDI jack to connect with PC to achieve an infinity interaction with GM International
Standard sound.
MIDI keyboard: Connect with PC via a USB cable from USB jack to achieve music arrangement..
Bluetooth MIDI: To connect with devices via Bluetooth MIDI function.
Bluetooth audio: To connect with devices via Bluetooth function to play music.
Audio input: support MP3/MP4/DVD/PC/IPAD/IPHONE audio input.
Speaker system: 2 sub-frequency technology, Four-channel independent power amplifier, max 4*25W output
power.
Intelligent piano teaching system: Wired/Bluetooth connection with APP to achieve intelligent teaching
function.
Interface: USB jack*1, pedal jack*1, Power jack*1, Headphone jack*12, Line IN/OUT*1.
Auto-o󰀨: 30/60/120mins auto-off setting can be arranged. Turn off the auto-off function is settable.
Power: DC 18V, 3500mA
Maximum output: 4*25W
Dimension: 1375*350*770mm (L*W*H)
Weight: 36kg
Accessories: Power adapter,Guarantee card,Quality certificate,User manual.
*Specifications and descriptions in this owner's manual are for information purposes only. Our
company reserves the right to change or modify products or specifications at any time without prior
notice. Since specifications, equipment or options may not be the same in every countries, please check
with your dealer for any question.
15

Troubleshooting
NOTE: This instrument has been tested and it is according with the relevant regulations of EMC. Wireless
communication might caused the interference with this instrument. Or the instrument might caused the interference
with wireless. The user should adopt the following measure to improve it.
- Relocation or adjust the receiving antenna.
- Keep a distance between the device and receiver.
- Connect the receiver and the device cord in different plug.
- Please consult your dealer or experienced wireless technician.
Caution:Do not modified the device by yourself.
**Our company reserves the right to change or modify products or specifications at any time without prior notice.
Problem Cause/Solution
There is noise when turn on/off the power. This is normal.
After turn on the power, no sound is
produced when press the keys.
Please confirm the master volume is set in a right level. Please confirm if
the headphone jack is connected.
The note and its timber are of a little
differences under the same patch. This is normal, because of the difference of the timber sampling.
When use the sustain function, some
patches are long while others are short. This is normal,Different sound have been setting a max sustain length.
The volume is too low. Please turn up the the sound by using the volume switch button.
Some MIDI information can not
transmit,even the MIDI cable connection is
good.
This is normal, it is about the factory setting.
Noise comes from speakers when near cell
phones.
Mobile phone could bring in disturbance. To avoid the noise, turn off the
mobile or keep away from the piano.
Pitch from speakers does not match the key
you are playing.
Please check if the double keyboard mode or transposition mode is on,
then turn it off, the piano will be recovered.
Distortion or intermittent when playing
demo songs.
The cause could be the overheating of the speakers,when you play for
a long time with the maximum volume, at this point please lower the
volume or turn the piano off for a while.
Two tones come out at the same time when
playing.
Dual sound function might by activated, please turn off it to avoid it.
Pitch wrong. Please confirm the pitch setting or set it to “Zero”
No automatic Accompaniment and Chord. Please confirm the accompaniment volume or if the Chord function is
turned on
Dynamics is not same as before. There are 5 piano touch curve, Default,Soft,Standard,Hard,off. You
might choose the wrong dynamics. Please set the one you need.
16

Parts Name Hazardous Chemicals(Element)
Pb Hg Cd Cr（VI）PBB PBDE
PCB Χ ○ ○ ○ ○ ○
Cable Χ ○ ○ ○ ○ ○
Adapter Χ ○ ○ ○ ○ ○
Speaker Χ Χ Χ ○ ○ ○
Light Χ ○ ○ ○ ○ ○
○：Means the hazardous chemicals of the parts comply with the standard Regulation SJ/T11363-
2006.
Χ：Means the hazardous chemicals of the parts exceed the standard regulation of SJ/T11363-
2006.
The meaning of the Mark: Do not throw it into the trash can.
The meaning of the Mark: The product is only suitable to use safely under non-tropical
climate.
The meaning of the Mark: The product is only suitable to use safely in the area below
2000 meter altitude.
17
